In brief17Automatic transmissionP:park positionR:reverseN:neutral modeD:automatic modeM:manual mode<:upshift]:downshift
The selector lever can only be movedout of P when the ignition is on and
the brake pedal is applied. To engage
P or R, press the release button.
Automatic transmission 3 192.
Starting off
Check before starting off ● Tyre pressure and condition 3 262, 3 297.
● Engine oil level and fluid levels 3 241.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors, seats, and seat belts 3 29, 3 38,
3 46.
● Brake function at low speed, particularly if the brakes are wet.Starting the engine
● Turn key to position 1.
● Move the steering wheel slightly to release the steering wheel
lock.
● Operate clutch and brake pedal. ● Automatic transmission: operate brake pedal and move selector
lever to P or N.
● Do not operate accelerator pedal.

Storage81Loading information
● Heavy objects in the loadcompartment should be placed
against the seat backrests.
Ensure the backrests are
securely engaged. If objects can
be stacked, the heavier objects should be placed at the bottom.
● Prevent sliding of loose objects by securing them with straps
attached to the lashing eyes
3 75.
● Do not allow the load to protrude above the upper edge of the
backrests.
● Do not place any objects on the load compartment cover or theinstrument panel.
● The load must not obstruct the operation of the pedals, parking
brake and gear selector lever, or
hinder the freedom of movement
of the driver. Do not place any
unsecured objects in the interior.
● Do not drive with an open load compartment.9Warning
Always make sure that the load in
the vehicle is securely stowed.
Otherwise objects can be thrown
around inside the vehicle and
cause personal injury or damage
to the load or car.
● The payload is the difference between the permitted gross
vehicle weight (see identification
plate 3 287) and the EC kerb
weight.
To calculate the payload, enter
the data for your vehicle in the
weights table at the front of this
manual.
The EC kerb weight includes
weights for the driver (68 kg),
luggage (7 kg) and all fluids (fuel
tank 90% full).
Optional equipment and
accessories increase the kerb
weight.
● Driving with a roof load increases
the sensitivity of the vehicle to
cross-winds and has a
detrimental effect on vehicle
handling due to the vehicle's
higher centre of gravity.
Distribute the load evenly and secure it properly with retaining
straps. Adjust the tyre pressure
and vehicle speed according to
the load conditions. Check and
retighten the straps frequently.
Do not drive faster than
120 km/h.
The permissible roof load is
75 kg for vehicles without roof
railing and 100 kg for vehicles
with roof railing. The roof load is
the combined weight of the roof
rack and the load.

96Instruments and controlsAirbag deactivation
ONV illuminates yellow.
Illuminates for approx. 60 seconds
after the ignition is switched on. The
front passenger airbag is activated.
OFF * illuminates yellow.
The front passenger airbag is
deactivated 3 54.
9 Danger
Risk of fatal injury for a child using
a child restraint system together
with activated front passenger
airbag.
Risk of fatal injury for an adult
person with deactivated front
passenger airbag.
Charging system
p illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be
effective. Seek the assistance of a
workshop.
Malfunction indicator light Z illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Fault in the emission control system. The permitted emission limits may be exceeded. Seek the assistance of a
workshop immediately.
Flashes when the engine is
running
Fault that could lead to catalytic converter damage. Ease up on the
accelerator until the flashing stops.
Seek the assistance of a workshop
immediately.
Brake and clutch system
R illuminates red.
The brake and clutch fluid level is too low, when manual parking brake is
not applied 3 244.

238Vehicle careVehicle careGeneral Information...................239
Accessories and vehicle modifications .......................... 239
Vehicle storage ........................239
End-of-life vehicle recovery .....240
Vehicle checks ........................... 240
Performing work ......................240
Bonnet ..................................... 240
Engine oil ................................. 241
Engine coolant ......................... 242
Power steering fluid .................243
Washer fluid ............................ 244
Brakes ..................................... 244
Brake fluid ............................... 244
Vehicle battery ......................... 244
Diesel fuel system bleeding .....246
Wiper blade replacement ........246
Bulb replacement .......................247
Halogen headlights ..................247
LED headlights ........................ 249
Front fog lights ......................... 249
Tail lights ................................. 250
Side turn lights ......................... 253
Number plate light ...................253Interior lights ............................ 254
Instrument panel illumination ...254
Electrical system ........................254
Fuses ....................................... 254
Engine compartment fuse box . 256
Instrument panel fuse box .......258
Load compartment fuse box ....259
Vehicle tools .............................. 261
Tools ........................................ 261
Wheels and tyres .......................261
Winter tyres ............................. 261
Tyre designations ....................261
Tyre pressure .......................... 262
Tyre pressure monitoring system .................................... 263
Tread depth ............................. 266
Changing tyre and wheel size . 267
Wheel covers ........................... 267
Tyre chains .............................. 267
Tyre repair kit .......................... 267
Wheel changing .......................270
Spare wheel ............................ 271
Jump starting ............................. 276
Towing ....................................... 278
Towing the vehicle ...................278
Towing another vehicle ...........279Appearance care .......................280
Exterior care ............................ 280
Interior care ............................. 282

Vehicle care239General Information
Accessories and vehicle modifications
We recommend the use of genuine
parts and accessories and factory
approved parts specific for your
vehicle type. We cannot assess or guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control
units) may invalidate the warranty
offered by Opel. Furthermore, such
changes may affect driver assistance systems, may impact fuel
consumption, CO 2 emissions and
other emissions of the vehicle and
cause the vehicle to no longer
conform to the operating permit,
impacting the validity of your vehicle
registration.Caution
When transporting the vehicle on
a train or on a recovery vehicle, the
mud flaps might be damaged.
Vehicle storage
Storage for a long period of time
If the vehicle is to be stored for several months:
● Wash and wax the vehicle.
● Have the wax in the engine compartment and underbody
checked.
● Clean and preserve the rubber seals.
● Fill up fuel tank completely.
● Change the engine oil.
● Drain the washer fluid reservoir.
● Check the coolant antifreeze and
corrosion protection.
● Adjust tyre pressure to the value specified for full load.
● Park the vehicle in a dry, wellventilated place. Engage first or
reverse gear or set selector lever
to P. Prevent the vehicle from
rolling.
● Do not apply the parking brake.
● Open the bonnet, close all doors and lock the vehicle.
● Disconnect the clamp from the negative terminal of the vehicle
battery. Beware that all systems
are not functional, e.g. anti-theft
alarm system.
Putting back into operation
When the vehicle is to be put back into
operation:
● Connect the clamp to the negative terminal of the vehicle
battery. Activate the electronics
of the power windows.
● Check tyre pressure.
● Fill up the washer fluid reservoir.
● Check the engine oil level.
● Check the coolant level.

244Vehicle careWasher fluid
Fill with clean water mixed with a
suitable quantity of approved
windscreen washer fluid which
contains antifreeze.
Caution
Only washer fluid with a sufficient
antifreeze concentration provides
protection at low temperatures or
a sudden drop in temperature.
Brakes
In the event of minimum thickness of
the brake lining, a squealing noise
sounds during braking.
Continued driving is possible but
have the brake lining replaced as
soon as possible.
Once new brake linings are installed,
do not brake unnecessarily hard for
the first few journeys.
Brake fluid9 Warning
Brake fluid is poisonous and
corrosive. Avoid contact with eyes, skin, fabrics and painted surfaces.
The brake fluid level must be betweenthe MIN and MAX marks.
If fluid level is below MIN seek the
assistance of a workshop.
Brake and clutch fluid 3 285.
Vehicle battery
The vehicle battery is maintenance-
free, provided that the driving profile
allows sufficient charging of the
battery. Short-distance-driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.

286Service and maintenanceSelect the appropriate engine oil
based on its quality and on the
minimum ambient temperature
3 289.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of the oil.
Multigrade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates the
low temperature viscosity and the
second figure the high temperature viscosity.
Select the appropriate viscosity grade
depending on the minimum ambient
temperature 3 289.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.Coolant and antifreeze
Use only organic acid type-long life
coolant (LLC) antifreeze approved for
the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -28 °C. In
northern countries with very low
temperatures the factory filled coolant provides frost protection down to
approx. -37 °C. This concentration
should be maintained all year round.
The use of additional coolant
additives that intend to give additional
corrosion protection or seal against
minor leaks can cause function
problems. Liability for consequences
resulting from the use of additional coolant additives will be rejected.
Brake and clutch fluidOver time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should therefore be replaced at the specified
interval.Washer fluid
Use only washer fluid approved for
the vehicle to prevent damage of wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
AdBlue
Only use AdBlue to reduce the nitrogen oxides in the exhaust
emission 3 190.

308IndexAAccessories and vehicle modifications .......................... 239
Activating Bluetooth music .........144
Activating phone .........................167
Activating radio ........................... 137
Activating the navigation system 150
Activating USB audio ..................144
Activating USB movie .................147
Activating USB picture ................145
Active Emergency Braking .........216
Active head restraints ...................37
Adaptive cruise control .......101, 206
AdBlue .......................... 99, 190, 285
Adjustable air vents ...................179
Airbag and belt tensioners ...........95
Airbag deactivation ................54, 96
Airbag label................................... 49 Airbag system .............................. 49
Air conditioning regular operation ................................ 180
Air conditioning system .............. 174
Air intake .................................... 180
Air vents...................................... 179
Antilock brake system ................ 196
Antilock brake system (ABS) .......97
Anti-theft alarm system ................26
Anti-theft locking system .............. 26
Appearance care ........................280
Armrest ......................................... 41Armrest storage ........................... 65
Ashtrays ....................................... 88 Audio files ................................... 143
Automatic anti-dazzle ..................30
Automatic light control ...............115
Automatic locking ........................24
Automatic transmission .............192
Autostop ..................................... 185
Auto volume................................ 134
Auxiliary heater ........................... 179
B Basic operation ........................... 131
Battery discharge protection ......123
Battery voltage ........................... 107
BlueInjection ............................... 190
Bluetooth Bluetooth connection ..............164
Bluetooth music menu ............144
Connecting device ..................143
General information ................143
Pairing ..................................... 164
Phone ...................................... 167
Bluetooth connection ..................164
Bonnet ....................................... 240
Brake and clutch fluid .................285
Brake and clutch system .............96
Brake assist ............................... 199
Brake fluid .................................. 244
Brakes ............................... 196, 244

309Breakdown.................................. 278
BringGo ...................................... 148
Bulb replacement ....................... 247
C Call Functions during a call ............167
Incoming call ........................... 167
Initiating a phone call ..............167
Ring tone ................................. 167
Call history .................................. 167
Capacities .................................. 295
Cargo management system ........75
Catalytic converter .....................189
Central locking system ................22
Centre console lighting ..............122
Centre console storage ...............65
Changing tyre and wheel size ...267
Charging system .......................... 96
Child locks ................................... 25
Child restraint installation locations ................................... 59
Child restraints.............................. 56
Child restraint systems ................56
Cigarette lighter ........................... 88
Climate control ............................. 16
Climate control systems .............173
Clock............................................. 86
Code ........................................... 106
Contacts ..................................... 155Control elements
Infotainment system ................126
Steering wheel ........................ 126
Control elements overview .........126
Control indicators.......................... 92
Control of the vehicle .................182
Controls ........................................ 83
Convex shape .............................. 29
Coolant and antifreeze ...............285
Cruise control ....................100, 203
Cupholders .................................. 62
Curtain airbag system .................. 54
Curve lighting.............................. 118
D
DAB ............................................ 141
Danger, Warnings and Cautions ...4
Daytime running lights ...............117
Declaration of conformity ............298
DEF ............................................ 190
Destination input ........................155
Diesel exhaust fluid ....................190
Diesel fuel system bleeding .......246
Digital audio broadcasting ..........141
Displaying pictures .....................145
Display settings ..................145, 147
Door open .................................. 101
Door panel storage .......................64
Doors ............................................ 25
Driver assistance systems ..........203Driver Information Centre ...........101
Driving characteristics and towing tips .............................. 233
Driving hints ................................ 182
E Electric adjustment ......................29
Electrical system......................... 254
Electric parking brake ...........97, 197
Electric parking brake fault ...........97
Electronic climate control system 175
Electronic driving programmes ..194
Electronic Stability Control.......... 200
Electronic Stability Control and Traction Control system ............98
Electronic Stability Control off....... 98
Emergency call ........................... 167
End-of-life vehicle recovery .......240
Engine compartment fuse box ...256
Engine coolant ........................... 242
Engine coolant temperature gauge ....................................... 90
Engine data ............................... 292
Engine exhaust .......................... 188
Engine identification ...................288
Engine oil ................... 241, 285, 289
Engine oil pressure ......................99
Entry lighting .............................. 122
Event data recorders ..................304
Exhaust filter ......................... 99, 188
