PEUGEOT 3008 2010 Repair Manual
Manufacturer: PEUGEOT, Model Year: 2010, Model line: 3008, Model: PEUGEOT 3008 2010Pages: 315, PDF Size: 23.05 MB
Page 61 of 315
60
M a n u a l o p e r a t i o n
If you wish, you can make a different
choice from that offered by the system
by changing a setting. The other func-
tions will still be controlled automati-
cally.
Pressing the "AUTO" button returns
the system to completely automatic
operation.
Press this button to switch
off the air conditioning. 6 . A i r d i s t r i b u t i o n a d j u s t m e n t
Press one or more but-
t o n s t o d i r e c t t h e a i r fl o w
towards:
7 . A i r fl o w a d j u s t m e n t
Turn this control to the left
t o d e c r e a s e t h e a i r fl o w o r
to the right to increase the
a i r fl o w .
5 . A i r c o n d i t i o n i n g O n / O f f
- the windscreen and side windows ( d e m i s t i n g o r d e f r o s t i n g ) ,
- the windscreen, the side windows and the vents,
- the windscreen, the side windows, the vents and the footwells,
- the vents and the footwells,
- the vents,
- the footwells,
- the windscreen, the side windows and the footwells.
T h e a i r fl o w i n d i c a t o r l a m p s , b e t w e e n
the two fans, come on progressively in
relation to the value requested.
For maximum cooling or heat-
ing of the passenger compart-
ment, it is possible to exceed
the minimum value 14 or the maxi-
mum value 28.
Turn control 2 or 3 to the left un-
til "LO" ( l o w ) i s d i s p l a y e d o r t o
the right until "HI" ( h i g h ) i s d i s -
played. Switching the system off could result in
s o m e d i s c o m f o r t ( h u m i d i t y , c o n d e n s a -
t i o n ) .
Press this button again to return to
automatic operation of the air con-
ditioning. The indicator lamp on the
"A/C" button comes on.
Page 62 of 315
61
9 . M o n o - z o n e / D u a l - z o n e
Press this button to equal-
ise the comfort value on the
passenger side with that
o n t h e d r i v e r ' s s i d e ( m o n o -
z o n e ) . T h e i n d i c a t o r l a m p
on the button comes on.
8. Air recirculation
This button activates the recir-
culation of air in the passenger
compartment and can permit
automatic operation.
Avoid prolonged recirculation
o f i n t e r i o r a i r ( r i s k o f c o n d e n -
sation and deterioration of the
a i r q u a l i t y ) .
S h u t t i n g o f f / I n t a k e o f a i r
( a u t o m a t i c m o d e )
S h u t t i n g o f f t h e i n t a k e o f a i r
( m a n u a l m o d e )
I n t a k e o f a i r ( m a n u a l m o d e )
Press this button to recir-
culate the interior air, the
indicator lamp comes on.
Air recirculation enables the passenger
compartment to be isolated from exte-
rior odours and smoke.
Press this button, the indi-
cator lamp comes on.
The automatic mode has an
exterior air quality sensor. It
analyses the air and isolates
the passenger compartment from the
outside when it detects the presence
o f p o l l u t a n t s ( e . g . i n a t u n n e l ) . I n t h i s
case, it activates the air recirculation
automatically.
Press this button to permit
the intake of outside air
and prevent condensation,
the indicator lamp switch-
es off.
The air quality sensor is not active.
S w i t c h i n g t h e s y s t e m o f f
T u r n t h e a i r fl o w c o n t r o l t o t h e l e f t
until all of the indicator lamps switch
off.
This action switches off all of the func-
tions of the system.
Temperature related comfort is no lon-
g e r g u a r a n t e e d b u t a s l i g h t fl o w o f a i r ,
due to the movement of the vehicle, can
still be felt.
T u r n t h e a i r fl o w d i a l t o t h e r i g h t o r
press the "AUTO" button to reacti-
vate the system with the values set
before it was switched off.
Avoid driving for prolonged
periods with the system off.
Page 63 of 315
62
FRONT SEATS
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Raise the control and slide the seat
forwards or backwards. D r i v e r ' s o r p a s s e n g e r ' s s e a t h e i g h t
a d j u s t m e n t
Pull the control upwards to raise
or push it downwards to lower, as
many times as necessary, to obtain
the position required. S e a t b a c k a n g l e a d j u s t m e n t
Push the control rearwards.
M a n u a l a d j u s t m e n t s
Page 64 of 315
63
D R I V E R ' S E L E C T R I C S E A T
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Push the control forwards or rear-
wards to slide the seat. S e a t c u s h i o n h e i g h t a n d a n g l e
a d j u s t m e n t
Tilt the rear part of the control up-
wards or downwards to obtain the
required height.
Tilt the front part of the control up-
wards or downwards to obtain the
required angle. S e a t b a c k a n g l e a d j u s t m e n t
Tilt the control forwards or rearwards
to adjust the angle of the seat back. The electrical functions of the
driver's seat are active approxi-
mately one minute after opening
the front door. They are deactivated ap-
proximately one minute after the ignition
is switched off and in economy mode.
To reactivate them, switch on the
ignition.
Page 65 of 315
64
Heated seats control
With the engine running, the front seats
can be heated separately.
Use the adjustment dial, placed on
the side of each front seat, to switch
on and select the level of heating
required:
0
: Off.
1
: Low.
2
: Medium.
3
: High.
H e a d r e s t r a i n t h e i g h t a n d a n g l e
a d j u s t m e n t
To raise the head restraint, pull it for-
wards and upwards at the same time.
To remove the head restraint, press
the lug A and pull the head restraint
upwards.
To put the head restraint back in
place, engage the head restraint
stems in the openings keeping them
in line with the seat back.
To lower the head restraint, press
the lug A and the head restraint at
the same time.
To adjust the angle of the head re-
straint, tilt its lower part forwards or
rearwards. T h e h e a d r e s t r a i n t i s fi t t e d w i t h
a frame with notches which
prevents it from lowering; this
is a safety device in case of
impact.
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e u p p e r e d g e o f t h e h e a d r e s t r a i n t i s
l e v e l w i t h t h e t o p o f t h e h e a d .
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.
L u m b a r a d j u s t m e n t
Turn the dial to obtain the correct
lumbar position.
Page 66 of 315
65
F o l d i n g t h e s e a t b a c k
Check that no object, either on or
underneath the seat, could hinder
its movement.
To make the operation easier, place
the head restraint in the low position
o r r e m o v e i t ( i f t h e s e a t i s i n t h e f u l l y
f o r w a r d p o s i t i o n ) .
Lift the control, located behind the
seat, then guide the seat back for-
wards. When the seat back is in this position,
the seat behind it and the centre rear
seat must not be occupied.
This position, associated with that of the
rear seats, allows you to transport long
objects inside the vehicle.
The maximum weight on the seat is
30 kg.
T a b l e p o s i t i o n , f r o n t p a s s e n g e r seat
R e t u r n i n g t h e s e a t t o t h e n o r m a l
p o s i t i o n
Lift the control, located behind the
seat, then guide the seat back rear-
wards until it locks.
Page 67 of 315
66
F o l d i n g t h e s e a t f r o m t h e b o o t
E a c h s e c t i o n o f t h e b e n c h s e a t ( 1 / 3 o r
2 / 3 ) h a s i t s o w n c o n t r o l t o r e l e a s e t h e
seat back and its seat cushion from the
boot.
Check that nothing is preventing
t h e s e a t b a c k f r o m f o l d i n g ( h e a d r e -
s t r a i n t , s e a t b e l t s , . . . ) ,
check also that no object on or under
the seat could hinder its movement,
pull the control from the boot.
REAR SEATS
Never drive with rear passen-
gers when the head restraints
are removed; the head re-
straints must be in place and in the
high position.
R e a r h e a d r e s t r a i n t s
T h e s e h a v e a h i g h p o s i t i o n ( c o m f o r t a n d
s a f e t y ) a n d a l o w p o s i t i o n ( r e a r v i s i b i l i t y ) .
They can also be removed.
To remove a head restraint:
pull the head restraint fully upwards,
then, press the lug A .
B e n c h s e a t t h e l e f t - h a n d ( 2 / 3 ) o r r i g h t -
h a n d ( 1 / 3 ) s e c t i o n o f w h i c h c a n b e f o l -
ded to adapt the boot load space.
Page 68 of 315
67
The seat cushion lowers to be
covered by the seat back; this
l e a v e s a fl a t b o o t fl o o r , i f t h e
a d j u s t a b l e fl o o r i s i n t h e i n t e r m e d i a t e
position.
F o l d i n g t h e s e a t f r o m t h e r e a r
Check that no object, either on or un-
derneath the seat, could hinder its
movement.
Move the corresponding front seat
forwards if necessary,
check that the seat belt is positioned
correctly on the side of the seat
back,
place the head restraints in the low
position or remove them if necessary,
pull the control 1 forwards to release
the seat back 2 which tilts easily
onto the seat cushion 3 .
R e t u r n i n g t h e s e a t b a c k t o i t s o r i g i n a l p o s i t i o n
Put the seat back in the upright posi-
tion and secure it, the seat cushion
also returns to its original position,
check that the red indicator, located
at the control 1 , is no longer visible,
r e fi t t h e h e a d r e s t r a i n t s o r p u t t h e m
back in place.
When returning the rear seat back to
its original position, take care not to
trap the seat belts and ensure that their
buckles are positioned correctly.
Page 69 of 315
68
The objects observed are, in
reality, closer than they ap-
pear.
Take this into account in order to cor-
rectly judge the distance of vehicles
approaching from behind.
MIRRORS
D o o r m i r r o r s
E a c h fi t t e d w i t h a n a d j u s t a b l e m i r r o r
glass permitting the lateral rearward vi-
sion necessary for overtaking or parking.
They can also be folded for parking in
c o n fi n e d s p a c e s . F o l d i n g
- Automatic: lock the vehicle using
the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
The folding and unfolding of
the door mirrors using the re-
mote control can be deactivat-
ed by a PEUGEOT dealer.
Fold the mirrors when putting your
vehicle through an automatic car
wash.
A d j u s t m e n t
U n f o l d i n g
- Automatic: unlock the vehicle using the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
If the mirrors are folded using
control
A , they will not unfold
when the vehicle is unlocked.
Pull again on control A .
Move control A to the right or to
the left to select the corresponding
mirror.
Move control B in all four directions
to adjust.
Return control A to the central
position.
D e m i s t i n g - D e f r o s t i n g
I f y o u r v e h i c l e i s fi t t e d w i t h h e a t e d m i r -
rors, the demisting-defrosting operates
with the engine running, by switching
o n t h e h e a t e d r e a r s c r e e n ( r e f e r t o t h e
" R e a r s c r e e n d e m i s t - d e f r o s t " p a g e ) .
Page 70 of 315
69
A d j u s t m e n t
Adjust the mirror so that the glass
i s d i r e c t e d c o r r e c t l y i n t h e " d a y "
position.
As a safety precaution, the
mirrors must be adjusted to
r e d u c e t h e " b l i n d s p o t " .
M a n u a l d a y / n i g h t m o d e l
D a y / n i g h t p o s i t i o n
P u l l t h e l e v e r t o c h a n g e t o t h e " n i g h t "
anti-dazzle position.
Push the lever to change to the nor-
m a l " d a y " p o s i t i o n .
R e a r v i e w m i r r o r
Adjustable mirror providing a central
rearward view.
Equipped with an anti-dazzle system,
useful in poor light.
In order to guarantee opti-
mum visibility during your ma-
noeuvres, the mirror lightens
automatically when reverse gear is
engaged.
A u t o m a t i c d a y / n i g h t m o d e l
By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes between the day and night
uses.
It has an anti-dazzle system which dark-
ens the mirror glass: this reduces any
driver discomfort caused by the light
beam of following vehicles, the sun...
