OPEL KARL 2018.5 Instruktionsbog (in Danish)

Tekniske data179MotordataMotorens typebetegnelseD10XEB10XL LPGSalgsbetegnelse1.01.0 LPGSlagvolumen [cm3
]999999Motoreffekt [kW]5454ved omdr./min.65006500Drejningsmoment [Nm]9592ved omdr./min.45004500BrændstoftypeBenzinFlydende gas/BenzinOktantal RON 2)anbefalet9595mulig9191mulig9898Yderligere brændstoftype–Flydende gas (LPG)2)
En landespecifik mærkat på tankklappen kan være gældende i stedet for motorspecifikke krav.

180Tekniske dataYdelseMotorD10XEB10XL LPGTophastighed [km/t]Manuel gearkasse170170Automatiseret gearkasse170–Vægt
EgenvægtMotorManuel gearkasseAutomatiseret gearkasseAutomatisk gearkasseminimum / maksimum
[kg]D10XE938 / 1034938 / 1039–B10XL LPG1024 / 1091––
Ekstraudstyr og tilbehør øger egenvægten. Læsseinformation 3 57.

Tekniske data181DimensionerLængde [mm]3675Bredde uden sidespejle [mm]1595-16323)Bredde med to sidespejle [mm]1876Højde (uden antenne) [mm] uden tagbagagebærer1476-14953)Længde på bagagerumsgulv [mm]486Længde på bagagerum med nedfældede bagsæder [mm]1109Bagagerumsbredde [mm]968Lastrumshøjde med afdækning [mm]499Højde på bagagerumsåbning [mm]608Akselafstand [mm]2385Vendediameter [m] 3)9,8 - 10,73)
Afhængigt af udstyrsvarianter.

182Tekniske dataKapaciteter
MotorolieMotorD10XE
B10XL LPGinkl. filter [l]3,5mellem MIN og MAX [l]1,0
Brændstoftank
MotorD10XEB10XL LPGBenzin, genopfyldningsmængde [l]3232LPG, genopfyldningsmængde [l]–20

Tekniske data183DæktrykKomfort med op til 3 personerECO med op til 3 personerMed fuld lastMotorDækforbagforbagforbag[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])D10XE,
B10XL LPG165/65 R14,
185/55 R15,
195/45 R16220/2,2 (32)210/2,1 (30)270/2,7 (39)250/2,5 (36)260/2,6 (38)300/3,0 (44)Nødhjul
T105/70D14420/4,2 (60)

184KundeinformationKundeinformationKundeinformation......................184
Overensstemmelseserklæring . 184
REACH .................................... 187
Softwarebekræftelse ...............187
Registrerede varemærker .......190
Bildataregistrering og databe‐
skyttelse ..................................... 191
Registrering af hændelsesdata .......................191
Radiofrekvensidentifikation (RFID) ..................................... 194Kundeinformation
Overensstemmelseserklæ‐ring
Radiotransmissionssystemer
Denne bil indeholder systemer, der
sender og/eller modtager radiobøl‐
ger, der er omfattet af
Direktiv 2014/53/EU. Fabrikanterne
af nedenstående systemer erklærer,
at systemerne er i overensstemmelse
med Direktiv 2014/53/EU. Den fulde
ordlyd af EU-overensstemmelseser‐
klæringen for hvert system findes på
følgende internetadresse:
www.opel.com/conformity.
Importøren er
Opel / Vauxhall, Bahnhofsplatz,
65423 Ruesselsheim am Main,
Germany.
Antenne
INFAC ELECS
Saneop-ro 155beon-gi Gwonseon-
gu, Suwon city, Gyeonggi-do, Korea
Driftsfrekvens: I/T
Maksimalt output: I/TAntenne
Laird
Daimlerring 31, 31135 Hildesheim,
Germany
Driftsfrekvens: I/T
Maksimalt output: I/T
Startspærre
Robert Bosch GmbH
Robert Bosch Platz 1, 70839 Gerlin‐
gen, Germany
Driftsfrekvens: 125 kHz
Maksimalt output: 5,1 dBµA/m ved 10
m
Infotainment system R 4.0 / Navi 4.0
LG Electronics
Electronics European Shared Service Center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsDriftsfrekvens
(MHz)Maksimalt
output (dBm)2400,0 - 2483,542400,0 - 2483,5135725,0 - 5850,013

Kundeinformation185Infotainment system R300 BT
Humax Automotive Co. Ltd.
2, Yeongmun-ro, Cheoin-gu, Yong-
in-si, Gyeonggi-do, Korea
Driftsfrekvens: 2402-2480 MHz
Maksimalt output: 4 dBm EIRP
OnStar-modul
LG Electronics
Electronics European Shared Service
Center B.V., Krijgsman 1, 1186 DM
Amstelveen, The NetherlandsDriftsfrekvens
(MHz)Maksimalt
output (dBm)2402 - 248042412 - 246218880 - 915331710 - 1785241850 - 1910241920 - 1980242500 - 257023
Fjernbetjeningens senderenhed
Continental Automotive GmbH
Siemensstraße 12, 93055 Regen‐
sburg, Germany
Driftsfrekvens: 433,92 MHz
Maksimalt output: -5,7 dbm
Robert Bosch GmbH
Robert Bosch Platz 1, 70839 Gerlin‐
gen, Germany
Driftsfrekvens: 433,92 MHz
Maksimalt output: -4 dbm
Fjernbetjeningens modtagerenhed
Robert Bosch GmbH
Robert Bosch Platz 1, 70839 Gerlin‐
gen, Germany
Driftsfrekvens: I/T
Maksimalt output: I/T
Dæktrykssensorer
Schrader Electronics Ltd.
11 Technology Park, Belfast Road,
Antrim BT41 1QS, Northern Ireland,
United Kingdom
Driftsfrekvens: 433,92 MHz
Maksimalt output: 10 dBm

186KundeinformationDonkraft

Kundeinformation187Oversættelse af original overens‐
stemmelseserklæring
Overensstemmelseserklæring i
henhold til EF-direktiv 2006/42/EF
Vi erklærer, at produktet:
Produktbetegnelse: Donkraft
Type/GM-reservedelsnummer:
13584087
er i overensstemmelse med bestem‐
melserne i direktiv 2006/42/EF.
Anvendte tekniske standarder:GM 14337:standarddonkraft -
materielprøverGMW15005:standarddonkraft og
reservehjul, biltestDen person, der har tilladelse til at udarbejde den tekniske dokumenta‐
tion, er
Hans-Peter Metzger
Engineering Group Manager Chassis
& Structure
Adam Opel AG
D-65423 RüsselsheimUnderskrevet af
Daehyeok An
Engineering Group Manager Tyre
Wheel Systems
GM Korea
Bupyung, Incheon, 403-714, Korea
Incheon, Republikken Korea, 4. april,
2014
REACH
Registration, Evaluation, Authorisa‐
tion and Restriction of Chemicals
(REACH) er en EU-forordning, der er
vedtaget for at forbedre beskyttelse af menneskers sundhed og miljøet mod
de risici, der kan opstå på grund af
kemikalier. Besøg www.opel.com/
reach for at læse mere og få adgang
til kommunikationen artikel 33.
Softwarebekræftelse
Visse OnStar-komponenter indehol‐
der libcurl- og unzip-software og
anden tredjepartssoftware. Herunder
findes de meddelelser og licenser,
der er tilknyttet libcurl og unzip, og foranden tredjepartssoftware henvises
til http://www.lg.com/global/support/
opensource/index.
Du kan se den oversatte tekst under
den oprindelige tekst.
libcurl Copyright and permission notice
Copyright (c) 1996 - 2010, Daniel
Stenberg, .
All rights reserved.
Permission to use, copy, modify, and
distribute this software for any
purpose with or without fee is hereby
granted, provided that the above
copyright notice and this permission
notice appear in all copies.
The software is provided "as is",
without warranty of any kind, express or implied, including but not limited to
the warranties of merchantability,
fitness for a particular purpose and
noninfringement of third party rights.
In no event shall the authors or copy‐
right holders be liable for any claim,
damages or other liability, whether in

188Kundeinformationan action of contract, tort or other‐
wise, arising from, out of or in connec‐ tion with the software or the use or
other dealings in the software.
Except as contained in this notice, the
name of a copyright holder shall not
be used in advertising or otherwise to
promote the sale, use or other
dealings in this Software without prior
written authorization of the copyright
holder.
unzip This is version 2005-Feb-10 of theInfo-ZIP copyright and license. The
definitive version of this document
should be available at ftp://ftp.info-
zip.org/pub/infozip/license.html inde‐
finitely.
Copyright (c) 1990-2005 Info-ZIP. All
rights reserved.
For the purposes of this copyright and
license, “Info-ZIP” is defined as the
following set of individuals:
Mark Adler, John Bush, Karl Davis,
Harald Denker, Jean-Michel Dubois,
Jean-loup Gailly, Hunter Goatley, Ed
Gordon, Ian Gorman, Chris Herborth, Dirk Haase, Greg Hartwig, RobertHeath, Jonathan Hudson, Paul
Kienitz, David Kirschbaum, Johnny
Lee, Onno van der Linden, Igor
Mandrichenko, Steve P. Miller, Sergio Monesi, Keith Owens, George
Petrov, Greg Roelofs, Kai Uwe
Rommel, Steve Salisbury, Dave
Smith, Steven M. Schweda, Christian Spieler, Cosmin Truta, Antoine
Verheijen, Paul von Behren, Rich
Wales, Mike White.
This software is provided “as is,”
without warranty of any kind, express
or implied. In no event shall Info-ZIP
or its contributors be held liable for
any direct, indirect, incidental, special
or consequential damages arising out of the use of or inability to use this
software.
Permission is granted to anyone to
use this software for any purpose,
including commercial applications,
and to alter it and redistribute it freely,
subject to the following restrictions:
1. Redistributions of source code must retain the above copyright
notice, definition, disclaimer, and
this list of conditions.2. Redistributions in binary form (compiled executables) must
reproduce the above copyright
notice, definition, disclaimer, and
this list of conditions in documen‐
tation and/or other materials
provided with the distribution. The sole exception to this condition is
redistribution of a standard
UnZipSFX binary (including
SFXWiz) as part of a self-extrac‐
ting archive; that is permitted
without inclusion of this license,
as long as the normal SFX banner
has not been removed from the
binary or disabled.
3. Altered versions--including, but not limited to, ports to new opera‐ting systems, existing ports with
new graphical interfaces, and
dynamic, shared, or static library
versions--must be plainly marked
as such and must not be misre‐
presented as being the original
source. Such altered versions
also must not be misrepresented
as being Info-ZIP releases--inclu‐
ding, but not limited to, labeling of
the altered versions with the
names “Info-ZIP” (or any variation
