Introduction3Vehicle specific dataPlease enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and
maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.
Disregarding the description given in
this manual may affect your warranty.When this Owner's Manual refers to a
workshop visit, we recommend your
Opel Service Partner.
For gas vehicles we recommend an
Opel Repairer authorised for
servicing gas vehicles.
All Opel Service Partners provide
first-class service at reasonable
prices. Experienced mechanics
trained by Opel work according to
specific Opel instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ● This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model
variant, country specifications,
special equipment or
accessories.
● The "In brief" section will give you
an initial overview.● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● This Owner's Manual depicts left-
hand drive vehicles. Operation is similar for right-hand drive
vehicles.
● The Owner's Manual uses the engine identifier code. The
corresponding sales designation
and engineering code can be
found in the section "Technical
data".
● Directional data, e.g. left or right, or front or back, always relate to
the direction of travel.
● Displays may not support your specific language.
● Display messages and interior labelling are written in bold
letters.

In brief111Turn and lane-change
signals, headlight flash,
low beam and high beam ....118
Exit lighting ......................... 121
Parking lights ...................... 119
Buttons for Driver
Information Centre ................97
2 Instruments .......................... 84
3 Forward collision alert
indicator ............................. 157
4 Driver Information Centre ...... 97
5 Infotainment controls ...........76
6 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 77
7 Central locking system ..........24
City mode ............................ 153
Fuel selector ......................... 86
Eco button for stop-start
system ................................. 136
Traction Control system .....151
Electronic Stability Control . 152Parking assist ..................... 160
Seat heating .......................... 40
Heated steering wheel ..........76
8 Anti-theft alarm system
status LED ........................... 28
9 Hazard warning flashers ....117
Control indicator for airbag
deactivation .......................... 92
Control indicator for front
passenger seat belt .............91
10 Colour-Info-Display ............101
Graphic-Info-Display ...........102
11 Centre air vents .................. 131
12 Side air vents, passenger
side ..................................... 131
13 Airbag deactivation switch
(behind glovebox cover) ......49
14 Glovebox .............................. 57
15 Climate control system ........ 123
16 Power outlet .......................... 82
17 USB input .............................. 10
18 Selector lever,
transmission ....................... 144
19 Parking brake ......................15020Ignition switch with
steering wheel lock ............134
21 Horn ..................................... 77
Driver airbag ........................ 47
22 Bonnet release lever ..........191
23 Steering wheel adjustment ..76
24 Light switch ........................ 113
Headlight range
adjustment ......................... 115
Rear fog light ...................... 118
Fuse box ............................ 209
Brightness of instrument
panel illumination ................119
25 Power windows .....................32
26 Exterior mirrors .....................30
27 Cruise control .....................154
Speed limiter ...................... 156
Forward collision alert ........157

In brief131Turn and lane-change
signals, headlight flash,
low beam and high beam ....118
Exit lighting ......................... 121
Parking lights ...................... 119
Buttons for Driver
Information Centre ................97
2 Instruments .......................... 84
3 Forward collision alert
indicator ............................. 157
4 Driver Information Centre ...... 97
5 Infotainment controls ...........76
6 Windscreen wiper,
windscreen washer
system, rear window
wiper, rear window washer
system ................................... 77
7 Central locking system ..........24
City mode ............................ 153
Fuel selector ......................... 86
Eco button for stop-start
system ................................. 136
Traction Control system .....151
Electronic Stability Control . 152Parking assist ..................... 160
Seat heating .......................... 40
Heated steering wheel ..........76
8 Anti-theft alarm system
status LED ........................... 28
9 Hazard warning flashers ....117
Control indicator for airbag
deactivation .......................... 92
Control indicator for front
passenger seat belt .............91
10 Colour-Info-Display ............101
Graphic-Info-Display ...........102
11 Centre air vents .................. 131
12 Side air vents, passenger
side ..................................... 131
13 Airbag deactivation switch
(behind glovebox cover) ......49
14 Glovebox .............................. 57
15 Climate control system ........ 123
16 Power outlet .......................... 82
17 USB input .............................. 10
18 Selector lever,
transmission ....................... 144
19 Parking brake ......................15020Ignition switch with
steering wheel lock ............134
21 Horn ..................................... 77
Driver airbag ........................ 47
22 Bonnet release lever ..........191
23 Steering wheel adjustment ..76
24 Light switch ........................ 113
Headlight range
adjustment ......................... 115
Rear fog light ...................... 118
Fuse box ............................ 209
Brightness of instrument
panel illumination ................119
25 Power windows .....................32
26 Exterior mirrors .....................30
27 Cruise control .....................154
Speed limiter ...................... 156
Forward collision alert ........157

Keys, doors and windows23Key with foldaway key section
Press button to extend. To fold the
key, first press the button.
Car Pass The Car Pass contains security-
related vehicle data and should
therefore be kept in a safe place.
When the vehicle is taken to a
workshop, this vehicle data is needed
in order to perform certain operations.
Radio remote control
Used to operate:
● central locking system
● anti-theft locking system
● anti-theft alarm system
The radio remote control has a range of approx. 20 metres. It can be
restricted by external influences. The
hazard warning flashers confirm
operation.
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Fault
If the central locking system cannot be operated with the radio remote
control, it may be due to the following:
● The range is exceeded.
● The battery voltage is too low.
● Frequent, repeated operation of the radio remote control while not
in range, which will require re-
synchronisation.
● Overload of the central locking system by operating at frequent
intervals, the power supply is
interrupted for a short time.
● Interference from higher-power radio waves from other sources.
Unlocking 3 24.
Basic settings Some settings can be changed in the
Info-Display.
Vehicle personalisation 3 106.

24Keys, doors and windowsRadio remote control battery
replacement
Replace the battery as soon as the
range reduces.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Extend the key and open the unit
sideways. Replace the battery
(battery type CR 2032), paying
attention to the installation position.
Close the unit and synchronise.
Radio remote control
synchronisation
After replacing the battery, unlock the
door with the key in the driver's door
lock. The radio remote control will be
synchronised when the ignition is
switched on.
Memorised settings
Whenever the key is removed from
the ignition switch, the following
settings are automatically memorised by the key:
● lighting
● electronic climate control
● presets for Infotainment system
● central locking system
● comfort settingsThe saved settings are automatically
used the next time the memorised key
is inserted into the ignition switch and
turned to position 1 3 134.
A precondition is that Personalization
by driver is activated in the personal
settings of the Info-Display. This must
be set for each key used.
Vehicle personalisation 3 106.
Central locking system Unlocks and locks doors, load
compartment and fuel filler flap.
From inside the vehicle with the doors locked, pull an interior door handle to
unlock the respective door. Pulling the handle once more opens the door.
Note
In the event of an accident in which
airbags or belt pretensioners are
deployed, the vehicle is
automatically unlocked.
Note
Three minutes after unlocking with
the remote control, the doors are
relocked automatically if no door has
been opened.

Keys, doors and windows25Unlocking
Press c.
Two settings are selectable in the
Info-Display:
● To unlock only the driver's door, load compartment and fuel filler
flap; press c once. To unlock all
doors; press c twice.
● Press c once to unlock doors,
load compartment and fuel filler
flap.
Vehicle personalisation 3 106.
The setting can be saved for the key
being used.
Memorised settings 3 24.
Unlocking and opening the tailgate
3 27.
Locking
Close doors, load compartment and
fuel filler flap.
Press e
.
If the driver's door is not closed
properly, the central locking system will not work.
Central locking buttons Locks or unlocks doors, the load
compartment and fuel filler flap from
inside the passenger compartment.
Press e to lock.
Press c to unlock.
Delayed door lock
Switch off engine and remove key from the lock. Press e with at least
one door opened and three chimes
will sound. When the last door is
closed, the vehicle will automatically
lock all doors after five seconds and
feedback is given.
After ten minutes, the vehicle will
automatically lock all doors even if a
door is still open. This function may be activated or deactivated in the Info-
Display. Vehicle personalisation
3 106.

26Keys, doors and windowsFault in radio remote control
system
Unlocking
Manually unlock the driver's door by
turning the key in the lock. Switch on
the ignition and press the central
locking button c to unlock the other
doors, load compartment and fuel
filler flap.
By switching on the ignition, the anti-
theft locking system is deactivated.
Locking
Manually lock the driver's door by
turning the key in the lock.
Fault in central locking system
Unlocking
Manually unlock the driver's door by
turning the key in the lock. The other
doors can be opened by pulling the
interior handle twice. The load
compartment and fuel filler flap
cannot be opened.
To deactivate the anti-theft locking system, switch on the ignition 3 28.
Locking
Press inside locking knob of all doors
except driver's door. Then close the driver's door and lock it from the
outside with the key.
The fuel filler flap and tailgate cannot
be locked.
Automatic locking
This security feature can be
configured to automatically lock
doors, load compartment and fuel
filler flap as soon as a certain speed
is exceeded.Additionally, it is configurable to
unlock the driver's door or all doors after the ignition is switched off and
the ignition key is removed (manual
transmission) or the selector lever is
moved to position P (automatic
transmission).
Settings can be changed in the
Info-Display.
Vehicle personalisation 3 106.
The settings can be saved for the key being used 3 24.
Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.

38Seats, restraints
● Sit with buttocks as far backagainst the backrest as possible.
Adjust the distance between the
seat and the pedals so that legs
are slightly angled when fully
pressing the pedals. Slide the
front passenger seat as far back
as possible.
● Set seat height high enough to have a clear field of vision on all
sides and of all display
instruments. There should be at
least one hand of clearance
between head and the roof
frame. Your thighs should rest
lightly on the seat without
pressing into it.
● Sit with shoulders as far back against the backrest as possible.
Set the backrest rake so that it is possible to easily reach the
steering wheel with arms slightly
bent. Maintain contact between
shoulders and the backrest when
turning the steering wheel. Do
not angle the backrest too far
back. We recommend a
maximum rake of approx. 25°.
● Adjust seat and steering wheel in
a way that the wrist rests on top
of the steering wheel while the
arm is fully extended and
shoulders on the backrest.
● Adjust the steering wheel 3 76.
● Adjust the head restraint 3 36.
● Adjust the height of the seat belt 3 42.
Seat adjustment
Drive only with engaged seats and
backrests.Longitudinal adjustment
Pull handle, slide seat, release
handle. Try to move the seat back and forth to ensure that the seat is locked
in place.

Instruments and controls75Instruments and
controlsControls ....................................... 76
Steering wheel adjustment ........76
Steering wheel controls .............76
Heated steering wheel ...............76
Horn ........................................... 77
Windscreen wiper/washer .........77
Rear window wiper/washer .......79
Outside temperature ..................79
Clock ......................................... 80
Power outlets ............................. 82
Inductive charging .....................82
Cigarette lighter ......................... 83
Ashtrays .................................... 83
Warning lights, gauges and indi‐
cators ........................................... 84
Instrument cluster ......................84
Speedometer ............................. 84
Odometer .................................. 84
Trip odometer ............................ 84
Tachometer ............................... 85
Fuel gauge ................................ 85
Fuel selector .............................. 86
Engine coolant temperature gauge ....................................... 87Service display.......................... 87
Control indicators ......................88
Turn signal ................................. 90
Seat belt reminder .....................91
Airbag and belt tensioners .........91
Airbag deactivation ....................92
Charging system .......................92
Malfunction indicator light ..........92
Service vehicle soon .................92
Brake and clutch system ...........93
Operate pedal ............................ 93
Antilock brake system (ABS) .....93
Gear shifting .............................. 93
Power steering .......................... 93
Lane departure warning ............93
Ultrasonic parking assist ...........94
Electronic Stability Control off ...94
Electronic Stability Control and Traction Control system ...........94
Traction Control system off .......94
Preheating ................................. 94
Diesel particle filter ....................94
Tyre pressure monitoring system ...................................... 95
Engine oil pressure ....................95
Low fuel ..................................... 95
Immobiliser ................................ 95
Reduced engine power .............95
Autostop .................................... 96
Exterior light .............................. 96High beam................................. 96
High beam assist .......................96
Fog light ..................................... 96
Rear fog light ............................. 96
Cruise control ............................ 96
Vehicle detected ahead .............96
Speed limiter ............................. 96
Traffic sign assistant ..................96
Door open .................................. 96
Information displays .....................97
Driver Information Centre ..........97
Colour-Info-Display ..................101
Graphic-Info-Display ................102
Vehicle messages ......................103
Warning chimes .......................105
Battery voltage ........................ 105
Vehicle personalisation ..............106
Telematics service .....................109
OnStar ..................................... 109

Instruments and controls79Pull lever. Washer fluid is sprayed
onto the windscreen and the wiper
wipes a few times.
Washer fluid 3 194
Rear window wiper/washer
Press the rocker switch to activate the
rear window wiper:
upper position:continuous
operationlower position:intermittent
operationmiddle position:off
Push lever. Washer fluid is sprayed
onto the rear window and the wiper
wipes a few times.
Do not use if the rear window is
frozen.
Switch off in car washes.
The rear window wiper comes on
automatically when the windscreen
wiper is switched on and reverse gear
is engaged.
Activation or deactivation of this
function can be changed in the menu Settings in the Info-Display.
Washer fluid 3 194
Vehicle personalisation 3 106.
Outside temperature
A drop in temperature is indicated
immediately and a rise in temperature
after a time delay. Temperatures
below 3 °C flash on the display.
Illustration shows Graphic-Info-
Display.
