Vehicle care239If w illuminates at lower temperatures
and extinguishes after some driving,
this could be an indicator for
approaching a low tyre pressure
condition. Check tyre pressure.
Vehicle messages 3 123.
If the tyre pressure must be reduced
or increased, switch off ignition.
Only mount wheels with pressure
sensors, otherwise the tyre pressure
will not be displayed and w
illuminates continuously.
A temporary spare wheel is not
equipped with pressure sensors. The
tyre pressure monitoring system is
not operational for these wheels.
Control indicator w illuminates. For
the further three wheels the system remains operational.
The use of commercially available
liquid tyre repair kits can impair the
function of the system. Factory-
approved repair kits can be used.
Operating electronic devices or being
close to facilities using similar wave
frequencies could disrupt the tyre
pressure monitoring system.Each time the tyres are replaced, tyre pressure monitoring system sensors
must be dismounted and serviced.
For the screwed sensor: replace
valve core and sealing ring. For
clipped sensor: replace complete
valve stem.
Vehicle loading status
Adjust tyre pressure to load condition according to the tyre information label
or tyre pressure chart 3 273, and
select the appropriate setting in the Tyre load menu in the Driver
Information Centre 3 117. This
setting is the reference for the tyre
pressure warnings.
The Tyre load menu only appears if
the vehicle is at a standstill and the
parking brake is applied. On vehicles
with automatic transmission the
selector lever has to be in P.
Select Tyre load page under Vehicle
Information Menu ? in the Driver
Information Centre 3 117.
Select: ● Light for comfort pressure up to
3 people.
● Eco for Eco pressure up to
3 people.
● Max for full load.
Tyre pressure sensor matching
process
Each tyre pressure sensor has a
unique identification code. The
identification code must be matched
to a new wheel position after rotating

240Vehicle carethe wheels or exchanging the
complete wheel set and if one or more tyre pressure sensors were replaced.The tyre pressure sensor matching
process should also be performed
after replacing a spare wheel with a
road wheel containing the tyre
pressure sensor.
The malfunction light w and the
warning message or code should extinguish at the next ignition cycle.The sensors are matched to the
wheel positions, using a relearn tool,
in the following order: left side front
wheel, right side front wheel, right
side rear wheel and left side rear
wheel. The turn signal light at the
current active position is illuminated
until sensor is matched.
Consult your workshop for service.
There are two minutes to match the
first wheel position, and five minutes
overall to match all four wheel
positions. If it takes longer, the
matching process stops and must be
restarted.
The tyre pressure sensor matching
process is:
1. Apply the parking brake.2. Turn the ignition on.
3. On vehicles with automatic transmission: set the selector
lever to P.
On vehicles with manual
transmission: select neutral.
4. Press MENU on the turn signal
lever to select the Vehicle
Information Menu ? in the
Driver Information Centre.
5. Turn the adjuster wheel to scroll to
the tyre pressure menu.6. Press SET/CLR to begin the
sensor matching process. A
message requesting acceptance
of the process should be
displayed.
7. Press SET/CLR again to confirm
the selection. The horn sounds
twice to indicate the receiver is in
relearn mode.
8. Start with the left side front wheel.
9. Place the relearn tool against the tyre sidewall, near the valve stem.Then press the button to activate
the tyre pressure sensor. A horn
chirp confirms that the sensor
identification code has been
matched to this wheel position.
10. Proceed to the right side front wheel, and repeat the procedure
in Step 9.
11. Proceed to the right side rear wheel, and repeat the procedure
in Step 9.
12. Proceed to the left side rear wheel, and repeat the procedure
in Step 9. The horn sounds twice
to indicate the sensor
identification code has been

Vehicle care257Clean the leather upholstery with
clear water and a soft cloth. In case of
heavy soiling, use leather care.
The instrument cluster and the
displays should only be cleaned using
a soft damp cloth. If necessary use a
weak soap solution.
Clean fabric upholstery with a
vacuum cleaner and brush. Remove
stains with an upholstery cleaner.
Clothing fabrics may not be
colourfast. This could cause visible
discolourations, especially on light- coloured upholstery. Removable
stains and discolourations should be
cleaned as soon as possible.
Clean seat belts with lukewarm water or interior cleaner.Caution
Close Velcro fasteners as open
Velcro fasteners on clothing could damage seat upholstery.
The same applies to clothing with
sharp-edged objects, like zips or
belts or studded jeans.
Plastic and rubber parts
Plastic and rubber parts can be
cleaned with the same cleaner as
used to clean the body. Use interior cleaner if necessary. Do not use any
other agent. Avoid solvents and petrol in particular. Do not use high-
pressure jet cleaners.

258Service and maintenanceService and
maintenanceGeneral information ...................258
Service information ..................258
Recommended fluids, lubricants
and parts .................................... 259
Recommended fluids and lubricants ................................ 259General information
Service information In order to ensure economical and
safe vehicle operation and to
maintain the value of your vehicle, it
is of vital importance that all
maintenance work is carried out at the proper intervals as specified.
The detailed, up-to-date service
schedule for your vehicle is available
at the workshop.
Service display 3 107.
European service intervals Maintenance of your vehicle is
required every 30,000 km or after
1 year , whichever occurs first, unless
otherwise indicated in the service display.
A shorter service interval can be valid for severe driving behaviour, e.g. for
taxis and police vehicles.
The European service intervals are
valid for the following countries:Andorra, Austria, Belgium, Bosnia-
Herzegovina, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany,
Greece, Greenland, Hungary,
Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania,
Luxembourg, Macedonia, Malta,
Monaco, Montenegro, Netherlands,
Norway, Poland, Portugal, Romania,
San Marino, Serbia, Slovakia,
Slovenia, Spain, Sweden,
Switzerland, United Kingdom.
Service display 3 107.
International service intervals
Maintenance of your vehicle is
required every 15,000 km or after
1 year , whichever occurs first, unless
otherwise indicated in the service
display.
Severe operating conditions exist if
one or more of the following
circumstances occur frequently: Cold starting, stop and go operation, trailer
operation, mountain driving, driving
on poor and sandy road surfaces,
increased air pollution, presence of
airborne sand and high dust content,

Service and maintenance259driving at high altitude and large
variations of temperature. Under
these severe operating conditions, certain service work may be required
more frequently than the regular service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 107.
Confirmations Confirmation of service is recorded inthe Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or
goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 107.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

284GGauges ....................................... 104
Gear shifting ............................... 114
General information ...................208
Glass panel .................................. 34
Glovebox ..................................... 66
H Halogen headlights ....................222
Hand brake ................................. 166
Hazard warning flashers ............137
Headlight flash ........................... 134
Headlight range adjustment ......134
Headlights................................... 132 Headlights when driving abroad 135
Head restraint adjustment .............8
Head restraints ............................ 36
Heated mirrors ............................. 30
Heated rear window ..................... 33
Heated steering wheel .................97
Heating ........................................ 43
Heating and ventilation system . 142
High beam ......................... 116, 133
High beam assist ................116, 133
Hill start assist ........................... 168
Horn ....................................... 14, 98
I
Identification plate .....................262
Ignition switch positions .............151
Immobiliser .......................... 28, 116Indicators.................................... 104
Info display ................................. 121
Information displays.................... 117
Instrument cluster ......................104
Instrument panel fuse box .........232
Instrument panel illumination .....229
Instrument panel illumination control .................................... 139
Instrument panel overview ........... 10
Interactive driving system ...........171
Interior care ............................... 256
Interior lighting ............................ 139
Interior lights ...................... 139, 228
Interior mirrors .............................. 30
Interruption of power supply ......164
Introduction .................................... 3
J
Jump starting ............................. 251
K Keys ............................................. 20
Keys, locks ................................... 20
L Lane departure warning .....114, 197
Lashing eyes ............................... 88
LED headlights ...........116, 136, 224
Lighting features .........................140
Light switch ................................ 132
Load compartment ................25, 79Load compartment cover .............81
Load compartment fuse box ......233
Loading information .....................94
Load rails and hooks ...................88
Low fuel ..................................... 116
M Malfunction indicator light ..........112
Manual anti-dazzle ......................30
Manual mode ............................. 163
Manual seat adjustment ...............39
Manual transmission .................. 165
Manual windows ..........................31
Memorised settings ......................22
Mirror adjustment ........................... 8
Misted light covers .....................138
N
New vehicle running-in ..............151
Number plate light .....................228
O Object detection systems ...........188
Odometer ................................... 104
Oil, engine .................. 216, 259, 264
OnStar ........................................ 128
Operate pedal ............................. 113
Outside temperature ..................100
Overhead console .......................68
Overrun cut-off ........................... 153

285PParking ................................ 19, 156
Parking assist ............................ 188
Parking brake ............................ 166
Parking lights ............................. 138
Particulate filter ........................... 157
Performance .............................. 269
Performing work ........................215
Pollen filter ................................. 149
Power outlets ............................. 102
Power seat adjustment ................41
Power steering............................ 114
Power steering fluid ....................218
Power windows ............................ 31
Preheating ................................. 115
Puncture ..................................... 245
Q Quickheat ................................... 148
R
Radio Frequency Identification (RFID) ..................................... 281
Radio remote control ...................21
Reading lights ............................ 140
Rear carrier system ......................70
Rear floor storage cover ..............83
Rear fog light .....................116, 138
Rear seats .................................... 44
Rear storage ................................. 81
Rear view camera ...................... 192Rear window wiper/washer ........ 100
Recommended fluids and lubricants ........................ 259, 264
Refuelling ................................... 202
Registered trademarks ...............280
Retained power off .....................152
Reversing lights .........................138
Ride control system ....................169
Roller blinds ................................. 34
Roof .............................................. 34
Roof load ...................................... 94
Roof rack ..................................... 93
S Safety net .................................... 90
Seat adjustment ............................. 6
Seat belt ........................................ 8
Seat belt reminder .....................111
Seat belts ..................................... 50
Seat heating ................................. 43
Seat position ................................ 38
Second row seats ........................44
Selective catalytic reduction .......159
Selector lever ............................. 162
Service ............................... 149, 258
Service display .......................... 107
Service information ....................258
Side airbag system ......................57
Side blind spot alert ....................190
Sidelights .................................... 132Side turn signal lights ................227
Software acknowledgement .......278
Spare wheel ............................... 247
Speed limiter....................... 117, 174
Speedometer ............................. 104
Starting and operating ................151
Starting off ................................... 17
Starting the engine ....................152
Steering ...................................... 151
Steering wheel adjustment ......9, 97
Steering wheel controls ...............97
Stop-start system........................ 154
Storage ......................................... 66
Storage compartments .................66
Sunvisor lights ........................... 140
Sun visors .................................... 33
Symbols ......................................... 4
T
Tachometer ............................... 105
Tail lights ................................... 225
Third row seats ............................ 48
Three-point seat belt .................... 51
Tools .......................................... 235
Tow bar....................................... 208
Towing ................................ 208, 252
Towing another vehicle .............253
Towing equipment .....................209
Towing the vehicle .....................252
Traction Control system ............. 169

286Traction Control system off......... 114
Traffic sign assistant ...........117, 194
Trailer coupling ........................... 208
Trailer stability assist .................212
Trailer towing ............................. 209
Transmission ............................... 16
Transmission display .................162
Tread depth ............................... 241
Trip odometer ............................ 104
Turn and lane-change signals ...137
Turn signal ................................. 110
Tyre chains ................................ 242
Tyre designations ......................236
Tyre pressure ............................ 236
Tyre pressure monitoring system ............................. 115, 238
Tyre pressures ........................... 273
Tyre repair kit ............................. 242
U
Ultrasonic parking assist............. 188
Underseat storage .......................68
Upholstery .................................. 256
Using this manual ..........................3
V Vehicle battery ........................... 219
Vehicle checks............................ 215
Vehicle data ................................ 264
Vehicle data recording and privacy ..................................... 280Vehicle detected ahead..............117
Vehicle dimensions .................... 270
Vehicle Identification Number ....262
Vehicle jack ................................ 235
Vehicle messages .....................123
Vehicle personalisation .............125
Vehicle security ............................ 26
Vehicle specific data ......................3
Vehicle storage ........................... 214
Vehicle tools ............................... 235
Vehicle unlocking ........................... 6
Vehicle weight ........................... 270
Ventilation ................................... 142
W
Warning chimes .........................124
Warning lights ............................. 104
Warning triangle .......................... 92
Washer and wiper systems .........14
Washer fluid ............................... 218
Wheel changing .........................245
Wheel covers ............................. 241
Wheels and tyres .......................236
Windows ....................................... 31
Windscreen................................... 31
Windscreen wiper/washer ...........98
Winter tyres ............................... 236
Wiper blade replacement ..........221
