PEUGEOT 206 2006 Workshop Manual

51
-Audio equipment and telematics
COMPACT DISC CHANGER
Selecting CD changer mode
Press the "SOURCE" button several times.
Selecting a track
Press button M to select the follow-ing track.
Press button N to return to the start of the current track or to select the previous track.
Press several times in succession to skip several tracks.
Contextual menu
By pressing knob G, the contextual menu permits you to switch the fol-lowing functions on or off:
- playing of the start of the track ("In-troscan"),- random play ("Random"),- programming of the track playing order,- list of tracks.
Selecting a disc
Press one of the buttons "1" to "5"on the audio/telephone to select the appropriate disc.
Accelerated play
Press and hold button M or Noror for forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.Buttons H and I allow you to select respec-tively the previous or following disc in the changer.
Playing of the first track on the disc be-gins automatically.
Following each change of source, on returning to CD changer mode, play will resume where it stopped.

52 -Audio equipment and telematics
TELEPHONE
This function is aGSM dual-band telephone (900 and 1 800 MHz) in-corporated in the RT3 GPS audio/telephone system.
It is a "hands free" telephone. This function is provided by a microphone located next to the front courtesy light, the speakers, a steering column con-trol and voice commands which allow access to most of the functions (the audio/telephone control panel buttons allow access to all the functions).
Display of the principal "mobile" type functions, as well as consulta-tion of the indexes, is provided by the multi-function display.
This function is active, whatever position the ignition key is in even af-ter thirty minutes, when the message"Economy mode active" appears on the multi--function display.
"Telephone and telematic services" menu
Press the MENU button then, using the knob G, select the "Telephone and telematic services" application and confirm to gain access to the fol-lowing options:
- "Call".- "Service", permits access to the PEUGEOT services.- "Telephone functions", permits setting of all of the telephone func-tions.- "Text messages (SMS)", permits management of all of the functions for the text messages (SMS).
Contextual menu
Press button D to display the tele-phone contextual menu.
This menu enables you to gain ac-cess to the following functions:
- "List of calls".- "Enter number".- "Access to directory".- "Access to your voice mail"(message service of your GSM operator).
Note:
Do not allow yourself to become distracted when you are behind the wheel and comply with current na-tional legislation. The driver is advised to stop in order to hold a telephone conversation or carry out certain ac-tions (manual dialling of a number, for example).

53
-Audio equipment and telematics
Within each menu:
Move around and se-lect a function by turn-ing the G button then validate by pressing the button.
Using the alphanumeric keypad
For a given button, to input a charac-ter in the second or subsequent rows press until you obtain the character required.
Buttons Associated characters
[1] 1 or[1][1]space
[2] 2 or A B C 2 or a b c 2[2][2]
[3] 3 or D E F 3 or d e f 3[3][3]
[4] 4 or G H I 4 or g h i 4[4][4]
[5] 5 or J K L 5 or j k l 5[5][5]
[6] 6 or M N O 6 or m n o 6[6][6]
[7] 7 or P Q R S 7 or p q r s 7[7][7]
[8] 8 or T U V 8 or t u v 8[8][8]
[9] 9 or W X Y Z 9 or w x y z 9[9][9]
[0] 0 or + (long[0][0]press)
[#] # or validation[#][#]
[*] * or erasing of last character [*][*]input (long press)
Cancel an operation using the "ESC"button.
Using the menus, example "Telephone functions"
Press the "MENU" button to display thegeneral menu. Select the "Telephone and telematic services" application, validate "Telephone functions" to ac-cess the principal telephone functions, then the various menus, in order to reach the one required.
This menu allows you to access the following functions:
- "Network": allows you to select the network search mode and to see the networks available.- "Duration of calls": allows you to consult the duration recorder of calls made and zero re-set.- "Process the PIN code": allows you to use or modify the PIN code.- "Call options": allows you to con-figure the calls with entering of my number, automatic answering after X rings, specification of ring options and allows you to configure the di-version number for the text mes-sages and clear the list of calls and the text messages.

54 -Audio equipment and telematics
Installing the SIM card
Open flapL by pressing the point of a pencil on the circular opening above the flap.
Insert your SIM card, available from a mobile telephone operator, as indi-cated in the graphics, then close the flap.
Note: removal or insertion of the SIM card must only be carried out after the RT3 audio/telephone has been switched off (key in position S (igni-tion switch) and screen off).
If you have a duplicate card, when carrying out the first installation or to update your directory you must insert your mobile telephone’s SIM card then transfer its information to the RT3 audio/telephone directory - refer to the Directory main menu.
Input your PIN code using the al-phanumeric keypad and validate by pressing buttonG or button # to ac-cess the network. Connection to the network is validated by the appear-ance of a symbol on the screen.
Warning: if you make three errors in succession when inputting your PIN code, your SIM card will be blocked. To unblock it, you will need to input the PUK code. The PUK code will be supplied to you by the person selling your SIM card (input of the PUK code allows for 10 errors in succession;after this the SIM card becomes per-manently unusable).
Note: the PIN code is required each time the ignition is switched on, un-less the PIN code has been stored in the memory or protection by PIN code is not activated on the SIM card.
Inputting the PIN codeCancelling of PIN code request
In the menu "Telephone functions" select "Process the PIN code", then validate the "Cancel" function.
Warning: in this case, do not lose your SIM card. Losing it would mean anyone who finds it would be able to make unlimited calls.

55
-Audio equipment and telematics
Telephone function screens
Not in use
This screen indicates the presence of voice messages or text messages (SMS) not listened to/read, the cumu-lative time in use since the last zeroreset and the status of your telephone.
In use
This screen indicates the time elapsed since the start of the con-versation, as well as the number* or name of the person to whom you are speaking (if recorded in the index) and the status of your telephone.
* If this option and service are available.
Making a call
Press buttonD to display the contex-tual menu of the telephone.
Entering a number
Select the function "Call" then "Enter number"then enter the number of the person you wish to speak to using the alpha-numeric keypad.
Press button D to make the call.
Making a call from a directory
Select the "Call" function then "Directory" to access all the files containing a telephone number or the "List of calls" function to access the list of the last twenty incoming (if the number display option is active) or outgoing calls.
Note: there are two directories, the RT3 audio/telephone directory and the SIM card directory.
Receiving a call
When a ringing sounds to let you know that a call is waiting, you can choose either to accept it by pressing button D or the end of the steering wheel remote control or not to accept it by pressing the button Q or by selecting and validating the "NO" button on the "Answer?" screen.
If you accept the call, to end your communication, press button Q.
If you do not accept the call, it is transferred to your voice mail or to a call diversion number.

56 -Audio equipment and telematics
Text messages (SMS)
Receiving text messages
When the buzzer sounds (if the SMS text messages buzzer option is active) and a superimposed screen announc-es "Do you wish to read the new text message (SMS)?", you can choose to read the text message received by selecting and validating "YES" or post-pone reading it by selecting and vali-dating "NO", by pressing the "ESC"button or by waiting until the announce-ment disappears. The message is read by the voice synthesiser, if it is active.
Note: the old text messages stored and the new text messages, the read-ing of which you wished to postpone, can be consulted. Press the "MENU"button then validate the "Telematic" icon, select "Textmessages (SMS)"and validate the function "Reading of SMS received" by pressing button G. Then scroll through the list by turning the button and press the button to se-lect the text message to be read (if the voice synthesiser is active).
Sending a text message
In the menu "Text messages (SMS)"validate the function "Typing of an SMS". Type your text message using the alphanumeric keypad and vali-date it using the "OK" button to store it or validate the "Send" button to send it. Validation of the "Send" but-ton enables you to enter the number of your recipient or select it from the directory or from the list of calls and send the message.
"Duration of calls" menu
Select the "Duration of calls" function from the "Telephone functions"menu to consult the duration counters for the calls made. The partial counter totals the duration of the calls since the last zero reset carried out using the "Zero reset" button.
"Telephone options" menu
Select the "Call options" function from the "Telephone functions" menu to access the functions:
- "Configure the calls" which per-mits activation and deactivation of the "show my number" and "auto-matic answering after X rings" func-tions- "Ringing options" which permits adjustment of the ringing volume for voice calls, activation of the text messages (SMS) receipt buzzer and selection of a ring tone from the five offered- "Voice call diversion number"which permits recording of the call diversion number chosen by the customer, otherwise the call will be transferred to the voice mail if the call diversion box is ticked.
Replying to a text message
After reading a text message, you can:
Reply directly to the sender by se-lecting "Reply". A screen appears automatically to enable you to enter your message.
Record the number of the sender of the text message in your current di-rectory by selecting "Record".

57
-Audio equipment and telematics
Services*
Press button E to dis-play the "Services"menu and select one of the following services:
Emergency call*
In an emergency, press but-ton V until a signal is heard and a call validation/deletion screen is displayed (delay of 6 seconds) or enter 112 di-rectly.
Make an emergency call if you are involved in a situa-tion which leads you to fear serious consequences (injuries, ...) for those who are exposed to it (if you witness or are involved in an accident result-ing in injuries, an attack, ...).
Before making a call of this kind, the audio/telephone must detect a cellu-lar network.
If you have not signed the specific PEUGEOT contract, the parameters of the SOS button are set so that a call is made to 112 - unique number made available by the worldwide GSM net-work, reserved for emergency calls.
No security mode is required and, depending on the network or country, you do not need to insert your SIM card or enter your PIN.
If you have signed the specific PEUGEOT contract, your call will be located and you will be put in contact with a PEUGEOT assistance team.
For further details, refer to the gen-eral conditions of your contract.
"PEUGEOT Assistance"/Emergency call
During a connection to "PEUGEOT Assistance" or an emergency call, it is not possible to send or receive calls or SMS text messages; these will be transferred to your voice mail.
In this case, a green diode flashes on the RT3 GPS audio/telephone panel, when the emergency call or "PEUGEOT Assistance" call pro-cedure begins, then lights continu-ously when the call is taken by the services concerned.
* If option and service available.
"Customer Contact Centre" which enables you to contact the PEUGEOT Customer Contact Centre directly and access the services offered (this type of call is suspended if an emer-gency or breakown call is made).
"PEUGEOT Assistance" which en-ables you to contact the call centre which controls the PEUGEOT break-down service directly and receive rapid assistance (you have 6 seconds within which to cancel the call when it is made). During the breakdown call phase it is not possible to make any other calls with the exception of emer-gency calls. If you have signed the specific PEUGEOT contract, your call will be located.
"Operator services" which gives access to the list of services spe-cific to your operator (e.g.: customer service, consumption monitoring, news, stock market, weather, travel, games, etc) if they are available.

58 -Audio equipment and telematics
The Directory
General
The directory can contain up to 396 files divided into 4 independent sub-directories ("User 1", "User 2", "User 3" and "User 4").
When the system is delivered, the default current directory is "User 4".
A file can contain:
- an address,- 5 telephone numbers,- 5 e-mails,- a note,- a voice description which can be used for a voice command.The address is entered by indicating the town and the street.
Note: if you enter the address in the absence of the navigation CD ROM, you will not be able to use this ad-dress for navigation.
To modify an existing file, select it us-ing the "Consult or modify a file"function of the "Management of di-rectory files" menu then make the modifications.
Note: when the address is entered, the navigation CD-Rom must be present in order to obtain guidance to this destination.
"Directory" menu
Press the MENU button then, using the knob G, select the "Directory"application and confirm to gain ac-cess to the following options:
- "Management of directory files"with:• "Consult or modify a file".• "Add a file", enter the descrip-tion of the new file then select on the file the section to be com-pleted then confirm and enter the information.• "Delete a file".• "Delete all files" in a directory.- "Directory configuration" with:• "Select a directory".• "Name a directory".• "Select the starting directory"(current directory).- "File transfer", with:• "Exchange by infrared" of the files to portable equipment and vice versa.• "Exchange with the SIM card"of the information entered in the RT3 GPS audio/telephone.
"Consult or modify a file"

59
-Audio equipment and telematics
Description of a directory file
When a description is linked to a di-rectory file, you can record the de-scription vocally so that it can be used subsequently for direct access by voice commands (e.g.: "Call""[Name of the voice description]"or "Guide to" "[Name of the voice description]").
Select "Consult or modify the file" from the "Management of directory files" menu to access the screen which permits entering and recording of the description.
TMC (Traffic Message Channel) RDS Traffic Information
You can access information regard-ing the traffic conditions from the "Navigation - Traffic Info" menu, then from the "TMC Traffic Informa-tion" function (see section "Satellite navigation system").
"File transfer"
Press the record button and follow the instructions.
Send all of the files to the SIM card from the current directory of your RT3 GPS audio/telephone.
Send one file to the SIM card from the current directory of your RT3 GPS audio/telephone.
Receive all of the files from the SIM card in the current directory of the RT3 GPS audio/telephone.
Receive one file from the SIM card in the current directory of the RT3 GPS audio/telephone.
Reminder: when transferring a file from the RT3 GPS audio/telephone to the SIM card, only the first number entered in the file is recorded.
Note: The SIM card represents an independent collection of information among which the telephone numbers may be accessible by consulting the current directory.
To "Exchange by infrared" between the RT3 GPS audio/telephone and portable equipment (which has an infrared port) all or some of the files recorded in the current directory.
Following selection of the "File transfer" menu and of the direction of this transfer, you must initiate the exchange by presenting at the same time opposite the infrared port, the portable equipment on which you started the transfer (consult the in-structions provided with this equip-ment). A message confirms that the exchange is progressing correctly.
To "Exchange with the SIM card":

60 -Audio equipment and telematics
VOICE COMMANDS
The voice commands make it pos-sible to use pre-recorded words or phrases to control a certain number of functions of the RT3 GPS audio/telephone.
They are organised in three levels (levels 1, 2 and 3).
When you say a level 1 command, the system makes the level 2 com-mands available; when you say a level 2 command, the system makes the level 3 commands available.
Pressing the "MENU" button for more than 2 seconds permits access to the "list of voice commands".
Activation of the voice commands
Press the button on the end of the lights stalk to activate or deactivate this function.
Activation of the function is con-firmed by a bleep and the opening of a window on the screen. The system is then listening.
Example: to recall the radio station stored on button 3, the key words are: "Radio" "Memory" "3".
To use these key words, you must say the word "Radio", wait for the audible confirmation signal, then say the word "Memory", wait for the au-dible confirmation signal, then end with the word "3", wait for the audible confirmation signal which will carry out the action requested.
Saying the phrase "Help" or "What can I say" displays all of the com-mands available on the screen.
Saying the word "Cancel" cancels all of the voice commands.
Miscellaneous words: STOP/DELETE/YES/NO/PREVIOUS/NEXT
Notes:
- between two key words, a screen indicates the time remaining and the key word recognised,- in the absence of any voice com-mands, this function will be switched off after approximately five seconds,- if a command is not understood, the system transmits "Pardon" and displays "Word not recognised"on the screen.
