engine OPEL VIVARO C 2020.25 Manual user

44Keys, doors and windowsMechanical child lock for rear
windows
To activate, turn the child lock with the key upwards. The sliding window
cannot be opened from the inside.
To deactivate, turn the child lock with
the key downwards. The sliding
window can be opened from the
inside.
Tailgate window
The tailgate window can be opened to give access to the load compartment
without opening the tailgate.
The tailgate and the tailgate window
cannot be opened at the same time.
Opening
After unlocking, press the button and
open the window until it is fully
opened.
Closing
Press on the centre of the window
until it is fully closed.
Heated rear window Operated by pressing è. Depending
on the version, the heated rear
window is operated together with the
heated exterior mirrors.
Heating works with the engine
running and is switched off
automatically after a short time.
Depending on climate control system, è is located at a different position.

Keys, doors and windows45
Heated windscreen
This function heats the windscreen
along its bottom and along both sides of the windscreen.
Thus, the function allows a fast
detaching of the windscreen wiper
blades if they are frozen to the
windscreen. Additionally, an
accumulation of snow caused by the
operation of the windscreen wipers is
prevented.
Heating is operated by pressing 9.
LED in button illuminates.
Heating works with the engine
running and is switched off
automatically depending on the
ambient temperature.
Pressing 9 again switches off the
heating operation. LED in button is
extinguished.
Sun visors
The sun visors can be folded down or
swivelled to the side to prevent
dazzling.
The cover of the mirrors should be
closed when driving.
A ticket holder is located on the
backside of the sun visor.
Roller blinds

Seats, restraints53Activate seat heating by turning the
thumb wheel " for the respective
front seat. There are three intensity
levels of heating.
To deactivate the seat heating turn
the thumb wheel " to 0.
Prolonged use of the highest setting
for people with sensitive skin is not
recommended.
Seat heating is operational when engine is running and during an
Autostop.
Stop-start system 3 157.
MassageActivate the back massage function
by pressing K. The LED in the button
illuminates to indicate activation.
The massage function is activated for
a period of 1 hour. During this time,
massage is performed in six cycles
with breaks in between.
To adjust the intensity of the massage press L. Two levels of massage are
available.
Pressing K once more deactivates
massage function. The LED goes off.
The massage function is operational
when engine is running and during an Autostop.
Stop-start system 3 157.Rear seats9 Warning
When seats are being adjusted or
folded, keep hands and feet away
from the moving area. Risk of
injury.
Ensure that there are no objects
on the anchor points or rails.
Never adjust seats while driving as they could move uncontrollably.
Drive only with engaged seats and
backrests.
Depending on version the levers of
the seats can be located at different
places. The illustrations show
examples.
Seat backrest
Folding backrest down to table
position
1. Push the head restraint down or remove it before folding the
backrest.
Head restraints 3 47.

Instruments and controls93Instruments and
controlsControls ....................................... 94
Steering wheel adjustment ........94
Steering wheel controls .............94
Horn ........................................... 95
Steering column controls ...........95
Windscreen wiper and washer ..95
Rear window wiper and washer ...................................... 97
Outside temperature ..................97
Clock ......................................... 98
Power outlets ............................. 98
Warning lights, gauges and indi‐ cators ......................................... 101
Instrument cluster ....................101
Speedometer ........................... 105
Odometer ................................ 106
Trip odometer .......................... 106
Tachometer ............................. 107
Fuel gauge .............................. 107
Engine coolant temperature gauge ..................................... 108
Engine oil level monitor ...........109
Service display ........................ 109
Control indicators ....................110Turn lights................................ 110
Seat belt reminder ...................110
Airbag and belt tensioners .......111
Airbag deactivation ..................111
Charging system .....................111
Malfunction indicator light ........111
Service vehicle soon ...............112
Stop engine ............................. 112
System check .......................... 112
Brake system ........................... 112
Parking brake .......................... 112
Antilock brake system (ABS) ...112
Gear shifting ............................ 113
Lane departure warning ..........113
Electronic Stability Control and Traction Control system .........113
Engine coolant temperature ....113
Preheating ............................... 113
Exhaust filter ............................ 113
AdBlue ..................................... 114
Deflation detection system ......114
Engine oil pressure ..................114
Low fuel ................................... 114
Autostop .................................. 115
Exterior light ............................ 115
Low beam ................................ 115
High beam ............................... 115
High beam assist .....................115
LED headlights ........................ 115
Front fog lights ......................... 115Rear fog light........................... 115
Rain sensor ............................. 115
Cruise control .......................... 115
Adaptive cruise control ............115
Vehicle detected ahead ...........115
Side blind spot alert .................116
Active emergency braking .......116
Speed limiter ........................... 116
Door open ................................ 116
Displays ..................................... 116
Driver Information Centre ........116
Info Display .............................. 120
Head-up display ......................121
Vehicle messages ......................123
Warning chimes .......................123
Vehicle personalisation ..............124
Telematics services ...................128
Opel Connect .......................... 128

Instruments and controls105Overview1Turn lights 3 110aSeat belt reminder 3 110dAirbag and belt tensioners
3 111eAirbag deactivation 3 111SCharging system 3 111WMalfunction indicator light
3 111CService vehicle soon
3 112
LED headlights 3 115STOPStop engine 3 112XSystem check 3 112hParking brake 3 112iAntilock brake system
(ABS) 3 112,Gear shifting 3 113QLane departure warning
3 113JElectronic Stability Control
and Traction Control
system 3 113zPreheating 3 113+Exhaust filter 3 113BAdBlue 3 114qTyre deflation detection
system 3 114TEngine oil pressure 3 114r 2Low fuel 3 114V 2Engine coolant temperature
high 3 113ñAutostop 3 1151Exterior light 3 115DLow beam 3 115AHigh beam 3 115BHigh beam assist 3 115GFront fog lights 3 115HRear fog light 3 115yRain sensor 3 115V ,Vehicle detected ahead
3 115,Side blind spot alert 3 116vCruise control 3 115QAdaptive cruise control
3 1155Speed limiter 3 116mActive emergency braking
3 188ODoor open 3 116
Speedometer

Instruments and controls107Uplevel instrument cluster
Trip odometer counts up to
1,999.9 km and resets then
automatically.
Press 000 for 2 seconds to reset trip
odometer.
Driver Information Centre 3 116.
Tachometer
Displays the engine speed.
Drive in a low engine speed range for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded. Engine at risk.
Fuel gauge
Displays the fuel level in the tank.
Never run the fuel tank dry.
The arrow indicates the vehicle side
where the fuel filler flap is located.
Because of the fuel remaining in the
tank, the top-up quantity may be less
than the specified tank capacity.Baselevel cluster
A scale consisting of white segments
shows the fuel level.
If the control indicator r illuminates
yellow, refuel the tank immediately.

108Instruments and controlsMidlevel and uplevel instrument
cluster
If the control indicator 2 illuminates
yellow, refuel the tank immediately.
Engine coolant temperature gauge
Displays the coolant temperature.
Caution
If engine coolant temperature is
too high, stop vehicle, switch off
engine. Danger to engine. Check
coolant level.
Baselevel cluster
A scale consisting of white segments
shows the engine coolant
temperature.
If the engine coolant temperature is
too high, the control indicator V
illuminates red.
Switch off engine immediately.
Midlevel and uplevel instrument
cluster70 °C:engine operating
temperature not yet
reached90 °C:normal operating
temperaturered zone:temperature too high
Control indicator 2 illuminates if
coolant temperature is too high.
Switch off engine immediately.

Instruments and controls109Engine oil level monitor
The state of the engine oil level is
displayed in the Driver Information
Centre for a few seconds following
the service information after switching on the ignition.
A proper state of engine oil level is
confirmed.
If engine oil level is low, T flashes
and warning message is indicated in
the Driver Information Centre.
Depending on the version, D
flashes in the Driver Information
Centre. Confirm engine oil level by
using the oil dipstick and top up
engine oil respectively.
Engine oil 3 214.
A fault of measurement is indicated
by E or a message in the Driver
Information Centre together with
T . Check engine oil level manually
by using the dipstick.
Service display
The service system informs when to
change the engine oil and filter or a
vehicle service is required. Based ondriving conditions, the interval at
which an engine oil and filter change
is required can vary considerably.
Service information 3 259.
A required service due is displayed in the Driver Information Centre for
several seconds after switching on
the ignition.
If no service is required for the next
3000 km or more no service
information appears in the display.
If service is required within the next
3000 km, A illuminates temporary
as reminder. Simultaneously, the
remaining distance or time duration is
indicated for several seconds.
Depending on the version, the
distance travelled since the due date
is indicated in the Driver Information
Centre.
If service is required in less than
1000 km, A flashes and then
illuminates permanently. Remaining distance or time duration is indicated for several seconds. Simultaneously,
the remaining distance or time
duration is indicated for several
seconds. Depending on the version,the distance travelled since the due
date is indicated in the Driver
Information Centre.
Overdued service is indicated by a
message in the Driver Information
Centre which indicates the overdued
distance. A flashes and then
illuminates permanently until service
is executed. Additionally, the control
indicator C or SERVICE
illuminates.
Reset of service interval After each service, the service
indicator must be reset to ensure
proper functionality. It is
recommended to seek the assistance
of a workshop.
If service is executed by yourself,
operate as following:
● switch off ignition
● press and hold F, G
or CHECK
● switch on ignition, the distance indication begins a countdown
● when the display indicates =0,
release the button and
A disappears

Instruments and controls111Airbag and belt tensionersd illuminates yellow.
When the ignition is switched on, the
control indicator illuminates for
several seconds. If it does not
illuminate, does not extinguish after
several seconds or illuminates whilst
driving, there is a fault in the airbag
system. Seek the assistance of a
workshop. The airbags and belt
pretensioners may fail to trigger in the
event of an accident.
Deployment of the belt pretensioners
or airbags is indicated by continuous
illumination of d.9Warning
Have the cause of the fault
remedied immediately by a
workshop.
Belt pretensioners 3 57.
Airbag system 3 61.
Airbag deactivation
H ON illuminates yellow.
The front passenger airbag is
activated.
g OFF illuminates yellow.
The front passenger airbag is
deactivated.
Airbag deactivation 3 65.
Charging system
S illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be
effective. Seek the assistance of a
workshop.
Malfunction indicator light
W illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Fault in the emission control system.The permitted emission limits may be
exceeded. Seek the assistance of a
workshop immediately.

112Instruments and controlsFlashes when the engine is
running
Fault that could lead to catalytic
converter damage. Ease up on the
accelerator until the flashing stops.
Seek the assistance of a workshop
immediately.
Service vehicle soon
C or SERVICE illuminates yellow.
Illuminates briefly when the ignition is
switched on.
May illuminate together with other
control indicators and a
corresponding message in the Driver
Information Centre.
Seek the assistance of a workshop
immediately.
Stop engine
STOP illuminates red.
Illuminates briefly when the ignition is switched on.Illuminates together with other control
indicators, accompanied by a warning chime and a corresponding message
in the Driver Information Centre.
Stop engine immediately and seek
the assistance of a workshop.
System check
W illuminates yellow.
Illuminates together with STOP.
A major engine fault has been
detected.
Stop engine as soon as possible and seek the assistance of a workshop.
Brake system
h illuminates red.
The brake fluid level is too low.9 Warning
Stop. Do not continue your
journey. Consult a workshop.
Parking brake
h illuminates red.
Illuminates when the manual parking
brake is applied and ignition is
switched on 3 170.
Antilock brake system (ABS)
i illuminates yellow.
Illuminates for a few seconds after the ignition is switched on. The system is
ready for operation when the control
indicator extinguishes.
If i does not extinguish after a few
seconds, or if it illuminates while
driving, there is a fault in the ABS. The brake system remains operational butwithout ABS regulation.
If i illuminates together with h, a
fault with the electronic brake force distribution has been detected.
Stop engine immediately and seek
the assistance of a workshop.
Antilock brake system 3 169.
