Peugeot 307 SW Dag 2002 Owner's Manual

TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP) These systems are linked and com-
plement the ABS system.
The ASR system optimises drive to prevent the wheels skidding, byacting on the brakes of the drivewheels and on the engine. It alsoallows the directional stability of thevehicle to be improved on accelera-tion. If there is a variation between the tra- jectory followed by the vehicle and
that required by the driver, the ESPsystem automatically acts on theengine and the brake of one or morewheels, in order to put the vehicleback on course.
Operation of the ASR and
ESP systemsWhen one of these two sys- tems is operating, this lightflashes. Disarming the ESP / ASR systems* In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheels spinand regain grip.
Press the switch "ESP OFF",
situated on the central part of the fascia.
The switch lights up and theindicator light comes on; the
ESP and ASR systems nolonger act on the brake andengine operation.
They engage again: automatically above 30 km/h,
manually by pressing the switch again.
* According to destination. Operating check
When a malfunction of thesystem occurs, the switchlight flashes and the indica-tor light comes on, accom-panied by an audible signal
and the message "ESP/ASR not
operational" on the multifunction
display.
Contact a PEUGEOT dealer to have the system checked.
YOUR 307 SW IN DETAIL
96
The ESP system offers increased safety duringnormal driving, but shouldnot incite the driver totake risks or to drive at
high speed. The operation of the system is ensured to the extent to which therecommendations of the manufac-turer regarding the wheels (tyresand wheel rims), the braking com-ponents, the electronic compo-nents and the assembly and repairprocedures within the PEUGEOTnetwork are observed. After an impact, have the system
checked by a PEUGEOT dealer.

CRUISE CONTROL Cruise control enables the vehicle to maintain a steady speed program-
med by the driver, regardless of theroad characteristics and without thedriver having to touch the acceleratoror brake pedals. In order for it to be memorised, the vehicle speed must be greater thanapproximately 40 km/h.Operation
Place switch 1in the ONposition.
A speed can be memorised. Place switch 1in the OFFposi-
tion to cancel.
Memorising a speed As soon as you reach the chosen speed, press button 2or 3.
This memorises the speed, which will
be maintained automatically. Note: It is possible to accelerate
momentarily without disarming the cruise control. Cancelling the memorised speed If you wish to cancel the memorised speed: Press button 4or the brake or
clutch pedal. Recalling the memorised speed After cancellation, press button
4.
Your vehicle will return to the last memorised speed. Changing a memorised speed
To memorise a speed higher than the previous one: press button 3;
release it when you have rea- ched the required speed.
To memorise a speed lower than theprevious one: press button 2;
release it when you have rea- ched the required speed.
Cancelling the cruise control place switch 1in the OFFposi-
tion or switch off the ignition.
YOUR 307 SW IN DETAIL 97
Do not use cruise control on slippery roads or inheavy traffic.

REAR PARKING ASSISTANCE This system consists of four proximi- ty sensors, located in the rear bum-
per, and a special speaker fitted inthe fascia. This detects any obstacle (person, vehicle, tree, gate, pavement etc.)behind the vehicle. Note:this function will be disarmed
automatically when the vehicle is towing a trailer or when a bicycle car-rier is fitted (vehicle fitted with towingattachment or bicycle carrier recom-mended by PEUGEOT). In wintry
weather, ensure that the sensors are
not covered with frost or snow.
Activation The system is activated as soon as reverse gear is engaged; an audiblebleep shows that it is active. The proximity information is given by an audible signal, which becomesmore rapid as the vehicleapproaches the obstacle. When distance between the rear of the vehicle and the obstacle is lessthan approximately twenty-five centi-metres, the audible signal becomescontinuous.Deactivation
Change to neutral, the system is again inactive.
YOUR 307 SW IN DETAIL
98
Detection zone
If there is an operating fault, the audible signalwill be a short bleep follo-wed by a long bleep when
changing to reverse gear.

AIR BAGS The air bags have been designed to maximise the safety of the occupantsin the event of serious collisions.They works in conjunction with theforce-limiting seat belts. The electronic detectors register and analyse any abrupt deceleration ofthe vehicle: if the triggering thresholdis reached the air bags inflate ins-tantly and protect the occupants ofthe vehicle. Immediately after the impact, the air
bags deflate rapidly, so that they donot hinder the visibility of the occu-pants and their exit if necessary fromthe vehicle. The air bags are not deployed in the case of collisions which are notserious, for which the seat belt is suf-ficient to ensure maximum protec-
tion. The seriousness of a collisiondepends on the nature of the obs-tacle and the speed of the vehicle atthe moment of the collision. Air bags only operate when the ignition is switched on. Note: the gas escaping from the
cushion can be a minor irritant. FRONT AIR BAGS These are folded in the centre of the steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,except in cases where the air bag isdisarmed. Front air bag fault
If this warning light comes on, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multi-function display,
contact a PEUGEOT dealer to havethe system checked. Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the pas-senger air bag when you install arear-facing child seat on the frontpassenger seat.
With the ignition switched off, insert the key into the passengerair bag disarming slot 1, turn it to
the "OFF" position, then remove
it keeping the slot in this position.
The air bag warning light on the instru-ment panel is lit throughout the disar-ming process.
* According to destination.
YOUR 307 SW IN DETAIL 99

In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is removed, turn the air bag slot to the "ON" posi-
tion to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
With the ignition on (2ndnotch), illumination of thiswarning light accompaniedby an audible signal and themessage "Passenger air
bag disarmed" on the multi-function
display, indicates that the passengerair bag is disarmed (slot in the "OFF"
position). SIDE AIR BAGS* AND
CURTAIN AIR BAGS* The side air bags are incorporated into the front seat backs on the doorside. The curtain air bags are incorporated into the door pillars and the upperpart of the passenger compartment. They are deployed independently of each other depending on which sidethe collision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multi-function display,
contact a PEUGEOT dealer to havethe system checked.
* According to destination.
YOUR 307 SW IN DETAIL
100

For the front, side* and curtain* air bags to be fully effective, observe the following safety rules:
¥Wear a correctly adjusted seat belt.
¥ Sit in a normal upright position.
¥ Do not leave anything between the occupants of the front seats and the air bags (pet, child, object...). This could hamper the operation of the air bags or injure the occupants.
¥ All work on the air bag system is strictly forbidden unless it is carried out by qualified personnel of the PEUGEOT network.
¥ After an accident or if the vehicle has been stolen or broken into, have the air bag systems checked.
¥ The air bag systems have been designed to be fully operational for 10 years after the vehicle has been registered.Have them replaced by a PEUGEOT dealer after this period.
Front air bags
¥ Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.
¥ Passengers must not place their feet on the fascia
¥ Smoke as little as possible; deployment of the air bags can cause burns or the risk of injury from a cigarette or pipe.
¥ Never remove or pierce the steering wheel or hit it violently.
Side air bags*
¥ Only put approved covers on the front seats. Contact your PEUGEOT dealer.
¥ Do not fix or glue anything to the front seat backs. This could cause injury to the chest or arms when the side air baginflates.
¥ Do not sit with the upper part of the body any nearer to the door than necessary.
Curtain air bags*
¥ Do not fix or glue anything to the pillars or the roof. This could cause injury to the head when the curtain air baginflates. Do not remove the bolts from the grab handles installed on the roof, they play a part in securing the curtain air bags.
* According to destination.
YOUR 307 SW IN DETAIL101

In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is removed, turn the air bag slot to the "ON" posi-
tion to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
With the ignition on (2ndnotch), illumination of thiswarning light accompaniedby an audible signal and themessage "Passenger air
bag disarmed" on the multi-function
display, indicates that the passengerair bag is disarmed (slot in the "OFF"
position). SIDE AIR BAGS* AND
CURTAIN AIR BAGS* The side air bags are incorporated into the front seat backs on the doorside. The curtain air bags are incorporated into the door pillars and the upperpart of the passenger compartment. They are deployed independently of each other depending on which sidethe collision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comeson, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multi-function display,
contact a PEUGEOT dealer to havethe system checked.
* According to destination.
YOUR 307 SW IN DETAIL
100

For the front, side* and curtain* air bags to be fully effective, observe the following safety rules:
¥Wear a correctly adjusted seat belt.
¥ Sit in a normal upright position.
¥ Do not leave anything between the occupants of the front seats and the air bags (pet, child, object...). This could hamper the operation of the air bags or injure the occupants.
¥ All work on the air bag system is strictly forbidden unless it is carried out by qualified personnel of the PEUGEOT network.
¥ After an accident or if the vehicle has been stolen or broken into, have the air bag systems checked.
¥ The air bag systems have been designed to be fully operational for 10 years after the vehicle has been registered.Have them replaced by a PEUGEOT dealer after this period.
Front air bags
¥ Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.
¥ Passengers must not place their feet on the fascia
¥ Smoke as little as possible; deployment of the air bags can cause burns or the risk of injury from a cigarette or pipe.
¥ Never remove or pierce the steering wheel or hit it violently.
Side air bags*
¥ Only put approved covers on the front seats. Contact your PEUGEOT dealer.
¥ Do not fix or glue anything to the front seat backs. This could cause injury to the chest or arms when the side air baginflates.
¥ Do not sit with the upper part of the body any nearer to the door than necessary.
Curtain air bags*
¥ Do not fix or glue anything to the pillars or the roof. This could cause injury to the head when the curtain air baginflates. Do not remove the bolts from the grab handles installed on the roof, they play a part in securing the curtain air bags.
* According to destination.
YOUR 307 SW IN DETAIL101

PRACTICAL INFORMATION
102
1.6 LITRE 16V PETROL ENGINE 1 -
Power steering reservoir.
2 - Wash/wipe and headlamp wash
reservoir. 3 -
Coolant reservoir.
4 - Brake fluid reservoir.
5 - Battery.
6 - Fuse box. 7 -
Air filter.
8 - Dipstick.
9 - Engine oil filler cap.

PRACTICAL INFORMATION103
2 LITRE 16V PETROL ENGINE 1 -
Power steering reservoir.
2 - Windscreen/headlamp wash
reservoir. 3 -
Coolant reservoir.
4 - Brake fluid reservoir.
5 - Battery.
6 - Fuse box. 7 -
Air filter.
8 - Dipstick.
9 - Engine oil filler cap.
