YOUR 306 CABRIOLET AT A GLANCE
6
FRONT AIRBAGS Disarming the passenger airbag. Insert the ignition key in switch 1
and turn it:
Ð to the ÒONÓposition, the pas-
senger airbag is armed,
Ð to the ÒOFFÓposition, the pas-
senger airbag is not armed.
Operational check This is by means of the warning light on the instru-ment panel.
If the passenger airbag is not armed, the warning light remainson. Always contact your PEUGEOT dealer if the warning light flashes.
THE REMOTE CONTROL
A single press on button Alocks
the doors and boot.
A single press on button Bunlocks
the vehicle.
KEYS
Using the key in the driverÕs door lock will lock or unlock the doorsand boot.
Passenger airbagprecautions
If the passenger airbag is armed or if your vehicle is not fitted with apassenger airbag, the warninglight comes on for 6 seconds whenthe ignition is switched on.For a vehicle fitted with a disarm-ing switch:
Ð disarm theairbag if youinstall arearwards-facing childseat.
Ð arm the airbag whenan adult is inthe seat.
For a vehicle not fitted with a disarming switch:
Ð do not install rear-wards-facingchild seats on thefront passengerseat.
Never place your feet or any object on the fascia.
A
B
103

YOUR 306 CABRIOLET AT A GLANCE
4
Confidential card This contains the identification combination which is required ifany work is carried out on the
system by a PEUGEOT dealer.This combination is concealed bya strip which must not be removedunless required. Keep your card in a safe place, never in your vehicle.
ELECTRONIC ENGINEIMMOBILISER This locks the engine control system a few moments after the
ignition has been switched off andtherefore prevents starting of thevehicle by anyone who has not
got the key.
Operation Each key has an electronic chip which has a special code. When the ignition is switched on the key code is recognised andstarting is possible. If the key does not have a code
or has a different code from that
stored in the system memory, thevehicle will not start. Additional key
You can store up to 5 keys in the
memory. If you require an additional key or
wish to change a faulty key, you
must visit a PEUGEOT dealerwith the confidential card and allthe keys in your possession.
When buying a second hand car: ensure that you are given the confidential card: it is advisable to have the key codes memorised by a PEUGEOT dealer toensure that the keys in your possession are the only ones which
can start the vehicle. Do not make any modifications to the PEUGEOT electronic engine immobiliser system.

Never leave a child in a vehicle which is exposedto the sun and has thewindows closed.
To protect young children
from the sun, fit sunblinds to the rear windows. Never leave the keys in the reach
of children inside the car. Strap children into their child seats even on short journeys.
84
YOUR 306 CABRIOLET IN DETAIL
Observe the precautions concern- ing the passenger airbag.
CHILD SEATS All children under the age of 10 are required to travel in approved child safety seats*, fitted with seat belts.
After carrying out numerous tests, PEUGEOT recommend the following systems :Up to 9 months (up to 22 lbs. or 10 kg)
ÇBaby SafeÈ, a seat secured with its back to the engine and secured with a three-point seat belt, on either the front or rear seat.
From 9 months to 3 or 4 years (20 to 40 lbs. or 9 to 18 kg)
ÇRšmer PeggyÈ is fitted to the rear seat with a three-point belt.
For your childÕs safety, the seat cushion and the tray must never be separated.
From 3 to 10 years of age (33 to 80 lbs or 15 to 36 kg) ÒKlippan OptimaÓ : is fitted in the rear with a three point belt (removable seatback). from 33 to 55 lbs. [15 to 25 kg] : booster + seatback.from 55 to 80 lbs. [25 to 36 kg] : use the booster on its own.
For maximum safety, fasten the three-point seat belts or the child seat straps keeping
the slack in relation to the childÕs body to a minimum, even for short journeys. Also, do not open the rear windows more than a third.
This was one of PEUGEOTÕs main criteria when designing your vehicle, however the safety of your children also depends on you. For maximum peace of mind,please follow these simple precautions: *According to current legislation.
1
2
3
123

YOUR 306 CABRIOLET IN DETAIL
78
THE REMOTE CONTROL
A single press on button Alocks the
doors and boot, this is displayed by the direction indicators staying on forabout 2 seconds.
A single press on button Bunlocks
the vehicle, this is displayed by the
direction indicators flashing rapidly.
KEYS
Without central locking The key individually Iocks and unlocks the doors and boot.
With central locking
Turning the key in the driverÕs door lock will lock or unlock the doors andboot. If either of the front doors is notclosed, the central locking will notwork. CHANGING THE REMOTE
CONTROL BATTERIES
To gain access to the battery, unclip the key casing with a coin where youcan see the ring (CR
1620/3 volt
battery). If the remote control does not work after the battery has been changed,re-programme the remote control. PROGRAMMING THE REMOTE CONTROL Manual synchronisation
- Switch off the ignition,
- Switch on the ignition,
- Immediately after switching on the ignition press button A.
The remote control is now working again. Automatic synchronisation
- Switch on the ignition (position M),
- Switch off the ignition and, during the next four minutes, lock the vehicle using the remote control(button A).
The remote control is now workingagain.
Note: Do not repeatedly press the button of your remote control out of range of
your vehicle. You risk causing it not towork and the remote control wouldhave to be reprogrammed.
A
B

79
YOUR 306 CABRIOLET IN DETAIL
1
2
Locking or unlocking the boot The boot can be locked indepen- dently using the key or together withthe doors by way of the central locking function. The boot can only be unlocked using
the key. This system prevents unauthorised access to the boot when the hood isopen.
Opening and closing thedoors from inside the vehicle 1
Locking control.
2 Opening handle.
Take careful note of the numbers on the keys. The key number is coded on the label attached to
the key. If the key is lost
your PEUGEOT dealer can rapidlysupply you with new keys or aremote control. As a safety precaution (with chil- dren on board) remove the igni-tion key when you leave the vehi-cle, even for a short time. The high frequency remote con- trol is a high-performance systemwhich has a powerful beam.Therefore do not operate it while itis in your pocket as there is a pos-sibility that it may unlock yourvehicle.

17
C O N T E N T S
4 YOUR 306 CABRIOLET IN DETAIL 46 99
Electric hood
Opening ...................................................................46
Closing automatically ..............................................47
Closing manually .....................................................48Hard-top
Removal ..................................................................50
Refitting ...................................................................52Heating / air conditioning
Ventilation ................................................................54
Heating ....................................................................56
Air conditioning ........................................................57Audio equipment
Audio RB1 ...............................................................58
Audio RD1 ...............................................................68 Doors and boot
Keys ........................................................................78
Remote control ........................................................78
Doors .......................................................................79
Boot .........................................................................79
Bonnet .....................................................................80Filling with fuel.........................................................81Seats
Front seats ..............................................................82Child seats...............................................................84
Seat belts ................................................................85Instruments and controls
Steering wheel controls ...........................................86Instrument dials and lights ......................................88
Service indicator ......................................................92
Electric windows ......................................................94
Mirrors .....................................................................95
Comfort and safety ..................................................96
5 DRIVING YOUR 306 CABRIOLET
100 105
Automatic autoadaptive gearbox ...........................100Manual gearbox - brakes.......................................102 Airbags ..................................................................103
6 TECHNICAL DATA106 109
Engines .................................................................106
Consumption .........................................................107
Weights ................................................................107 Dimensions............................................................108
Identification elements of your 306 cabriolet .........109
8 ALPHABETICAL INDEX112 113
7 SPECIAL FEATURES110 111

MAINTENANCE OF YOUR 306 CABRIOLET
30
Special features of the alloy wheels* Bolt covers Alloy wheel bolts are covered by chrome trims. Use tool
3to remove the trims befo-
re slackening the bolts. Anti-theft bolts** If your wheels are fitted with an anti- theft bolt (one per wheel), the chro-me trim and then the plastic covermust be removed using tool
3, befo-
re unscrewing the bolt using one ofthe two anti-theft sockets (whichwere given to you on delivery of yourvehicle with the duplicate keys andthe confidential card) and the wheelbrace 1.
Comment: make a careful note of
the code number engraved on the
head of the anti-theft socket. Thiswill enable you to obtain a duplicateof the anti-theft sockets from a
Peugeot dealer.
* According to specification.
** According to model and destina- tion.
Fitting the spare wheel If your vehicle is fitted with a steel spare wheel, it is
normalto notice
that the bolt washers do not come
into contact with the rim. The sparewheel is secured by the cone-sha-
ped support of each bolt. Tighten the
bolts fully.
Fitting snow tyres If you fit snow tyres mounted on steel wheels, it is essentialto use special
bolts available from your PEUGEOT
dealer.
