odometer OPEL MOVANO_B 2018.5 Manual user

Instruments and controls87Instruments and
controlsControls ....................................... 88
Steering wheel adjustment ........88
Steering wheel controls .............88
Horn ........................................... 88
Steering column controls ...........88
Windscreen wiper and washer ..89
Outside temperature ..................90
Clock ......................................... 91
Power outlets ............................. 91
Cigarette lighter ......................... 93
Ashtrays .................................... 93
Warning lights, gauges and indi‐ cators ........................................... 93
Instrument cluster ......................93
Speedometer ............................. 93
Odometer .................................. 94
Trip odometer ............................ 94
Tachometer ............................... 94
Fuel gauge ................................ 95
AdBlue gauge ............................ 95
Engine coolant temperature gauge ....................................... 95
Engine oil level monitor .............96
Service display .......................... 96Transmission display .................97
Control indicators ......................97
Turn lights ................................ 100
Seat belt reminder ...................100
Airbag and belt tensioners .......100
Airbag deactivation ..................100
Charging system .....................101
Malfunction indicator light ........101
Service vehicle soon ...............101
Stop engine ............................. 102
Brake system ........................... 102
Antilock brake system (ABS) ...102
Upshift ..................................... 102
Lane departure warning ..........103
Electronic Stability Program ....103
Electronic Stability Program off ........................................... 103
Engine coolant temperature ....103
Preheating ............................... 103
AdBlue ..................................... 103
Tyre pressure monitoring system .................................... 104
Engine oil pressure ..................104
Low fuel ................................... 104
Drain fuel filter ......................... 105
Stop-start system ....................105
Exterior light ............................ 105
Low beam ................................ 105
High beam ............................... 105
High beam assist .....................105Fog light................................... 105
Rear fog light ........................... 105
Cruise control .......................... 105
Active emergency braking .......105
Speed limiter ........................... 106
Tachograph ............................. 106
Door open ................................ 106
Displays ..................................... 106
Driver Information Centre ........106
Info Display .............................. 107
Vehicle messages ......................107
Warning chimes .......................108
Trip computer ............................. 109
Tachograph ................................ 111

94Instruments and controlsSpeed limiterMaximum speed may be restricted by
a speed limiter. As a visible indication
of this, a warning label is located on
the instrument panel.
A warning chime will sound for
10 seconds if the vehicle briefly
exceeds the set limit.
Note
Under certain conditions (e.g. steep
inclines) the vehicle speed may
exceed the set limit.
Speed limiter 3 166.
Cruise control 3 164.Odometer
Displays the recorded distance in km.
Trip odometer
The trip odometer displays the
distance travelled since the last reset.
Press button once on end of
windscreen wiper lever to display the
trip odometer.
To reset, with the trip odometer
displayed, press and hold button for a few seconds with the ignition on. The
display will flash and the value will
reset to 0.
Tachograph 3 111.
Tachometer
Displays the engine speed.
Drive in a low engine speed range for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded. Engine at risk.

106Instruments and controlsIlluminates
The system has been deactivated or
a fault has been detected.
Additionally, a warning message is
displayed in the Driver Information
Centre.
Check the reason of the deactivation
3 167 and in case of a system fault,
seek the assistance of a workshop.
Flashes
The system is actively engaged.
Depending on the situation, the
vehicle may automatically brake
moderately or hard.
Active emergency braking 3 167.
Speed limiter
U illuminates yellow.
Illuminates when the system is on.
Speed limiter 3 166.
Tachograph
& illuminates when there is a fault
3 111.Door open
y illuminates yellow.
Illuminates with the ignition switched
on when a door or the load
compartment is open.
Depending on version, control
indicator also illuminates in
transmission display, indicating
relevant open door.Displays
Driver Information Centre
The Driver Information Centre is
located in the instrument cluster
below the speedometer.
Depending on vehicle configuration,
the following items appear in the
display:
● outside temperature 3 90
● clock 3 91
● odometer, trip odometer 3 94
● engine oil level monitor 3 96
● service display 3 96

Instruments and controls109● There is a fault with the powerdoor lock system 3 30.
● If the vehicle has manual transmission automated 3 155,
the parking brake has not been
applied, neutral is not selected or the brake pedal has not been
depressed. A corresponding
message may also appear in the
Driver Information Centre 3 106.
● If the sliding side door exterior handle is in the open position
when unlocking the vehicle 3 32.
● If the parking brake is not applied
when the power sliding door
switch is pressed 3 32.
● If the power sliding door is locked
from the inside with the child lock active 3 32.
● If the engine is in an Autostop but
not switched off. Stop-start
system 3 140.Trip computer
The trip computer provides
information on driving data, which is
continually recorded and evaluated
electronically.
Depending on vehicle, the following
functions can be selected by pressing button repeatedly on end of wiper
lever:
● fuel used
● average consumption
● instantaneous consumption
● range
● distance travelled
● average speed
● distance before service 3 96
● clock 3 91
● cruise control 3 164
● speed limiter 3 166
● fault and information messages
● odometer 3 94
● trip odometer 3 94
Fuel used
Displays the amount of fuel
consumed since the last reset.
The measurement can be restarted at
any time by pressing and holding the
button on the end of the wiper lever.
Average consumption The value is displayed after driving a
distance of 400 m.
Average consumption is displayed,
taking into consideration the distance
travelled and the fuel used since the
last reset.
The measurement can be restarted at
any time.

110Instruments and controlsInstantaneous consumption
The value is displayed after reaching a speed of 30 km/h.
Range
The value is displayed after driving a
distance of 400 m.
The range is calculated from the
current contents of the fuel tank and
the average consumption since the
last reset.
The range will not display if control
indicator Y is illuminated in the
instrument cluster 3 104.
The measurement can be restarted at
any time.
Distance travelled
Displays the distance driven since the
last reset.
The measurement can be restarted at
any time.
Average speed
The value is displayed after driving a
distance of 400 m.The average speed since the last reset is displayed.
The measurement can be restarted at
any time.
Interruptions in the journey with the
ignition off are not included in the
calculations.
Reset trip computer information
To reset the trip computer, select one
of its functions then press and hold
button on end of wiper lever.
The following trip computer
information can be reset:
● fuel used
● average consumption
● distance travelled
● average speed
The trip computer will reset
automatically when the maximum
value of any of the parameters is
exceeded.Fuel economy rating (ecoScoring)
If equipped, a rating of 0 to 100 is
shown in the Info Display, to help
evaluate fuel efficiency, based on
your driving style.
Higher ratings indicate better fuel
economy.
Tips to improve fuel economy are also
given in the display. Journeys can be
saved in the system memory,
enabling you to compare
performances. Refer to Infotainment
manual for further information.
Vehicle messages 3 107.
Journey record
When the engine is switched off, a record of the last journey may be
shown in the Info Display.
The following information is
displayed:
● average fuel consumption
● trip odometer
● fuel saved in km
Refer to Infotainment manual for
further information.

Instruments and controls111Interruption of power supply
If the power supply has been
interrupted or if the vehicle battery
voltage has dropped too low, the
values stored in the trip computer will be lost.Tachograph
The tachograph is operated as
described in the operating
instructions supplied. Observe
regulations regarding use.
Control indicator & illuminates in the
instrument cluster in the event of a
fault. Seek the assistance of a
workshop.
Note
When a tachograph is fitted, the total distance travelled may be shown
only on the tachograph and not in the
odometer within the instrument
display.
Odometer 3 94.

265Lighting....................................... 112
Lighting features .........................119
Light switch ................................ 112
Limited-slip rear axle ..................163
Load compartment .................26, 79
Load compartment fuse box ......202
Load compartment grille ...............83
Load compartment lighting .........117
Loading information .....................85
Low beam ................................... 105
Low fuel ..................................... 104
Luggage floor net .........................79
M
Malfunction indicator light ..........101
Manual adjustment ......................40
Manual anti-dazzle ......................42
Manual door locks ........................25
Manual mode ............................. 156
Manual transmission............. 18, 154
Manual transmission automated ......................... 18, 155
Manual windows ..........................43
Messages ................................... 107
Mirror adjustment ........................... 9
Mirrors .................................... 40, 42
Misted light covers .....................116
N New vehicle running-in ..............138
Number plate light .....................198O
Object detection systems ...........169
Odometer ..................................... 94
Oil ............................................... 183
Oil, engine .......................... 228, 232
Oil level ......................................... 96
Oil pressure ................................ 104
Outside temperature ....................90
Overcab storage ..........................79
Overhead console .......................78
Overrun cut-off ........................... 140
P Parking ................................ 20, 143
Parking assist ............................ 169
Parking brake ............................ 159
Parking distance control .............169
Parking ticket holder .....................45
Particulate filter ........................... 146
Pedals......................................... 137
Performing work ........................182
Power door locks ..........................30
Power outlets ............................... 91
Power side step ............................ 32
Power sliding door ........................32
Power steering fluid ....................185
Power take-off ............................ 178
Power windows ............................ 43
Preheating ......................... 103, 139
Puncture ............................. 211, 214R
Radio Frequency Identification (RFID) ..................................... 261
Radio remote control ...................23
Rain sensor .................................. 89
REACH ....................................... 258
Reading lights ............................ 118
Rear air conditioning system .....126
Rear bench seat storage ..............78
Rear courtesy light...................... 117
Rear doors ................................... 35
Rear fog light ............................. 105
Rear fog lights ....................112, 116
Rear heating system .................. 124
Rear reading light .......................118
Rear reversing lens ......................44
Rear seats ................................... 54
Bus ............................................ 54
Installing .................................... 54
Rear seat access ......................54
Removing .................................. 54
Rear storage ................................. 79
Rear view camera ...................... 171
Rear windows .............................. 44
Recommended fluids and lubricants ........................ 228, 232
Refuelling ................................... 175 Registered trademarks ...............258
Remote control ............................. 23
Retractable parking brake ..........159

266Reversing lights .........................116
Ride control systems ..........161, 163
Ride height ................................. 144
Roof .............................................. 46
Glass panel ............................... 46
Roof load ...................................... 85
Roof rack ..................................... 85
S Safety belts ................................... 57
Safety net .................................... 83
Seat adjustment ....................... 7, 49
Seat belt ........................................ 8
Seat belt reminder .....................100
Seat belts ..................................... 57
Seat heating ................................. 54
Seat position ................................ 48
Selective catalytic reduction .......147
Selector lever ............................. 155
Service ............................... 134, 226
Service display ....................96, 101
Service information ....................226
Service vehicle soon .................. 101
Side airbag system ......................65
Sidelights .................................... 112
Side turn lights ........................... 196
Side windows................................ 44
Sliding door .................................. 32
Sliding side door ........................... 32
Spare wheel ............................... 216Speed limiter ................93, 106, 166
Speedometer ............................... 93
Starting and operating ................138
Starting off ................................... 19
Starting the engine .......19, 139, 155
Steering ...................................... 137
Steering column controls ..............88
Steering wheel adjustment ....10, 88
Steering wheel controls ...............88
Stop engine ................................ 102
Stop-start system.......... 19, 105, 140
Storage ......................................... 76
Storage compartments .................76
Storage net ............................. 77, 78
Sun visors .................................... 45
Suspension height ......................144
Suspension seat ........................... 49
Swivelling shelf ............................. 77
Symbols ......................................... 4
T
Tachograph ........................ 106, 111
Tachometer ................................. 94
Tail lights ................................... 195
Technical data ....................232, 233
Three-point seat belt .................... 58
Tools .......................................... 204
Top-Tether .................................... 67
Touchscreen ............................... 107
Tow bar....................................... 177Towing ........................................ 177
Towing another vehicle .............222
Towing a trailer ........................... 177
Towing equipment .....................178
Towing eye ................................. 221
Towing the vehicle .....................221
Traction Control system ............. 161
Trailer coupling ........................... 177
Trailer stability assist .................178
Trailer towing ............................. 177
Transmission ............................... 18
Transmission display ...........97, 155
Tread depth ............................... 209
Trip computer ............................ 109
Trip odometer .............................. 94
Turbo engine warm-up ...............139
Turn lights .......................... 100, 115
Tyre chains ................................ 210
Tyre changing ............................. 214
Tyre designations ......................206
Tyre pressure ............................ 206
Tyre pressure monitoring system ............................. 104, 207
Tyre pressures ........................... 252
Tyre repair kit ............................. 211
Tyres .......................................... 205
Tyres and wheel size, changing. 210
