10 -Passenger air bag.
11 - Glove box.
12 - Side adjustable heating/ ven- tilation vents and air flow reg-ulation.
13 - Window demisting vent.
14 - Speaker (tweeter) location.
15 - Multi-function display.
16 - Heating/ventilation controls.
17 - Radio.
18 - Gear lever.
19 - Front ashtray.
20 - Rear footwell heating vent.
21 - Lighter. 22 -
Heated seat switches. Coin storage. Passenger air bag disarming switch.
23 - Handbrake.
24 - Cup-holder.
25 - Rear ashtray.
26 - Steering lock and ignition.
27 - Steering wheel adjustment.
28 - Fuse box.
29 - Electronic stability programme (ASR/ESP)
30 - Headlamp height adjustment.
31 - Cruise control.
YOUR 406 COUPE AT A GLANCE
3
1 - Electric mirror controls. Window controls.
2 - Lights and direction indicators stalk.
3 - Driver's air bag.Horn.
4 - Instrument dials.
5 - Radio remote control stalk.
6 - Windscreen wash-wipe stalk.
Trip computer stalk.
7 - Hazard warning lights switch.
8 - Central adjustable heating/ventilation vents and air flowregulation.
9 - Windscreen demistingvents.
01-07-2002

FRONT AIR BAGS Disarming the passenger air bag*
 Insert the ignition key in switch1and turn it to:
Ð the " ON" position, the passen-
ger air bag is armed.
Ð the " OFF" position, the pas-
senger air bag is disarmed.
Operating check
With the igntition switched on(2nd notch) this warning light,accompanied by an audible sig-nal and the message "Passen-
ger air bag disarmed" on the
multi-function display, indicatesthat the passenger air bag is disarmed (switch in the "OFF"
position). The warning light remains on throughout the disarming pro-cess. Passenger air bagprecautions For a vehicle fitted with a disarm- ing switch:
- disarm the airbag if youinstall a rear-facing childseat.
- arm the air bag for anadult
passenger.
For a vehicle not fitted with a disarming switch: - do not install rear-facing child seats onthe front passengerseat.
Never place your feet or anyobject on the fascia. SIDE AIR BAGS These are incorporated into the front seat back, on the door side.
They are triggered independently, on the side on which the collisionoccurs.
Operating check
This is by means of the warning light on the instrument panel. It comes on for six seconds when the ignition is switched on. If the warning light:
- does not come on when the ignition is switched on or,
- does not switch off after six seconds or,
- flashes for five minutes then remains on,
Consult your PEUGEOT dealer. * According to destination.
8
YOUR 406 COUPE AT A GLANCE
01-07-2002
125

Moving Off
With the engine turning, to move off from position P:
 press the brake pedal to change out of position P (shift lock),
 select the required position ( R, D, 3, 2or 1) then gradually release the brake pedal; the vehicle moves off imme-
diately.
You can also move off from position N :  release the handbrake, keeping your foot on the brake pedal,
 select the required position ( R, D, 3, 2or 1) then gradually release the brake pedal; the vehicle moves off imme-
diately.
The four speed automaticgearbox offers a choice between the comfort of integral operation,enhanced by a
sport programme (switch A) and a snowprogramme (switch B).
Gear selection gate  Move the lever in the gate to select a position.
Once the position is selected, the indicator light for that position illuminates on the instrument panel display.
P ark: for immobilising the vehicle and starting the engine , with the handbrake on or off.
R everse: for reversing (select this position with the vehicle stationary, engine at idle).
N eutral: for starting the engine and for parking, with the handbrake on.
D rive: for driving in autoadaptive mode (automatic changing of the four gears).
3 - for driving in townor on winding roads (automatic changing of the first 3 gears only).
2 - for driving in the mountainsor for towing a trailer (automatic changing of the first 2 gears only).
1 - for tackling steep gradients (selection of first gear only).
Special feature of the gearbox (2 litre petrol engine) Selection of first gear is by press- ing switch Cwith the selector
lever in position 2.
To change out of first gear, pressswitch Cagain or move
the gear lever.
AUTOMATIC AUTOADAPTIVE GEARBOX
2 litre engine
YOUR 406 COUPE AT A GLANCE
12
V6 engine
01-07-2002
11 9

SERVICE INDICATOR This is a visual reminder of when the
next service is due. This service is tobe carried out according to the man-ufacturer's servicing schedule. Operation As soon as the ignition is switched on and for 5 seconds, the spannersymbolising ''service operation'' is lit.The trip recorder display shows youthe distance remaining (in round fig-ures) before the next service. Example:4,800 km remain before
the next service is due. When the ignition comes on and for 5 secondsthe display indicates: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the display shows the total or tripdistances. The distance remaining before the next service is less than 1,000 km. Example:
900 km remain before the
next service is due. When switching on the ignition and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the symbol remains lit. This indicates that a service should
be carried out shortly. The displayshows the total or trip distances. The service is overdue Each time the ignition is switched on and for 5 seconds, the symbol andthe excess distance flash. Example:
the service is overdue by
300 km. The service should be car-
ried out very shortly. When the ignition is switched on and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operation
and the symbol remains lit. The dis-play shows the total or trip distances.
YOUR 406 COUPE IN DETAIL 109
01-07-2002

Resetting the service indicator
Your PEUGEOT dealer carries out this operation after each service.
However, if you carry out the serviceyourself, the reset procedure is asfollows: - Switch off the ignition.
- Press and hold button 1.
- Switch on the ignition.
The display begins a 10 second countdown. - Keep button 1pressed for 10
seconds.
The display shows [= 0] and the ser-
vice symbol disappears.
YOUR 406 COUPE IN DETAIL
110
01-07-2002

YOUR 406 COUPE IN DETAIL
104
WARNING LIGHTS AND INDICATORS
A permanently lit warning light, or flashing with the engine running, is an indication of a malfunction in the relevant unit. Some warning lights may
be linked to buzzers and a message on the multiÐfunction display. Do notignore this warning: contact a PEUGEOT dealer as quickly as possible.
If the Central (STOP) warning light comes on when you are driving, stop your vehicle immediately where it is safe to do so.
Central (STOP) warning light Linked to the "engine oil pressure", ''the low brake fluid level'', '' the coolant temperature gauge'' and ''electronic brake force distribu-tion system fault'' warning lights. It comes on each time the igni-tion is switched on.
Stop immediately if it flashes with the engine running.
Contact a PEUGEOT dealer.
Engine oil pressure warning light
Linked to the central (STOP) warning light.Stop immediately if it comes on with the engine running.
It indicates either:
Ðinsufficient oil pressure,Ðlack of oil in the lubrication circuit. Top up the oil level.
Contact a PEUGEOT dealer as soon as possible. Low coolant level warning light
Stop immediately. Allow the engine to cool before top- ping up. The cooling system is pressurised.In the event of a breakdown and to prevent the risk of scalding, turn thecap to the first notch to allow thepressure to drop. Once the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer.
Fuel filler cap warning light This comes on if the fuel cap is not correctly screwed
on or is missing.
01-07-2002

YOUR 406 COUPE IN DETAIL105
Handbrake, low brake fluid level and electronic brake force distribution warning light. This comes on each time the ignition is switched on.
It indicates either:
Ðthat the handbrake is on or has not been released correctly,
and when coupled with the central (STOP) warning light:
Ðan excessive drop in the brake fluid level (if the light remains on even with the handbrake released),
Ðlit at the same time as the ABS warning light, it indicates a malfunction of theelectronic brake force distribution system.
Stop immediately.
Contact a PEUGEOT dealer.
Anti-lock braking system (ABS) warning light This comes on for 3 seconds each time the ignition is switched on.If it comes on at over 8 m.p.h. (12 km/h), it indicates a malfunction of the ABS.
However, the vehicle retains conventional servo-assisted braking.
Contact a PEUGEOT dealer.
Clogging of the partic- ulate emission filterwarning light (dieselengine)
Display of this warning light is accompanied by an audible signal. The flashing of this light while the engine is running is caused either bythe particulate emission filter being
overloaded or by the engine runningtoo long at idle (white smoke from
the exhaust). There is a risk of the fil-ter clogging if the same conditions ofoperation are maintained. As soon as possible, drive for at least three minutes at a speedexceeding 37 m.p.h. (60 km/h), if driving conditions allow this. If the light comes on, contact a
PEUGEOT dealer as soon as possi-ble. Front brake pad wear warning light
For your safety, have the pads replaced as soon as this light comes on.
ESP Electronic Stabili- ty Programme opera-
tion indicator light
This flashes when the system is operating. It is lit continuously if disarmed or if there is a fault.
01-07-2002

YOUR 406 COUPE IN DETAIL
106
Passenger air bag disarming warninglight Illumination of this warning
light is accompanied by an audible signal and a message on the multi-
function display. If the passenger airbag is disarmed, the indicator lightcomes on when the ignition isswitched on and remains on. In all cases, if the warning light flash-
es, contact a PEUGEOT dealer.
Air bag warning light The warning light comes on for 6 seconds when theignition is switched on.
Illumination of this warning light, withthe engine running, is accompaniedby an audible signal and a messageon the multi-function display indicat-ing the cause of the front, side or curtain air bag fault.
Contact a PEUGEOT dealer.
Water in diesel filter warning light (according to destination)
Contact a PEUGEOT dealer as soon as possible.
There is a risk of damage to the injection system. Diesel pre-heating indicator lightIf the engine is warm enough, the light will not come on and you can start the engine without waiting.
If the light comes on, wait until it goes out before trying the starter. Engine diagnostics warning light This comes on each time the ignition is switched on. If it is lit continuously with the engine runnning, this indicates a fault in
the emission control system.If it flashes with the engine running, this indicates a malfunction in the injection
or ignition system. There is a risk of damage to the catalytic converter (petrol
engine only). Contact a PEUGEOT dealer as soon as possible. Battery charge warning light This comes on each time the ignition is switched on.If it comes on with the engine running it can indicate:
Ðfaulty operation of the charging circuit,
Ðloose battery or starter terminals,
Ða cut or slack alternator belt,
Ðan alternator fault.
Contact a PEUGEOT dealer.
01-07-2002

Lighting rheostat
With the lights on, press the button to vary the intensity of the lighting of theinstruments and controls. When thelighting reaches the minimum (ormaximum) setting, release the but-ton then press it again to increase (orreduce) the brightness. As soon as the lighting is of the required brightness, release the but-ton.
Trip recorder zero reset
With the ignition on, press the but- ton. Instrument panel display After switching on the ignition, three functions are shown in succession:
-engine oil level indicator,
-service indicator,
-total distance recorder.
Engine oil level When the ignition is switched on, the engine oil level indicator is displayed for approximately five seconds, then the service indicator is displayed for five sec-onds. Maximum Use the dipstick to confirm the level on the indicator; a surplus of oil can cause damage to the engine.
Contact a PEUGEOT dealer as soon as possible.
Minimum Check the level with the dipstick and top it up. The indication isonly correct if the vehicle has been on stable, level ground, withthe engine stopped, for 10 minutes.
No oil It is essential to top up the oil to the correct level, otherwise thereis a risk engine will be damaged.
YOUR 406 COUPE IN DETAIL
108
01-07-2002

This enables the following information to be displayed:
- the time,
- the date,
- the outside temperature (the ¡C symbol flashes when there is a risk of ice),
- the radio displays,
- the status of the doors. The display shows you whether a door, the boot or thebonnet is open and if the fuel filler cap is missing.
- the warning messages (e.g. ''battery low'') or information messages (e.g. "top up fuel tank''), displayed temporarily, can be cleared by pressing button 1or
2 ,
- the trip computer. Setting the parameters Press button 1for two seconds to access the settings. The information flashes
to show it is ready to be modified.Then, individual presses on button 1 allow you to scroll through the various data
in the following sequence:
- language in which the information is displayed,
- unit of distance (kms or miles),
- unit of temperature (Celsius or Fahrenheit),
- time format (12 then 24 hour mode)
- hour,
- minutes,
- year,
- month,
- day, Pressing button 2allows you to change the information selected. Maintain the
pressure for rapid scrolling.After ten seconds without action, the display returns to the main screen and the modified data are recorded.Display B
YOUR 406 COUPE IN DETAIL 111
