7
YOUR AT A GLANCE
STARTING The four positions of the key in the ignition:
STOP position:
the ignition is off.
1st notch, Accessories position:
the ignition is off but the acces-sories can be used. 2nd notch, Running position: the ignition is on. Starting position:
operates the starter. Steering lock Before starting, unlock the steer-
ing if necessary, by gently tur-ning the steering wheel at the
same time as you turn the key. It is advisable to press the clutch pedal while operating the starter
to make starting easier. Starting the engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until the engineturns.
THE KEYS The keys operate independently the locks for the doors, the boot(opening), the fuel filler flap, thesteering lock, the glove box andthe passenger air bag disarmingswitch. Central locking
From the driverÕs door, the keys allow you to:
Ð simultaneously lock the doors
and the boot,
Ð simultaneously unlock just the doors.
You can only unlock the boot by using the lock. The remote control Pressing button A
allows you to lock the doors and boot. This is displayed by the continuous light-ing of the direction
indicators forapproximately twoseconds. Pressing button B
allows you to unlock the doors
only. This is indicated by the quick flashing of the direc-tion indicators for approxi-mately two seconds.
Never race a coldengine.
Never run the engine in anenclosed space. Do not make any modications to the steering lock.
07-10-200269

INSTRUMENTS AND CONTROLS29
Front and side air bags warning light The warning light comes on
for a few seconds when the ignition is switched on. Switching on of this warning light, with the engine running, is accompanied byan audible signal and a message onthe multifunction display indicating afault in the air bags.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light* When the ignition is switched
on, the warning light comes on when the driver has not fastened his seat belt. Engine autodiagnostics warning light This comes on each time the
ignition is switched on. If it comes on when the engine is run-ning, it indicates a malfunction in theinjection, ignition or emission control
system. There is a risk of damage to
your catalytic converter.
Contact a PEUGEOT dealer rapidly.
Low fuel level warning light When the warning light first
comes on, you have enough fuel to drive at least 35 miles (50 km) (the tank capac-
ity is approximately 47 litres (10.3 gal-lons)).
Coolant temperature indicator light
Ð When the needle is in zone (A), the
temperature is correct.
Ð When the needle is in zone ( B), the
temperature is too high. The central
STOP warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Dynamic stability control (ESP/ASR) warning light This comes on for a few seconds each time the igni-
tion is switched on. If the warning light remains on or comes on with the engine running, it isaccompanied by an audible signal andthe message "ESP/ASR not opera-
tional" on the multifunction display;
contact a PEUGEOT dealer. With the engine running and the vehi- cle moving, it flashes when the systemcomes into operation (if there is a dif-ference between the trajectory fol-lowed by the vehicle and that desiredby the driver). It comes on permanently when the system is disarmed.
* According to destination.
Passenger air bag disarming indicatorlight*
Switching on of this indicator light is accompanied by an audible signal andthe message "Passenger air bag
disarmed" on the multifunction dis-
play. If the passenger air bag is disarmed, the indicator light switches on andremains on. In all cases, if the warning light flashes,
contact a PEUGEOT dealer.
Battery charge warning light This can indicate any of the
following situations:
Ð faulty operation of the charging circuit,
Ð loose battery or starter terminals, Ð a cut or slack alternator belt,Ð an alternator fault.
Contact a PEUGEOT dealer.
07-10-2002

INSTRUMENTS AND CONTROLS29
Front and side air bags warning light The warning light comes on
for a few seconds when the ignition is switched on. Switching on of this warning light, with the engine running, is accompanied byan audible signal and a message onthe multifunction display indicating afault in the air bags.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light* When the ignition is switched
on, the warning light comes on when the driver has not fastened his seat belt. Engine autodiagnostics warning light This comes on each time the
ignition is switched on. If it comes on when the engine is run-ning, it indicates a malfunction in theinjection, ignition or emission control
system. There is a risk of damage to
your catalytic converter.
Contact a PEUGEOT dealer rapidly.
Low fuel level warning light When the warning light first
comes on, you have enough fuel to drive at least 35 miles (50 km) (the tank capac-
ity is approximately 47 litres (10.3 gal-lons)).
Coolant temperature indicator light
Ð When the needle is in zone (A), the
temperature is correct.
Ð When the needle is in zone ( B), the
temperature is too high. The central
STOP warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Dynamic stability control (ESP/ASR) warning light This comes on for a few seconds each time the igni-
tion is switched on. If the warning light remains on or comes on with the engine running, it isaccompanied by an audible signal andthe message "ESP/ASR not opera-
tional" on the multifunction display;
contact a PEUGEOT dealer. With the engine running and the vehi- cle moving, it flashes when the systemcomes into operation (if there is a dif-ference between the trajectory fol-lowed by the vehicle and that desiredby the driver). It comes on permanently when the system is disarmed.
* According to destination.
Passenger air bag disarming indicatorlight*
Switching on of this indicator light is accompanied by an audible signal andthe message "Passenger air bag
disarmed" on the multifunction dis-
play. If the passenger air bag is disarmed, the indicator light switches on andremains on. In all cases, if the warning light flashes,
contact a PEUGEOT dealer.
Battery charge warning light This can indicate any of the
following situations:
Ð faulty operation of the charging circuit,
Ð loose battery or starter terminals, Ð a cut or slack alternator belt,Ð an alternator fault.
Contact a PEUGEOT dealer.
07-10-2002

07-10-2002
YOUR 206 CC IN DETAIL
42
COMPACT DISC Selecting CD mode After insertion of a disc, printed face upwards, the player starts automatically. If a disc is already inserted, press button N.
Ejection of a disc Press button Dto eject the disc from the player.
Selecting a track Press button Jto select the next track.
Press button Lto return to the start of the current track or to select the previous track.
Accelerated play Keep button Jor Lpressed for forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released. Shuffle When the CD player is selected, keep button Npressed for two seconds. The tracks will be played in random sequence.
Pressing the button again for two seconds returns you to normal play.
Shuffle mode is de-activated each time the audio is switched off.
The use of copied compact discs may cause malfunctions.
Insert circular compact discs only.

07-10-2002
YOUR 206 CC IN DETAIL43
CD CHANGER* Selecting CD changer mode Press button M.
Selecting a disc Press one of the buttons "1"to "6" on the radio to select the corresponding disc.
Selecting a track Press button Jto select the next track.
Press button Lto return to the start of the current track or to select the previous track.
Accelerated playKeep button Jor Lpressed for forwards or backwards accelerated play. Accelerated play stops as soon as the button is released.
ShuffleWhen the CD changer is selected, keep button Mpressed down for two seconds.
The tracks will be played in random sequence. Pressing the button again for two seconds returns you to normal play.
* Available as an accessory.
The use of copied compact discs may cause malfunctions.
Insert circular compact discs only.

07-10-2002
YOUR 206 CC IN DETAIL57
Windscreen ,side windows
and footwells. Footwells.
These settings are recommended for cold climates. Centre and side vents.
This setting is recommended for hotclimates.
3. Air flow adjustment Turn the control from position 1to position 4to give a suffi-
cient air flow for comfort. 4. Air intake control
Outside air intake.
This is the position for normal use.
Recirculation of interior air.
This position prevents the entry ofunpleasant odours and fumes from theoutside and increases the speed ofheating.
As soon as possible, place the control inthe outside air position, otherwise thereis a risk of the windows misting up.
5. De-icing the rear screen and the mirrors
With the engine running, pressing the button de-ices therear screen and the mirrors.
It switches off automatically afterapproximately twelve minutes. Pressing the button again starts it again for twelve minutes.
It is possible to stop the de-icing opera-tion by pressing the button before thetwelve minutes have elapsed.
Note: this function is disarmed when
the roof is stored in the boot.

07-10-2002
YOUR 206 CC IN DETAIL
76
AUTOMATIC SWITCHING ON OF LIGHTS Side lights and dipped beam head- lamps switch on automatically if thelight is poor and when the windscreen
wipers operate continuously.
They switch off when the light becomes bright enough or the wind-screen wipers stop. Note:
In foggy weather or in snow, the
brightness sensor can detect sufficient
light. As a consequence, the lights will
not come on automatically. This function is active when the vehi-
cle is supplied to the customer. To dis-arm or activate the function:
Ð Start with the key in the accessories
position (1st notch),
Ð Press the end of the stalk for more than four seconds.
Note: after the ignition is switched off
and depending on the brightness, the lights remain on for 45 seconds or untilthe vehicle is locked.
The brightness sensor, coupled with
the rain sensor, is located in the centre
of the windscreen, behind the interior
mirror. It is used for automatic switch-ing on of the lights. Operating check Activation Acivation of this function is accompanied by an audible signal and the message"Automatic lighting active''
on the mul-
tifunction display. Disarming Disarming of the function is accompa- nied by an audible signal. Note: the function is temporarily dis-
armed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come on).The driver is alerted by an audible sig-nal, accompanied by the message
"Automatic switching on of lightsfaulty" .
Contact a PEUGEOT dealer to have thesystem checked.

07-10-2002
YOUR 206 CC IN DETAIL77
Windscreen and headlamp wash
Pull the wiper stalk towards you. The windscreen wash, then the wind-screen wipers, operate for a specifiedtime. The windscreen and the headlamp
wash operate simultaneously for twoseconds,
only if the dipped beam
lights or the headlamps areswitched on.
Operation In position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, then resumesits initial speed when the vehicle startsagain. In the Intermittent position, the wiping
speed is proportional to the speed of the vehicle.
In the AUTO position, the wiping
speed is proportional to the heaviness of the rain fall.
When the ignition has been switched off for more than oneminute with the stalk in the wipeposition, it is necesary to reactivatethis function. To do this, move the
stalk to any position, then move it backto the required position.
WINDSCREEN WIPER
STALK Stalk with intermittent wipe Front windscreen wiper
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.
Single wipe (press down- wards). Stalk with automatic wipe Front windscreen wiper
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
Single wipe (press down- wards).

07-10-2002
PRACTICAL INFORMATION109
BATTERY
To charge the battery using a battery charger:
Ð Disconnect the battery,
Ð Follow the instructions for use given by the battery charger manufacturer,
Ð Reconnect starting with the negative (Ð) terminal,
Ð Check that the terminals and connectors are clean. If they are covered with sul-
phate (white or greenish deposit), disconnect them and clean them.
To start the vehicle from another battery:
Ð Connect the red cable to the positive (+) terminals of the two batteries,
Ð Connect one end of the green or black cable to the negative (Ð) terminal of the slave battery,
Ð Connect the other end of the green or black cable to an earth point on the bro- ken down vehicle as far as possible from the battery,
Operate the starter, let the engine run.
Wait for the engine to return to idle, then disconnect the cables. ECONOMY MODE FUNCTION After the engine has stopped, with the key in the accessories position, cer-
tain functions (windscreen wiper, elec-tric windows, courtesy lights, audioequipment etc.) can only be used forthirty minutes, to prevent discharging
the battery.
Once the thirty minutes are over, the message
"Economy mode active"
appears on the multifunction displayand the active functions are put on
standby.
A flat battery will prevent the engine from starting.
Ð Never disconnect a terminal when the engine is running.
Ð Never charge a battery without first disconnecting the terminals.
Ð After every reconnection of the battery, switch on the ignition and wait
1 minute before starting to allow the electronic systems to be ini- tialised. If slight difficulties are experienced after this, please contact
a PEUGEOT dealer.
It is advisable to disconnect the battery if the vehicle is not
to be used for a period of more than one month.
