Peugeot 206 Dag 2004.5 Owner's Guide

30 -
31-01-2005
31
-
31-01-2005
Button Function
A Radio on/off.
B - Decrease volume.
C + Increase volume.
D RDS RDS function on/off.
Press for more than 2 seconds: regional following mode on/off.
E TA Trafic information priority on/off.
F Press fully: cassette rewind.
G Press fully: fast forward.
F + G 3478Press half way: reversal of direction of play of the cassette.
Press fully: ejection of the cassette.
H ¯Selection of bass, treble, loudness, sound distribution and a
utomatic volume correction.
I 5Increase setting of functions associated with button
H.
J 6Decrease setting of functions associated with button
H.
K SRC Selection of source: radio, cassette or CD changer.
Press for more than 2 seconds: CD shufle.
L 8Manual and automatic search of higher frequency.
Selection of next CD track and PTY (radio).
M MAN Manual/automatic operation of buttons L and N in radio mode.
N 7Manual and automatic search of lower frequency.
Selection of previous CD track and PTY (radio).
O BND
AST Selection of FM1, FM2, FMast and AM wavebands.
Press for more than 2 seconds: automatic storing of stations in the
memory (autostore).
1 to 6 1 2 3 4 5 6 Selection of station stored in the memory.
Press for more than 2 seconds: storing of a station in the memory.
1 to 5 1 2 3 4 5 Selection of a CD changer disc.
Audio equipment and telematics

34 -
31-01-2005
35
-
31-01-2005
GENERAL FUNCTIONS
AUDIO SETTINGS
Adjusting the loudness
This function automatically empha-
sises bass and treble tones. Press
button I or J to switch the function
on or off.
On/off
With the ignition key
in the accessories or
ignition position, press
button
A to switch the
set on or off.
The set can operate for 30 minutes
without the vehicle ignition being
switched on.
Anti-theft system
The audio system is coded in such a
way that it can operate only on your
vehicle. It would not function if itted
to another vehicle.
The anti-theft system is automatic
and requires no action on your
part.ADJUSTING THE VOLUME
Press button C to increase the volume,
or button B to decrease it.
Continuous pressure on buttons C
and B allows a gradual adjustment
of the volume. Adjusting the bass
Adjusting the treble
When
"TREB" is displayed, press
button I or J to vary the setting.
- "TREB -9" for a minimum treble
setting,
- "TREB 0" for a normal setting,
- "TREB +9" for a maximum treble
setting.
Press button
H sev-
eral times in succes-
sion to access the
bass (BASS) , treble
(TREB) , loudness
(LOUD) , fader (FAD) ,
balance ( BAL) and
automatic volu me cor-
rection settings.
Exit from audio mode is automatic
after a few seconds without pressing
any button, or by pressing button H
after coniguration of the automatic
volume correction.
Note: bass, treble and loudness set-
tings are speciic to each source. It
is possible to set them differently for
radio, cassette (RB3), CD (RD3) and
CD changer. When "
BASS" is dis-
played, press button
I or J to vary the set-
ting.
-
"BASS -9" for a
minimum bass setting,
- "BASS 0" for a
normal setting,
- "BASS +9" for a maximum bass
setting.
Audio equipment and telematics

34 -
31-01-2005
35
-
31-01-2005
RADIO
Notes on radio reception
Your car radio is subject to phenom-
ena which do not affect domestic
radio sets. Both AM (MW/LW) and
FM reception are subject to various
forms of interference. This is no re-
lection on the quality of the equip-
ment, but is due to the nature of the
signals and the way in which they are
transmitted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the result
of increasing distance from the trans-
mitter, delection of the signals by
obstacles (mountains, hills, buildings,
etc.), or of being in an area which is
not covered by a transmitter. Selecting radio mode
Selecting a waveband
Adjusting the front/rear sound
distribution (Fader)
When
"FAD" is displayed, press but-
ton I or J.
Button I increases the volume in the
front.
Button J increases the volume in the
rear.
Adjusting the right/left sound
distribution (Balance)
When "BAL" is displayed, press but-
ton I or J.
Button I increases the volume on the
right-hand side.
Button J increases the volume on the
left-hand side.
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons I or J to switch the
function on or off. Audio RB3:
press the
"SRC" button several
times in succession.
Audio RD3: press
button R.
Audio RB3: briely
press the "BND/AST"
button to select the
FM1, FM2, FM ast and AM wavebands.
Audio RD3: briely
press button R to select
the FM1, FM2 FMast
and AM wavebands.
Audio equipment and telematics

34 -
31-01-2005
35
-
31-01-2005
RADIO
Notes on radio reception
Your car radio is subject to phenom-
ena which do not affect domestic
radio sets. Both AM (MW/LW) and
FM reception are subject to various
forms of interference. This is no re-
lection on the quality of the equip-
ment, but is due to the nature of the
signals and the way in which they are
transmitted.
On MW/LW, interference may be
noticed when passing under high
voltage power lines or bridges, or in
tunnels.
On FM, interference may be the result
of increasing distance from the trans-
mitter, delection of the signals by
obstacles (mountains, hills, buildings,
etc.), or of being in an area which is
not covered by a transmitter. Selecting radio mode
Selecting a waveband
Adjusting the front/rear sound
distribution (Fader)
When
"FAD" is displayed, press but-
ton I or J.
Button I increases the volume in the
front.
Button J increases the volume in the
rear.
Adjusting the right/left sound
distribution (Balance)
When "BAL" is displayed, press but-
ton I or J.
Button I increases the volume on the
right-hand side.
Button J increases the volume on the
left-hand side.
Automatic volume correction
This function enables the volume to
be automatically adjusted depending
on the level of noise produced by the
speed of the vehicle.
Press buttons I or J to switch the
function on or off. Audio RB3:
press the
"SRC" button several
times in succession.
Audio RD3: press
button R.
Audio RB3: briely
press the "BND/AST"
button to select the
FM1, FM2, FM ast and AM wavebands.
Audio RD3: briely
press button R to select
the FM1, FM2 FMast
and AM wavebands.
Audio equipment and telematics

36 -
31-01-2005
37
-
31-01-2005
Manual station search
Press the "MAN" button.
Briely press button L or N to in-
crease or decrease the frequency
displayed.
By continuing to press the button
in the direction selected, you will
obtain continuous scrolling of the
frequency.
The scrolling stops as soon as the
button is released.
Pressing the "MAN" button again
returns you to automatic station
search. Automatic storing of FM stations
in the memory (autostore)
Your radio automatically stores the 6
stations with the strongest signal in
FM
. These stations are stored in the
FMast waveband.
If it is not possible to ind 6 stations,
the remaining memories are empty.
Automatic station search
Manual storing of stations in the
memory
Select the station required.
Press one of the buttons "1" to "6"
for more than two seconds.
The sound stops then becomes audi-
ble again, conirming that the station
has been stored in the memory. Audio RB3:
press
and hold the "BND/
AST" button for more
than two seconds.
Audio RD3: press and
hold button R for more
than two seconds.
Recalling stations stored in the
memory
For each waveband, briely press
buttons "1" to "6" to recall the cor-
responding station.
Briely press button
L or N to search
for the station immediately above or
below. By continuing to press the
button in the direction selected, you
will obtain continuous scrolling of the
frequency.
The scrolling stops at the irst sta-
tion found as soon as the button is
released.
If the TA trafic program is selected,
only stations broadcasting this type
of program are selected.
Searching for a station occurs irst in
"LO" sensitivity (selection of the most
powerful transmitters) during scan-
ning of the waveband, then in "DX"
sensitivity (selection of the weakest
and most distant transmitters).
To make a direct search in "DX" sen-
sitivity, press button L or N twice.
Audio equipment and telematics

36 -
31-01-2005
37
-
31-01-2005
RDS
Using the RDS (Radio Data
System) function on FM
Radio Data System allows you to
continue listening to the same sta-
tion, whatever frequency it is using
for the region you are going through. Trafic information program Regional following mode
When they are part of a network,
certain stations broadcast regional
programs in the various areas they
serve. With regional following mode
you can keep listening to the same
program.
Press the "RDS" button for more
than two seconds to switch the func-
tion on or off.
RDS station following
The display indicates the name of the
station selected. The radio is contin-
ually searching for the station which
has the best reception and which is
transmitting the same program. Press the
"TA" button
to switch the function
on or off.
The multi-function dis-
play will show:
- "TA" if the function is selected,
- "(TA)" if the function is selected but
not available.
Any trafic information lash will be
given priority, whatever source you
are listening to (radio, cassette or
CD changer).
If you wish to interrupt a message,
press the "TA" button; this switches
the function off.
Note: the volume of trafic infor-
mation announcements is inde-
pendent of the volume of normal
radio listening. You can adjust
it using the volume button. The
setting will be stored and will be
used when the next messages are
broadcast.
Briely press the
"RDS"
button to switch the
function on or off.
The multi-function display will show:
- "RDS" if the function is selected.
- "(RDS)" if the function is selected
but not available.
Audio equipment and telematics

38 -
31-01-2005
39
-
31-01-2005
EON system: Audio RD3
This connects stations which are part
of the same network. It enables the
broadcast of trafic information or a
PTY program, by a station that is part
of the same network as the station to
which you are listening.
This service is available when you
have selected the TA trafic informa-
tion program or the PTY function.
PTY function: Audio RD3
This allows you to listen to stations
broadcasting a speciic type of pro-
gram (news, culture, sport, rock,
etc.).
To search for a
PTY program:
With FM selected,
press the "TA" but-
ton for two seconds to
switch this function on
or off. - select the
PTY function,
- briely press button L or N to scroll
down the list of the various types of
programs offered.
- when the program of your choice is displayed, keep button L or N
pressed for two seconds to carry
out an automatic search (after an
automatic search the PTY function
is switched off).
In PTY mode the different types of
programs can be stored in the mem-
ory. To do this, press the preselection
buttons "1" to "6" for two seconds.
Briely press the corresponding but-
ton to recall the type of program
stored in the memory.
Audio equipment and telematics

38 -
31-01-2005
39
-
31-01-2005
CASSETTE:
AUDIO RB3
Selecting cassette mode
Fast forward/rewind
Fully press button F or G to fast for-
ward or rewind the cassette. At the
end of the fast forward/rewind, the
set plays the current side. Recommendations for using
casssettes
- Use good quality cassettes.
- Avoid the use of cassettes which
play for longer than 90 minutes.
- Never expose the cassettes to heat or the direct rays of the sun.
- Re-tighten the tape if necessary before inserting the cassette into
the player.
- Clean the playing head regularly with a damp-type cleaning cassette.
When a cassette is
inserted, the cassette
player will start auto-
matically.
If a cassette is already
inserted, press the "SRC" button un-
til cassette mode is selected.
Note: before inserting the cassette,
ensure that the tape is taut.
Ejecting the cassette Direction of play
The player will play sides 1 and 2 of
the cassette alternately, by automati-
cally reversing the direction of play at
the end of a side.
To manually reverse the direction of
play, press buttons
F and G half-way.
Fully press buttons
F and G to eject the
cassette from the
player.
Audio equipment and telematics

40 -
31-01-2005
41
-
31-01-2005
Selecting a track
Shufle (RDM)
When the CD changer is selected:
- audio RB3: press and hold the
"SRC" button for two seconds;
- audio RD3: press and hold button
P for two seconds.
The tracks will be played in random
sequence. Pressing the button again
for two seconds returns you to nor-
mal play.
CD CHANGER
Selecting CD changer mode
Audio RB3: press the
"SRC" button several
times in succession.
Audio RD3: press
button P. Selecting a disc
Press buttons
"1" to "5" on the radio
to select the corresponding disc. Accelerated play
Press and hold button
L or N for
forwards or backwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Press button L to select the next
track.
Press button N to return to the start
of the current track or to select the
previous track.
The use of copied compact
discs may cause faults.
Insert circular compact
discs only.
Audio equipment and telematics

32 -
31-01-2005
33
-
31-01-2005
AUDIO RD3
Stalk movement Function
1 - Press (behind) Increase volume.
2 - Press (behind) Decrease volume.
1 + 2 - Simultaneous press Sound cut-off (mute); restoring of the sound b y pressing any button.
3 - Press Automatic search of higher frequencies (radio) -
Selection of the next track (CD).
4 - Press Automatic search of lower frequencies (radio) -
Selection of the previous track (CD).
5 - Press the end Change of source (radio/CD/CD changer).
6 - Rotation
(clockwise) Selection of next station stored in the memory (radio) -
Selection of following CD.
7 - Rotation
(anti-clockwise) Selection of previous station stored in the memory (radio) -
Selection of previous CD.
Audio equipment and telematics
