child lock OPEL INSIGNIA BREAK 2017.75 Manual user

20Keys, doors and windowsKeys, doors and
windowsKeys, locks ................................... 20
Electronic key system ................20
Memorised settings ...................22
Central locking system ..............22
Automatic locking ......................26
Child locks ................................. 27
Doors ........................................... 27
Load compartment ....................27
Vehicle security ............................ 33
Anti-theft locking system ...........33
Anti-theft alarm system ..............33
Immobiliser ................................ 35
Exterior mirrors ............................ 36
Convex shape ........................... 36
Electric adjustment ....................36
Folding mirrors .......................... 36
Heated mirrors ........................... 37
Automatic dimming ....................37
Interior mirrors ............................. 38
Manual anti-dazzle ....................38
Automatic anti-dazzle ................38
Windows ...................................... 38
Windscreen ............................... 38Power windows......................... 39
Heated rear window ..................41
Heated windscreen ....................41
Sun visors .................................. 41
Roof ............................................. 42
Sunroof ...................................... 42Keys, locks
Electronic key system
Enables a keyless operation of the
following functions:
● central locking system 3 22
● switching on ignition and starting the engine 3 164

Keys, doors and windows27To prevent passive locking of the
vehicle e.g. when refuelling or if
passengers remain in the vehicle, the
system must be disabled.
To disable the system, press the
central locking button c for a few
seconds while one door is open. An
acoustic signal sounds three times to
confirm deactivation. The function
remains disabled until the central
locking button e is pressed or the
ignition is switched on.
Activation or deactivation of passive
locking can be set in the menu
Settings , I Vehicle in the Info-Display.
Info-Display 3 120.
Vehicle personalisation 3 126.
The setting can be saved for each electronic key being used 3 22.Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.
Move the pin in the rear door to the front position. The door cannot be
opened from the inside.
To deactivate, move the pin to the
rear position.
Doors
Load compartment
Tailgate Opening5-door Hatchback
After unlocking, push the brand
emblem and open the tailgate.

28Keys, doors and windowsSports Tourer
After unlocking, push the touchpad
switch under the tailgate moulding
and open the tailgate manually.
Central locking system 3 22.
Closing
Use the interior handle.
Central locking system 3 22.
Power tailgate
9 Warning
Take care when operating the
power tailgate. Risk of injury,
particularly to children.
Keep a close watch on the
movable tailgate when operating.
Ensure that nothing becomes
trapped during operating and no
one is standing within the moving
area.
The power tailgate can be operated
by:
● Pressing X twice on the
electronic key. To prevent
unintended opening of the
tailgate, X must be pressed
longer than during locking or unlocking.
● Handsfree operation with motion sensor below the rear bumper.
● The touchpad switch under the exterior tailgate moulding and
C in the open tailgate.
● The switch C on the inside of
the driver's door.
On vehicles with automatic
transmission, the tailgate can only be operated when the vehicle is
stationary and with selector lever in P.
The turn signal lights flash and a
chime sounds when the power
tailgate is operating.

Seats, restraints55Seat belts
The seat belts are locked during
heavy acceleration or deceleration of
the vehicle, holding the occupants in
the seat position. Thereby the risk of
injury is considerably reduced.
9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Seat belts are designed to be used by only one person at a time. Child
restraint system 3 63.
Periodically check all parts of the belt
system for damage, soiling and
proper functionality.
Have damaged components replaced by a workshop. After an accident,
have the belts and triggered belt
pretensioners replaced by a
workshop.
Note
Make sure that the belts are not
damaged by shoes or sharp-edged objects or trapped. Prevent dirt from getting into the belt retractors.
Seat belt reminder
Each seat is equipped with a seat belt reminder, indicated for front seats by
control indicators X and k, or for rear
seats by the symbol X in the Driver
Information Centre 3 106.
Belt force limiters
Stress on the body is reduced by the
gradual release of the belt during a
collision.Belt pretensioners
In the event of a head-on, rear-end or
side-on collision of a certain severity,
the front and rear seat belts are
tightened. The front seat belts and the outer rear seat belts are tightened by
one pretensioner per seat.9 Warning
Incorrect handling (e.g. removal or
fitting of belts) can trigger the belt
pretensioners.
Deployment of the belt pretensioners
is indicated by continuous illumination
of control indicator v 3 107.
Triggered belt pretensioners must be replaced by a workshop. Belt
pretensioners can only be triggered
once.
Note
Do not affix or install accessories or
other objects that may interfere with
the operation of the belt
pretensioners. Do not make any
modifications to belt pretensioner components as this will invalidate
the operating permit of your vehicle.

316IndexAAccessories and vehicle modifications .......................... 239
Active bonnet ................................ 70
Active emergency braking ..........202
Adaptive cruise control .......112, 190
AdBlue ................................ 110, 171
Adjustable air vents ...................158
Airbag and belt tensioners .........107
Airbag deactivation ..............62, 107
Airbag label................................... 57
Airbag system .............................. 57
Air conditioning regular operation ................................ 160
Air conditioning system .............. 149
Air intake .................................... 159
Air vents...................................... 158
All-wheel drive ........................... 179
Antilock brake system ................ 179
Antilock brake system (ABS) .....109
Anti-theft alarm system ................33
Anti-theft locking system .............. 33
Appearance care ........................280
Armrest ................................... 52, 54
Armrest storage ........................... 73
Ashtrays ....................................... 96 Automatic anti-dazzle ..................38
Automatic dimming ......................37
Automatic light control ...............136
Automatic locking ........................26Automatic transmission .............174
Autostop ..................................... 166
Auxiliary heater ........................... 158
B Baselevel display ........................113
Battery discharge protection ......147
Battery voltage ........................... 125
Belts.............................................. 55 BlueInjection ............................... 171
Bonnet ....................................... 241
Brake and clutch fluid .................285
Brake and clutch system ...........108
Brake assist ............................... 181
Brake fluid .................................. 244
Brakes ............................... 179, 244
Breakdown.................................. 278
Bulb replacement ....................... 248
C Capacities .................................. 300
Cargo management system ........80
Catalytic converter .....................170
Central locking system ................22
Centre console lighting ..............146
Centre console storage ...............73
Changing tyre and wheel size ...267
Charging system ........................ 108
Child locks ................................... 27
Child restraint installation locations ................................... 66

317Child restraints.............................. 63
Child restraint systems ................63
Climate control ............................. 16
Clock............................................. 92
Collision damage repair ..............310
Control indicators........................ 106
Control of the vehicle .................162
Controls ........................................ 88
Convex shape .............................. 36
Coolant and antifreeze ...............285
Cruise control ....................112, 187
Cupholders .................................. 72
Curtain airbag system .................. 61
Curve lighting.............................. 139
D Danger, Warnings and Cautions ...4
Daytime running lights ...............139
Declaration of conformity ............308
DEF ............................................ 171
Diesel exhaust fluid ....................171
Diesel fuel system bleeding .......246
Diesel particle filter ....................169
Door open .................................. 112
Doors ............................................ 27
Driver assistance systems ..........187
Driver Information Centre ...........113
Driving characteristics and towing tips .............................. 235
Driving hints ................................ 162E
Electric adjustment ......................36
Electrical system......................... 257
Electric parking brake .........108, 180
Electric parking brake fault .........108
Electronic climate control system 152
Electronic key system ...................20
Electronic Stability Control.......... 183
Electronic Stability Control and Traction Control system ..........109
Electronic Stability Control off..... 109
End-of-life vehicle recovery .......240
Engine compartment fuse box ...258
Engine coolant ........................... 243
Engine coolant temperature ......110
Engine coolant temperature gauge ..................................... 105
Engine data ............................... 293
Engine exhaust .......................... 169
Engine identification ...................289
Engine oil ................... 242, 285, 290
Engine oil pressure ....................110
Entry lighting .............................. 146
Event data recorders ..................313
Exit lighting ................................ 146
Exterior care .............................. 280
Exterior light ............................... 111
Exterior lighting ....................13, 135
Exterior mirrors ............................. 36F
First aid kit ................................... 83
Fixed air vents ........................... 159
Fog light ..................................... 111
Fog lights ................................... 250
Folding mirrors ............................. 36
Following distance ......................109
Following distance indication ......201
Forward collision alert................. 198
Front airbag system .....................60
Front fog lights ........................... 143
Front pedestrian protection ........205
Front seats.................................... 46
Front storage ................................ 73
Fuel............................................. 230
Fuel consumption - CO 2-
Emissions ............................... 234
Fuel for diesel engines ..............231
Fuel for petrol engines ...............230
Fuel gauge ................................. 104
Funnel......................................... 232
Fuses ......................................... 257
G Gauges ....................................... 102
Gear shifting ............................... 109
General information ...................235
Glovebox ..................................... 72
