length OPEL ASTRA K 2019 Owner's Manual

Vehicle care2639Warning
Do not drive faster than 80 km/h.
Do not use for a lengthy period.
Steering and handling may be
affected.
If you have a flat tyre:
Apply the parking brake and engage
first gear, reverse gear or P.
On 5-door hatchback the tyre repair
kit is on the right side in the load
compartment behind a cover.
On Sports Tourer the tyre repair kit is
in a suitcase on the right side of the
load compartment behind a cover.
The suitcase is secured with a strap.
1. Remove the sealant bottle.
2. Insert thumb into the opening and
pull out the compressor.3. Remove the electrical connection cable and air hose from the
stowage compartments on the
underside of the compressor.

Technical data293Vehicle dimensions5-door hatchbackSports TourerLength [mm]4370-43864702Width without exterior mirrors [mm]18091809Width with two exterior mirrors [mm]20422042Height (without antenna) [mm]1437-15311452-1580Length of load compartment floor [mm]8281065Length of load compartment with folded rear seats [mm]15751872Load compartment width [mm]10011028Load compartment height [mm]600747Wheelbase [mm]26622662Turning circle diameter [m]11.05-11.4411.05-11.44
