inflation pressure Peugeot 308 SW BL 2013 Owner's Manual

8
138
SAFETY
TYRE UNDER-INFLATIONDETECTION
System which automatically and contin-
uously checks the pressure of the tyres
while driving. All repairs and changing of tyres on
a wheel fi tted with this system must
be carried out by a PEUGEOT
dealer or a qualifi ed workshop.
If, when changing a tyre, you fi t a
wheel which is not detected by your
vehicle (example: fi tting of snow
tyres), you must have the system
reinitialised by a PEUGEOT dealer
or a qualifi ed workshop.
This system does not avoid the
need to have the tyre pressures
checked regularly (refer to the
"Identifi cation markings" section) to
ensure that the optimum dynamic
performance of the vehicle is main-
tained and prevent premature wear
of the tyres, particularly in arduous
driving conditions (heavy load, high
speed).
The tyre pressures must be checked
cold, at least once a month. Re-
member to check the pressure of
the spare wheel.
The tyre under-infl ation detection
system may experience temporary
interference due to electro-magnet-
ic emissions on a frequency close
to that used by the system.
Sensors fi tted in each valve trigger a
warning in the event of problem (speed
above 12 mph (20 km/h)).
This warning lamp is displayed
in the instrument panel and/or a
message appears in the screen,
accompanied by an audible signal,
to identify the wheel concerned.


)
Check the tyre pressures as soon
as possible.

This check must be carried out when the tyres are cold.


Under-infl ated tyre
The STOP
warning lamp comes
on and/or this warning lamp
is displayed in the instrument
panel, accompanied by an au-
dible signal and a message in
the screen identifying the wheel
concerned.


)
Stop as soon as it is safe to do so,
avoiding any sudden movement of
the steering wheel and the brakes.

)
Repair or change the damaged
wheel (punctured or very defl ated
tyre), and have the tyre pressure
checked as soon as possible.

Puncture
The tyre under-infl ation detection sys-
tem is an aid to driving which does not
replace the need for the driver to be
vigilant or to drive responsibly.
Sensor(s) not detected or faulty
This warning lamp is displayed
on the instrument panel and/
or a message appears in the
screen, accompanied by an
audible signal, to locate the wheel or
wheels which are not detected or to in-
dicate a malfunction of the system.
Contact a PEUGEOT dealer or a quali-
fi ed workshop to replace the faulty
sensor(s).
This message is also displayed
when one of the wheels is away
from the vehicle (being repaired) or
when one or more wheels without a
sensor are fi tted.
If your vehicle is equipped with a
spare wheel, this is not fi tted with
a sensor.

376
ALPHABETICAL INDEX
Under-inflation (detection) ....................138Under floor storage............................... 117Unlocking................................................83Unlocking from the inside.......................92Update risk areas .........................265,302Updating POIs ......................................265USB (Peugeot Connect) ............... 112,352
Warning lamps............................29, 33, 43Wash-wipe, rear...................................r106Weights.........................................219, 228Welcome lighting..........................103, 109Window controls.....................................89Windscreen zones for toll/car park cards..................................111Wiper, rear............................................r106Wiper control stalk.........................105-107Wipers..........................................105, 107Writing table............................................70
Xenon headlamps................................194U
W
X
Torch.....................................................124Total distance recorder...........................r43Towbar..................................................r214
Towed loads.................................219,228Towing another vehicle .................211,213Traction control (ASR)..........................140Traffic information (TA).........................268, 312, 325,350Traffic information (TMC).......................267,268,311,312Trailer...................................................r214Trip computer.............................r57,58,60Trip distance recorder............................r43Tyre pressures ......................................241Tyres .......................................................23Tyre under-inflation detection ...............138
Vehicle configuration.....45,47,49,52,54Vehicle diagnosis....................................49Vehicle identification.............................241Ventilation ..........................................61-63Voice commands..................................250
V
