tow Peugeot 307 SW 2002 Owner's Manual

5YOUR 307 SW AT A GLANCE
STEERING WHEEL
STALKS LIGHTING
Front and rear lights (ring A)
Lights off. Side lights.
Dipped / main beam headlamps. Automatic switching on of lights
Automatic switching on of lights
To activate or disarm this func- tion, place the key in the acces-sories posiiton, the lighting stalkin position 0and press for more
than two seconds on the end ofthe stalk.Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp (rotationof the ring forwards)
Vehicles fitted with front foglamps and a rear fog lamp(ring C) Front fog lamps (first rota-tion of the ring forwards)
Front fog lampsand rear fog lamp(second rotation ofthe ring forwards)
Switching off: rotation ofthe ring backwards.
77
WINDSCREEN WIPERS Front 2 Rapid wipe
1 Normal wipe
I Intermittent wipe
or
AUTO Automatic wipe
0 Off
Single wipe
Windscreen wash: pull the stalk towards you. Rear
Off. Intermittent wipe.
Automatic wipe In the AUTO position,
the wiper operates auto- matically and adjusts its
speed to the intensityof the rainfall.
79
Windscreen wash

12YOUR 307 SW AT A GLANCE
AUTOMATIC GEARBOX "PORSCHE TIPTRONIC SYSTEM" The four speed automaticgearbox offers a
choice between the comfort of automatic inte-
gral regulation enhanced by a sportand snow
programme , or the pleasure of manual gear
changing.
Gear selection gate ➜ Move the lever in the gate to select one of the functions. Once the function is selected, the indicator light for that function illuminates on the instru-
ment panel display.
S : sport programme.

: snow programme.
P ark: to immobilise the vehicle or to start the engine , with the hand-
brake on or off.
R everse: to reverse(select this function with the vehicle stationary and
the engine at idle).
N eutral: to start the engine or to park, with the handbrake on.
Note: if position Nis engaged by mistake while the car is moving, allow the
engine to return to idling speed before engaging function Dto accelerate.
D rive: for automatic gear changing.
M anual: for manual gear changing.
To change the four gearsmanually:
➜ Push the lever to the +symbol to change up to the next gear and pull
it towards the -symbol to change down a gear.
Note: the S(sport) and
(snow) programmes do not operate in manual
mode. Moving Off With the engine running, to move
off from position
P:
➜ It is essential to press thebrake pedal to exit positionP,
➜ Select function R, D or M, then
gradually release the pressureon the brake pedal; the vehicle
will move off immediately.
You can also move off from posi-tion N:
➜ Release the handbrake, withyour foot on the brake.
➜ Select function R, D or Mthen
gradually release the pressureon the brake pedal; the vehicle
will move off immediately.
When the engine is idling
with the brakes notapplied, if function R, Dor M is selected, thevehicle moves without the acce-lerator being pressed.
For this reason, do not leave
children unsupervised inside the vehicle, with the enginerunning.
93

ARDUOUS CONDITIONS OF USE
¥ Continuous door-to-door use.
¥ Town use (e.g. taxi).¥ Repeated short journeys, with the engine cold at low temperatures.
¥ A prolonged stay under the following conditions : Ð countries with temperatures often above +30 ¡C,Ð countries with temperatures often below -15 ¡C,Ð countries with a dusty atmosphere,Ð countries whose lubricants or fuels do not conform to our recommendations.
Recommendations: Ð replace the air filter every 24,000 miles (40 000 km) for petrol engines and every 27,000 miles (45 000 km) for diesel
engines,
Ð to replace the timing belt, contact a PEUGEOT dealer.
PEUGEOT SERVICING
24

Manual operation
If you wish, you can make a different
choice from that offered by the sys-
tem by changing a setting. The otherfunctions will still be controlled auto-
matically. Pressing the "AUTO" but-ton returns the system to completelyautomatic operation.
4. Air conditioningPress this button to switch
off the air conditioning. Thesymbol "ECO" is displayed.Automatic operation of the
air conditioning is resumed when the
button is pressed again. The symbol"A/C" is displayed. Note It is quite normal that the condensa- tion created by the air conditioningresults in a flow of water under the
vehicle when it is stationary.
5. Air distribution
Pressing this button several times in successionenables the air flow to bedirected in turn towards:
Ð the windscreen (de-icing or demis- ting), Ð the windscreen and the footwells,
Ð the footwells,
Ð the centre and side vents and the
footwells,
Ð the centre and side vents.
6. Air flow
The flow of air can be increased or reducedby pressing buttons +
or - respectively.
7. Air intake Press this button to enablethe interior air to be recir-culated. Recirculation,
shown on the display,
enables the passenger compartmentto be insulated from exterior odoursand smoke.
Avoid prolonged recirculation of
interior air. To do this, press the but-ton again to resume intake of exte-
rior air. 8. Switching the system off
The "OFF" button enablesthe entire system to be swit-
ched off.
9. Demisting the rear screen Press this button to demistthe rear screen and the mir-
rors. Demisting switches off
automatically. It is possibleto stop operation of the
demisting before it is switched offautomatically by pressing the buttonagain.
Important precaution Operate the air conditioning for 5 to 10 minutes, once or twice a month,
to keep it in good working order. If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer. Note: to optimise the operation of
the air conditioning, leave the vents open.
YOUR 307 SW IN DETAIL 55

FRONT SEATS
1. Forwards/backwards adjustment Lift the control and slide the seat forwards or backwards.
2. Seat back angle adjustment Push the handle towards the rear.
3. Driver's or passenger's seat height adjustment Pull the handle upwards or push it downwards as many times asnecessary to obtain the requiredposition.
4. Armrests These can be folded down andare removable.
To remove them, press the but- ton located between the armrestand the side of the seat and pullit.
YOUR 307 SW IN DETAIL
56

THE LIGHTS STALK Front and rear lights Selection is by turning ring A.
Lights off Side lights Dipped/Main beam headlamps Automatic switching on of lights Dipped/Main beam change Pull the stalk towards you. Note:
with the ignition off, when the
driver's door is opened, a buzzer sounds if you have left your lights on. Front fog lamps and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The statusis confirmed by the light on the instru-ment panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This operates with the dipped/main beam headlamps.
Vehicles fitted with front fog lamps and a rear fog lamp (ring C) Front fog lamps (first rota- tion of the ring forwards)
These operate with the side lightsand the dipped beam headlamps. Front and rear foglamps (2nd rotation ofthe ring forwards). These operate with the
side lights and the dipped/main beam headlamps. Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring backwards twice in succession. Direction indicators (flashers)
Left : downwards.
Right : upwards.
YOUR 307 SW IN DETAIL 77
In good or rainy weather, both day and night, therear fog lamp is dazzlingand is prohibited. Do not forget to switch
the fog lamp off when it is no lon- ger needed.

WINDSCREEN WIPER STALK Stalk with intermittent wipe Front windscreen wiper2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.
Single wipe (press downwards). Stalk with automatic wipeFront windscreen wiper
2 Fast wipe (heavy rain).
1 ormal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
Single wipe (press downwards). OperationIn position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, then resumesits initial speed when the vehicle startsagain. In the Intermittent position, the wiping speed is proportional to the speed ofthe vehicle. In the AUTO position, the wiping speed
is proportional to the heaviness of the rain. When the ignition has been swit- ched off for more than one minutewith the stalk in the wipe position, itis necesary to reactivate this func-tion. To do this, move the stalk to any
position, then move it back to the requi-red position.
Windscreen wash Pull the wipers stalk towards you. The windscreen wash, then the windscreen wipers, operate for afixed period.
YOUR 307 SW IN DETAIL 79

YOUR 307 SW IN DETAIL91
BOOT LAYOUT
1 - Grab handles and coat hooks
2 - High load retaining net fastenings The high load retaining net can be fitted in the 2nd or
3rd row. Open the covers of the corresponding upper faste- nings. Fit the ends of the metal bar in these fastenings.Secure the two opaque material strap hooks in the sto-
wing rings on the floor. The rings are located directly below the corresponding upper fastenings. Pull the two straps taut.Secure the two hooks on the elastic parts of the opaque material in these rings. Note: the net must be positioned so that the label can
be seen from the boot. This ensures that the central
seat belt is routed correctly.
3 - 12V Socket for accessories This is a 12 volt socket (lighter type), installed on thetonneau left support.
It is supplied with the ignition off.
4 - Rear armrests with grab handle
5 - Storage nets One of them contains the luggage retaining net. 6 - Tonneau
To install it:
Ð position one end of the tonneau roller in the 2nd row,
Ð compress the opposite end of the roller and position it,
Ð release it to allow it to engage,
Ð unroll the tonneau as far as the boot pillars,
Ð insert the tonneau guides in the rails in the pillars. To remove it:
Ð remove the tonneau guides from the pillar rails,
Ð return the tonneau into its roller,
Ð compress it and remove it from its support at the 2nd row,
To store it, pull it back and place it with the two storage nets, already lowered. Note: the roller has two hooks for securing the lugga-
ge retaining net depending on where it is installed.
7 - Luggage retaining net Secure the net's seven hooks in the stowing rings and
the fastenings on the floor.
8 - Luggage retaining net fastenings ("hammock" version) in the tailgate Fold the net in two. Secure the two centre hooks in the stowing rings on the
floor. Secure the net's remaining four hooks on the boot pillars.
See configuration of the nets (next page)

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"handbrake on" on the
multi-function display, indi-cates that the handbrake is
still on or has not been properlyreleased.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation thegearbox operates in downgrade
mode (locked in 3rd gear). You mayfeel a substantial knock when chan-ging from Pto Rand from Nto R
(this will not cause any damage tothe gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. When this warning lightcomes on, accompanied byan audible signal and themessage
"Braking fault"
on the multi-function display
it indicates that there is a malfunctionof the electronic brake force distribu-tion, which can cause a loss ofcontrol of the vehicle when braking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS system with Electronic Brake Force Distribution (EBFD)increases the stability and manoeu-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 SW IN DETAIL 95
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking
pressure to be reached more quickly,thus reducing the stopping distance. It is triggered according to the speed
of activation of the brake pedal. The
effect of this is a reduction in theresistance of the pedal and an
increase in braking efficiency.

Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"handbrake on" on the
multi-function display, indi-cates that the handbrake is
still on or has not been properlyreleased.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation thegearbox operates in downgrade
mode (locked in 3rd gear). You mayfeel a substantial knock when chan-ging from Pto Rand from Nto R
(this will not cause any damage tothe gearbox). Do not exceed 60 mph (100 km/h), speed restrictions permitting.
Contact a PEUGEOT dealer as soon as possible. When this warning lightcomes on, accompanied byan audible signal and themessage
"Braking fault"
on the multi-function display
it indicates that there is a malfunctionof the electronic brake force distribu-tion, which can cause a loss ofcontrol of the vehicle when braking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS system with Electronic Brake Force Distribution (EBFD)increases the stability and manoeu-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 SW IN DETAIL 95
If the battery is flat and the lever is in position
P, it
will be impossible tochange to another posi-tion.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking
pressure to be reached more quickly,thus reducing the stopping distance. It is triggered according to the speed
of activation of the brake pedal. The
effect of this is a reduction in theresistance of the pedal and an
increase in braking efficiency.
