108Instruments and controlsAuto Rear Defog: Activates the
heated rear window
automatically.
● Collision / Detection Systems
Rear View Camera Guidelines :
Activates or deactivates the rear view camera guidelines on the
Info Display.
Park Assist : Activates or
deactivates the ultrasonic
sensors.
● Comfort and Convenience
Chime Volume : Changes the
volume of warning chimes.
Personalization By Driver :
Activates or deactivates the
personalisation function.
Auto Wipe in Reverse Gear :
Activates or deactivates
automatic switching on of the
rear window wiper when reverse gear is engaged.
● Lighting
Vehicle Locator Lights : Activates
or deactivates the entry lighting.Exit Lighting : Activates or
deactivates and changes the
duration of exit lighting.
Left or Right Hand Traffic :
Changes between lighting for left
or right-hand traffic.
Adaptive Forward Lighting :
Changes the settings of the
functions of the LED headlights.
● Power Door Locks
Unlocked Door Anti Lock Out :
Activates or deactivates the door locking function while a door is
open.
Auto Door Lock : Activates or
deactivates the automatic door
locking function after switching on ignition.
Delayed Door Lock : Activates or
deactivates the delayed door
locking function.
● Remote Lock, Unlock, Start
Remote Unlock Light Feedback :
Activates or deactivates the
hazard warning flasher feedback
whilst unlocking.Remote Lock Feedback :
Changes what kind of feedback
is given when locking the vehicle.
Remote Door Unlock : Changes
the configuration to unlock only
the driver's door or the whole
vehicle whilst unlocking.
Relock Remotely Unlocked
Doors : Activates or deactivates
the automatic relock function
after unlocking without opening
the vehicle.
Remote Window Operation :
Activates or deactivates the
operation of power windows with
remote control.
Passive Door Unlock : Changes
the configuration to unlock only
the driver's door or the whole
vehicle whilst unlocking.
Passive Door Lock : Activates or
deactivates the passive locking
function. This feature locks the
vehicle automatically after
several seconds if all doors have been closed and an electronickey has been removed from the
vehicle.

Instruments and controls109Remote Left in Vehicle Alert:
Activates or deactivates the
warning chime when the
electronic key remains in the
vehicle.
Personal settings
8" Colour Info Display
Press ; then select the SETTINGS
icon.
In the corresponding submenus the
following settings can be changed:
Vehicle
● Climate and Air Quality
Auto Fan Speed : Modifies the
level of the cabin airflow of the
climate control in automatic
mode.
Auto Heated Seats :
Automatically activates the seat
heating.
Auto Demist : Activates or
deactivates auto demist.
Auto Rear Demist : Activates the
heated rear window
automatically.
● Collision / Detection Systems
Park Assist : Activates or
deactivates the ultrasonic
sensors.
● Comfort and Convenience
Chime Volume : Changes the
volume of warning chimes.
Personalisation by Driver :
Activates or deactivates the
personalisation function.
Auto Wipe in Reverse Gear :
Activates or deactivates
automatic switching on of therear window wiper when reverse
gear is engaged.
● Lighting
Vehicle Locator Lights : Activates
or deactivates the entry lighting.
Exit Lighting : Activates or
deactivates and changes the duration of exit lighting.
Left or Right Hand Traffic :
Changes between lighting for left or right-hand traffic.
Adaptive Forward Lighting :
Changes the settings of the
functions of the LED headlights.
● Power Door Locks
Unlocked Door Anti-Lockout :
Activates or deactivates the door
locking function while a door is open.
Auto Door Lock : Activates or
deactivates the automatic door
locking function after switching on ignition.
Delayed Door Lock : Activates or
deactivates the delayed door
locking function. This feature

Lighting111LightingExterior lighting.......................... 111
Light switch .............................. 111
Automatic light control .............112
High beam ............................... 112
High beam assist .....................113
Headlight flash ......................... 113
Headlight range adjustment ....114
Headlights when driving abroad .................................... 114
Daytime running lights .............115
Adaptive forward lighting .........115
Hazard warning flashers ..........117
Turn lights ................................ 118
Front fog lights ......................... 118
Rear fog light ........................... 118
Reversing lights .......................118
Misted light covers ...................119
Interior lighting ........................... 119
Instrument panel illumination control ..................................... 119
Interior lights ............................ 119
Reading lights .......................... 120
Glove box lighting ....................120
Sunvisor lights ......................... 120Lighting features ........................120
Entry lighting ............................ 120
Exit lighting .............................. 121
Battery discharge protection ....121Exterior lighting
Light switch
Turn light switch:
m:lights off8:sidelights9:low beam
Control indicator 8 3 96.

Lighting117Activation
The high beam assist is activated by
pushing the indicator lever twice. The high beam is switched on
automatically at a speed above
40 km/h.
The green control indicator f
illuminates continuously when the
assist is activated, the blue one 7
illuminates when high beam is on.
Control indicator f 3 96.
Deactivation
Push indicator lever once. It is also
deactivated when front fog lights are
switched on.
If a headlight flash is activated when
the high beam is on, the high beam
assist will be deactivated.
If a headlight flash is activated when
the high beam is off, the high beam
assist will remain activated.
The latest setting of the high beam
assist will remain after the ignition is
switched on again.
Reverse parking function
To assist driver's orientation when
parking, both corner lights and
reversing light illuminate when
headlights are on and reverse gear is engaged. They remain illuminated for
a short time after disengaging reverse gear or until driving faster than
7 km/h in a forward gear.
Eco mode
If the vehicle stops, e. g. due to traffic lights, an energy saving mode for
headlights is activated.Dynamic automatic headlight
levelling
To prevent oncoming traffic from being dazzled, headlight levelling is
automatically adjusted based on
vehicle inclination information.
Fault in AFL-LED lighting system
When the system detects a failure in
the LED headlight system, f
illuminates and a warning is displayed
in the Driver Information Centre.
Hazard warning flashers
Operated by pressing ¨.

146Driving and operatingBrakes
The brake system comprises two
independent brake circuits.
If a brake circuit fails, the vehicle can
still be braked using the other brake
circuit. However, braking effect is
achieved only when the brake pedal
is depressed firmly. Considerably
more force is needed for this. The
braking distance is extended. Seek the assistance of a workshop before
continuing the journey.
When the engine is not running, the
support of the brake servo unit
disappears once the brake pedal has been depressed once or twice.
Braking effect is not reduced, but
braking requires significantly greater
force. It is especially important to bear this in mind when being towed.
Control indicator R 3 93.
Antilock brake system
Antilock brake system (ABS)
prevents the wheels from locking.ABS starts to regulate brake pressure as soon as a wheel shows a tendency to lock. The vehicle remains
steerable, even during hard braking.
ABS control is made apparent
through a pulse in the brake pedal
and the noise of the regulation
process.
For optimum braking, keep the brake
pedal fully depressed throughout the
braking process, despite the fact that the pedal is pulsating. Do not reduce
the pressure on the pedal.
After starting-off the system performs
a self-test which may be audible.
Control indicator u 3 94.
Adaptive brake light
During full braking, all three brake
lights flash for the duration of ABS
control.Fault9 Warning
If there is a fault in the ABS, the
wheels may be liable to lock due
to braking that is heavier than
normal. The advantages of ABS are no longer available. During
hard braking, the vehicle can no longer be steered and may
swerve.
Have the cause of the fault remedied
by a workshop.
Parking brake

Driving and operating159
Trajectory lane of the vehicle is
shown in accordance with the
steering angle.
Warning symbols
Warning symbols are indicated as
triangles 9 on the picture which show
obstacles detected by the rear
sensors of the advanced parking
assist.
Additionally 9 appears on the top line
of the Info Display with the warning to
check the vehicle surrounding.
Deactivation
The camera is deactivated when acertain forward speed is exceeded or
if reverse gear is not engaged for
approx. 10 s.
Rear view camera can be manually
deactivated in the vehicle
personalisation menu in the Info
Display. Select the relevant setting in
Settings .
Vehicle personalisation 3 106.
Deactivation of guiding lines and
warning symbols7'' Colour Info Display: Activation or
deactivation of the visual guiding lines and the warning symbols can be
changed via touch buttons in the
lower zone of the display.
8'' Colour Info Display: Activation or
deactivation of the visual guiding lines
and the warning symbols can be
changed in the Settings menu in the
Info Display.
Info Display 3 102.
Vehicle personalisation 3 106.
Fault
Fault messages are displayed with a 9 on the top line of the Info Display.
The rear view camera may not
operate properly when:
● The surrounding is dark.
● The sun or the beam of headlights is shining directly into
the camera lens.
● Ice, snow, mud, or anything else covers the camera lens. Clean
the lens, rinse it with water, and
wipe it with a soft cloth.
● The vehicle is towing a trailer.

Vehicle care177Vehicle checks
Performing work9 Warning
Only perform engine compartment
checks when the ignition is off.
The cooling fan may start
operating even if the ignition is off.
9 Danger
The ignition system and Xenon
headlights use extremely high
voltage. Do not touch.
Bonnet
Opening
Pull the release lever and return it to
its original position.
Move the safety catch sideways to the left vehicle side and open the bonnet.

184Vehicle careHalogen bulbs9Warning
Halogen bulbs have pressurized
gas inside and can burst if you
drop or scratch the bulb. You or others could be injured. Be sure to read and follow the instructions onthe bulb package.
LED lighting
This vehicle has several LED lights.
For replacement of any LED lighting
assembly, contact a workshop.
Halogen headlights
Baselevel headlight assembly
The base model vehicle has halogen
high beam and low beam headlights,
LED turn lights, a sidelight and
daytime running lights on the
headlight assembly.
Passenger side shown, driver side
similar.
On the driver side remove the
windscreen washer bottle filler neck,
before changing a bulb.
1. High beam headlights
2. Low beam headlights
High beam and low beam headlights 1. Open the bonnet.
Bonnet 3 177.2. Remove the protective cover.
3. Turn the bulb anticlockwise and pull straight back.
4. Disconnect the wiring harnessconnector from the bulb.

241Control indicators.......................... 88
Control of the vehicle .................129
Controls ........................................ 77
Convex shape .............................. 33
Coolant and antifreeze ...............217
Cruise control ...................... 96, 150
Cupholders .................................. 59
Curtain airbag system .................. 51
D Danger, Warnings and Cautions ...4
Daytime running lights ...............115
Declaration of conformity ............231
DEF ............................................ 139
Delayed locking ............................ 28
Descent control system .......94, 149
Diesel exhaust fluid ....................139
Diesel fuel system bleeding .......182
Door open .................................... 97
Doors ............................................ 30
Driver assistance systems ..........150
Driver Information Centre .............97
Driving characteristics and towing tips .............................. 171
Driving hints ................................ 129
E Electric adjustment ......................33
Electrical system......................... 188
Electronic climate control system 124
Electronic driving programmes ..143Electronic key system ...................23
Electronic Stability Control.......... 148
Electronic Stability Control and Traction Control system ............94
Electronic Stability Control off....... 94
End-of-life vehicle recovery .......176
Engine compartment fuse box ...189
Engine coolant ........................... 179
Engine coolant temperature gauge ....................................... 87
Engine data ............................... 224
Engine exhaust .......................... 137
Engine identification ...................220
Engine oil ................... 178, 217, 221
Engine oil pressure ......................95
Entry lighting .............................. 120
Event data recorders ..................236
Exhaust filter ............................... 137
Exit lighting ................................ 121
Exterior care .............................. 213
Exterior light ................................. 96
Exterior lighting ....................13, 111
Exterior mirrors ............................. 33
F
Fault ........................................... 143
First aid kit ................................... 73
Fixed air vents ........................... 127
Flex-Fix system ............................ 61
Folding mirrors ............................. 33Following distance indication ......155
Forward collision alert................. 153
Front airbag system .....................50
Front fog lights .............96, 118, 185
Front seats.................................... 40
Front storage ................................ 60
Fuel............................................. 164
Fuel for diesel engines ..............166
Fuel for liquid gas operation .......166
Fuel for petrol engines ...............164
Fuel gauge ................................... 85
Fuel selector ................................ 86
Fuses ......................................... 188
G
Gauges ......................................... 84
Gear shifting ................................. 94
General information ...................171
Glovebox ..................................... 59
Glove box lighting .......................120
H Halogen headlights ....................184
Hand brake ................................. 146
Hazard warning flashers ............117
Headlight flash ........................... 113
Headlight range adjustment ......114
Headlights when driving abroad 114
Head restraint adjustment .............8
Head restraints ............................ 39
Heated mirrors ............................. 34

242Heated rear window ..................... 37
Heated steering wheel .................77
Heating ........................................ 43
Heating and ventilation system . 122
High beam ........................... 96, 112
High beam assist ..................96, 113
Hill start assist ........................... 147
Horn ....................................... 14, 78
I
Identification plate .....................219
Ignition switch positions .............130
Immobiliser ............................ 32, 96
Indicators ...................................... 84
Info Display ................................. 102
Information displays...................... 97
Initial drive information.................... 6
Instrument panel fuse box .........190
Instrument panel illumination control .................................... 119
Instrument panel overview ........... 10
Interior care ............................... 215
Interior lighting ............................ 119
Interior lights .............................. 119
Interior mirrors .............................. 34
Interruption of power supply ......144
Introduction .................................... 3
J
Jump starting ............................. 209K
Key, memorised settings ..............25
Keys ............................................. 21
Keys, locks ................................... 21
L
Lane departure warning .......94, 163
Lashing eyes ............................... 73
Lighting features .........................120
Light switch ................................ 111
Load compartment ................30, 71
Load compartment cover .............72
Load compartment fuse box ......192
Loading information .....................74
Low fuel ....................................... 95
LPG .............................. 86, 166, 221
M Malfunction indicator light ............93
Manual anti-dazzle ......................34
Manual mode ............................. 143
Manual transmission .................. 144
Manual windows ..........................35
Memorised settings ......................25
Midlevel display ............................ 97
Mirror adjustment ........................... 8
Misted light covers .....................119
N New vehicle running-in ..............129
Number plate light .....................187O
Object detection systems ...........156
Odometer ..................................... 84
Oil, engine .......................... 217, 221
Outside temperature ....................80
Overrun cut-off ........................... 134
P Parking ................................ 19, 136
Parking assist ............................ 156
Parking brake ............................ 146
Particulate filter ........................... 137
Performance .............................. 226
Performing work ........................177
Power button .............................. 131
Power outlets ............................... 83
Power steering fluid ....................179
Power windows ............................ 35
Preheating ................................... 95
Puncture ..................................... 205
R Radio Frequency Identification (RFID) ..................................... 239
Radio remote control ...................22
REACH ....................................... 234
Reading lights ............................ 120
Rear carrier system ......................61
Rear floor storage cover ..............73
Rear fog light ...............96, 118, 187
Rear view camera ...................... 158
