Peugeot 307 SW Dag 2004 Owner's Manual

15-03-200415-03-2004
104105YOUR 307 SW IN DETAIL
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped / Main beam change
Pull the stalk towards you.
Note:
with the ignition off, when the
driver's door is opened, a buzzer
sounds if you have left your lights
on.
Front fog lamps and rear fog lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel. Vehicles itted with front fog
lamps and a rear fog lamp (ring C)
Lights off
Side lights
Dipped / main beam
headlampsAutomatic switching on
of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off
the rear fog lamp and the front fog
lamps, turn the ring backwards twice
in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights will remain
on (turn the ring backwards to switch
off the front fog lamps. The side lights
will then be switched off).
Vehicles itted with a rear fog
lamp (ring B)
This only operates with the dipped /
main beam headlamps.
Note:
when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps will re-
main on (turn the ring backwards
to switch off the rear fog lamp. The
dipped headlamps and side lights will
then be switched off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.

15-03-200415-03-2004
104105
"Follow me home" lighting
In poor light or at night, if you leave
your vehicle, the side lights and
dipped headlamps can be left on for
approximately one minute.
To do this:
- place the key in the STOP posi-
tion,
- place the lights stalk in the 0 posi-
tion,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the vehi-
cle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/
0 position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
YOUR 307 SW IN DETAIL
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards.

15-03-200415-03-2004
106107YOUR 307 SW IN DETAIL
WINDSCREEN WIPER STALK
Front windscreen wiper with
intermittent wipe
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
l Intermittent wipe.
0 Off.
ê Single wipe (press downwards).
In the Intermittent position, the wip-
ing speed is in proportion to the ve-
hicle speed. Front windscreen wiper with
automatic wipe
2
Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.
ê Single wipe (press downwards).
In the AUTO position, the wiping
speed is in proportion to the intensity
of the rainfall. The command must be reactivated
each time the ignition is switched
back on:
- move the stalk to any position,
- then move it back to the required
position.
Special position of the front
windscreen wiper
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen.
This action enables you to position
the wiper blades for winter parking,
cleaning or replacement (See sec-
tion "Practical information -
Chang-
ing a wiper blade").
To park the wipers after this has
been done, switch on the ignition and
operate the stalk.
Windscreen and headlamp wash
Pull the windscreen wiper stalk to-
wards you.
The windscreen wash then the wind-
screen wipers operate for a ixed
period.
The windscreen wash and headlamp
wash operate simultaneously for two
seconds, only if the headlamps are
on .

15-03-200415-03-2004
106107YOUR 307 SW IN DETAIL
Automatic windscreen wipers
In the AUTO position, the wind-
screen wipers operate automatically
and adapt their speed to the intensity
of the rainfall.
Operating check
Activation
When the function is activated, the
message "Automatic wiping ac-
tive" appears on the multi-function
display.
Disarming
In the event of malfunction , the
driver is informed by an audible sig-
nal and the message "Auto wiper
fault" on the multi-function display.
In the AUTO position, the wind-
screen wiper will operate in intermit-
tent mode.
Contact a PEUGEOT dealer to have
the system checked.
Do not cover the rain sen-
sor located on the wind-
screen behind the interior
mirror.
When using an automatic car
wash, switch off the ignition or
check that the wiper stalk is not in
the automatic position.
In winter, it is advisable to wait
for the windscreen to completely
clear of ice before operating the
automatic wipe. Rear windscreen wiper
Turn ring A to the irst notch
for intermittent wiping.
Rear windscreen wash
Turn ring A past the irst
notch; the windscreen wash
then the windscreen wiper
operate for a ixed period.

15-03-200415-03-2004
108109
TRIP COMPUTERColour screen DT
YOUR 307 SW IN DETAIL
Monochrome screen B
- the remaining range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
In addition, it allows access to the
warning log information.
Zero reset
Press the stalk for more than two
seconds. - the
"Current information"
with:
• the range,
• the current consumption,
• the distance still to be driven.
- "Route 1" with:
• the distance travelled,
• the average consumption,
• the average speed,
- "Route 2" with the same features.
It also permits access to the warning
log information.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.
Each time the button on the end
of the
wiper stalk is pressed, the
following sequence of data is dis-
played:Monochrome screen CT
- the 'vehicle' tab with:
• range, current consumption
and
the distance still to be driven,
- tab '1' (route '1') with:
• the distance driven, the average consumption and the average
speed calculated over route "1"
- tab '2' (route '2') with the same fea-
tures.
It also permits access to the warning
log information.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.

15-03-200415-03-2004
108109
Range
This shows the distance that can still
be covered with the fuel remaining in
the tank.
Note: this igure may increase if
there is a change in the style of driv-
ing or the road surface, producing a
signiicant drop in current consump-
tion.
When the range is less than 20 miles
(30 km), three segments are dis-
played. After illing with fuel, the
range is displayed when it exceeds
62 miles (100 km).
If horizontal segments are displayed
for long periods instead of digits,
contact a PEUGEOT dealer.
Current consumption
This is the average quantity of fuel
consumed during the last few sec-
onds.
This function is displayed only when
the vehicle is travelling at a speed
greater than 20 mph (30 km/h).
Average consumption
This is the average fuel consump-
tion since the computer was last set
to zero.
Distance travelled
This indicates the distance travelled
since the computer was last set to
zero.
Distance remaining to be
travelled
This is the distance remaining to the
destination. It can either be calcu-
lated by the navigation if guidance
is activated, or entered by the user,
minus the distance covered since the
distance was entered.
Note: if digits are missing, dashes
are displayed in their place.
Average speed
This is the average speed calculated
since the computer was last set to
zero (with the ignition on).
The warning log
This summarises the active warning
messages by displaying them on the
multi-function display.
The routes
The routes "1" and ''2'' are independ-
ent but have identical application.
Route "1" for example allows you
to make daily calculations and route
"2" monthly calculations.
YOUR 307 SW IN DETAIL

15-03-200415-03-2004
110111YOUR 307 SW IN DETAIL
Specific features of the
monochrome screen CT and
the colour screen DT
General menu
Press the "MENU" button to access
the general menu.
Select the icon ''On-board com-
puter'' using the dial, then validate
to access the ''On-board computer''
menu.
The ''On-board computer'' menu of-
fers various choices:
- On-board computer coniguration,
- Warning log.
'On-board computer' context
menu
The context menu associated with
the "On-board computer" applica-
tion appears as a superimposed dis-
play when the on-board computer is
the application currently being used
in the main screen window.
Briely press the continuous applica-
tion 'On-board computer' button to
select one of the following functions:
- Warning log,
- Distance to destination. On-board computer coniguration
This function allows the distance to
the destination to be input (when
guidance is not activated; otherwise
this information is given by the navi-
gation system) and also changing of
the units of measurement (°C or °F,
km and litres or miles and gallons).
Distance to destination
When guidance is not activated, this
enables an approximate value to be
entered to make all the on-board
computer calculations possible.

15-03-200415-03-2004
110111
ELECTRIC WINDOWS
1 - Driver's electric window switch.
2 - Passenger's electric window
switch.
3 - Rear right electric window
switch.
4 - Rear left electric window
switch.
5 - Disarming of the rear electric window switches (child lock).
You have two options:
Manual operation:
Press or pull switch gently. The win-
dow stops as soon as the switch is
released. Automatic operation:
Press or pull switch fully: the window
opens or closes completely when
the switch is released. Pressing the
switch again stops the movement of
the window.
Note:
when one of the doors is
opened or approximately 45 seconds
following removal of the ignition key,
none of the windows can be opened
or closed. The ignition must be
switched on again to open or close
the windows.
Safety auto-reverse
When the window rises and meets
an obstacle, it stops and partially
lowers again.
Note:
In the event of unwanted opening of
the window on closing (for example
in the presence of frost), press the
switch until it opens completely, then
pull it immediately until it closes.
Continue to hold the switch for ap-
proximately one second after the
window has closed.
The safety auto-reverse function
is not active during these opera-
tions.
Disarming the rear window
controls
For the safety of your children, press
switch 5 to prevent operation of the
rear windows irrespective of their
position.
YOUR 307 SW IN DETAIL
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
In the event of contact during op-
eration of the windows, you must
reverse the movement of the win-
dow. To do this, press the switch
concerned.
When the driver operates the pas-
senger electric window switches,
he must ensure that no one is
preventing correct closing of the
windows.
The driver must ensure that the
passengers use the electric win-
dows correctly.
Be aware of children when operat-
ing the windows.
When the button is raised, disarming
is active. When the button is lowered,
disarming is deactivated.
REINITIALISATION OF THE
WINDOWS
Following reconnection of the battery
or in the event of a malfunction, re-
lease the switch and pull it again until
it closes completely. Hold the switch
for approximately one second after
closing.
The safety auto-reverse function
is not active during these opera-
tions.

15-03-200415-03-2004
102103YOUR 307 SW IN DETAIL
OPENING THE BONNET
From inside: push the handle on the
left-hand side under the fascia.
From outside: lift the catch and
raise the bonnet.
Bonnet strut
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked. The engine must be switched off

when illing with fuel.
F Open the fuel iller lap.
F Insert the key then turn it to the
left.
F Remove the cap and hang it on the
hook located on the inside of the
lap.
A label afixed to the inside of the fuel
iller lap indicates which type of fuel
to use.
When you ill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is ap-
proximately 60 litres.
F After illing the tank, lock the cap
and close the fuel iller lap.
FILLING WITH FUEL
Low fuel level
When the minimum
fuel level in the tank is
reached, this warning
light comes on.
You can still drive ap-
proximately 30 miles (50 km).
Flashing of the warning light indicates
a malfunction of the fuel gauge.
Contact a PEUGEOT dealer.

15-03-200415-03-2004
104105YOUR 307 SW IN DETAIL
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped / Main beam change
Pull the stalk towards you.
Note:
with the ignition off, when the
driver's door is opened, a buzzer
sounds if you have left your lights
on.
Front fog lamps and rear fog lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel. Vehicles itted with front fog
lamps and a rear fog lamp (ring C)
Lights off
Side lights
Dipped / main beam
headlampsAutomatic switching on
of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off
the rear fog lamp and the front fog
lamps, turn the ring backwards twice
in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights will remain
on (turn the ring backwards to switch
off the front fog lamps. The side lights
will then be switched off).
Vehicles itted with a rear fog
lamp (ring B)
This only operates with the dipped /
main beam headlamps.
Note:
when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps will re-
main on (turn the ring backwards
to switch off the rear fog lamp. The
dipped headlamps and side lights will
then be switched off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.
