In brief111Fixed air vents .................... 131
2 Headlight range
adjustment ......................... 111
Ultrasonic parking assist .....164
Traction control system ......157
Electronic Stability
Program ............................. 158
3 Side air vents .....................130
4 Light switch ........................ 109
Turn and lane-change
signals ................................ 112
High beam and low beam,
headlight flash ....................110
Sidelights ............................ 109
Automatic light control .......109
Exit lighting ......................... 116
Front fog lights ...................113
Rear fog light ...................... 113
High beam assist ................110
5 Instruments .......................... 90
Transmission display ............94Driver Information Centre .... 103
Trip computer ...................... 105
6 Horn ..................................... 85
Driver airbag ........................ 60
7 Remote control on
steering wheel .......................85
Cruise control .....................160
8 Windscreen wiper,
windscreen washer system ..86
Trip computer ...................... 105
9 Coin tray ............................... 73
10 Power outlet, USB slot ..........88
11 Centre air vents .................. 130
12 Storage compartment ...........73
13 Info-display .......................... 103
14 Front passenger airbag .........60
15 Storage compartment ..........73
16 Glovebox .............................. 74
17 Seat belt reminder ................. 97
Front passenger airbag
deactivation ........................... 61
18 Cupholders ........................... 7419Climate control system ....... 117
Electronic climate control
system ................................. 119
20 Cigarette lighter .................... 90
Power outlet ......................... 88
21 Gear lever, Manual
transmission ........................ 151
Manual transmission
automated ........................... 151
22 Cruise control and speed
limiter ................................. 160
Manual transmission
automated,
Winter and Laden modes ....153
Idle speed control ...............137
Stop-start system ................137
ECO mode .......................... 134
23 Ignition switch with
steering wheel lock ............135
24 Steering column controls .....85
25 Steering wheel adjustment ..85
26 Bonnet release lever ..........177
27 Auxiliary heater ...................124

Seats, restraints579Warning
The lap belt must be positioned as
low as possible across the pelvis
to prevent pressure on the
abdomen.
Airbag system
The airbag system consists of a
number of individual systems
depending on the scope of
equipment.
When triggered the airbags inflate
within milliseconds. They also deflate
so quickly that it is often unnoticeable
during the collision.9 Warning
The airbag system deploys in an
explosive manner, repairs must be performed by skilled personnel
only.
9 Warning
Adding accessories that change
the vehicle's frame, bumper
system, height, front end or side
sheet metal, may keep the airbag
system from working properly. The operation of the airbag system can
also be affected by changing any
parts of the front seats, seat belts,
airbag sensing and diagnostic
module, steering wheel,
instrument panel, inner door seals including the speakers, any of the
airbag modules, ceiling or pillar
trim, front sensors, side impact
sensors or airbag wiring.
Note
The airbag systems and belt
pretensioner control electronics are
located in the centre console area.
Do not put any magnetic objects in
this area.
Do not affix any objects onto the
airbag covers and do not cover them with other materials. Have damagedcovers replaced by a workshop.
Each airbag is triggered only once.
Have deployed airbags replaced by
a workshop. Furthermore, it may be
necessary to have the steering
wheel, the instrument panel, parts of
the panelling, the door seals,
handles and the seats replaced.

112LightingThe lights operate automatically
when the ignition is switched on.
If the vehicle is equipped with the
automatic light control function, the
system switches between daytime
running lights and headlights
automatically depending on the
lighting conditions. Automatic light
control 3 109.
Adaptive forward lighting
Cornering light Depending on the steering angle,
vehicle speed and gear selected
when cornering, an additional light
will illuminate the corner of the road
on the respective side when the
headlights are switched on.
The cornering light is switched off
automatically after prolonged use and
at vehicle speeds above 40 km/h.Hazard warning flashers
Operated by pressing ¨.
In the event of hard braking, the
hazard warning flashers may turn on automatically. Switch off by pressing
¨ .
Turn and lane-change
signalslever up:right turn signallever down:left turn signal
A resistance point can be felt when
moving the lever.
Constant flashing is activated when
the lever is moved beyond the
resistance point. It is deactivated
when the steering wheel is moved in
the opposite direction or lever is
manually moved back to its neutral
position.

Driving and operating173In the case of trailer loads of
1200 kg or more, the vertical coupling
load should not be less than 50 kg.
Rear axle loadWhen the trailer is coupled and the
towing vehicle fully loaded (including all occupants), the permissible rear
axle load (see identification plate or
vehicle documents) must not be
exceeded.
Towing equipmentCaution
When operating without a trailer,
remove the coupling ball bar.
Towing equipment audible
warning
For vehicles fitted with towing
equipment, when connected to a
trailer the pitch of the audible warning
changes upon operation of the turn
signals.
The pitch of the audible warning will
change if a turn signal light on the
trailer or the towing vehicle fails.
Trailer stability assist
If the system detects snaking
movements, engine power is reduced
and the vehicle/trailer combination is
selectively braked until the snaking ceases. While the system is working,keep steering wheel as still as
possible.
Trailer stability assist (TSA) is a
function of the Electronic Stability
Program (ESP) 3 158.Auxiliary features
Power take-off
Activation
To activate the power take-off, with
the vehicle stationary and the engine
idling:
● Set the gearshift lever to neutral (vehicles with manual
transmission automated:
selector lever in position N).
● Depress the clutch pedal.

208Vehicle care
19. Continue driving immediately sothat the sealant is evenlydistributed throughout the tyre.
After driving approx. ten km, but
no more than ten minutes, stop
and check tyre pressure using the
compressor. Screw compressor
air hose directly onto tyre valve
and compressor when doing this.
20. If the tyre pressure is more than 3.1 bar , set it to the correct value.
Repeat the procedure until there
is no more loss of pressure.
If the tyre pressure has fallen
below 3.1 bar, the vehicle must
not be driven. Seek the
assistance of a workshop.
21. Stow tyre repair kit under the front
seat.
Note
The driving characteristics of the repaired tyre are severely affected,
therefore have this tyre replaced.
If unusual noise is heard or the
compressor becomes hot, turn
compressor off for at least
30 minutes.
The built-in safety valve opens at a
pressure of seven bar.
Note the expiry date of the kit. After
this date its sealing capability is no
longer guaranteed. Pay attention to
storage information on sealant
bottle.
Replace the used sealant bottle. Dispose of the bottle as prescribed
by applicable laws.
The compressor and sealant can be
used from approx. -30 °C.Wheel changing
Some vehicles are equipped with a
tyre repair kit instead of a spare wheel
3 205.
Make the following preparations and
observe the following information:
● Park the vehicle on a level, firm and non-slippery surface. The
front wheels must be in the
straight-ahead position.
● Apply the parking brake and engage first gear or reverse gear
(manual transmission) or N
(manual transmission
automated).
● Switch off the air suspension system 3 141.
● Remove the spare wheel 3 210.
● Never change more than one wheel at a time.
● Use the jack only to change wheels in case of puncture, not
for seasonal winter or summer
tyre change.
● The jack is maintenance-free.

210Vehicle careby turning the wrench until the
wheel is clear of the ground.
Vehicles with Rear-wheel drive:
Pay attention to the operating
instructions supplied with the
hydraulic jack (vehicle tools
3 199) and assemble the parts
required as specified.
Position the adapter at the jacking
hole located nearest the wheel
concerned.
Ensure the jack is positioned
correctly. The jack head must be
level with the jacking hole. Pump
the jack by pressing the wheel
wrench/adapters, to position the
base plate correctly.
Raise the vehicle (max. 3 cm) by pressing the wheel wrench until
the wheel is clear of the ground.
4. Unscrew wheel bolts/nuts completely and wipe clean with a
cloth.
Put wheel bolts/nuts somewhere
where the threads will not be
soiled.
5. Change the wheel.
6. Screw in the wheel bolts/nuts.
7. Lower vehicle.
8. Install the wheel wrench (depending on vehicle, attach
wheel wrench to adapters)
ensuring that it locates securely
and tighten each wheel bolt/nut in a crosswise sequence. Tighteningtorque is: 172 Nm (Front-wheel
drive), 235 Nm (Rear-wheel drive
with twin rear wheels), 264 Nm
(Rear-wheel drive with single rear
wheels).
9. Refit wheel cover. Rear-wheel drive, with twin rear
wheels: Install the tyre valve
extender to the inner rear wheel
before refitting the wheel cover.Note
If applicable, fit anti-theft bolts
nearest the tyre valve (otherwise it
may not be possible to refit the wheel cover).
10. Stow the replaced wheel 3 210
and the vehicle tools 3 199.
11. Have the new wheel balanced on the vehicle. Check the tyre
pressure of the installed tyre
3 247 and also the wheel bolt/nut
torque as soon as possible.
Have the defective tyre renewed or
repaired.
Spare wheel Some vehicles are equipped with a
tyre repair kit instead of a spare wheel
3 205.
If mounting a spare wheel which is
different from the other wheels, this
wheel might be classified as a
temporary spare wheel and the
corresponding speed limits apply,
even though no label indicates this.
Seek the assistance of a workshop to
check the applicable speed limit.

260Reversing lights .........................113
Ride control systems ..........157, 160
Ride height ................................. 141
Roof .............................................. 41
Glass panel ............................... 41
Roof load ...................................... 82
Roof rack ..................................... 82
S Safety belts ................................... 53
Safety net .................................... 80
Seat adjustment ....................... 7, 45
Seat belt ........................................ 8
Seat belt reminder .......................97
Seat belts ..................................... 53 Seat heating ................................. 50
Seat position ................................ 44
Selective catalytic reduction .......144
Selector lever ............................. 152
Service ............................... 131, 221
Service display ......................93, 98
Service information ....................221
Service vehicle soon .................... 98
Side airbag system ......................61
Sidelights .................................... 109
Side turn signal lights ................191
Side windows................................ 39
Sliding door .................................. 28
Sliding side door ........................... 28
Spare wheel ............................... 210Speed limiter......................... 90, 164
Speedometer ............................... 90
Starting and operating ................135
Starting off ................................... 18
Starting the engine .......18, 136, 152
Steering ...................................... 134
Steering column controls ..............85
Steering wheel adjustment ......9, 85
Steering wheel controls ...............85
Stop engine .................................. 99
Stop-start system.......... 18, 101, 137
Storage ......................................... 73
Storage compartments .................73
Storage net ............................. 74, 75
Sun visors .................................... 41
Suspension height ......................141
Suspension seat ........................... 45
Swivelling shelf ............................. 74
Symbols ......................................... 4
T
Tachograph ........................ 102, 107
Tachometer ................................. 91
Tail lights ................................... 189
Technical data ....................227, 228
Three-point seat belt .................... 54
Tools .......................................... 199
Top-Tether .................................... 63
Touchscreen ............................... 103
Tow bar....................................... 172Towing ........................................ 172
Towing another vehicle .............217
Towing a trailer ........................... 172
Towing equipment .....................173
Towing eye ................................. 216
Towing the vehicle .....................216
Traction Control system ............. 157
Trailer coupling ........................... 172
Trailer stability assist .................173
Trailer towing ............................. 172
Transmission ............................... 17
Transmission display ...........94, 151
Tread depth ............................... 204
Trip computer ............................ 105
Trip odometer .............................. 91
Turbo engine warm-up ...............136
Turn and lane-change signals ...112
Turn signal ................................... 97
Tyre chains ................................ 205
Tyre changing ............................. 208
Tyre designations ......................200
Tyre pressure ............................ 201
Tyre pressure monitoring system ............................. 100, 202
Tyre pressures ........................... 247
Tyre repair kit ............................. 205
Tyres .......................................... 200
Tyres and wheel size, changing. 204
