FAMILIARISATION
4 -
INSTRUMENTS AND
CONTROLS
1. Cruise control/speed limiter
control.
2. S t e e r i n g w h e e l a d j u s t m e n t
control.
3. Lights and direction indicators
stalk.
4. Instrument panel.
5. Driver's air bag.
Horn.
6. Gear lever.
7. Handbrake.
8. Bonnet release.
9. Fuse box.
10. Dynamic stability control
(ESP/ASR) button.
11. R e a r e l e c t r i c w i n d o w s
deactivation control.
12. Passenger air bag disarming
control.
13. Headlamp height adjustment.
14. Side adjustable and closing vent.
15. S i d e w i n d o w d e m i s t i n g v e n t .
16. S p e a k e r ( t w e e t e r ) .
17. Windscreen demisting vent.
Page 14 of 127
17
INSTRUMENTS and CONTROLS
-
1. S e a t b e l t n o t f a s t e n e d w a r n i n g
light
2. Passenger air bag disarmed
w a r n i n g l i g h t
3. A i r b a g s w a r n i n g l i g h t
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
w a r n i n g l i g h t
6. Rear fog lamp indicator light
7. D i e s e l p r e - h e a t w a r n i n g l i g h t
8. Left hand direction indicator 9.
T o t a l d i s t a n c e r e c o r d e r , s e r v i c e ,
engine oil level and speed
limiter/cruise control indicator
10. Right hand direction indicator
11.
E m i s s i o n c o n t r o l s y s t e m w a r n i n g l i g h t
12. Main beam headlamps indicator
light
13. H a n d b r a k e , l o w b r a k e l u i d
level and electronic brake force
d i s t r i b u t i o n w a r n i n g l i g h t
14. Dipped beam headlamps
indicator light
15. B a t t e r y c h a r g e w a r n i n g l i g h t
16. Engine oil pressure and
t e m p e r a t u r e w a r n i n g l i g h t
17. Engine oil temperature indicator 18.
Total distance recorder button
19. C e n t r a l ( S T O P ) w a r n i n g l i g h t
20. Speedometer
21. Coolant temperature indicator
22. Rev counter
23. Lighting rheostat button
24. Fuel level indicator
25. L o w f u e l l e v e l w a r n i n g l i g h t
26. Dynamic stability control
( E S P / A S R ) w a r n i n g l i g h t
27. Speed limiter/cruise control
indicator light
INSTRUMENT DIALS: PETROL - DIESEL MANUAL GEARBOX
Page 15 of 127
INSTRUMENTS and CONTROLS
18 -
1. S e a t b e l t n o t f a s t e n e d w a r n i n g
light
2. Passenger air bag disarmed
w a r n i n g l i g h t
3. A i r b a g s w a r n i n g l i g h t
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)
w a r n i n g l i g h t
6. Rear fog lamp indicator light
7. Left hand direction indicator
8. T o t a l d i s t a n c e r e c o r d e r , s e r v i c e ,
engine oil level and speed
limiter/cruise control indicator 9.
Right hand direction indicator
10.
E m i s s i o n c o n t r o l s y s t e m w a r n i n g l i g h t
11. Main beam headlamps indicator
light
12. H a n d b r a k e , l o w b r a k e l u i d
level and electronic brake force
d i s t r i b u t i o n w a r n i n g l i g h t
13. Dipped beam headlamps
indicator light
14. B a t t e r y c h a r g e w a r n i n g l i g h t
15. Engine oil pressure and
t e m p e r a t u r e w a r n i n g l i g h t
16. Operating programmes
17. Gear indicator
18. Total distance recorder button 19.
C e n t r a l ( S T O P ) w a r n i n g l i g h t
20. Speedometer
21. Coolant temperature indicator
22. Rev counter
23. Lighting rheostat button
24. Fuel level indicator
25. L o w f u e l l e v e l w a r n i n g l i g h t
26. Dynamic stability control
( E S P / A S R ) w a r n i n g l i g h t
27. Speed limiter/cruise control
indicator light
INSTRUMENT DIALS: PETROL AUTOMATIC GEARBOX
Page 69 of 127
63
VISIBILITY
-
LIGHTS STALK
Dipped/Main beam change
P u l l t h e s t a l k t o w a r d s y o u . V e h i c l e s i t t e d w i t h f r o n t f o g
lamps and a rear fog lamp (ring C)
Side lights Dipped/Main beam
headlamps A u t o m a t i c s w i t c h i n g
on of lights Rear fog lamp F r o n t f o g l a m p s ( i r s t r o t a t i o n
o f t h e r i n g f o r w a r d s )
Front and rear fog
lamps (2nd rotation of
t h e r i n g f o r w a r d s ) .
Note: t o s w i t c h o f f t h e r e a r f o g l a m p
a n d t h e f r o n t f o g l a m p s , t u r n t h e r i n g
b a c k w a r d s t w i c e i n s u c c e s s i o n .
Note: w h e n t h e l i g h t s a r e s w i t c h e d
o f f a u t o m a t i c a l l y o r w h e n t h e d i p p e d
h e a d l a m p s a r e s w i t c h e d o f f m a n u -
a l l y , t h e f r o n t f o g l a m p s , t h e r e a r f o g
lamp and the side lights remain on
( t u r n t h e r i n g b a c k w a r d s t o s w i t c h o f f
the front fog lamps. The side lights
t h e n s w i t c h o f f ) .
V e h i c l e s i t t e d w i t h a r e a r f o g
lamp (ring B)
T h i s o n l y o p e r a t e s w i t h t h e d i p p e d /
main beam headlamps.
Note: w h e n t h e l i g h t s a r e s w i t c h e d
o f f a u t o m a t i c a l l y , t h e r e a r f o g l a m p
and the dipped headlamps remain on
( t u r n t h e r i n g b a c k w a r d s t o s w i t c h o f f
the rear fog lamp. The dipped head-
l a m p s a n d s i d e l i g h t s t h e n s w i t c h
off).
T h e f r o n t f o g l a m p s o p e r a t e w i t h t h e
side lights and the dipped headlamps.
Lights off Front fog lamps and rear
fog lamp
R o t a t e t h e r i n g f o r w a r d s t o s w i t c h o n
a n d b a c k w a r d s t o s w i t c h o f f . T h e s t a
-
t u s i s c o n i r m e d b y t h e i n d i c a t o r l i g h t
on the instrument panel.
Lights on reminder
With the ignition off and the auto-
m a t i c l i g h t i n g f u n c t i o n s w i t c h e d o f f ,
w h e n t h e d r i v e r ’ s d o o r i s o p e n e d , a
buzzer sounds if you have left your
lights on.
Front and rear lights
Selection is by turning ring A.
Page 70 of 127
VISIBILITY
64 -
"Follow me home" lighting
W h e n y o u l e a v e y o u r v e h i c l e , t h e
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
p o s i t i o n ,
- place the lights stalk in the 0 p o s i t i o n ,
- l a s h t h e h e a d l a m p s ,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
h e a d l a m p s s w i t c h o n a u t o m a t i c a l -
l y i f t h e l i g h t i s p o o r a n d w h e n t h e
w i n d s c r e e n w i p e r s o p e r a t e c o n t i n u -
o u s l y a n d s w i t c h o f f w h e n t h e l i g h t
b e c o m e s b r i g h t e n o u g h o r t h e w i n d -
s c r e e n w i p e r s a r e s w i t c h e d o f f .
In foggy weather or in snow, the
brightness sensor can detect suf-
i c i e n t l i g h t , t h e l i g h t s w i l l n o t
come on automatically. If neces-
sary, the dipped headlamps must
be switched on manually.
T h i s f u n c t i o n i s a c t i v e w h e n t h e v e -
hicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories p o s i t i o n ( 1 s t n o t c h ) ,
- Place the lights stalk in the AUTO/0 p o s i t i o n ,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights. Operating check
I n g o o d o r r a i n y w e a t h e r ,
b o t h d a y a n d n i g h t , t h e
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
D o n o t f o r g e t t o s w i t c h t h e m o f f
w h e n t h e y a r e n o l o n g e r n e e d e d .
Direction indicators
( l a s h e r s ) Left: d o w n w a r d s .
Right: u p w a r d s . Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
l i g h t i n g c o n t r o l s , t h e f u n c t i o n i s t e m
-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Consult a PEUGEOT dealer.
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Page 71 of 127
VISIBILITY
64 -
"Follow me home" lighting
W h e n y o u l e a v e y o u r v e h i c l e , t h e
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
p o s i t i o n ,
- place the lights stalk in the 0 p o s i t i o n ,
- l a s h t h e h e a d l a m p s ,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
h e a d l a m p s s w i t c h o n a u t o m a t i c a l -
l y i f t h e l i g h t i s p o o r a n d w h e n t h e
w i n d s c r e e n w i p e r s o p e r a t e c o n t i n u -
o u s l y a n d s w i t c h o f f w h e n t h e l i g h t
b e c o m e s b r i g h t e n o u g h o r t h e w i n d -
s c r e e n w i p e r s a r e s w i t c h e d o f f .
In foggy weather or in snow, the
brightness sensor can detect suf-
i c i e n t l i g h t , t h e l i g h t s w i l l n o t
come on automatically. If neces-
sary, the dipped headlamps must
be switched on manually.
T h i s f u n c t i o n i s a c t i v e w h e n t h e v e -
hicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories p o s i t i o n ( 1 s t n o t c h ) ,
- Place the lights stalk in the AUTO/0 p o s i t i o n ,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights. Operating check
I n g o o d o r r a i n y w e a t h e r ,
b o t h d a y a n d n i g h t , t h e
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
D o n o t f o r g e t t o s w i t c h t h e m o f f
w h e n t h e y a r e n o l o n g e r n e e d e d .
Direction indicators
( l a s h e r s ) Left: d o w n w a r d s .
Right: u p w a r d s . Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
l i g h t i n g c o n t r o l s , t h e f u n c t i o n i s t e m
-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Consult a PEUGEOT dealer.
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Page 72 of 127
65
VISIBILITY
-
WINDSCREEN WIPER STALK
Front windscreen wiper with
automatic wipe
2 F a s t w i p e ( h e a v y r a i n ) .
1
N o r m a l w i p e ( m o d e r a t e r a i n ) .AUTO A u t o m a t i c w i p e .
0 Off.
â S i n g l e w i p e ( p r e s s d o w n -
w a r d s ) .
In the AUTO p o s i t i o n , t h e w i p i n g
speed is in proportion to the intensity
of the rainfall. The command must be reacti-
vated
w h e n e v e r t h e i g n i t i o n h a s b e e n
s w i t c h e d o f f f o r m o r e t h a n o n e m i n u t e :
- m o v e t h e s t a l k t o a n y p o s i t i o n ,
- then move it back to the required position.
Front windscreen wiper with
intermittent wipe
2 F a s t w i p e ( h e a v y r a i n ) .
1 N o r m a l w i p e ( m o d e r a t e r a i n ) .
I I n t e r m i t t e n t w i p e .
0 Off.
â S i n g l e w i p e ( p r e s s d o w n w a r d s ) .
In the I n t e r m i t t e n t p o s i t i o n , t h e w i p i n g
speed is in proportion to the vehicle
speed. Windscreen wash
P u l l t h e w i p e r s t a l k t o w a r d s y o u . T h e
w i n d s c r e e n w a s h , t h e n t h e w i n d
-
s c r e e n w i p e r s , o p e r a t e f o r a s p e c i i e d
time.
T h e h e a d l a m p w a s h i s a l s o a c t i v a t e d
if the headlamps are on .
Page 77 of 127
LAYOUT
70 -
HEADLAMP ADJUSTMENT
D e p e n d i n g o n t h e l o a d i n y o u r v e h i c l e ,
it is recommended that the headlamp
beam is adjusted.
0. 1 or 2 people in the front seats.
-. 3 people.
1. 5 people.
2. 5 people + maximum
authorised load.
3. Driver + maximum
authorised load.
Initial setting is position 0.
STEERING WHEEL HEIGHT
ADJUSTMENT
W h e n s t a t i o n a r y , l o w e r t h e h a n d l e t o
u n l o c k t h e s t e e r i n g w h e e l .
Adjust to the desired height and
lift the handle to lock the steering
w h e e l .
HORN
Press one of the spokes of
t h e s t e e r i n g w h e e l .
Page 100 of 127
91
CHECKS
-
CHECKING THE LEVELS
T h e r e a r e t w o m a r k s o n
the dipstick:
A = maximum
N e v e r i l l p a s t t h i s m a r k .
B = minimum
To maintain the reliability
of engines and emission
c o n t r o l s y s t e m s , t h e u s e
of additives in engine oil
is prohibited.
Oil change
According to the information given in
the servicing booklet.
Note: avoid used oil coming into pro-
l o n g e d c o n t a c t w i t h t h e s k i n . E m p t y
the used oil into the containers intend-
ed for this purpose in the PEUGEOT
n e t w o r k .
Brake fluid level:
T h e b r a k e l u i d m u s t b e c h a n g e d a c -
cording to the manufacturer's servic-
ing schedule.
U s e l u i d s r e c o m m e n d e d b y t h e
m a n u f a c t u r e r , w h i c h f u l i l D O T 4
standards.
Note: b r a k e l u i d i s h a r m f u l t o h e a l t h
and very corrosive. Avoid all contact
w i t h t h e s k i n . Used oil
D o n o t d i s p o s e o f u s e d o i l , b r a k e l u i d
or coolant into drains or onto the
ground.
Dipstick
Viscosity selection
I n a l l c a s e s , t h e o i l s e l e c t e d m u s t
meet the manufacturer's require-
ments. Cooling system
U s e t h e l u i d r e c o m m e n d e d b y t h e
manufacturer.
W h e n t h e e n g i n e i s w a r m , t h e t e m
-
perature of the coolant is controlled
by the engine fan. As this fan can ope-
r a t e w i t h t h e i g n i t i o n k e y r e m o v e d
and because the cooling system is
p r e s s u r i s e d , w a i t f o r a t l e a s t o n e h o u r
after the engine has stopped before
c a r r y i n g o u t a n y w o r k .
S l a c k e n t h e c a p b y t w o t u r n s t o r e -
lease the pressure to prevent any
risk of scalding. When the pressure
h a s d r o p p e d , r e m o v e t h e c a p a n d
top up the level.
Note: the coolant does not need to
be changed.
For vehicles equipped with a
p a r t i c l e i l t e r , t h e e n g i n e f a n m a y
operate after the ignition has been
switched off, even when the en-
gine is cold. Power steering reservoir
F
O p e n t h e r e s e r v o i r , w i t h t h e
engine at ambient temperature.
T h e l e v e l s h o u l d a l w a y s b e
above the MIN. mark and close
to the MAX. mark.
Windscreen and headlamp
wash level
For best quality cleaning and for your
s a f e t y , w e w o u l d a d v i s e t h a t y o u u s e
products recommended by PEUGEOT.
For optimum cleaning and to prevent
f r e e z i n g , t h i s l u i d m u s t n o t b e t o p p e d
u p o r r e p l a c e d w i t h w a t e r .
Oil level
F
Check the level regularly and
t o p u p b e t w e e n c h a n g e s . T h e
maximum consumption is 0.5 l
per 600 miles (1 000 km).
C h e c k t h e l e v e l w i t h t h e v e h i c l e l e v e l ,
e n g i n e c o l d , u s i n g t h e o i l l e v e l g a u g e
on the instrument panel or the dip-
stick.
Page 106 of 127
PRACTICAL INFORMATION
96 -
Dipped headlamps H7 55W/
main beam headlamps H1 55 W
F Remove the protective cover A
for the H7 55 W bulb or B for the
H1 55 W bulb.
F Disconnect the connector(s) C.
F Press the end of the securing
clip(s) D to remove it(them).
Change the faulty bulb.
CHANGING A BULB
T o m a k e a c c e s s e a s i e r , on the right-
hand side , i r s t r e m o v e t h e s c r e e n
w a s h r e s e r v o i r i l l e r p i p e :
F a l i g n t h e n o t c h e s b y t u r n i n g ,
F p u l l u p w a r d s .
1. Dipped beam headlamps/
main beam headlamps
2. Side lights
3. Direction indicators F
O n i t t i n g , e n s u r e t h a t t h e
direction notches are in the
correct position and that the
securing clip(s) is(are) secured
correctly.
F Reconnect the connector.
F R e p l a c e t h e p r o t e c t i v e c o v e r ( s ) ,
t h e n t h e s c r e e n w a s h r e s e r v o i r
i l l e r p i p e ( r i g h t - h a n d s i d e ) .
