gearbox Peugeot 306 Dag 2002 Owner's Manual

1
B
A
YOUR 306 AT A GLANCE13
THE AUTOMATIC
AUTOADAPTIVE GEARBOX
P.Park.
R. Reverse.
N. Neutral.
D. Drive: in this position, all four gears change automatically.
3. Automatic changing of the first three gears only.
2. Automatic changing of the first two gears only.
1. Selection of first gear only. Selection of first gear is from position 2by pressing switch 1.
A. Sport programme.
B. Snow programme.
Position of selector leverThis is shown by an indicator on the instrument panel.
Starting
To start the engine, place the selector lever in position
Nor P.
Press the brake pedal when start-ing the engine or when selecting a
forwards or reverse gear.
105

AA
A
CC
AACC
MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000) 80,000 (120 000)
1st service at
6,000 miles (10 000 km)* or 6 months*
The validity of the
Warranty depends
on this service.
100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000) 180,000 (270 000)
20
TYPES OF SERVICE
Each vehicle has its own servicing cycle, defined by the manufacturer in accordance with each vehicleÕs specific technical fea- tures.
This cycle consists of alternating 2 types of service A and C, intermediate visits, and a few additional operations depending on your vehicle ; these correspond to key stages in the life of your 306. Services of type B are designed for less recent vehicles.
Your dealer will indicate the type and content of the next service when the first service is carried out, and at each sub- sequent service.
Intermediate visit
* Whichever comes first Automatic gearbox oil level every 40,000 miles (60,000km) Brake fluid
replacement every 2 years or every 40,000 miles (60,000km)
These operations are carried out with synthetic based oil; Fuel Economy oil or
synthetic oil can also be used.
MAINTENANCE OF YOUR 306
THE MAINTENANCE CYCLE FOR YOUR PETROL 306
Service every 20,000 miles (30 000 km) or 2 years
+ timing belt replacement+ timing belt replacement

MAINTENANCE OF YOUR 30623
PEUGEOT SERVICING LEVELS A AND C
: All driving conditions : Arduous conditions
Level
Operations Description of operations for 1st serviceFirst serviceACIntermediate visit
DRAIN AND REFILL- Engine oil- Bleed fuel filter (diesel)- Oil filter.- Fuel filter (Petrol).REPLACEMENT- Fuel filter element (Diesel).- Air filter element.- Spark plugs (Petrol).- Engine oil (check + top up).- Manual gearbox oil (check + top up).- Battery (check + top up) if cap is removableLEVEL- Front/rear windscreen wash (check + top up).- Coolant (check + top up).- Brake fluid (check + top up).- Power steering fluid (check + top up according to specification).- Operation of lights and indicators.- Condition of glass, headlamp and light lenses and mirrors.- Horn.- Windscreen washer jets.- Condition of wiper blades.- Condition and tension of ancillary drive belts.- Handbrake.- Condition of hydraulic circuits (hoses and covers), check for leaks.CHECK- Condition of rubber boots and gaiters.- Brake pad wear. - Play in hubs, rods, ball joints, flexible mountings- Shock absorbers for leaks- Rear drum brake lining wear- Condition and pressure of tyres (including spare wheel).- Emission control check according to current legislation (Petrol).- Smoke opacity (Diesel).- Pollen filter check (according to specification). - Visual check of the whole vehicle by a PEUGEOT dealer.
SERVICE- Courtesy vehicle
ROAD TEST

0W203040
50
20W
15W
10W
5W
25
MAINTENANCE OF YOUR 306
Recommendations for approved lubricants
The oils which appear in the tableopposite are suitable for most purposes. The diagram opposite states the optimum range of viscosity depen-ding on the temperatures at which theoils are to be used. It is also possible to use synthetic oils of Ôsuperior qualityÕ. In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJquality (for petrol engines), or CD/CFquality (for diesel engines) may beused by following the ÔArduous Condi-
tionsÕ maintenance schedule whichspecifies shorter intervals. Do not hesitate to ask for advice from
a PEUGEOT dealer to maintaindriving pleasure and to minimise themaintenance cost of your vehicle. For countries outside Europe, please
contact a local PEUGEOT dealer.
ESSENTIAL ESSENTIAL
Manual gearbox ESSO GEAR OIL BVTOTAL TRANSMISSION BV75W 80 PR 9736.41 75W 80
Automatic ESSENTIAL
gearbox AL4 ATF 4HP20-AL4 PR 9736.22
Automatic ESSO ATF D TOTAL FLUIDE AT42
gearbox PR 9730.944 HP-14
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Brake fluid PEUGEOT DOT4 Coolant PROCOR TM108 / GLYSANTIN G33 or REVKOGEL 2000
ESSENTIAL Protection to minus 35 ¡C
Other approved products

5678910 11 12 13 14 15 16
4 321
28 27 26 25 24 23 22 21 20 19 18 17
94
YOUR 306 IN DETAIL
1 Low coolant level*.
2 headlamp main beam.
3 Pre-heat (Diesel)*.
4 headlamp dipped beam.
5 Water in fuel filter warning light* (Diesel).
6 Speedometer.
7 Left indicator.
8 Low oil pressure warning light.
9 Gear indicator (automatic gearbox).
10 Handbrake low brake fluid level and electronic brake force distribution. 11
Battery charge.
12 Right indicator.
13 Rev counter.
14 Front fog lamps*.
15 Rear fog lamp.
16 ABS: anti-lock braking system*.
17 Fuel gauge.
18 Low fuel level.
19 Oil level.
20 STOP warning.
21 Seat belt not fastened warninglight*. 22
Disarming of passenger airbag**.
23 Side airbags warning light**.
24 Front* and side** airbag warninglight and disarming passengerairbag*.
25 Autodiagnostics*.
26 Trip recorder and service indicator.
27 Trip recorder zero reset and clocksetting.
28 Coolant temperature gauge.
* According to specification or country.
** According to model.
INSTRUMENT PANEL

1
B
A
DRIVING YOUR 306105
AUTOMATIC AUTOADAPTIVE GEARBOX Positions of the selector lever These positions are displayed on the instrument panel. P.
Park: use with the handbrake when parked.
R. Reverse: this must only be engaged when the vehicle is stationary and the engine idling.
N. Neutral: if Nis engaged by mistake while the car is moving, allow the engine
to return to idling speed before engaging a new forward gear.
D. Drive: in this position, the four gear ratios change automatically. The gearchange points vary depending on the programme selected.
3. Automatic changes of the first three gears only. Select this position when you notice frequent changes between third and fourth gear (town driving or on winding roads).
2 Automatic changes of the first two gears only. This position is particularly suitable for mountain roads, when going uphill (to make the best use of the engine's power) and downhill (engine braking).
1. Selection of first gear only.
For use on steep gradients, especially when towing a trailer.Selection of first gear is by pressing switch 1with the lever in position 2.
To exit position 1, press switch 1again or move the selector lever.
Starting
To start the engine, put the selector lever in
Nor P.
Press the brake pedal when starting the engine and to exit position P.

DRIVING YOUR 306
106
Any disruption of the system is signalled by thesimultaneous flashing ofthe Sport and Snow lightson the instrument panel. In
such a case, the gearbox will
operate in downgraded mode. Youmay feel a substantial knock whenreverse is selected from Por N
(without any risk of damage to thegearbox). Do not exceed 60 m.p.h. (100km/h). Contact a PEUGEOT dealer
without delay. When the engine is idling with the
car in gear, the car will move evenwithout you accelerating. Do not accelerate while a gear is being selected, when the vehicle is
stationary.
When stationary, have your foot on the brake pedal when selecting a
gear. Do not accelerate in gear with the brakes on. If work needs to be done with the engine running, apply the hand-brake and select position P.
Do not change down to brake onslippery roads. Never select position Nwhen the
vehicle is moving.Never engage Por Rif the vehicle
is not stationary.Do not allow children inside the vehicle unsupervised when theengine is running.
Operating programmes
You have a choice of three operating programmes:
- Auto-adaptive (normal).
- Sport.
- Snow.One press on button
Aor Bwill select
Sport or Snow respectively. The selec- tion is displayed on the instrumentpanel. Pressing the button a secondtime will return to the auto-adaptive(normal) programme. Auto-adaptive programme (normal) Gear changes are carried out on the basis of various parameters, such as:
- driving style,
- road characteristics,
- the vehicleÕs load.The gearbox continuously scans the
different programmes in the memoryand selects the one most suitable forthe driving conditions at any givenmoment. Sport programme The Sport programme favours perfor- mance for sporty driving and moredynamic acceleration. Snow Programme In position
Dthe Snow programme
provides smooth driving suited to slip- pery roads in order to improve trac-
tion and stability. Starting is in 2ndgear and changing down is at lowengine speeds. Special operating features
- During prolonged braking, the gearbox changes down automati-
cally, so as to provide efficientengine braking.
- If you take your foot off the accel- erator suddenly (when you aretaken by surprise, for example), thegearbox will not change up, so as to
improve safety.
-When the engine is cold, thegearbox automatically selects aspecial programme which enablesthe engine to reach its ideal tem-perature more quickly to decrease pollution.
Kickdown For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as
it will go. The gearbox will changedown automatically or stay in the gearselected, up to maximum enginespeed.

107
DRIVING YOUR 306
Handbrake Application When you have parked the vehicle, pull up the handbrake to apply it.
To ease application and release of the handbrake, press the brake pedal andpull up the handbrake with the enginerunning. Release Press the button before releasing the handbrake.THE ABS ANTI-LOCKBRAKING SYSTEM* In conjunction with tyres of an approved make and in good condition,
the ABS system with electronic brakeforce distribution improves the stabil-ity and handling of your vehicle, par-ticularly on an uneven or slipperysurface. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
Manual gearbox The positions are indicated on the gear lever knob. Reverse gear can only be engaged from neutral when the vehicle is
stationary, with the engine idling. Special features of the six speed gearbox* Raise the lock ring under the knobbefore engagingreverse. In the event of emergency braking,press very firmly without reducingthe pressure. In some conditions
the normal operation of the ABSmay be felt as vibrations of thebrake pedal.
* According to specification.
Power steering
This is a comfort device which offers the best compromise for parking, andfor driving at high speeds.

MAINTENANCE OF YOUR 30631
Power steering reservoir
Open the reservoir, with the engine cold, at outside temperature, the levelshould always be above the MINImark, close to the MAXI mark.
Windscreen and headlamp wash reservoir* For best quality cleaning and for your
safety, we recommend that you useproducts approved by PEUGEOT(capacity 4,4 litres or 6 litres withheadlight wash). Battery
At the start of winter, have your battery
checked by a PEUGEOT dealer. Air filter Regular replacement of the filter element is essential. If you drive invery dusty conditions, change it twiceas often. Brake pads Brake pad wear depends on the style of driving, in particular for vehicleswhich are used in town or for shortjourneys or which are driven in a
sporty manner, it may be necessaryto check the thickness of the padseven between services. Manual gearbox This does not need an oil change. Check the level according to the
manufacturerÕs service schedule. Autoadaptive automatic gearbox This does not need an oil change: have the level checked by a
PEUGEOT dealer according to the
manufacturerÕs service schedule.
Only use products appro-
ved by Automobiles
PEUGEOT.
To ensure best perfor-
mance from components as impor- tant as the power steering and the braking system, PEUGEOTselects and offers quite specific products. Fuel supply cut-off* In a serious collision, a system pre- vents fuel from reaching the engine.
To re-establish the fuel supply, press the switch on the angle of the front
left-hand suspension assembly, underthe bonnet.
* According to specification.

MAINTENANCE OF YOUR 30631
Power steering reservoir
Open the reservoir, with the engine cold, at outside temperature, the levelshould always be above the MINImark, close to the MAXI mark.
Windscreen and headlamp wash reservoir* For best quality cleaning and for your
safety, we recommend that you useproducts approved by PEUGEOT(capacity 4,4 litres or 6 litres withheadlight wash). Battery
At the start of winter, have your battery
checked by a PEUGEOT dealer. Air filter Regular replacement of the filter element is essential. If you drive invery dusty conditions, change it twiceas often. Brake pads Brake pad wear depends on the style of driving, in particular for vehicleswhich are used in town or for shortjourneys or which are driven in a
sporty manner, it may be necessaryto check the thickness of the padseven between services. Manual gearbox This does not need an oil change. Check the level according to the
manufacturerÕs service schedule. Autoadaptive automatic gearbox This does not need an oil change: have the level checked by a
PEUGEOT dealer according to the
manufacturerÕs service schedule.
Only use products appro-
ved by Automobiles
PEUGEOT.
To ensure best perfor-
mance from components as impor- tant as the power steering and the braking system, PEUGEOTselects and offers quite specific products. Fuel supply cut-off* In a serious collision, a system pre- vents fuel from reaching the engine.
To re-establish the fuel supply, press the switch on the angle of the front
left-hand suspension assembly, underthe bonnet.
* According to specification.
