technical data OPEL GRANDLAND X 2020 Manual user

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............21
Seats, restraints ........................... 45
Storage ........................................ 69
Instruments and controls .............79
Lighting ...................................... 113
Climate control ........................... 123
Driving and operating .................134
Vehicle care ............................... 211
Service and maintenance ..........251
Technical data ........................... 257
Customer information ................269
Index .......................................... 276Contents

Introduction3Vehicle specific dataPlease enter your vehicle's data on
the previous page to keep it easily
accessible.
Please refer to the sections "Service
and maintenance", "Technical data",
the vehicle’s identification plate and
national registration documents.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.Disregarding the description given in
this manual may affect your warranty.
When this Owner's Manual refers to a
workshop visit, we recommend your Opel Service Partner.
All Opel Service Partners provide
first-class service at reasonable
prices. Experienced mechanics
trained by Opel work according to
specific Opel instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ● This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model
variant, country specifications,
special equipment or
accessories.
● The "In brief" section will give you
an initial overview.● The table of contents at the beginning of this manual and
within each section shows where the information is located.
● The index will enable you to search for specific information.
● This Owner's Manual depicts left-
hand drive vehicles. Operation is similar for right-hand drive
vehicles.
● The Owner's Manual uses the engine identifier code. The
corresponding sales designation
and engineering code can be
found in the section "Technical
data".
● Directional data, e.g. left or right, or front or back, always relate to
the direction of travel.
● Displays may not support your specific language.
● Display messages and interior labelling are written in bold
letters.

Technical data257Technical dataVehicle identification..................257
Vehicle identification number ..257
Identification plate ...................257
Engine identification ................258
Vehicle data ............................... 259
Recommended fluids and lubricants ................................ 259
Engine data ............................. 261
Performance ............................ 264
Vehicle dimensions .................265
Capacities ................................ 266
Tyre pressures ........................ 267Vehicle identification
Vehicle identificationnumber
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the windscreen, or in the engine compartment on the
right body panel.
Identification plate
The identification plate is located on
the front left or right door frame.

258Technical dataInformation on identification label:1:manufacturer2:type approval number3:vehicle identification number4:permissible gross vehicle weight
rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle
load in kg7:maximum permissible rear axle
load in kg8:vehicle-specific or country-
specific data
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight.
Vehicle's kerb weight depends on the
specification of the vehicle, e.g.
optional equipment and accessories. Refer to the EEC Certificate of
Conformity provided with your vehicle
or other national registration
documents.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identification
The technical data tables show the
engine identifier code.
Engine data 3 261.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided
with your vehicle or other national
registration documents.

Technical data259Vehicle data
Recommended fluids and lubricants
Required engine oil quality Country groups 3 251
Countries included in country groups 1 to 3EB2FA
EB2ADT
EB2ADTS
EP6FADTXD
DV5RC
DV5RD
DV5REEP6FDTM
EB2DT
EC5F
DW10FC
DV6D
DV6FD
DV6FEOpel Original engine oilB71 2010 / B71 2312B71 2312
Engine EC5F: B71 2290, B71 2296 or B71 300 may also be used.
Countries included in country group 4
all enginesOpel Original engine oilB71 2302 / B71 2297
Engine EC5F: B71 2296 or B71 300 may also be used.

260Technical dataCountries included in country group 5all enginesOpel Original engine oilB71 2297
Engine oil viscosity gradesCountry groups 3 251
B71 2010B71 2312B71 2302B71 2297Engine oil viscosity gradeSAE 0W-20SAE 0W-30SAE 0W-30SAE 5W-30

Technical data261Engine dataEngine identifier codeD12xHT / F12xHTA16xHLA16NHTD16xHTSales designation1.2 Turbo1.61.61.6Engineering codeEB2ADTSEP6FDTMDEP6FDTMEP6FADTXDPiston displacement [cm3
]1200159815981598Engine power [kW]96110121133at rpm55001)60005500Torque [Nm]2301)240250at rpm17501)14001750Fuel typePetrolPetrolPetrolPetrolOctane rating RON 2)3)recommended95959595possible98989898possible91919191Additional fuel type––––1)
Not available at time of printing.
2) A country specific label at the fuel filler flap can supersede the engine specific requirement.
3) In certain countries, the use of a particular fuel, e.g. a specific octane rating, may be required to ensure proper engine operation.

262Technical dataEngine identifier codeD15DTHD20DTHSales designation1.52.0Engineering codeDV5RCDW10FCPiston displacement [cm3
]14991997Engine power [kW]96130at rpm37503750Torque [Nm]300400at rpm17502000Fuel typeDieselDieselEngine identifier codeF16XHRElectric engine (front axle)Electric engine (rear axle)Sales designation1.6 Turbo--Engineering codeEP6FADTXD--Piston displacement [cm 3
]1598--Engine power [kW]14781.283at rpm6000250014000Torque [Nm]300320166at rpm3000500-25000-4760

Technical data263Engine identifier codeF16XHRElectric engine (front axle)Electric engine (rear axle)Sales designation1.6 Turbo--Engineering codeEP6FADTXD--Fuel typePetrol--Octane rating RON4)5)recommended95--possible98--possible91--Additional fuel type---4)
A country specific label at the fuel filler flap can supersede the engine specific requirement.
5) In certain countries, the use of a particular fuel, e.g. a specific octane rating, may be required to ensure proper engine operation.

264Technical dataPerformanceEngineD12xHT / F12xHTD16xHTD15DTHD20DTHA16NHTF16XHRA16xHLMaximum speed [km/h]Manual transmission188–195––––Automatic transmission1966)1902142012356)6)Not available at time of printing.
