dimensions OPEL VIVARO B 2017.5 Manual user

Technical data205Technical dataVehicle identification..................205
Vehicle Identification Number ..205
Identification plate ...................206
Engine identification ................206
Vehicle data ............................... 207
Recommended fluids and lubricants ................................ 207
Engine data ............................. 208
Vehicle weight ......................... 210
Vehicle dimensions .................212
Capacities ................................ 217
Tyre pressures ........................ 218Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number is
visible through the windscreen.
The VIN is also displayed behind a
removable plastic cover on the right-
hand side door step.

212Technical data
ModelEngineWheelbaseTrim level
Additional minimum weights (approx.)6)
[kg]Front axleRear axleTotalDouble cabR9ML1Base246185Mid276996Upper3278110L2Base315485Mid356196Upper41691106) Final weight may vary according to the specification of the vehicle, e.g. options, deleted options and accessories. Refer to identification
plate on the right-hand door pillar.Vehicle dimensionsTypeVanCombiDouble cabPlatform cabWheelbaseL1L2L1L2L1L2L2Length [mm]4999539949995399499953995248Width without exterior mirrors [mm]1956195619561956195619561955Width with two exterior mirrors [mm]2283228322832283228322832283

Technical data213TypeVanCombiDouble cabPlatform cabWheelbaseL1L2L1L2L1L2L2Height - unladen (without antenna) [mm]
H1
1971196719711971197119671971
H224982498-----Wheelbase [mm]3098349830983498309834983498Track width [mm]
Front
1615161516151615161516151615
Rear1628162816281628162816281628
Loadspace dimensions
Wheelbase
VanL1L2Roof heightH1H2H1H2Maximum rear door aperture height [mm]1320182913201829Rear door aperture width (at floor) [mm]1391139113911391Maximum load area height [mm]1387189713871897Maximum load area width [mm]1662166216621662Width between wheel arches [mm]1268126812681268
