gearbox Peugeot 307 Break 2002.5 Owner's Manual

Moving Off
With the engine running, to move
off from position P:
➜ It is essential to press the
brake pedal to exit position P,
➜ Select the required function(R ,D or M) then gradually
release the pressure on the
brake pedal; the vehicle will
move off immediately.
You can also move off from posi
tion N:
➜ Release the handbrake, with
your foot on the brake.
➜ Select the required function ( R,
D or M) then gradually release
the pressure on the brake
pedal; the vehicle will move off
immediately.
When the engine is idling
with the brakes not
applied, if function R, D or
M is selected, the vehicle
moves without the accel
erator being pressed.
For this reason, do not
leave children unsuper
vised inside the vehi
cle, with the engine
running.
126
1212YOUR 307 AT A GLANCE
AUTOMATIC GEARBOX
'PORSCHE TIPTRONIC SYSTEM'
The four speed automatic gearbox offers a choice between the comfort of
automatic integral regulation enhanced by a sportand snow pro
gramme, or the pleasure of manual gear changing.
Gear selection gate ➜ Move the lever in the gate to select one of the functions.
Once the function is selected, the indicator light for that function illumi
nates on the instrument panel display.
S: sport programme.


: snow programme.
Park: forparking or forstarting the
engine, with the handbrake on or off.
Reverse: to reverse ; select this function with
the vehicle stationary and the engine at idle.
Neutral: for starting the engine or for parking ,
with the handbrake on.
Note: if function Nis engaged by mistake while
the car is moving, allow the engine to return to
idling speed before engaging function Dto accel
erate.
D rive: for automatic gear changing.
Manual: for manual gear changing.
To change the four gears manually:
➜ Push the lever to the +symbol to change up to the next gear and pull
the lever towards the –symbol to change down to the next gear.
Note: the Ssport and snow programmes do not operate in manual mode.
09-09-2002

09-09-2002
PEUGEOT SERVICING25
A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT
Level
Operations Description of operation 1st Service
A C Intermediate
DRAIN/REFILL Engine oil Bleed fuel filter (diesel) Oil filter Fuel filter *(petrol)REPLACE Fuel filter element (diesel) Air filter element Spark plugs (petrol) Engine oil (check + topup) Manual gearbox oil (check + topup) Battery (check + topup) if cap is removableLevel Screen wash (check + topup) Coolant (check + topup) Brake fluid (check + topup) Power steering fluid (check + top up according to specification) Operation of lights and indicators Condition of glass, headlamp and light lenses and mirrors Horn Windscreen washer jets Condition of wiper blades Condition and tension of the ancillary drive belts Handbrake Condition of hydraulic circuits (hoses and covers)CHECK Condition of rubber boots and gaiters Brake pads Play in hubs, link rods, ball joints, flexible mountings Shock absorbers Rear drum brake lining wear. Condition and pressure of tyres (including spare wheel) Emission control check as per current legislation (petrol) Smoke opacity (diesel) Pollen filter (according to specification) Visual check of the whole vehicle
SERVICE* Courtesy vehicle
ROAD TEST
: All driving conditions: Arduous conditions * According to country.

09-09-2002
RECOMMENDATIONS FOR
APPROVED LUBRICANTS
The oils which appear in the table
opposite are suitable for most pur
poses.
The diagram opposite states the
optimum range of viscosity depend
ing on the temperatures at which the
oils are to be used.
It is also possible to use "superior
quality" synthetic oils.
In the absence of semisynthetic or
synthetic oils, oils of API SH/SJ qual
ity (for petrol engines), or CD/CF
quality (for diesel engines) may be
used by following the "Arduous
Conditions" servicing schedule,
which specifies shorter intervals.
Do not hesitate to ask for advice from
a PEUGEOT dealer to maintain dri
ving pleasure and to minimise the
maintenance cost of your vehicle.
For countries outside Europe, please
contact a local PEUGEOT dealer.
PEUGEOT SERVICING27
Manual
ONLY ONLY
Gearbox ESSO Gear Oil BV TOTAL TRANSMISSION BV 75W80 PR 9736.41 75W80
AutomaticONLY
GearboxATF 4HP20AL4PR 9736.22
Other approved products
Power steering FLUIDE DA PR 9730. A1
Brake fluid PEUGEOT DOT4
Coolant
ONLY PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000
Protection to minus 35C

09-09-2002
1 Rev counter.
2 Seat belt not fastened warning
light.
3 Engine diagnostics warning
light.
4 Handbrake and low brake fluid
level warning light.
5 Lefthand direction indicator.
6 Coolant temperature indicator. 7
Battery charge warning light.
8 Central (STOP) warning light.
9 Engine oil pressure warning
light.
10 Low fuel level warning light.
11 Righthand direction indicator.
12 Fuel gauge.
13 ABS warning light. 14
Air bag warning light.indicator
light.
16 Speedometer.
17 Service indicator, oil level and
total distance recorder.
18 Trip recorder zero reset.
19 Rear fog lamp indicator light.
20 ESP/ASR warning light
21 Front fog lamps indicator
light.
22 Diesel engine preheating light.
23 Main beam headlamps
indicator light.
24 Low coolant level warning light.
25 Dipped beam headlamps
indicator light.
26 Water in diesel filter warning
light.
27 Lighting rheostat.
INSTRUMENTS AND CONTROLS
28
PETROL / DIESEL INSTRUMENT PANEL DIALS: MANUAL GEARBOX

09-09-2002
INSTRUMENTS AND CONTROLS29
1
Rev counter.
2 Seat belt not fastened warning
light.
3 Engine diagnostics warning
light.
4 Handbrake and low brake fluid
level warning light.
5 Lefthand direction indicator.
6 Coolant temperature indicator. 7
Battery charge warning light.
8 Central (STOP) warning light.
9 Engine oil pressure warning
light.
10 Low fuel level warning light.
11 Righthand direction indicator.
12 Fuel gauge.
13 ABS warning light. 14
Air bag warning light.
15 Passenger air bag disarming
indicator light.
16 Speedometer.
17 Service indicator, oil level and
total distance recorder.
18 Trip recorder zero reset.
19 Rear fog lamp indicator
light.
20 ESP/ASR warning light
21 Front fog lamps indicator light.
22 Main beam headlamps indicator
light.
23 Low coolant level warning light.
24 Dipped beam headlamps
indicator light.
25 Lighting rheostat.
26 Sport programme indicator light.
27 Snow programme indicator
light.
28 Gear lever position indicator.
PETROL INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX

"SPORT" indicator light
This comes on when the "SPORT"programme on
the automatic gearbox is selected.
"SNOW" indicator light
This comes on when the "SNOW"programme on
the automatic gearbox is selected.
Park
Reverse
Neutral
Drive
Manual mode: 1st gear engaged
2nd gear engaged
3rd gear engaged
4th gear engaged
INSTRUMENTS AND CONTROLS 33
Selector lever positions on the automatic
gearbox display Automatic gearbox indicator lights
09-09-2002

09-09-2002
Membuka penguncian
Tarik tuas dan tekan tombol untuk melepaskan rem tangan.Menyalanya indikator perin-gatan yang disertai dengansinyal akustik dan pesan"Handbrake still applied" di
display multifungsi menunjuk-
kan bahwa rem tangan masih terpa-sang atau tidak dilepas dengan baik.
Gangguan pengoperasian Setiap gangguan yang terjadi pada pengoperasian diinformasikan mela-lui sinyal akustik yang disertai pesan"Automatic gearbox faulty" di dis-
play multifungsi dan lampu peringa-tan Sport dan Musim Dingin di panelinstrumen yang berkedip. Dalam hal ini, transmisi berfungsi dalam mode darurat (penguncian
pada rasio ketiga). Anda dapat mera-sakan hentakan keras saat meng-ganti posisi dari Pke Rdan dari Nke
R (hentakan ini tidak akan merusak
transmisi). Jangan melampaui kecepatan
100 km/jam sesuai batasan padaperaturan setempat. Hubungi Dealer servis resmi
PEUGEOT sesegera mungkin. SISTEM PENGEREMAN ABS
Sistem ABS dengan Distribusi daya pengereman elektronis (EBFD)meningkatkan stabilitas dan gerakan
manuver kendaraan Anda, terutamapada permukaan jalan yang rusakatau licin. Catatan :
jika mengganti roda (ban
dan velg), gantilah dengan yang telah direkomendasikan.
Sistem ABS akan berfungsi secara otomatis jika ada risiko penguncianroda.
Indikator peringatan yangmenyala, yang disertaisinyal akustik dan pesan"Braking fault" di display
multifungsi ini mengindikasi-
kan adanya disfungsi pada distribusidaya pengereman elektronis yangdapat menyebabkan hilangnya ken-dali kendaraan saat pengereman.
Anda harus menghentikan kendaraan.
Hubungi Dealer servis resmi PEU-
GEOT.
REM TANGAN Mengunci
Tarik rem tangan untuk menghenti-
kan kendaraan Anda. Perhatian :
bila parkir pada permu-
kaan yang miring, putar roda kenda- raan hingga menempel ke trotoardan tarik rem tangan.
SELENGKAPNYA 307 ANDA
128
Jika baterai habis dan tuas dalam posisi P, per-
pindahan gigi ke posisilain tidak dapat dilakukan. Pengoperasian normal sistem ABSdapat diketahui pengemudi melaluigetaran ringan pada pedal rem. Jika harus melakukan pengere- man mendadak, tekan pedalrem dengan kuat dan kemudiantahan.

09-09-2002
Membuka penguncian
Tarik tuas dan tekan tombol untuk melepaskan rem tangan.Menyalanya indikator perin-gatan yang disertai dengansinyal akustik dan pesan"Handbrake still applied" di
display multifungsi menunjuk-
kan bahwa rem tangan masih terpa-sang atau tidak dilepas dengan baik.
Gangguan pengoperasian Setiap gangguan yang terjadi pada pengoperasian diinformasikan mela-lui sinyal akustik yang disertai pesan"Automatic gearbox faulty" di dis-
play multifungsi dan lampu peringa-tan Sport dan Musim Dingin di panelinstrumen yang berkedip. Dalam hal ini, transmisi berfungsi dalam mode darurat (penguncian
pada rasio ketiga). Anda dapat mera-sakan hentakan keras saat meng-ganti posisi dari Pke Rdan dari Nke
R (hentakan ini tidak akan merusak
transmisi). Jangan melampaui kecepatan
100 km/jam sesuai batasan padaperaturan setempat. Hubungi Dealer servis resmi
PEUGEOT sesegera mungkin. SISTEM PENGEREMAN ABS
Sistem ABS dengan Distribusi daya pengereman elektronis (EBFD)meningkatkan stabilitas dan gerakan
manuver kendaraan Anda, terutamapada permukaan jalan yang rusakatau licin. Catatan :
jika mengganti roda (ban
dan velg), gantilah dengan yang telah direkomendasikan.
Sistem ABS akan berfungsi secara otomatis jika ada risiko penguncianroda.
Indikator peringatan yangmenyala, yang disertaisinyal akustik dan pesan"Braking fault" di display
multifungsi ini mengindikasi-
kan adanya disfungsi pada distribusidaya pengereman elektronis yangdapat menyebabkan hilangnya ken-dali kendaraan saat pengereman.
Anda harus menghentikan kendaraan.
Hubungi Dealer servis resmi PEU-
GEOT.
REM TANGAN Mengunci
Tarik rem tangan untuk menghenti-
kan kendaraan Anda. Perhatian :
bila parkir pada permu-
kaan yang miring, putar roda kenda- raan hingga menempel ke trotoardan tarik rem tangan.
SELENGKAPNYA 307 ANDA
128
Jika baterai habis dan tuas dalam posisi P, per-
pindahan gigi ke posisilain tidak dapat dilakukan. Pengoperasian normal sistem ABSdapat diketahui pengemudi melaluigetaran ringan pada pedal rem. Jika harus melakukan pengere- man mendadak, tekan pedalrem dengan kuat dan kemudiantahan.

09-09-2002
Only use products
approved by Automobiles
PEUGEOT.
To ensure best perfor
mance from components
as important as the power steering
and the braking system,
PEUGEOT selects and offers quite
specific products.
CHECKS
Battery
At the start of winter, have your bat
tery checked by a PEUGEOT dealer.
Air filter and pollen filter
Have the filter elements replaced
regularly. If you drive in dusty con
ditions, change them twice as
often.
Brake pads
Brake pad wear depends on the style
of driving, in particular for vehicles
which are used in town, over short
distances. It may be necessary to
check the thickness of the pads,
even between services.
Parking brake
Where the parking brake travel is too
great or there is a reduction in the
performance of the system, the
handbrake should be adjusted, even
between services.
Have the system checked by a
PEUGEOT dealer. Manual gearbox
This does not need an oil change.
Check the level, according to the
manufacturer's servicing schedule.
Automatic gearbox
This does not need an oil change.
Have the level checked by a
PEUGEOT dealer, according to the
manufacturer's servicing schedule.
Oil filter
Change the filter regularly, in accor
dance with the servicing schedule.
RUNNING OUT OF FUEL
(DIESEL)
If you should run out of fuel, it is
necessary to reprime the circuit:
1.4 litre HDI engine
fill the fuel tank with at least five
litres of diesel,
operate the manual repriming pump, under the bonnet, until fuel
appears in the transparent pipe
under the bonnet,
operate the starter until the engine starts.
2 litre HDI engine
fill the fuel tank with at least five litres of diesel,
operate the manual repriming pump, under the bonnet, until
you feel resistance during the
manoeuvre,
operate the starter until the engine starts.
PRACTICAL INFORMATION 141

09-09-2002
CHANGING A WHEEL
(SALOON)
Parking the vehicle Park the vehicle on level, stable
and nonslippery ground.
Apply the handbrake, switch off
the ignition and engage first or
reverse gear (position Pfor the
automatic gearbox) .
Access to the spare wheel and
the jack in the boot Lift the floor using the handle and
secure it by hooking the cords to
the hooks of the parcel shelf. Tools
The following tools are located in a
polystyrene holder in the centre of
the spare wheel:
1
Wheelbrace.
2 Centralising tool.
3 Removable chock.
4 Jack with handle.
5 Removable towing eye.
6 Alloy wheel bolt trim remover. Removing the wheel
Place the holder and the chock
3(or chock 3 on its own if neces
sary) under the wheel diagonally
opposite to the one to be
changed.
Remove the trim, using the
wheelbrace 1, pulling at the valve
passage hole.
Loosen the wheel bolts (for vehi
cles fitted with alloy wheels,
remove the chrome trim first. See
paragraph on 'Special features of
alloy wheels').
PRACTICAL INFORMATION
142
