fuse box OPEL CASCADA 2017.5 Manual user

In brief111Power windows .....................33
2 Exterior mirrors .....................31
3 Cruise control .....................157
Speed limiter ....................... 159
Forward collision alert .........160
4 Side air vents ...................... 133
5 Turn and lane-change
signals, headlight flash,
low beam and high beam,
high beam assist .................120
Exit lighting ......................... 123
Parking lights ...................... 121
Buttons for Driver
Information Centre ................95
6 Instruments .......................... 85
7 Steering wheel controls .......79
8 Driver Information Centre ...... 95
9 Windscreen wiper,
windscreen washer
system, headlight washer
system ................................... 80
10 Sport mode ........................ 155
Central locking system ..........23Hazard warning flashers ....119
Control indicator for airbag deactivation .......................... 90
Control indicator for front
passenger seat belt .............89
Tour mode .......................... 155
11 Info-Display .......................... 99
12 Anti-theft alarm system
status LED ........................... 28
13 Centre air vents .................. 133
14 Glovebox, lockable ...............70
15 Traction Control system
(TC) ..................................... 153
Electronic Stability Control (ESC) .................................. 154
Parking assist systems .......163
Lane departure warning .....177
Eco button for stop-start
system ................................. 138
16 Climate control system ........ 125
17 AUX input, USB input ..........10
18 Power outlet .......................... 8319Soft top operation switch .....36
Central window switch .........33
20 Selector lever, transmission
21 Parking brake, manual or
electric operation ................151
22 Ignition switch with
steering wheel lock ............137
23 Horn ..................................... 80
Driver airbag ........................ 62
24 Bonnet release lever ..........190
25 Storage compartment ..........71
Fuse box ............................ 207
26 Steering wheel adjustment ..79
27 Light switch ........................ 112
Rear fog light ...................... 120 Instrument illumination .......121
Headlight range
adjustment ......................... 115
Front fog lights ...................120

In brief131Power windows .....................33
2 Exterior mirrors .....................31
3 Cruise control .....................157
Speed limiter ....................... 159
Forward collision alert .........160
4 Side air vents ...................... 133
5 Turn and lane-change
signals, headlight flash,
low beam and high beam,
high beam assist .................120
Exit lighting ......................... 123
Parking lights ...................... 121
Buttons for Driver
Information Centre ................95
6 Instruments .......................... 85
7 Steering wheel controls .......79
8 Driver Information Centre ...... 95
9 Windscreen wiper,
windscreen washer
system, headlight washer
system ................................... 80
10 Sport mode ........................ 155
Central locking system ..........23Hazard warning flashers ....119
Control indicator for airbag deactivation .......................... 90
Control indicator for front
passenger seat belt .............89
Tour mode .......................... 155
11 Info-Display .......................... 99
12 Anti-theft alarm system
status LED ........................... 28
13 Centre air vents .................. 133
14 Glovebox, lockable ...............70
Fuse box ............................. 207
15 Traction Control system
(TC) ..................................... 153
Electronic Stability Control (ESC) .................................. 154
Parking assist systems .......163
Lane departure warning .....177
Eco button for stop-start
system ................................. 138
16 Climate control system ........ 125
17 AUX input, USB input ..........10
18 Power outlet .......................... 8319Soft top operation switch .....36
Central window switch .........33
20 Selector lever, transmission
21 Parking brake, manual or
electric operation ................151
22 Ignition switch with
steering wheel lock ............137
23 Horn ..................................... 80
Driver airbag ........................ 62
24 Bonnet release lever ..........190
25 Storage compartment ..........71
Fuse box ............................ 207
26 Steering wheel adjustment ..79
27 Light switch ........................ 112
Rear fog light ...................... 120
Instrument illumination .......121
Headlight range
adjustment ......................... 115
Front fog lights ...................120

188Vehicle careVehicle careGeneral Information...................189
Accessories and vehicle modifications .......................... 189
Vehicle storage ........................189
End-of-life vehicle recovery .....190
Vehicle checks ........................... 190
Performing work ......................190
Bonnet ..................................... 190
Engine oil ................................. 191
Engine coolant ......................... 192
Washer fluid ............................ 193
Brakes ..................................... 193
Brake fluid ............................... 194
Vehicle battery ......................... 194
Diesel fuel system bleeding .....195
Wiper blade replacement ........196
Bulb replacement .......................196
Halogen headlights ..................196
Adaptive forward lighting .........198
Fog lights ................................. 199
Front turn signal lights .............200
Tail lights ................................. 201
Side turn signal lights ..............202
Number plate light ...................203Interior lights ............................ 204
Instrument panel illumination ...204
Electrical system ........................204
Fuses ....................................... 204
Engine compartment fuse box . 205
Instrument panel fuse box .......207
Load compartment fuse box ....208
Vehicle tools .............................. 210
Tools ........................................ 210
Wheels and tyres .......................211
Winter tyres ............................. 211
Tyre designations ....................211
Tyre pressure monitoring
system .................................... 211
Tyre pressure .......................... 215
Tread depth ............................. 216
Changing tyre and wheel size . 216
Wheel covers ........................... 217
Tyre chains .............................. 217
Tyre repair kit .......................... 217
Wheel changing .......................220
Spare wheel ............................ 223
Jump starting ............................. 226
Towing ....................................... 228
Towing the vehicle ...................228
Towing another vehicle ...........229Appearance care .......................230
Exterior care ............................ 230
Interior care ............................. 232

194Vehicle careBrake fluid9Warning
Brake fluid is poisonous and
corrosive. Avoid contact with eyes, skin, fabrics and painted surfaces.
The brake fluid level must be betweenthe MIN and MAX marks.
If fluid level is below MIN seek the
assistance of a workshop.
Brake and clutch fluid 3 234.
Vehicle battery
The vehicle battery is maintenance-
free provided that the driving profile
allows sufficient charging of the
battery. Short-distance-driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Laying up the vehicle for more than
four weeks can lead to battery
discharge. Disconnect the clamp from the negative terminal of the vehicle
battery.
Ensure the ignition is switched off
before connecting or disconnecting
the vehicle battery.
Battery discharge protection 3 124.
Disconnecting the battery
If the vehicle's battery is to be
disconnected (e.g. for maintenance
work), the alarm siren must be
deactivated as follows: Switch the
ignition on then off, then disconnect
the vehicle's battery within
15 seconds.
Replacing the vehicle battery Note
Any deviation from the instructions
given in this section may lead to
temporary deactivation of the stop-
start system.
When the vehicle battery is being
replaced, please ensure that there
are no open ventilation holes in the
vicinity of the positive terminal. If a
ventilation hole is open in this area, it
must be closed off with a dummy cap,
and the ventilation in the vicinity of the negative terminal must be opened.
Only use vehicle batteries that allow
the fuse box to be mounted above the
vehicle battery.

204Vehicle care5. Insert bulb holder into lamphousing and turn clockwise.
6. Insert lamp into bumper and let engage.
Interior lights Courtesy light, reading lights
Have bulbs replaced by a workshop.
Load compartment light
Have bulbs replaced by a workshop.
Instrument panel illumination
Have bulbs replaced by a workshop.Electrical system
Fuses Data on the replacement fuse mustmatch the data on the defective fuse.
There are three fuse boxes in the vehicle:
● In the front left of the engine compartment,
● In left-hand drive vehicles, in the interior behind the storage
compartment, or, in right-hand
drive vehicles, behind the
glovebox,
● Behind a cover on the left side of
the load compartment.
Before replacing a fuse, turn off the
respective switch and the ignition.
A blown fuse can be recognized by its melted wire. Do not replace the fuse
until the cause of the fault has been
remedied.
Some functions are protected by
several fuses.
Fuses may also be inserted without existence of a function.
Fuse extractor
A fuse extractor may be located in the
fuse box in the engine compartment.

Vehicle care205
Place the fuse extractor on the
various types of fuse from the top or
side, and withdraw fuse.
Engine compartment fuse
box
The fuse box is in the front left of the
engine compartment.
Disengage the cover and fold it
upwards until it stops. Remove the
cover vertically upwards.

Vehicle care207No.Circuit51–52Auxiliary heater, diesel engine53Transmission control module,
Engine control module54Vacuum pump, instrument
panel cluster, heating ventila‐
tion, air conditioning system
After having changed defective fuses,
close the fuse box cover and press
until it engages.
If the fuse box cover is not closed
correctly, malfunctions may occur.
Instrument panel fuse box
In left-hand drive vehicles, the fuse
box is behind the storage
compartment in the instrument panel.
Open the compartment and push it to the left to unlock. Fold the
compartment down and remove it.
In right-hand drive vehicles, the fuse
box is located behind a cover in the
glovebox. Open the glovebox, then
open the cover and fold it down.

208Vehicle careNo.Circuit1Displays2Body control unit, exterior lights3Body control unit, exterior lights4Infotainment system5Infotainment system, instru‐
ment6Power outlet, cigarette lighter7Power outlet8Body control module, left low
beam9Body control module, right low
beam10Body control module, door locks11Interior fan12Driver power seat13Passenger power seat14Diagnostic connector15Airbag16Boot lid relayNo.Circuit17Air conditioning system18Service diagnose19Body control module, brake
lights, tail lights, interior lights20-21Instrument panel22Ignition system23Body control module24Body control module25–26Trunk power outlet accessory
Load compartment fuse box
The fuse box is on the left side of the
load compartment behind a cover.
Remove the cover.
Fuse assignments

257Clock............................................. 82
Code ........................................... 101
Collision damage repair ..............252
Control indicators.......................... 88
Control of the vehicle .................136
Controls ........................................ 79
Convex shape .............................. 31
Coolant and antifreeze ...............234
Cruise control ...................... 94, 157
Cupholders .................................. 71
Curve lighting.............................. 116
D Danger, Warnings and Cautions ...4
Daytime running lights ...............116
Declaration of conformity ............249
DEF ............................................ 143
Diesel exhaust fluid ....................143
Diesel fuel system bleeding .......195
Diesel particle filter ...............92, 142
Door open .................................... 95
Doors ............................................ 26
Driver assistance systems ..........157
Driver Information Centre .............95
Driving characteristics and towing tips .............................. 183
Driving hints ................................ 136
E Electric adjustment ......................31
Electrical system......................... 204Electric parking brake ...........91, 151
Electric parking brake fault ...........91
Electronic climate control system 128
Electronic driving programmes ..148
Electronic Stability Control.......... 154
Electronic Stability Control and Traction Control system ............92
Electronic Stability Control off....... 92 End-of-life vehicle recovery .......190
Engine compartment fuse box ...205
Engine coolant ........................... 192
Engine coolant temperature gauge ....................................... 86
Engine data ............................... 241
Engine exhaust .......................... 142
Engine identification ...................237
Engine oil ................... 191, 234, 238
Engine oil pressure ......................93
Entry lighting .............................. 123
Event data recorders ..................254
Exit lighting ................................ 123
Exterior care .............................. 230
Exterior light ................................. 94
Exterior lighting ....................14, 112
Exterior mirrors ............................. 31
F
Fault ........................................... 149
First aid ......................................... 76
First aid kit ................................... 76Fixed air vents ........................... 133
Fog light ....................................... 94
Fog lights ................................... 199
Folding mirrors ............................. 31
Following distance indication ......162
Forward collision alert................. 160
Front airbag system .....................62
Front fog lights ........................... 120
Front seats.................................... 49
Front storage ................................ 71
Front turn signal lights ...............200
Fuel............................................. 178
Fuel consumption - CO 2-
Emissions ............................... 182
Fuel for diesel engines ..............179
Fuel for petrol engines ...............178
Fuel gauge ................................... 86
Fuses ......................................... 204
G Gauges ......................................... 85
General information ...................183
Glovebox ..................................... 70
Graphic-Info-Display, Colour- Info-Display .............................. 99
Ground clearance .......................136
H Halogen headlights ....................196
Hand brake ......................... 150, 151
Hazard warning flashers ............119

258Headlight flash ........................... 115
Headlight range adjustment ......115
Headlights................................... 112 Headlights when driving abroad 115
Head restraint adjustment .............8
Head restraints ............................ 47
Heated mirrors ............................. 32
Heated rear window ..................... 36
Heated steering wheel .................79
Heating ........................................ 55
Heating and ventilation system . 125
High beam ........................... 94, 114
High beam assist ..................94, 114
Hill start assist ........................... 153
Horn ....................................... 15, 80
I Identification plate .....................236
Ignition switch positions .............137
Immobiliser ............................ 30, 94
Indicators ...................................... 85
Information displays...................... 95
Instrument cluster ........................85
Instrument panel fuse box .........207
Instrument panel illumination .....204
Instrument panel illumination control .................................... 121
Instrument panel overview ........... 10
Interactive driving system ...........155
Interior care ............................... 232Interior lighting............................ 121
Interior lights ...................... 122, 204
Interior mirrors .............................. 32
Interruption of power supply ......149
Introduction .................................... 3
ISOFIX child restraint systems ....69
J Jump starting ............................. 226
K Key, memorised settings ..............23
Keys ............................................. 21
Keys, locks ................................... 21
L
Lane departure warning .......92, 177
Lashing eyes ............................... 76
Light switch ................................ 112
Load compartment ................26, 73
Load compartment fuse box ......208
Loading information .....................77
Low fuel ....................................... 94
M
Malfunction indicator light ............90
Manual anti-dazzle ......................32
Manual mode ............................. 148
Manual seat adjustment ...............50
Manual transmission .................. 150
Memorised settings ......................23Mirror adjustment ........................... 8
Misted light covers .....................121
N
New vehicle running-in ..............137
Number plate light .....................203
O Object detection systems ...........163
Odometer ..................................... 85
Oil, engine .......................... 234, 238
OnStar ........................................ 107
Operate pedal ............................... 90
Outside temperature ....................81
Overrun cut-off ........................... 138
P Parking ................................ 19, 140
Parking assist ............................ 163
Parking brake ............................ 151
Parking lights ............................. 121
Particulate filter ........................... 142
Performance .............................. 242
Performing work ........................190
Pollen filter ................................. 133
Power outlets ............................... 83
Power seat adjustment ................53
Power steering.............................. 92
Power windows ............................ 33
Preheating ................................... 92
Puncture ..................................... 220
