In brief111Side air vents ...................... 127
2 Ashtray .................................. 90
Cupholder ............................ 75
3 Light switch ........................ 108
Rear fog light ....................... 112
Front fog lights ...................111
Exit lighting .......................... 114
Turn and lane-change
signals ................................. 111
Sidelights ............................ 108
Headlight flash, low beam
and high beam ....................109
4 Instruments .......................... 91
Driver Information Centre .... 102
Trip computer .....................105
5 Horn ...................................... 85
Driver airbag ......................... 636Windscreen wiper,
windscreen washer system ..86
Rear window wiper, rear
window washer system ........87
Trip computer .....................105
7 Card reader for electronic
key system ............................ 24
8 Steering column controls ......85
9 Centre air vents ................... 127
10 Power outlet .......................... 88
Cigarette lighter ..................... 90
Coin tray, USB slot ................ 73
11 Info display .......................... 102
12 Front passenger airbag .........63
13 Glovebox .............................. 74
14 Heated exterior mirrors .........41
Heated rear window ..............45
Idle speed control ...............135
15 Power outlet .......................... 88
Cigarette lighter ..................... 9016 Climate control system ........ 116
Electronic climate control
system ................................. 118
17 Ashtray .................................. 90
Cupholder ............................ 75
18 Hazard warning flashers .....111
Central locking system ..........26
19 Power button for electronic
key system .......................... 132
20 Eco button for fuel
economy mode ...................130
21 Stop-start system ................136
Cruise control and speed
limiter ................................. 152
22 Remote control on
steering wheel ......................85
Cruise control .....................152
23 Ignition switch with
steering wheel lock .............132
24 Steering wheel adjustment ...85
25 Bonnet release lever ...........166
26 Fuse box ............................. 182

Storage73StorageStorage compartments................73
Instrument panel storage ...........73
Glovebox ................................... 74
Cupholders ................................ 75
Front storage ............................. 75
Door panel storage ....................76
Underseat storage .....................76
Overcab storage ........................78
Load compartment .......................78
Load compartment cover ...........79
Lashing eyes ............................. 79
Safety net .................................. 80
Load compartment grille ............81
Warning triangle ........................82
First aid kit ................................. 82
Roof rack system .........................82
Roof rack ................................... 82
Loading information .....................82Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Instrument panel storage
Storage compartments, pockets and
trays are located in the instrument
panel.
A coin holder may be located on the
instrument panel.
A phone holder may be located on the instrument panel.

74Storage
A tablet holder may be located on the
instrument panel.
To use the tablet holder, pull the
handle towards you fully. Swivel
holder and push it in fully. If required, lower the base of the holder to extend
it.
To refit, pull tablet holder fully towards you, lift it up until it is horizontal and
push it in fully.Depending on version, the tray
located on top of the instrument panel
may have a lid.
Glovebox
To open, pull the handle.
Depending on version, the glovebox
may feature a light that comes on
when the glovebox is opened, and
may also be lockable.
The glovebox should be closed while
driving.

108LightingLightingExterior lighting.......................... 108
Light switch .............................. 108
Automatic light control .............109
High beam ............................... 109
Headlight flash ......................... 109
Headlight range adjustment ....109
Headlights when driving abroad .................................... 110
Daytime running lights .............110
Adaptive forward lighting .........110
Hazard warning flashers ..........111
Turn and lane-change signals . 111
Front fog lights ......................... 111
Rear fog lights ......................... 112
Reversing lights .......................112
Misted light covers ...................112
Interior lighting ........................... 112
Instrument panel illumination control ..................................... 112
Interior lights ............................ 112
Load compartment lighting ......114
Reading lights .......................... 114
Glove box lighting ....................114
Lighting features ........................114
Entry lighting ............................ 114Exit lighting.............................. 114
Battery discharge protection ....115Exterior lighting
Light switch
Turn outer switch:
7:off8:sidelights9P:headlights
High beam control indicator P
3 101.
Low beam control indicator 9 3 101.
Note
If the headlights have been switched
on manually, a warning chime will
sound when the engine is switched

114LightingLoad compartment lighting
The lower load compartment lights
come on when the load compartment is opened.
Reading lights Front reading light
Operate rocker switch:
press 7:offpress l:on
Glove box lighting
The glovebox light comes on when
the glovebox is opened.
Lighting features
Entry lighting
Welcome lighting
Vehicle lights are switched on for a
short time to facilitate locating the
vehicle when it is dark.
Remote control operation
Lights switch on when unlocking the
vehicle with the remote control.
Electronic key system operation
Press t. Press again to switch off.
Exit lighting
If equipped, headlights come on for
approx. 30 seconds after the vehicle
is parked and the system is activated.
Activating 1. Switch off lights (position 7).
2. Switch off ignition.
3. Remove ignition key.
4. Open driver's door.
5. Pull turn signal lever towards steering wheel.
A corresponding message may
appear in the Driver Information
Centre 3 102.

116Climate controlClimate controlClimate control systems.............116
Heating and ventilation system 116
Air conditioning system ...........117
Electronic climate control system .................................... 118
Rear heating system ...............120
Rear air conditioning system ...121
Auxiliary heater ........................122
Air vents ..................................... 127
Adjustable air vents .................127
Fixed air vents ......................... 128
Glovebox cooler ......................128
Maintenance .............................. 128
Air intake ................................. 128
Pollen filter ............................... 128
Air conditioning regular operation ................................ 128
Service .................................... 129Climate control systems
Heating and ventilation system
Controls for: ● temperature
● fan speed
● air distribution
Heated rear window Ü 3 45.
Temperature
red:warmblue:coldHeating will not be fully effective until
the engine has reached normal
operating temperature.
Fan speed
Adjust the air flow by switching the fan
to the desired speed.
Air distributionM:to head areaL:to head area and foot wellK:to foot wellJ:to windscreen, front door
windows and foot wellV:to windscreen and front door
windows
Intermediate settings are possible.
Demisting and defrosting the
windows
● Set temperature control to warmest level.
● Set fan speed to highest level.
● Set air distribution control to V.
● Switch on heated rear window Ü.

128Climate controlTo open or close the centre air ventsand direct the flow of air, tilt the slats
up or down and turn the adjuster
wheel left or right.
Side air vents
To open or close the side air vents, tilt the slats up or down.
Direct the flow of air by rotating the
vents.
Depending upon the position of the
temperature control, air will be
directed into the vehicle via the side
air vents.
Rear air vents
Depending on vehicle, additional
adjustable air vents are located in the
rear passenger compartment.
Fixed air vents Additional air vents are located
beneath the windscreen and door
windows, in the foot wells and,
depending on vehicle, in the rear
passenger compartment.
Glovebox cooler
The air conditioning system can also
keep the contents of the glovebox
cool.Maintenance
Air intake The air intake in front of the
windscreen in the engine
compartment must be kept clear to
allow air intake. Remove any leaves,
dirt or snow.
Pollen filter
The pollen filter cleans dust, soot,
pollen and spores from the air
entering the vehicle through the air
intake.
Note
Pollen filter is only fitted to vehicles
with air conditioning system.
Air conditioning regular operation
In order to ensure continuously
efficient performance, cooling must
be operated for a few minutes once a month, irrespective of the weather
and time of year. Operation with
cooling is not possible when outside
temperature is too low.

180Vehicle care6.Reattach wiring connector to lamp
assembly.
7. Install lamp assembly with the two bolts.
Interior lights
Front and rear courtesy lights
1. Release lens assembly from the clips and the locator using a flat
blade screwdriver.
2. Renew bulb.
3. Install lens assembly.
Load compartment light
1. Release lens assembly from the clips using a flat blade
screwdriver.
2. Remove rear cover on lamp assembly.
3. Renew bulb.
4. Install rear cover and lamp assembly.
Glovebox light
1. Remove lens assembly using aflat blade screwdriver.
2. Renew bulb.
3. Install lens assembly.
Instrument panel illumination
Have bulbs replaced by a workshop.

230Exit lighting ................................ 114
Exterior care .............................. 200
Exterior light ............................... 101
Exterior lighting ....................14, 108
Exterior mirrors ............................. 40
F
Fault messages .......................... 103
First aid kit ................................... 82
Fixed air vents ........................... 128
Fog light ..................................... 101
Fog lights ............................ 111, 176
Fog tail light ............................... 179
Folding centre seatback ...............75
Folding front centre passenger seat ........................................... 50
Folding mirrors ............................. 41
Foot well lights ............................ 112
Front airbag system .....................63
Front courtesy lights ...................112
Front door pockets........................ 76
Front fog lights ....................108, 111
Front reading light....................... 114
Front seats.................................... 47
Front storage ................................ 75
Front turn signal lights ...............176
Fuel consumption - CO 2-
Emissions ............................... 161
Fuel cut-off system .....................135
Fuel economy gauge ....................93Fuel economy mode ...................101
Fuel economy rating ...........103, 105
Fuel for diesel engines ..............159
Fuel gauge ................................... 92
Fuel tank ..................................... 219
Fuse box ..................................... 182
Fuses ......................................... 181
G Gauges ......................................... 91
General information ...................162
Glovebox ..................................... 74
Glovebox cooler ......................... 128
Glove box lighting .......................114
Grab handles ................................ 78
H Hand brake ................................. 147
Hand brake - see Parking brake. 148
Hazard warning flashers ............111
Headlight flash ........................... 109
Headlight range adjustment ......109
Headlights .................. 108, 109, 175
Headlights when driving abroad 110
Head restraint adjustment .............8
Head restraints ............................ 46
Heated exterior mirrors .................17
Heated mirrors ............................. 41
Heated rear window ...............17, 45
Heating ........................................ 50
Heating and ventilation system . 116Heat-reflecting windscreen ...........43
High beam ......................... 101, 109
Hill start assist ........................... 148
Horn ....................................... 16, 85
I
Identification plate .....................208
Idle speed control .......................135
Ignition switch positions .............132
Immobiliser .................................. 40
Indicators ...................................... 91
Info display ................................. 102
Information displays.................... 102
Infotainment system ...................102
Initial drive information.................... 6
Instrument cluster ........................91
Instrument panel fuse box .........182
Instrument panel illumination .....180
Instrument panel illumination control .................................... 112
Instrument panel overview ........... 10
Instrument panel storage ..............73
Instrument panel tray ....................73
Interior care ............................... 202
Interior lighting ............................ 112
Interior lights ...................... 112, 180
Interior mirrors .............................. 42
Introduction .................................... 3
ISOFIX .......................................... 65
