Technical data209Engine oil viscosity gradesAll countries with international service interval 3 202Ambient temperaturePetrol enginesdown to -25 °CSAE 0W-30 or SAE 0W-40
SAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of engine oils with dexos quality is recommended.

210Technical dataEngine dataEngine identifier codeB / D / F10XFLB / D / F10XFTD12XELD14XEJSales designation1.01.01.21.4Engineering codeB10XFTB10XFTB12XERB14XERPiston displacement [cm3
]99999912291398Engine power [kW]66855155at rpm3700 - 60005000 - 600056004200 - 6000Torque [Nm]170170115130at rpm1800 - 37001800 - 450040004000Fuel typePetrolPetrolPetrolPetrolOctane rating RON 2)recommended95959595possible91919898possible98989191Additional fuel type––––2)
A country-specific label at the fuel filler flap can supersede the engine-specific requirement.

Technical data211Engine identifier codeD14XELD14NEJD14XELD14NEHSales designation1.41.41.4 LPG1.4 TurboEngineering codeB14XERB14NELB14XERB14NETPiston displacement [cm3
]1398136413981364Engine power [kW]667466110at rpm60003500 - 600060005000Torque [Nm]130200130220at rpm40001850 - 350040003000 - 4500Fuel typePetrolPetrolLiquid gas / PetrolPetrolOctane rating RON 2)recommended95959598possible98989895possible919191–Additional fuel type-–Liquid gas (LPG)–2)
A country-specific label at the fuel filler flap can supersede the engine-specific requirement.

212Technical dataVehicle dimensions5-door vehicle3-door vehicleLength [mm]40214021 - 4036Width with two exterior mirrors [mm]19441944Height (without antenna) [mm]3)1466 - 15161466 - 1501Length of load compartment floor [mm]705705Length of load compartment with folded rear seats [mm]13721372Load compartment width [mm]944944Load compartment height [mm]876843Turning circle diameter [m]4)11.0 - 11.911.0 - 11.93)
Depending on options.
4) Depending on body and equipment variants.
Capacities
Engine oilincluding filter [l]4.0between MIN and MAX [l]1.0

Technical data213Fuel tankPetrol, refilling quantity [l]45LPG, refilling quantity [l]31

214Technical dataTyre pressuresComfort with up to 3 peopleECO with up to 3 peopleWith full loadEngineTyresfrontrearfrontrearfrontrear[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])D12XEL,
D14XEL,
D14XEL LPG175/70 R14,
185/70 R14,
185/65 R15,
195/55 R16,
215/45 R17210/2.1 (31)210/2.1 (31)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)D14XEJ175/70 R14,
185/70 R14,
185/65 R15,
215/45 R17210/2.1 (31)210/2.1 (31)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)195/55 R16210/2.1 (31)230/2.3 (34)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)B / D / F10XFL,
B / D / F10XFT,
D14NEJ, D14NEH185/65 R15,
195/55 R16,
215/45 R17230/2.3 (34)230/2.3 (34)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)B / D / F10XFT Sport,
D14NEH Sport195/55 R16230/2.3 (34)230/2.3 (34)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)215/45 R17240/2.4 (35)240/2.4 (35)270/2.7 (39)250/2.5 (37)260/2.6 (38)320/3.2 (46)

Customer information215Customer
informationCustomer information ................215
Declaration of conformity .........215
REACH .................................... 218
Software acknowledgement ....218
Registered trademarks ............220
Vehicle data recording and pri‐
vacy ........................................... 220
Event data recorders ...............220
Radio Frequency Identification (RFID) ..................................... 223Customer information
Declaration of conformity
Transmission systems
This vehicle has systems that
transmit and / or receive radio waves
subject to Directive 2014/53/EU. The
manufacturers of the systems listed
below declare conformity with
Directive 2014/53/EU. The full text of the EU declaration of conformity for
each system is available at the
following internet address:
www.opel.com/conformity.
Importer is
Opel / Vauxhall, Bahnhofsplatz,
65423 Ruesselsheim am Main,
Germany.
Antenna
Laird
Daimlerring 31, 31135 Hildesheim,
Germany
Operation frequency: N/A
Maximum output: N/AImmobiliser
Robert Bosch GmbH
Robert Bosch Platz 1, 70839
Gerlingen, Germany
Operation frequency: 125 kHz
Maximum output:
5.1 dBµA/m @ 10 m
Infotainment system R 4.0 / Navi 4.0
LG Electronics
European Shared Service center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsOperation
frequency (MHz)Maximum output
(dBm)2400.0 - 2483.542400.0 - 2483.5135725.0 - 5850.013
Infotainment system R300 BT
Humax Automotive co. Ltd.
2, Yeongmun-ro, Cheoin-gu, Yong-
in-si, Gyeonggi-do, Korea
Operation frequency:
2402 - 2480 MHz

216Customer informationMaximum output: 4 dBm
OnStar module
LG Electronics
European Shared Service center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsOperation
frequency (MHz)Maximum output
(dBm)2402 - 248042412 - 246218880 - 915331710 - 1785241850 - 1910241920 - 1980242500 - 257023
Radio remote control transmitter
Continental Automotive GmbH
Siemensstraße 12, 93055
Regensburg, Germany
Operation frequency: 433.92 MHz
Maximum output: -5.7 dbm
Robert Bosch GmbH
Robert Bosch Platz 1, 70839
Gerlingen, Germany
Operation frequency: 433.92 MHz
Maximum output: -4 dbm
Parking heater remote conrtol
receiver
Eberspaecher Climate Control
Systems GmbH & Co. KG
Eberspaecherstrasse 24, 73730
Esslingen, Germany
Operation frequency: N/A
Maximum output: N/A
Parking heater remote conrtol
transmitter
Eberspaecher Climate Control
Systems GmbH & Co. KG
Eberspaecherstrasse 24, 73730
Esslingen, Germany
Operation frequency: 434.6 MHz
Maximum output: 10 dBm
Radio remote control receiver
Robert Bosch GmbH
Robert Bosch Platz 1, 70839
Gerlingen, GermanyOperation frequency: N/A
Maximum output: N/A
Tyre pressure sensors
Schrader Electronics Ltd.
11 Technology Park, Belfast Road,
Antrim BT41 1QS, Northern Ireland,
United Kingdom
Operation frequency: 433.92 MHz
Maximum output: 10 dBm

Customer information217Jack

218Customer informationTranslation of the original declarationof conformity
Declaration of conformity according
to EC Directive 2006/42/EC
We declare that the product:
Product designation: Jack
Type/GM part number: 13331922
is in compliance with the provisions of
Directive 2006/42/EC.
Applied technical standards:GMN9737:jackingGM 14337:standard equipment
jack – hardware
testsGMN5127:vehicle integrity –
hoisting and service
station jackingGMW15005:standard equipment
jack and spare tyre,
vehicle testISO TS 16949:quality
management
systemsThe signatory is authorised to
compile the technical documentation.
Rüsselsheim, 31st January 2014
signed by
Hans-Peter Metzger
Engineering Group Manager Chassis & Structure
Adam Opel AG
D-65423 Rüsselsheim
REACH
Registration, Evaluation,
Authorisation and Restriction of
Chemicals (REACH) is a European
Union regulation adopted to improve
the protection of human health and
the environment from the risks that
can be posed by chemicals. Visit
www.opel.com/reach for further
information and for access to the Article 33 communication.Software acknowledgement
Certain OnStar components include
libcurl and unzip software and other
third party software. Below are the
notices and licenses associated with
libcurl and unzip and for other third
party software please see http://
www.lg.com/global/support/
opensource/index.
libcurl Copyright and permission notice
Copyright (c) 1996 - 2010, Daniel
Stenberg, .
All rights reserved.
Permission to use, copy, modify, and
distribute this software for any
purpose with or without fee is hereby
granted, provided that the above
copyright notice and this permission
notice appear in all copies.
The software is provided "as is",
without warranty of any kind, express
or implied, including but not limited to the warranties of merchantability,
fitness for a particular purpose and
noninfringement of third party rights.
In no event shall the authors or
