PEUGEOT 206 SW 2005 Owners Manual

Accesses106 -
01-10-2005
107Accesses-
01-10-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must
reverse the movement of the
roof. To do this, press the control
concerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that
passengers use the sunroof
correctly.
Be aware of children when
operating the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.

Accesses106 -
01-10-2005
107Accesses-
01-10-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must
reverse the movement of the
roof. To do this, press the control
concerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that
passengers use the sunroof
correctly.
Be aware of children when
operating the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.

Visibility108 -
01-10-2005
109Visibility-
01-10-2005
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped/Main beam change
Pull the stalk towards you.
Note:
with the ignition off and the
automatic lighting function switched
off, when the driver's door is opened,
a buzzer sounds if you have left your
lights on. Vehicles itted with front fog lamps
and a rear fog lamp (ring C)
Side lights Dipped/Main beam
headlampsAutomatic switching
on of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring
backwards twice in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manually,
the front fog lamps, the rear fog lamp
and the side lights remain on (turn
the ring backwards to switch off the
front fog lamps. The side lights then
switch off).
Vehicles itted with a rear fog lamp
(ring B)
This only operates with the dipped/
main beam headlamps.
Note: when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps remain
on (turn the ring backwards to switch
off the rear fog lamp. The dipped
headlamps and side lights then
switch off). The front fog lamps operate with
the side lights and the dipped
headlamps.
When the main beam headlamps
are switched on, the front fog lamps
are switched off. They are switched
on again when the main beam
headlamps are switched off.
Lights off
Front fog lamps and rear fog
lamp
Rotate the ring forwards to switch
on and backwards to switch off. The
status is conirmed by the indicator
light on the instrument panel.

Visibility108 -
01-10-2005
109Visibility-
01-10-2005
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
position,
- place the lights stalk in the 0
position,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automatically
if the light is poor and when
the windscreen wipers operate
continuously and switch off when the
light becomes bright enough or the
windscreen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the
vehicle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness
sensor, coupled with the rain
sensor, located in the centre of the
windscreen, behind the interior
mirror. It is used for automatic
switching on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is
temporarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.

Visibility108 -
01-10-2005
109Visibility-
01-10-2005
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
position,
- place the lights stalk in the 0
position,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automatically
if the light is poor and when
the windscreen wipers operate
continuously and switch off when the
light becomes bright enough or the
windscreen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the
vehicle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness
sensor, coupled with the rain
sensor, located in the centre of the
windscreen, behind the interior
mirror. It is used for automatic
switching on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is
temporarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.

Visibility110 -
01-10-2005
111Visibility-
01-10-2005
WINDSCREEN WIPER STALK
Front windscreen wiper with
intermittent wipe
2 Fast wipe (heavy rain).
1 Normal wipe
(moderate rain).
l Intermittent wipe.
0 Off.
â Single wipe
(press downwards).
In the Intermittent position, the
wiping speed is in proportion to the
vehicle speed. Front windscreen wiper with
automatic wipe
2
Fast wipe (heavy rain).
1 Normal wipe
(moderate rain).
AUTO Automatic wipe.
0 Off.
â Single wipe
(press downwards).
In the AUTO position, the wiping
speed is in proportion to the intensity
of the rainfall. The command must be reactivated
whenever the ignition has been
switched off for more than one
minute:
- move the stalk to any position,
- then move it back to the required
position.
Windscreen wash

Pull the wiper stalk towards you.
The windscreen wash, then the
windscreen wipers, operate for a
speciied time.

Visibility110 -
01-10-2005
111Visibility-
01-10-2005
Automatic windscreen wipers
In the AUTO position, the windscreen
wipers operate automatically and
adapt their speed to the intensity
of the rainfall . Do not cover the rain
sensor located on the
windscreen behind the
interior mirror.
When using an automatic car
wash, switch off the ignition or
check that the wiper stalk is not in
the AUTO position.
In winter, it is advisable to wait
for the windscreen to completely
clear of ice before operating the
automatic wipe.Rear screen wiper
Rear screen wash
Turn ring A to the irst notch
for intermittent wiping.
If the ignition is switched
off, it is necessary to
reactivate the control each time.
To do this, move the stalk to any
position, then move it back to the
required position .
Turn ring A past the irst
notch; the screen wash then
the wiper operate for a ixed
period.
206 SW: the rear screen wiper and
rear screen wash functions are
disarmed automatically when the
rear screen is open.
Operating check
Activation
Activation of the function is accom-
panied by a message on the multi-
function display.
In the event of malfunction
, the
driver is informed by an audible
signal.
In the AUTO position, the windscreen
wiper will operate in intermittent
mode.
Contact a PEUGEOT dealer to have
the system checked. Automatic rear screen wiper
When the windscreen wipers control
is activated and you engage reverse
gear, the rear screen wiper operates
intermittently.
Note:
if you use a bicycle carrier,
consult a PEUGEOT dealer to have
this function deactivated or install a
speciic bicycle carrier approved by
PEUGEOT.

Visibility112 -
01-10-2005
113Visibility-
01-10-2005
TRIP COMPUTER
Pressing the button on the end of
the wash/wipe stalk enables the
following data to be displayed:
Display B
- the range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
Monochrome screen CT
- the "vehicle" tab with:
• range, current consumption and
the distance still to be driven,
- tab "1" (route "1") with:
• the distance driven, the average consumption and the average
speed calculated over route
"1"
- tab "2" (route "2") with the same
features.
It also permits access to the warning
log information.
Zero reset
Press the stalk for more than two
seconds.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.

Visibility112 -
01-10-2005
113Visibility-
01-10-2005
Range
This shows the distance that can still
be covered with the fuel remaining in
the tank.
Note: this igure may increase
if there is a change in the style
of driving or the road surface,
producing a signiicant drop in
current consumption.
When the range is less than 20 miles
(30 km), three segments are
displayed. After illing with fuel, the
range is displayed when it exceeds
62 miles (100 km).
If horizontal segments are displayed
for long periods instead of digits,
contact a PEUGEOT dealer.
Distance travelled
This indicates the distance travelled
since the computer was last set to
zero.
The routes
The routes "1" and ''2'' are independ-
ent but have identical application.
Route "1" for example allows you
to make daily calculations and route
"2" monthly calculations.
Current consumption
This is the average quantity of
fuel consumed during the last few
seconds.
This function is displayed only when
the vehicle is travelling at a speed
greater than 20 mph (30 km/h).
Average consumption
This is the average fuel consumption
since the computer was last set to
zero.
Distance remaining to be
travelled
This is the distance remaining to
the destination. It can either be
calculated by the navigation if
guidance is activated, or entered by
the user, minus the distance covered
since the distance was entered.
Note: if digits are missing, dashes
are displayed in their place.
Average speed
This is the average speed calculated
since the computer was last set to
zero (with the ignition on).
The warning log
This summarises the active warning
messages by displaying them on the
multifunction display.

Visibility112 -
01-10-2005
113Visibility-
01-10-2005
TRIP COMPUTER
Pressing the button on the end of
the wash/wipe stalk enables the
following data to be displayed:
Display B
- the range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
Monochrome screen CT
- the "vehicle" tab with:
• range, current consumption and
the distance still to be driven,
- tab "1" (route "1") with:
• the distance driven, the average consumption and the average
speed calculated over route
"1"
- tab "2" (route "2") with the same
features.
It also permits access to the warning
log information.
Zero reset
Press the stalk for more than two
seconds.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.
