change time Peugeot 306 C 2001 Owner's Manual

MAINTENANCE OF YOUR 306 CABRIOLET
18
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals:
¥ Every 20 000 miles (30 000km) or every 2 years for petrol engines. The extension of the service intervals means that the engine oil level must be checked regularly; topping up of the oil between oil changes is normal.
It is for this reason, and for your complete peace of mind, that your PEUGEOT dealer will carry out a levels check and top-up midway between each routine service, at the time or distance intervals specified. This will be undertaken free of charge, provided that the maintenance of your vehicle has been carried out within the
Peugeot network. At the same time, your Peugeot dealer will offer you a PEUGEOT Safety Check, for a nominal fee.
A PEUGEOT professional will carry out a quick check and will top up the levels if necessary (oil up to 1 litre, coolant and screen wash).
If the oil level is too low, there is a risk of serious damage to the engine: check the engine oil level at least every 1 500 m iles
(2 500km), depending on the conditions of use.
The date of the intermediate visit is not shown by the service indicator. It is to be carried out at least every 10 000 miles (15 000km) for petrol engines.

93
YOUR 306 CABRIOLET IN DETAIL
- Switch on the ignition.
- The display begins a 10 secondcountdown.
- Release the button before the countdown finishes.
- The service interval is displayed.
- Each brief press of button 1alter-
nates the service intervals.
To change the service interval
- Switch off the ignition.
- Press and hold button 1. Example:
- When the chosen service interval
is displayed, press button 1for
10 seconds (countdown) to confirm. Reset
Your PEUGEOT dealer carries out this operation after each service.
However, if you service the vehicleyourself, reset as follows:
- Switch off the ignition.
- Press and hold button
1.
- Switch on the ignition.
- The display begins a 10 second countdown.
- Keep button 1pressed for
10 seconds.
- The display shows [= 0]and the
service symbol disappears.
Service intervals If your vehicle is used in certain par-
ticularly difficult conditions it is ne-cessary to follow the "Arduous condi-tions" servicing schedule, whichinvolves shorter intervals between
services (see your Warranty andMaintenance Record booklet). Comment:
If the time limit between
two services is reached before the relevant mileage limit, the servicespanner symbol will light up and thedisplay will show 0.
1

93
YOUR 306 CABRIOLET IN DETAIL
- Switch on the ignition.
- The display begins a 10 secondcountdown.
- Release the button before the countdown finishes.
- The service interval is displayed.
- Each brief press of button 1alter-
nates the service intervals.
To change the service interval
- Switch off the ignition.
- Press and hold button 1. Example:
- When the chosen service interval
is displayed, press button 1for
10 seconds (countdown) to confirm. Reset
Your PEUGEOT dealer carries out this operation after each service.
However, if you service the vehicleyourself, reset as follows:
- Switch off the ignition.
- Press and hold button
1.
- Switch on the ignition.
- The display begins a 10 second countdown.
- Keep button 1pressed for
10 seconds.
- The display shows [= 0]and the
service symbol disappears.
Service intervals If your vehicle is used in certain par-
ticularly difficult conditions it is ne-cessary to follow the "Arduous condi-tions" servicing schedule, whichinvolves shorter intervals between
services (see your Warranty andMaintenance Record booklet). Comment:
If the time limit between
two services is reached before the relevant mileage limit, the servicespanner symbol will light up and thedisplay will show 0.
1

91
YOUR 306 CABRIOLET IN DETAIL
Anti-lock braking system (ABS) warninglight It comes on for 3 seconds
each time the ignition is switched on. If it comes on at over 8 m.p.h. (12 km/h.) it indicates a malfunction
of the ABS.
However, the vehicle retains conven- tional servo-assisted braking.
Contact a PEUGEOT dealer.
Front airbags* and disarming ofpassenger airbag* For operation, see section on AIR BAGS
Side air bags** For operation, see
section on AIR BAGS.
* According to specification.
Oil gauge* When the ignition is on, this indicates the oil level: The reading is only valid if the vehicle is on level ground and the engine has
been switched off for 10 minutes.
- needle in zone
C, the oil level is
correct
- needle in zone D, check the oil level
using the dipstick and top up if
necessary.
Never exceed the maximum level onthe dipstick.
The oil level indicator switches off approximately 15 seconds after star-ting the engine.
Front brake pad wearwarning light*
For your safety, change the brake pads when thewarning light comes on.
Contact a PEUGEOT dealer.
DC
* According to specification.
Coolant temperature gauge
- needle in zone
A, the temperature
is correct.
- needle in zone B, the temperature
is too high.
The STOP warning light comes on.
You must stop.
Contact a PEUGEOT dealer.A
B

91
YOUR 306 CABRIOLET IN DETAIL
Anti-lock braking system (ABS) warninglight It comes on for 3 seconds
each time the ignition is switched on. If it comes on at over 8 m.p.h. (12 km/h.) it indicates a malfunction
of the ABS.
However, the vehicle retains conven- tional servo-assisted braking.
Contact a PEUGEOT dealer.
Front airbags* and disarming ofpassenger airbag* For operation, see section on AIR BAGS
Side air bags** For operation, see
section on AIR BAGS.
* According to specification.
Oil gauge* When the ignition is on, this indicates the oil level: The reading is only valid if the vehicle is on level ground and the engine has
been switched off for 10 minutes.
- needle in zone
C, the oil level is
correct
- needle in zone D, check the oil level
using the dipstick and top up if
necessary.
Never exceed the maximum level onthe dipstick.
The oil level indicator switches off approximately 15 seconds after star-ting the engine.
Front brake pad wearwarning light*
For your safety, change the brake pads when thewarning light comes on.
Contact a PEUGEOT dealer.
DC
* According to specification.
Coolant temperature gauge
- needle in zone
A, the temperature
is correct.
- needle in zone B, the temperature
is too high.
The STOP warning light comes on.
You must stop.
Contact a PEUGEOT dealer.A
B

YOUR 306 CABRIOLET IN DETAIL
60
GENERAL FUNCTIONS On / off
With the ignition key in the ACCESSORIES or IGNITION position, press the "ON/VOL"button to switch the set
on or off. ANTI-THEFT SYSTEM
The first time you use the set following disconnection of the set or the battery, you must enter the confidential code which was given to you on handover of your vehicle. Entering the code Switch the set on. The display shows "CODE"then the set changes over to code request mode and " - - - -" is displayed.
Enter your four-digitcode number using buttons " 1" to " 6".
For example: if your code is 5345 press buttons " 5", " 3", " 4" and " 5" in turn.
When the fourth number has been entered correctly, the radio starts automatically.
Error in entering the code
If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio to prevent blocking it. Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When " - - - -" is displayed, you can enter the
code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on again.After incorrectly inputting the code 14 times, the radio will be permanently locked and the display will read " END".
ADJUSTING THE SOUND Adjusting the volume
Turn the "ON/VOL" button to increase or decrease the volume of the set.
If the radio overheats, the volume reduces. If an attempt is made to increase the volume the message " TOO HOTÕÕ
appears on the display. Note If you have a telephone fitted with a Ò muteÓ signal output connected to the set, the set will automatically change
to Ò mute Ó when the telephone is used.

70
YOUR 306 CABRIOLET IN DETAIL
GENERAL FUNCTIONS On / off
With the ignition key in the ACCESSORIES or IGNITION position, press the "ON/VOL"button to switch the set
on or off. The set can operate for 30 minutes without switching the ignition on. ANTI-THEFT SYSTEM
The first time you use the set following disconnection of the set or the battery, you must enter the confidential code which was given to you on handover of your vehicle. Entering the code Switch the set on. The display shows Ò CODEÓ then the set changes over to code request mode and " - - - -" is displayed.
Enter your four-digitcode number using buttons " 1" to " 6".
For example: if your code is 5345 press buttons " 5", " 3", " 4" and " 5" in turn.
When the fourth number has been entered correctly, the radio starts automatically.
Error in entering the code
If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio to prevent blocking it. Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When " - - - -" is displayed, you can enter the code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on again.After incorrectly inputting the code 14 times, the radio will be permanently locked and will display the message " END ".
ADJUSTING THE SOUND Adjusting the volume
Turn the " ON/VOL" button Mto increase or decrease the volume of the set.
In the event of the radio overheating, the volume level decreases.
NoteIf you have a telephone fitted with a Ò muteÓ signal output connected to the set, the set will automatically change
to Ò mute Ó when the telephone is used.

71
YOUR 306 CABRIOLET IN DETAIL
AUDIO SETTINGS Press the Ò AUDIOÓ button several times to select bass (BASS), treble(TREB) , loudness (LOUD), fader (FAD)and
balance (BAL).
Exit from audio mode is automatic after a few seconds, without pressing any button or by pressing the Ò AUDIOÓ
button after adjusting the balance. Note: the bass and treble settings are specific to each source. It is possible to set the radio, CD, or CD multi-changer
differently.
Bass setting When ÒBASSÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
-Ò BASS -9 Ó for a minimum bass setting,
-Ò BASS 0 Ó for a normal position,
-Ò BASS +9 Ó for a maximum bass setting.
Treble settingWhen Ò TREBÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
-Ò TREB -9 Ó for a minimum treble setting,
-Ò TREB 0 Ó for a normal position,
-Ò TREB +9 Ó for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press the ÒDÓor ÒEÓ buttons to switch this function on or off.
Setting the front/rear sound distribution (Fader) When Ò FA DÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
The Ò DÓ button increases the volume at the front.
The Ò EÓ button increases the volume at the rear.
This function may be switched off by simultaneously pressing buttons Ò MÓ and Ò FÓ.
Setting the right/left sound distribution (Balance)When Ò BALÓ is displayed, press the Ò DÓ or Ò EÓ buttons to vary the setting.
The ÒDÓbutton increases the volume on the right-hand side.
The ÒEÓbutton increases the volume on the left-hand side.

57
1 - Switching on Press the switch 1, the operating light will come on.
2 - Adjusting the temperature
Turn the knob 2to the blue zone (cold) or to the red zone (hot).
3 - Adjusting the air distribution
To direct the hot or cold air, turn the knob 3to the desired position. 4 - Adjusting the air flow
Turn the knob
4to obtain the desired
flow.
Entry of outside air This is the normal operating position. Recirculation of interior air This position prevents the
entry of outside air. Used at the same time as the
air conditioning, this will improve air conditioning performance. Used on its own, it prevents the entry of outside air (dust, unpleasantodours) but there is a risk of misting ofthe windows.
Avoid continuous operation in interior air recirculation mode. Important precautions: Operate the air conditioning system for 5 to 10 minutes once or twice amonth to keep it in good working
order. It is advisable to change the air con- ditioning system fluid every two years.
If the system is not producing cold air, stop using it and contact a
PEUGEOT dealer.
Windscreen and side windows. Windscreen, side windows and footwells. Footwells only. Side and central vents.
YOUR 306 CABRIOLET IN DETAIL
AIR CONDITIONING
43
21

DRIVING YOUR 306 CABRIOLET101
Any disruption of the system is signalled by theflashing of the Sport andSnow lights on the instru-ment panel. In such a case,
the gearbox will operate in down-
graded mode. You may feel a sub-stantial knock when reverse isselected from Pto R, or from Nto R
(without any risk of damage to thegearbox). Do not exceed 60 m.p.h. (100km/h). Contact a PEUGEOT dealer
without delay. When the engine is idling with the
car in gear, the car will move evenwithout you accelerating. Do not accelerate while a gear is being selected, when the vehicle is
stationary.
When stationary, have your foot on the
brake pedal when selecting a gear. Do not accelerate in gear with the brakes on. If work needs to be done with the engine running, apply the hand-brake and select position P.
Do not change down to brake onslippery roads. Never select position Nwhen the
vehicle is moving. Never engage Por Rif the vehicle
is not stationary. Do not allow children inside the vehicle unsupervised when theengine is running.Operating programmes
You have a choice of three operating programmes:
- Auto-adaptive (normal).
- Sport.
- Snow.One press on button Aor Bwill select
Sport or Snow respectively. The selection is displayed on the instru-ment panel. Pressing the button asecond time will return to the auto-adaptive (normal) programme. Auto-adaptive programme (normal) Gear changes are carried out on the basis of various parameters, such as:
- driving style,
- road characteristics,
- the vehicleÕs load.The gearbox continuously scans the
different programmes in the memoryand selects the one most suitable forthe driving conditions at any givenmoment. Sport programme The Sport programme favours perfor- mance for sporty driving and moredynamic acceleration. Snow Programme In position
Dthe Snow programme
provides smooth driving suited to slip- pery roads in order to improve trac-
tion and stability. Starting is in 2ndgear and changing down is at lowengine speeds. Special operating features During prolonged braking, the
gearbox changes down automatically,
so as to provide efficient enginebraking.
- If you take your foot off the acce- lerator suddenly (when you are taken by surprise, for example), thegearbox will not change up, so as to
improve safety.
-When the engine is cold, thegearbox automatically selects aspecial programme which enablesthe engine to reach its ideal tem-perature more quickly to decrease pollution.
Kickdown For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as
it will go. The gearbox will changedown automatically or stay in the gearselected, up to maximum enginespeed.
