Page 82 of 127

Peugeot 306 Dag 2002 Owners Manual 1
B
A
DRIVING YOUR 306105
AUTOMATIC AUTOADAPTIVE GEARBOX Positions of the selector lever These positions are displayed on the instrument panel. P.
Park: use with the handbrake when parked.
R. Reverse:

Page 111 of 127

Peugeot 306 Dag 2002 Owners Manual Fuse No. Rating*Functions*
15 20A Towing attachment
16 30A Front window and sun roof relay
17 20A Horn control
18 10A Front fog lamps
19 10A Right rear light
20 30A Ventilation - Heating and air con

Page 114 of 127

Peugeot 306 Dag 2002 Owners Manual TOWING
Without lifting (four wheels on the ground)
You must always use a towbar.From the front or the rearAttach the towbar to the towing eye.By lifting (two wheels only on the ground)It is preferab

Page 115 of 127

Peugeot 306 Dag 2002 Owners Manual MAINTENANCE OF YOUR 30647
Driving advice Distribution of loads: distribute the load in the trailer so that the heaviestloads are as close as possible to theaxle and the nose weight is close tothe maxi

MAINTENANCE OF YOUR 30647
Driving advice Distribution of loads: distribute the load in the trailer so that the heaviestloads are as close as possible to theaxle and the nose weight is close tothe maximum authorised without,
however, exceeding it. Cooling:
towing a trailer on a slope
increases the coolant temperature. As the fan is electrically controlled, itscooling capacity is not dependent onthe engine speed.
On the contrary, use a high gear to lower the engine speed, and reduceyour speed. The maximum towing load on a long slope depends on the gradient andthe outside temperature. In all cases, pay attention to the coolant temperature. If the warning light comes on, stop the
vehicle and switch off the engine assoon as possible.
TOWING A TRAILER,
CARAVAN, BOAT ETC.
Only use original PEUGEOT towbars which have been tested and appro-ved from the design stage of yourvehicle. The towbar must be fitted by a
PEUGEOT dealer.
Your vehicle is mainly designed for transporting people and luggage but it
may also be used to tow a trailer. Driving with a trailer subjects the towing vehicle to more significantforces and requires particular atten-
tion on the part of the driver. Air density decreases with altitude, thus also reducing engine perfor-
mance. Above 1000 metres, reducethe maximum towing load by 10 %and so on for each additional 1000 metres.
For use in arduous conditions(towed load at the limit of the Permis-
sible Gross Train Weight, in Summeron a long hill)
certain engines (1.9 l
Diesel) must be equipped with a
more resistant cooling system.
Consult a PEUGEOT dealer who, depending on your vehicle and what it
is used for, will be able to advise youabout suitable equipment. Pay attention to the coolant tempera- ture at all times. If the alarm warning light comes on,
stop the vehicle and switch off theengine as soon as possible.
Tyres: check the tyre pressures of the
towing vehicle and the trailer, obser- ving the recommended pressures. Brakes: towing increases the braking
distance. Drive at a moderate speed,
change down early, brake graduallyand avoid jerky braking. Lighting: adjust your headlamps so
as not to dazzle other road users. Check the electrical signalling on the
trailer. Side wind: sensitivity to side wind is
increased. Drive smoothly and at a moderate speed.

Page 123 of 127

Peugeot 306 Dag 2002 Owners Manual 116
TECHNICAL DATA
* The speed of a towing vehicle is limited to 60 mph (100 Km/h).
TOWING WEIGHTS AND LOADS (IN KG)
Engines
1.4 litre 1.6 litre 1.6 litre 1.8 litre 2 l 16 V 2 l 16 V 1.9 l D 2 l HDI
G

Page 124 of 127

Peugeot 306 Dag 2002 Owners Manual 117
TECHNICAL DATA
* The speed of a towing vehicle is limited to 60 mph (100 Km/h).
TOWING WEIGHTS AND LOADS (IN KG)
Engines
1.4 litre 1.6 litre 1.6 litre 1.8 litre 1.8 l 16 V 2 l 16 V 2 l 16 V 1.9 l
