ECU OPEL COMBO D 2017.5 Owner's Manual

20Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 20
Keys .......................................... 20
Car Pass .................................... 21
Radio remote control .................21
Manual door locks .....................22
Central locking system ..............24
Child locks ................................. 25
Doors ........................................... 26
Sliding door ............................... 26
Rear doors ................................. 26
Load compartment ....................28
Vehicle security ............................ 29
Anti-theft locking system ...........29
Immobiliser ................................ 29
Exterior mirrors ............................ 30
Convex shape ........................... 30
Manual adjustment ....................30
Electric adjustment ....................30
Folding mirrors .......................... 31
Heated mirrors ........................... 31
Interior mirrors ............................. 31
Manual anti-dazzle ....................31Windows...................................... 32
Windscreen ............................... 32
Manual windows ........................32
Power windows ......................... 32
Rear windows ............................ 34
Heated rear window ..................34
Sun visors .................................. 34Keys, locks
KeysCaution
Do not attach heavy or bulky itemsto the ignition key.
Replacement keys
The key number is specified in the
Car Pass or on a detachable tag.
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser
system.
Locks 3 172, Radio remote control
3 21, Central locking system
3 24, Starting the engine 3 115.

Keys, doors and windows21Key with foldaway key section
Press button to extend. To fold the
key, first press the button.
Car Pass The Car Pass contains security
related vehicle data and should
therefore be kept in a safe place.
When the vehicle is taken to a
workshop, this vehicle data is needed
in order to perform certain operations.
Radio remote control
Used to operate:
● central locking system 3 24
● anti-theft locking system 3 29
● power windows 3 32
The remote control has a range of up
to 5 metres. It can be restricted by
external influences. The hazard
warning flashers confirm operation.
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Fault
If the central locking system cannot be operated with the remote control,
it may be due to the following:
● Fault in remote control.
● The range is exceeded.
● The battery voltage is too low.
● Frequent, repeated operation of the remote control while not in
range.
● Overload of the central locking system by operating at frequent
intervals; the power supply is
interrupted for a short time.
● Interference from higher-power radio waves from other sources.
Unlocking 3 24.
Remote control battery
replacement
Replace the battery as soon as the
range reduces.

22Keys, doors and windows
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Key with foldaway key section
Extend the key (to reveal the battery
holder) and remove the battery holder
by undoing the screw with a suitable
screwdriver. Remove the battery
holder from the key and replace the battery (type CR 2032), paying
attention to the installation position.
Refit the battery holder in the key and
secure with the screw.
Manual door locks If the power supply has been
interrupted, the vehicle battery
voltage has dropped too low, or there
is a fault in the central locking system, the door locks cannot be operated
with the remote control.
UnlockingManually unlock the driver's door by
inserting the key in the lock cylinder
and turning towards the front of the
vehicle. Open the driver's door by
pulling the exterior handle.
The front passenger door and sliding side door(s) can then be opened by
operating the exterior or interior
handles.
Manually unlock the rear doors by
turning the key in the lock cylinder (if
available) or open from the inside.
The tailgate cannot be unlocked from the outside under the conditions
stated above.
Rear doors 3 26.
Emergency tailgate opening from inside the vehicle 3 28.
Child locks 3 25.
Locking
Close the rear doors/tailgate 3 26
and lock by turning the key in the lock
cylinder (if available).

26Keys, doors and windowsDoors
Sliding door
Unlock the sliding side door with the remote control 3 24.
Pull lever on interior handle (if
available) and slide the door.
Depending on version, it may only be
possible to open and close the sliding side door using the outside handle.
Caution
Ensure the sliding side door is fullyclosed and secure before driving
the vehicle.
Central locking system 3 24.
Caution
To avoid damage, do not attempt
to operate the sliding side door
when the fuel filler flap is open.
9 Danger
Do not drive with the sliding side
door open or ajar, e.g. when
transporting bulky objects, since
toxic exhaust gases, which cannot be seen or smelled, could enter
the vehicle. This can cause
unconsciousness and even death.
Refuelling 3 135.
Rear doors
Unlock the rear doors with the remote control or by turning the key in the rear
door lock cylinder.
Central locking 3 24, Manual door
locks 3 22.
Always open the left hand door before the right hand door.
To open the left hand rear door, pull
the exterior handle.

Keys, doors and windows27
The door is opened from inside the
vehicle by pressing down the interior
handle.
The right hand rear door is released
using the lever.9 Warning
The rear lights may be obscured if
the rear doors are open and the
vehicle is parked on the roadside.
Make other road users aware of the vehicle, by using a warning
triangle or other equipment
specified in the road traffic
regulations.
The doors are retained in the 90º
position by locking stays. To open the
doors to 180º, push the latch and
swing open to the desired position.9 Warning
Ensure extended opening doors
are secured when fully opened.
Opened doors may slam closed due to the force of the wind!
Always close the right hand doorbefore the left hand door.
9 Danger
Do not drive with the rear doors
open or ajar, e.g. when
transporting bulky objects, since
toxic exhaust gases, which cannot be seen or smelled, could enter
the vehicle. This can cause
unconsciousness and even death.
Central locking system 3 24.

Keys, doors and windows29Caution
Before opening the tailgate check
overhead obstructions, such as a
garage door, to avoid damage to
the tailgate. Always check the
moving area above and behind the tailgate.
Note
The installation of certain heavy
accessories onto the tailgate may
affect its ability to remain open.
Vehicle security
Anti-theft locking system9 Warning
Do not use the system if there are
people in the vehicle! The doorscannot be unlocked from the
inside.
The system deadlocks all the doors. All doors must be closed otherwise
the system cannot be activated.
Activating
Press e on the remote control twice.
Note
Depending on version, turning the manual key twice in the driver's door lock cylinder towards the rear of the
vehicle only deadlocks the rear
doors. Manual door locks 3 22.
Deactivating
The system is disabled automatically
on every door when:
● unlocking the doors
● turning the ignition switch to position 1
Immobiliser
The system is part of the ignition
switch and checks whether the
vehicle is allowed to be started with
the key being used.
The immobiliser is activated
automatically after the key has been removed from the ignition switch.
If the control indicator d illuminates
when starting, there is a fault in the
system; the engine cannot be started. Switch off the ignition and repeat the
start attempt.

36Seats, restraintsRear head restraints, height
adjustment
Pull the head restraint upwards or
press the release buttons and push
the head restraint downwards.
Removal
Rear head restraints, removal
Press both release buttons, pull the
head restraint upwards and remove.
Stow the removed head restraint
securely in the load compartment. Do not drive with head restraint removed
if the seat is occupied.
Note
Approved accessories may only be
attached if the seat is not in use.Front seats
Seat position9 Warning
Only drive with the seat correctly
adjusted.
9 Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.
9 Warning
Never adjust seats while driving as
they could move uncontrollably.
9 Warning
Never store any objects under the
seats except in the underseat
storage compartment 3 62.

Seats, restraints39Slide the front passenger seat as far
back as possible, to avoid contact
with the instrument panel during
folding.
Note
When seat height is in its highest
position, push head restraints down
3 35 before folding backrest.
Ensure that nothing prevents the
seat from folding, e.g. sun visor,
glovebox.
Pull release levers (1), fold backrest
fully forwards then release the levers. Then push the backrest down further
until it is completely flat.
Pull the flap (2) located at the base of
the backrest and simultaneously push
the backrest down as far as possible.
On some versions, there is a single
release lever located on the inboard
side of the front passenger seat. Pull
release lever, fold backrest fully
forwards, release lever then push
backrest down until it is completely
flat. The flap at the base of the
backrest is not present on some
versions.
Note
Do not operate handwheel for
backrest inclination when backrest is
folded forwards.
9 Warning
When the front passenger seat is
in the folded position, the front
passenger airbag system must be deactivated.
Airbag deactivation 3 53.
9 Warning
Always make sure that the load in
the vehicle is securely stowed.
Otherwise objects can be thrown
around inside the vehicle and
cause personal injury or damage
to the load or vehicle.
Unfolding front passenger seat
To restore the seat to the upright
position, pull the flap located at the
base of the backrest and
simultaneously pull up the backrest
as far as it will go.
Pull release levers and raise backrest
fully then release levers.

42Seats, restraints
3. Fold the seat assembly forwardcompletely.
Note
A label indicating the seat folding
procedure may be located on the
outer edge of the seat base.
9 Warning
When folding the seat use caution
- beware of moving parts. Ensure
the seat is secure when
completely folded.
Caution
For safety reasons, do not place
loads on the folded rear seats.
Unfolding the seats
1. Ensure that the seat belts are unfastened and that they do not
obstruct the unfolding
manoeuvre.
2. Lower the seat assembly to the floor, ensuring the seat is securely
latched into position.
3. Raise the backrest and adjust the
head restraint.
Note
The backrest is properly engaged
when the red mark on the release
lever is no longer visible.
9 Warning
When unfolding the seat, ensure
that the seat assembly is securely
locked in position before driving.
Failure to do so may result in
personal injury in the event of hard braking or a collision.9 Warning
Only drive the vehicle if the
backrests are securely locked into position. Otherwise there is a risk
of personal injury or damage to the
load or vehicle in the event of hard
braking or a collision.
Third row seats
9 Warning
When rear seats or backrests are
being adjusted or folded, keep
hands and feet away from the
moving area.
Never adjust seats while driving as they could move uncontrollably.
Drive only with engaged seats and
backrests.

Seats, restraints43Depending on version, the load
compartment area can be increased
by folding up the third row seats.
Folding the seats ● Press release buttons and push the head restraint downwards3 35.
● Unfasten the seat belts and ensure they do not obstruct the
seat folding manoeuvre.
● Remove the load compartment cover if necessary 3 63.
1. Pull the backrest release lever
and fold down the backrest onto
the seat cushion.
Note
The red mark on the release lever
becomes visible when the backrest
is disengaged.
2. Pull the lower loop and fold the seat assembly forwards.
3. Secure the folded seat in theupright position by attaching the
flexible cord (located on the seat
frame) to the head restraint of the
seat in front of the folded seat.
Note
A label indicating the seat folding
procedure may be located on the
lower rear part of the backrest.
9 Warning
When folding the seat use caution
- beware of moving parts. Ensure
the seat is secure when
completely folded.
9 Warning
No person is allowed to occupy a
rear seat when the seat in front is
in the folded position. Risk of
injury.
Caution
For safety reasons, do not place
loads on the folded rear seats.
Unfolding the seats
1. Ensure that the seat belts are unfastened and that they do not
obstruct the unfolding
manoeuvre.
