technical data OPEL GRANDLAND X 2019 Manual user

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............21
Seats, restraints ........................... 44
Storage ........................................ 68
Instruments and controls .............78
Lighting ...................................... 113
Climate control ........................... 123
Driving and operating .................134
Vehicle care ............................... 201
Service and maintenance ..........240
Technical data ........................... 246
Customer information ................259
Index .......................................... 270Contents

Introduction3Vehicle specific dataPlease enter your vehicle's data on
the previous page to keep it easily
accessible.
Please refer to the sections "Service
and maintenance", "Technical data",
the vehicle’s identification plate and
national registration documents.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.Disregarding the description given in
this manual may affect your warranty.
When this Owner's Manual refers to a
workshop visit, we recommend your Opel Service Partner.
All Opel Service Partners provide
first-class service at reasonable
prices. Experienced mechanics
trained by Opel work according to
specific Opel instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ● This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model
variant, country specifications,
special equipment or
accessories.
● The "In brief" section will give you
an initial overview.● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● This Owner's Manual depicts left-
hand drive vehicles. Operation is similar for right-hand drive
vehicles.
● The Owner's Manual uses the engine identifier code. The
corresponding sales designation
and engineering code can be
found in the section "Technical
data".
● Directional data, e.g. left or right, or front or back, always relate to
the direction of travel.
● Displays may not support your specific language.
● Display messages and interior labelling are written in bold
letters.

246Technical dataTechnical dataVehicle identification..................246
Vehicle Identification Number ..246
Identification plate ...................246
Engine identification ................247
Vehicle data ............................... 248
Recommended fluids and lubricants ................................ 248
Engine data ............................. 251
Performance ............................ 253
Vehicle weight ......................... 254
Vehicle dimensions .................255
Capacities ................................ 256
Tyre pressures ........................ 257Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen, or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

Technical data247Information on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weightrating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code.
Engine data 3 251.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

248Technical dataVehicle dataRecommended fluids and lubricantsService interval country groups 1 to 3 Required engine oil qualityAll countries listed in country groups 1 to 3 3 241Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
Diesel engines only: In case dexos quality is unavailable, you may use max. 1 l engine oil quality ACEA C3 once between
each oil change.
Engine oil viscosity grades
All countries listed in country groups 1 to 3 3 241Ambient temperaturePetrol and diesel enginesDiesel enginesdown to -25 °CSAE 5W-30SAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40below -25 °CSAE 5W-30SAE 0W-30 or SAE 0W-40

Technical data249Service interval country group 4Required engine oil qualityCountries included in country group 4 3 241Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesdexos1 Gen2✔–dexos2–✔
In case dexos quality is unavailable you may use the oil qualities listed below:
Countries included in country group 4 3 241Engine oil qualityPetrol engines
(including CNG, LPG, E85)Diesel enginesACEA A3/B4–✔ACEA C3–✔
Engine oil viscosity grades
Countries included in country group 4 3 241Ambient temperaturePetrol enginesDiesel enginesdown to -25 °CSAE 5W-30SAE 0W-30 or SAE 0W-40SAE 5W-30 or SAE 5W-40

250Technical dataCountries included in country group 4 3 241below -25 °CSAE 0W-30 or SAE 0W-40down to -20 °CSAE 10W-30 1)
or SAE 10W-40 1)1)
Permitted, but usage of oils with dexos quality is recommended.

Technical data251Engine dataEngine identifier codeB12XHT / D12xHTA16NHTD16XHTSales designation1.2 Turbo1.61.6Engineering codeEB2DTS / EB2ADTSEP6FDTMEP6FADTXDPiston displacement [cm3
]120015981598Engine power [kW]96121133at rpm550060005500Torque [Nm]230240250at rpm175014001750Fuel typePetrolPetrolPetrolOctane rating RON 2)3)recommended959595possible989898possible919191Additional fuel type–––2)
A country specific label at the fuel filler flap can supersede the engine specific requirement.
3) In certain countries, the use of a particular fuel, e.g. a specific octane rating, may be required to ensure proper engine operation.

252Technical dataEngine identifier codeA16DTHD15DTD15DTHD20DTHSales designation1.61.51.52.0Engineering codeDV6FCDV5RDDV5RCDW10FCPiston displacement [cm3
]1560149914991997Engine power [kW]887596130at rpm3500350037503750Torque [Nm]300250300400at rpm1750175017502000Fuel typeDieselDieselDieselDiesel

Technical data253PerformanceEngineB12xHTA16DTHD16XHTD15DTD15DTHD20DTHA16NHTMaximum speed [km/h]Manual transmission188189–179195––Automatic transmission1881854)–1902142014)Not available at time of printing.
