In brief9Exterior mirrors
Select the relevant exterior mirror by
pushing left or right mirror button.
LED in button indicates the selection.
Then swivel the control to adjust the
mirror.
Convex exterior mirrors 3 37,
Electric adjustment 3 37, Folding
exterior mirrors 3 37, Heated
exterior mirrors 3 38.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is fully locked. Do not adjust steering
wheel unless vehicle is stationary and steering wheel lock has been
released.
Airbag system 3 58.

10In briefInstrument panel overview

In brief111Power windows .....................40
2 Exterior mirrors .....................37
3 Central locking system ..........25
4 Side air vents ...................... 159
5 Cruise control .....................189
Speed limiter ....................... 190
Adaptive cruise control .......192
Forward collision alert .........200
6 Turn and lane-change
signals, headlight flash,
low/high beam, high beam
assist ................................... 143
Exit lighting ......................... 147
Parking lights ...................... 144
Buttons for Driver
Information Centre ..............114
7 Instruments ........................ 103
Driver Information Centre .... 114
8 Buttons for Driver
Information Centre ..............114
9 Head-up display ..................12210Windscreen wiper and
washer, headlight washer,
rear wiper and washer .........90
11 Centre air vents .................. 159
12 Hazard warning flashers ....143
13 Info-Display ........................ 121
14 Anti-theft alarm system
status LED ........................... 34
15 Electronic Stability Control . 185
Traction Control system .....184
16 Glovebox .............................. 73
17 Controls for Info-Display
operation ............................. 121
18 Climate control system ........ 150
19 Power outlet .......................... 95
20 Sport/Tour mode ................186
Parking assist/Advanced
parking assist .....................209
Lane keep assist ................229
Eco button for stop-start
system ................................. 167
21 Manual transmission ..........179
Automatic transmission ......17522Electric parking brake .........181
23 Power switch ....................... 164
24 Steering wheel adjustment ..89
25 Horn ..................................... 90
26 Bonnet release lever ..........241
27 Fuse box ............................ 261
28 Light switch ........................ 136
Headlight range
adjustment ......................... 139
Front/rear fog lights ............144
Instrument illumination .......145
29 Head-up display ..................122

12In brief

In brief13Exterior lightingAutomatic light controlAUTO:automatic light control
switches automatically
between daytime running
light and headlight8:sidelights9:headlights
Automatic light control 3 137.
Fog lights
>:front fog lightsr:rear fog lightHeadlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:push or pull lever
High beam 3 137.
Headlight flash 3 139.
LED headlights 3 140.
High beam assist 3 140.
Turn and lane-change signalslever up:right turn signallever down:left turn signal
Turn and lane-change signals
3 143, Parking lights 3 144.

14In briefHazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 143.
Horn
Press j.
Washer and wiper systems
Windscreen wiperHI:fastLO:slowINT:interval wiping or automatic
wiping with rain sensorOFF:off
For a single wipe when the
windscreen wiper is off, press the
lever down to position 1x.
Windscreen wiper 3 90, Wiper
blade replacement 3 246.

In brief15Windscreen washer
Pull lever.
Windscreen and headlight washer
system 3 90, Washer fluid 3 244.
Rear window wiper
Turn outer cap to activate the rear
window wiper:
OFF:offINT:intermittent operationON:continuous operationRear window washer
Push lever.
Washer fluid is sprayed on the rear
window and the wiper wipes a few
times.
Rear window wiper/washer 3 92.

16In briefClimate control
Heated rear window
Heating is operated by pressing b.
Heated rear window 3 42.
Heated windscreen
Heating is operated by pressing ,.
Heated windscreen 3 42.
Heated exterior mirrors
Pressing b also activates the heated
exterior mirrors.
Heated exterior mirrors 3 38.
Demisting and defrosting the
windows, air conditioning system
● Press á: fan automatically
switches to higher speed, the air
distribution is directed towards
the windscreen.
● Set temperature control to warmest level.
● Switch on air conditioning A/C if
required.
● Switch on heated rear window b.
● Open side air vents as required and direct them towards the doorwindows.
Air conditioning system 3 150.

In brief17Demisting and defrosting the
windows, electronic climate
control
● Press à. Temperature and air
distribution are set automatically
and the fan runs at high speed.
● Switch on air conditioning A/C ON in Climate setting menu
by pressing CLIMATE, if
required.
● Switch on heated rear window b.
Electronic climate control system 3 153.
Transmission
Manual transmission
Reverse: with the vehicle stationary,
depress clutch pedal, press the
release button on the selector lever
and engage the gear.
Manual transmission 3 179.
Automatic transmissionP:park positionR:reverseN:neutral modeD:automatic modeM:manual mode<:upshift]:downshift
The selector lever can only be moved
out of P when the ignition is on and
the brake pedal is applied. To engage
P or R, press the release button.
Automatic transmission 3 175.

18In briefStarting off
Check before starting off ● Tyre pressure and condition 3 264, 3 304.
● Engine oil level and fluid levels 3 242.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors, seats, and seat belts 3 37, 3 47,
3 57.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
● Manual transmission: operateclutch and brake pedal.
● Automatic transmission: operate brake pedal and move selector
lever to P or N.
● Do not operate accelerator pedal.
● Press Engine Start/Stop button.
● Release button after starting procedure begins.
Starting the engine 3 165.
Stop-start system
If the vehicle is at a low speed or at a
standstill and certain conditions are
fulfilled, an Autostop is activated.
An Autostop is indicated by the
needle at the AUTOSTOP position in
the tachometer.
A restart is indicated by the needle at
the idle speed position in the
tachometer.
Stop-start system 3 167.
