OPEL CROSSLAND X 2017.75 Owner's Manual

Technical data219Information on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weightrating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code. Engine data
3 223.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

220Technical dataVehicle dataRecommended fluids and lubricantsEuropean service schedule Required engine oil qualityAll European countries with European service interval 3 214Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 GEN2✔–dexos2–✔
Just for Diesel engines: In case dexos quality is unavailable, you may use max. one litre engine oil quality ACEA C3 once
between each oil change.
Engine oil viscosity grades
All European countries with European service interval 3 214Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40below -25 °CSAE 0W-30 or SAE 0W-40

Technical data221International service scheduleRequired engine oil qualityAll countries with international service interval 3 214Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 GEN2✔–dexos2–✔
In case dexos quality is unavailable you may use the oil qualities listed below:
All countries with international service interval 3 214Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B4–✔ACEA C3–✔
Engine oil viscosity grades
All countries with international service interval 3 214Ambient temperaturePetrol and diesel enginesdown to -25 °CSAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40

222Technical dataAll countries with international service interval 3 214below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of oils with dexos quality is recommended.

Technical data223Engine dataEngine identifier codeB12xEB12xHTB12xHTSales designation1.21.2 Turbo1.2 TurboEngineering codeEB2FEB2DTEB2DTSPiston displacement [cm3
]119911991199Engine power [kW]608196at rpm575055005500Torque [Nm]118205230at rpm275015001750Fuel typePetrolPetrolPetrolOctane rating RON 2)recommended959595possible989898Additional fuel type–––2)
A country-specific label at the fuel filler flap can supersede the engine-specific requirement.

224Technical dataEngine identifier codeB16DTB16DTHB16DTHSales designation1.61.61.6Engineering codeDV6FDDV6FCDV6FCPiston displacement [cm3
]156015601560Engine power [kW]738588at rpm375035003500Torque [Nm]254300300at rpm175017501750Fuel typeDieselDieselDieselAdditional fuel type–––

Technical data225PerformanceEngineB12xEB12xHTB12xHTMaximum speed [km/h]Manual transmission1701883)2064)Automatic transmission–187–3)
5-gear transmission
4) 6-gear transmissionEngineB16DTB16DTHMaximum speed [km/h]Manual transmission180187Automatic transmission––

226Technical dataVehicle weight
Kerb weight, basic model without any optional equipmentEngineManual
transmissionAutomatic
transmissionwithout/with
air conditioning
[kg]B12xE1163/1174–B12xHT1234/1245 5)1278/1289B12xHT1263/1274 6)–B16DT1278/1289–B16DTH1306/1319–5)
5-gear transmission
6) 6-gear transmission
Optional equipment and accessories increase the kerb weight.
Loading information 3 71.
Vehicle dimensionsCrossland XLength [mm]4212Width without exterior mirrors [mm]1765Width with two exterior mirrors [mm]1976

Technical data227Crossland XWidth with two exterior mirrors folded [mm]1825Height (without antenna) [mm]1597Length of load compartment floor [mm]793Length of load compartment with folded rear seats [mm]1483Load compartment width [mm]947Load compartment height with cover [mm]584Load compartment height without cover [mm]894Height of load compartment opening [mm]712Wheelbase [mm]2604Turning circle diameter [m]11.2

228Technical dataCapacities
Engine oilEngineB12xEB12xHTB16DTB16DTHincluding Filter [l]3.253.53.753.75between MIN and MAX [l]1.01.01.01.5
Fuel tank
Petrol/diesel, refilling quantity [l]45
AdBlue tank
AdBlue, refilling quantity [l]14.8
