In brief111Side air vents ...................... 127
2 Ashtray .................................. 90
Cupholder ............................ 75
3 Light switch ........................ 108
Rear fog light ....................... 112
Front fog lights ...................111
Exit lighting .......................... 114
Turn and lane-change
signals ................................. 111
Sidelights ............................ 108
Headlight flash, low beam
and high beam ....................109
4 Instruments .......................... 91
Driver Information Centre .... 102
Trip computer .....................105
5 Horn ...................................... 85
Driver airbag ......................... 636Windscreen wiper,
windscreen washer system ..86
Rear window wiper, rear
window washer system ........87
Trip computer .....................105
7 Card reader for electronic
key system ............................ 24
8 Steering column controls ......85
9 Centre air vents ................... 127
10 Power outlet .......................... 88
Cigarette lighter ..................... 90
Coin tray, USB slot ................ 73
11 Info display .......................... 102
12 Front passenger airbag .........63
13 Glovebox .............................. 74
14 Heated exterior mirrors .........41
Heated rear window ..............45
Idle speed control ...............135
15 Power outlet .......................... 88
Cigarette lighter ..................... 9016 Climate control system ........ 116
Electronic climate control
system ................................. 118
17 Ashtray .................................. 90
Cupholder ............................ 75
18 Hazard warning flashers .....111
Central locking system ..........26
19 Power button for electronic
key system .......................... 132
20 Eco button for fuel
economy mode ...................130
21 Stop-start system ................136
Cruise control and speed
limiter ................................. 152
22 Remote control on
steering wheel ......................85
Cruise control .....................152
23 Ignition switch with
steering wheel lock .............132
24 Steering wheel adjustment ...85
25 Bonnet release lever ...........166
26 Fuse box ............................. 182

96Instruments and controlsControl indicators in the roof
console
Overview
OTurn signal 3 96XSeat belt reminder 3 97vAirbag and belt tensioners
3 97Ó ONAirbag activation 3 97* OFFAirbag deactivation 3 97pCharging system 3 98ZMalfunction indicator light
3 98FService vehicle soon 3 98CStop engine 3 98RBrake system 3 98uAntilock brake system (ABS)
3 99kjUpshift, downshift 3 99RElectronic Stability Program
3 99ØElectronic Stability Program
off 3 99WEngine coolant temperature
3 99!Preheating 3 100YAdBlue 3 100wTyre pressure monitoring
system 3 100IEngine oil pressure 3 100ECOFuel economy mode 3 101YLow fuel 3 101DAutostop (Stop-start system)
3 101\Autostop inhibited (Stop-
start system) 3 1019Exterior light 3 1018Exterior light 3 101CHigh beam 3 101>Fog light 3 101øRear fog light 3 101mCruise control 3 102UCruise control speed limiter
3 102&Tachograph 3 102yDoor open 3 102
Turn signal
O flashes green.
Flashes if a turn signal or the hazard
warning flashers are activated.
Rapid flashing: failure of a turn signal
light or associated fuse.
An audible warning can be heard
when the turn signals are on.
Bulb replacement 3 175.

Instruments and controls97Fuses 3 181.
Turn signals 3 111.
Seat belt reminder X illuminates or flashes red.
If the seat belt is unfastened, control
indicator X will flash when vehicle
speed exceeds approx. 16 km/h. A
warning chime also sounds for up to
two minutes.
If the seat belt is fastened, the
indicator light extinguishes.
Note
Heavy objects on the front seats
may cause control indicator X to
illuminate. Remove the object from
the seat or fasten the seat belt.9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger
their fellow occupants and
themselves.
Three-point seat belts 3 56.
Airbag and belt tensioners
v illuminates yellow.
Illuminates briefly when the ignition is switched on.
If it does not illuminate or illuminates
whilst driving, there is a fault in the
belt tensioner or the airbag system.
The airbags and belt tensioners may
fail to trigger in the event of an
accident.
Deployment of the belt tensioners or airbags is indicated by continuous
illumination of v.9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
Belt tensioners 3 55.
Airbag system 3 59.
Airbag deactivation Ó ON illuminates yellow.
The front passenger airbag is
activated.
* OFF illuminates yellow.
The front passenger airbag is
deactivated 3 64.
If both control indicators ÓON and
* OFF are illuminated
simultaneously, there is a system
failure. The status of the system is not discernible, therefore no person is
permitted to occupy the front
passenger seat. Contact a workshop
immediately.
If illuminated in conjunction with v or
F , seek the assistance of a workshop.9 Danger
Risk of fatal injury for a child using
a child restraint system together
with activated front passenger
airbag.
Risk of fatal injury for an adult
person with deactivated front
passenger airbag.
Airbag system 3 59.
Belt tensioners 3 55.
Airbag deactivation 3 64.

Climate control123Remote control (Type A)1 Display:Displays preset, current
time or preset time,
temperature, Z, Ü , Y ,
Ö and x2 7:Long press: switch heater on,
short press: turns display on
or confirms selection3 l:Adjusts values up4 d:Long press: switch heater off,
short press: turns display on
or exit menu5 k:Adjusts values downIf no buttons are pressed within
ten seconds the display automatically
turns off.
Remote control (Type A) fault
displaysINIT:automatic detection –
wait until automatic
detection is finishedNO
SIGNAL:no signal –
check heater fuseZ:poor signal –
move closerÜ:battery low –
replace batteryY:heater fault –
consult workshopAdd, AddE:system in learning
mode
Teach remote control (Type A)
If the vehicle battery is reconnected, the LED in the instrument panel
button illuminates and the system
configures the remote control menu
automatically. If the LED flashes,
select Add or AddE and confirm.
Additional remote control units may
also be configured. Press the button
until LED flashes, switch on the
remote control, select Add and
confirm.
AddE teaches the current remote
control unit exclusively and blocks all
previously configured units. Add
teaches up to four remote control
units, but only one unit can operate
the system at any one time.
Remote control (Type B)1 Display:Displays preset, current
time or preset time,
temperature, Z, Ü , Y ,
Ö and x

124Climate control2 l:Adjusts values up3
OFF:Switch heater off, or press
Y and OFF simultaneously
to confirm selection4 Y:Switch heater on, or press Y
and OFF simultaneously to
confirm selection5 k:Adjusts values down
If no buttons are pressed within
30 seconds the display automatically
turns off.
9 Warning
When refuelling, switch off the
remote control unit as well as the
heater!
The remote control has a maximum
range of 1000 metres. The range may
be reduced due to environmental
conditions and as the battery
becomes weaker.
Remote control (Type B) fault
displaysZ:poor signal – adjust positionFAIL:error during signal
transmission –
move closer or check heater
fuseÜ:battery low – replace battery
Teach remote control (Type B)
Up to four additional remote control
units may also be configured. During
additional teaching processes, the
oldest transmitter will be deleted each
time.
Remove the heater fuse for
five seconds, then refit the fuse.
Within two - six seconds press OFF
for one second. Teaching is
completed.
If the remote has not been used for a long period, press the OFF button six
times at intervals of two seconds,
then press and hold for another
two seconds, then wait two minutes.
Manual control
Depending on version, the auxiliary
heater can also be switched on for the
last duration time or the default
duration 30 minutes, or cut-off
immediately, using the button on the
lower part of the instrument panel,
beside the steering wheel.
The LED in the button confirms
operation.
Battery replacement
Replace the battery when the range
of the remote control is reduced or when the battery charge symbol
flashes.

164Vehicle careVehicle careGeneral Information...................165
Accessories and vehicle modifications .......................... 165
Vehicle storage ........................165
End-of-life vehicle recovery .....166
Vehicle checks ........................... 166
Performing work ......................166
Bonnet ..................................... 166
Engine oil ................................. 167
Engine air filter ........................ 168
Engine coolant ......................... 169
Power steering fluid .................169
Washer fluid ............................ 170
Brakes ..................................... 170
Brake fluid ............................... 170
Vehicle battery ......................... 171
Diesel fuel filter ........................173
Diesel fuel system bleeding .....173
Wiper blade replacement ........174
Bulb replacement .......................175
Headlights ............................... 175
Fog lights ................................. 176
Front turn signal lights .............176
Tail lights ................................. 176
Side turn signal lights ..............177Centre high-mounted brake
light ......................................... 177
Reversing light ......................... 178
Number plate light ...................179
Fog tail light ............................. 179
Interior lights ............................ 180
Instrument panel illumination ...180
Electrical system ........................181
Fuses ....................................... 181
Instrument panel fuse box .......182
Vehicle tools .............................. 185
Tools ........................................ 185
Wheels and tyres .......................186
Tyres ....................................... 186
Winter tyres ............................. 186
Tyre designations ....................186
Tyre pressure .......................... 186
Tyre pressure monitoring system .................................... 188
Tread depth ............................. 190
Changing tyre and wheel size . 190
Wheel covers ........................... 190
Tyre chains .............................. 191
Tyre repair kit .......................... 191
Wheel changing .......................194
Spare wheel ............................ 195
Jump starting ............................. 197Towing....................................... 198
Towing the vehicle ...................198
Towing another vehicle ...........199
Appearance care .......................200
Exterior care ............................ 200
Interior care ............................. 202

Vehicle care181Electrical system
Fuses Data on the replacement fuse must
match the data on the defective fuse.
There are two fuse boxes in the
vehicle:
● on the left-hand side of the instrument panel, behind the trim
panel
● in the engine compartment located next to the battery
Note
The engine compartment fuse box
should only be accessed by a
workshop.
Before replacing a fuse, turn off the
respective switch and the ignition.
There are different types of fuses in
the vehicle.
Depending on the type of fuse, a
blown fuse can be recognised by its
melted wire. Do not replace the fuse until the cause of the fault has been
remedied.
It is advisable to carry a full set of
fuses. Provision is made in the fuse
box for the storing of spare fuses.
Some functions are protected by
several fuses.
Fuses may also be inserted without existence of a function.
Note
Not all fuse box descriptions in this
Owner's Manual may apply to your
vehicle. Refer to the fuse box label,
where fitted.
Fuse extractor

182Vehicle care
A fuse extractor may be located on
the instrument panel fuse box cover.
Place the fuse extractor on the
various types of fuse from the top or
side, and withdraw fuse.
Instrument panel fuse box
The fuse box is located on the left-
hand side of the instrument panel, behind a trim panel.
Pull upper part of trim panel and
remove to access the fuse box.
Do not store any objects behind this
panel.
Some circuits may be protected by
several fuses.

Vehicle care185No.Circuit40Rear power outlet41Starting / Body control module42Heated seats43Tachograph44Windscreen wiper45Heating / Air conditioning
After having changed defective fuses,
replace the trim panel.
Vehicle tools
Tools
The jack, wheel wrench, wheel bolt
sleeve, torx key, adapters, wheel
cover hook, towing eye are contained
in a unit, stowed under the driver's
seat.
Slide seat forwards and fold the
backrest forwards 3 48 to access the
tool box. The tool box may be secured
in position with a wing nut. Rotate
wing nut anticlockwise to release.
Wheel changing 3 194.
Spare wheel 3 195.
Vehicles with tyre repair kit: The wheel cover hook and torx key are
stored within the tyre repair kit case,
stowed under the driver's seat.
Tyre repair kit 3 191.

230Exit lighting ................................ 114
Exterior care .............................. 200
Exterior light ............................... 101
Exterior lighting ....................14, 108
Exterior mirrors ............................. 40
F
Fault messages .......................... 103
First aid kit ................................... 82
Fixed air vents ........................... 128
Fog light ..................................... 101
Fog lights ............................ 111, 176
Fog tail light ............................... 179
Folding centre seatback ...............75
Folding front centre passenger seat ........................................... 50
Folding mirrors ............................. 41
Foot well lights ............................ 112
Front airbag system .....................63
Front courtesy lights ...................112
Front door pockets........................ 76
Front fog lights ....................108, 111
Front reading light....................... 114
Front seats.................................... 47
Front storage ................................ 75
Front turn signal lights ...............176
Fuel consumption - CO 2-
Emissions ............................... 161
Fuel cut-off system .....................135
Fuel economy gauge ....................93Fuel economy mode ...................101
Fuel economy rating ...........103, 105
Fuel for diesel engines ..............159
Fuel gauge ................................... 92
Fuel tank ..................................... 219
Fuse box ..................................... 182
Fuses ......................................... 181
G Gauges ......................................... 91
General information ...................162
Glovebox ..................................... 74
Glovebox cooler ......................... 128
Glove box lighting .......................114
Grab handles ................................ 78
H Hand brake ................................. 147
Hand brake - see Parking brake. 148
Hazard warning flashers ............111
Headlight flash ........................... 109
Headlight range adjustment ......109
Headlights .................. 108, 109, 175
Headlights when driving abroad 110
Head restraint adjustment .............8
Head restraints ............................ 46
Heated exterior mirrors .................17
Heated mirrors ............................. 41
Heated rear window ...............17, 45
Heating ........................................ 50
Heating and ventilation system . 116Heat-reflecting windscreen ...........43
High beam ......................... 101, 109
Hill start assist ........................... 148
Horn ....................................... 16, 85
I
Identification plate .....................208
Idle speed control .......................135
Ignition switch positions .............132
Immobiliser .................................. 40
Indicators ...................................... 91
Info display ................................. 102
Information displays.................... 102
Infotainment system ...................102
Initial drive information.................... 6
Instrument cluster ........................91
Instrument panel fuse box .........182
Instrument panel illumination .....180
Instrument panel illumination control .................................... 112
Instrument panel overview ........... 10
Instrument panel storage ..............73
Instrument panel tray ....................73
Interior care ............................... 202
Interior lighting ............................ 112
Interior lights ...................... 112, 180
Interior mirrors .............................. 42
Introduction .................................... 3
ISOFIX .......................................... 65
