Peugeot 407 Dag 2005 Owner's Manual

100 -
14-02-2005
101
-
14-02-2005* If option and service available.
If you have signed the speciic
PEUGEOT contract, your call will
be located and you will be put in
contact with a PEUGEOT emergency
representative.
For further details, refer to the gen-
eral conditions of your contract.
"PEUGEOT Assistance"/
Emergency call
A green diode lashes on the RT3
GPS audio/telephone panel, when
the emergency call procedure or a
call to "PEUGEOT Assistance" be-
gins, then lights continuously when
the call is taken by the services con-
cerned.
It is not possible to make or receive
calls or send or receive SMS text
messages during the connection;
these will be diverted to your voice
mail.
Services*
Press the button to
display the "Services"
menu and select one of
the following services:
• "Customer Contact Centre" con-
tacts the PEUGEOT Customer
Contact Centre directly and permits
access to the services offered (this
call is suspended if an emergency
or assistance call has been made).
• "PEUGEOT Assistance" enables
you to contact the call centre which
controls the PEUGEOT assistance
service directly, make an assist-
ance request and receive rapid
assistance (you have 6 seconds
within which to cancel the call
when it is made) . During the as-
sistance call phase it is not pos-
sible to make any other calls with
the exception of emergency calls.
Signing the speciic PEUGEOT
contract means that you will be
located; in this case, a star will ap-
pear in the text on the multifunction
screen.
• "Operator services" gives access
to the list of services speciic
to your operator (e.g.: customer
service, consumption monitoring,
news, stock market, weather, travel,
games, etc) if access is available.
* If option and service available.
Emergency call*
In an emergency,
press and hold the
"SOS" button until a
signal is heard and
a call validation/de-
letion screen is dis-
played (delay of 6 seconds) or enter
112 directly.
Make an emergency call when you
are involved in a situation which
leads you to fear serious conse-
quences (injuries, ...) for those
exposed to it (if you witness or are
involved in an accident resulting in
injuries, an attack, ...).
Before making a call of this kind, the
audio/telephone must detect a cel-
lular network and you must have
inserted your SIM card .
If you have not signed the speciic
PEUGEOT contract, the parameters
of the "SOS" button are set so that a
call is made to 112 - unique number
made available by the worldwide
GSM network, reserved for emer-
gency calls.
407 saloon and 407 SW comfort

102 -
14-02-2005
103
-
14-02-2005
Main menu
From the general menu, select the
"Directory"
application to access its
main menu and select one of the fol-
lowing functions:
• "Call", to call a number stored in a ile,
• "Activate guidance to", to initiate guidance to a location stored in a
ile,
• "Management of directory iles", to add, delete, modify and consult di-
rectory iles or exchange them with
the SIM card,
• "Directory coniguration", to select the working directory and deine
the default directory when the sys-
tem is switched on. Creation/Modiication of a ile
To create a ile, from the "Directory"
menu, select the "Management of di-
rectory iles" function, then "Add".
In the ile, select the section to be
illed in, conirm and then enter the
information.
To modify an existing ile, select it by
means of the "Consult or modify the
ile" function of the "Management of
directory iles" menu, then make the
modiications.
When entering the address, the navi-
gation CD ROM must be present to
obtain guidance to this destination.
Recording a description
associated with a directory ile
When a description is associated
with a directory ile, you can record
the description vocally to use it later
for direct access by means of voice
commands (e.g.: "Call" "[Name of
voice description]" or "Guide to"
"[Name of voice description]").
Select "Consult or modify the ile"
from the "Management of directory
iles" menu to access the description
entering and recording screen.
Press the record button and follow
the instructions.
The "Directory" appli-
cation gives access to
400 iles divided into
4 independent sub-direc-
tories ("User1", "User2",
"User3" and "User4"). It
enables you to manage these iles,
make calls using the SIM card and
activate guidance.
Directory
General
RDS TMC (Traffic Message
Channel) Traffic Information
You can access the information relat-
ing to trafic conditions from the "Au-
dio functions" or "Telematics" menu,
then from the "TMC Trafic Informa-
tion" function (see section "Satellite
navigation system").
The RT3 GPS audio/telephone per-
mits access to the TMC RDS trafic
information broadcast free on the FM
waveband.
407 saloon and 407 SW comfort

96 -
14-02-2005
MONOCHROME DISPLAY CT
16/9 COLOUR DISPLAY
Displays the following information:
- the time,
- the date,
- the exterior temperature (the value dis-played lashes if there is a risk of ice),
- the accesses check,
- the vehicle function status mes- sages, displayed temporarily,
- the warning displays,
- the RT3 audio equipment displays, the direct inputting of the frequency
of a transmitter on the numeric key-
pad,
- the telematic systems displays (telephone, services, ...),
- the trip computer displays,
- the air conditioning displays,
- the satellite navigation system dis- plays. The general menu
Press the
"MENU" button to access the
general menu and select one of the fol-
lowing parameters and functions: Navi-
gation - Guidance, Audio functions, Trip
computer, Personalisation-coniguration,
Directory, Telematics, Map*, Video* and
Air Conditioning.
The "Personalisation-Coniguration"
menu provides access to successive
conirmation windows. Display coniguration
- Selection of the colours for the 16/9
display: selection of the colours
available for display.
- Sound: selection of the sound am- bience, setting of the voice synthe-
siser and of the voice commands.
- Brightness.
- Selection of the units of measure- ment.
* With the 16/9 colour display only.
Deine the vehicle parameters
Permits the activation or deactivation of
certain driving and comfort functions:
- permanent locking of the boot on
the 407 Saloon (OFF by default),
- automatic switching on of the lights (ON by default),
- automatic "follow-me-home" lighting (OFF by default),
- automatic rear wiping on engaging reverse gear on the 407 SW (ON
by default). Selection of the language
German, Spanish, French, English,
Italian, Dutch, Portuguese and
Brazilian Portuguese.
407 saloon and 407 SW comfort

114 -
14-02-2005
115
-
14-02-2005
You can connect video equipment
(camcorder, digital photographic
equipment, ...) to the three video
sockets, located in the glove box.
Video display is only possible when
stationary.
Select the Video menu from the gen-
eral menu:
- "Activate video mode" to activate/
deactivate the video,
- "Video parameters" to set the dis- play format, the brightness, the
contrast and the colours.
Press the "ESC" or "DARK" button to
exit video mode.
Press the "SOURCE" button sev-
eral times in succession to select an
audio source other than that of the
video.
VIDEO MENU**
** 16/9 colour screen only.
407 saloon and 407 SW comfort

102 -
14-02-2005
103
-
14-02-2005
SATELLITE NAVIGATION
SYSTEM
Introduction
The satellite navigation system
guides you, by means of vocal and
visual instructions, to your chosen
destination.
The heart of the system lies in the
use of a map data base and of the
GPS system. With this system you
can ix the position of your vehicle by
means of a satellite network.
The system uses the following
elements:
- the CD-Rom drive,
- the coniguration CD-Rom,
- the navigation CD-Rom,
- the last voice message recall control,
- the control keypad,
- the monochrome screen or the
colour screen.
Certain functions or services de-
scribed may vary depending on the
version of CD-Rom or the country
where the vehicle is sold. 1.
Ejection button on CD-Rom.
2. CD-Rom housing.
The navigation CD-Rom contains all
the map data.
It must be inserted in the drive,
printed face upwards.
Use only CD-Roms approved by
PEUGEOT. Pressing for more than two seconds
on the button at the end of the
lights stalk repeats the last voice
information.
For safety reasons, the in-
putting of navigation infor-
mation by the driver must be
carried out when the vehicle
is stationary.
The CD-Rom drive
This is part of the RT3 GPS audio/
telephone.
The last voice message recall
control
The control panel
This lets you navigate, select, choose
and validate the functions, from the
parameters displayed.
407 saloon and 407 SW comfort

104 -
14-02-2005
105
-
14-02-2005
Pressing the dial-navigator:
This allows: -
access to the list of controls (con-
textual menu) of the permanent
display, if there is no other display
superimposed.
- conirmation of the selected func-
tion or the modiied value.
- selection of a 'setting' or 'list'
type parameter for modiication.
"C" button:
- Brief press:
deletion of the last
character entered.
- Press for more than two seconds: deletion of the entire line.
"NAV" button:
- Brief press: access to the naviga-
tion - guidance permanent applica-
tion.
"MENU" button:
- Brief press: access to the general
menu .
- Press for more than two seconds: access to the help menu.
"ESC" button:
- Brief press: cancellation of the
operation in progress or clearing
of the last superimposed display.
- Press for more than two seconds: clearing of all of the superimposed
displays and return to the perma-
nent application.
" 5 " and " 6" buttons:
- Vertical movement in the menus,
screens and on the map on the 16/
9 colour screen.
" 3 " and " 4" buttons:
- Horizontal movement in the men-
us, screens and on the map on the
16/9 colour screen. Permanent locating
This function enables you to display
the name of the street along which the
vehicle is travelling when guidance is
not active, on condition that the navi-
gation CD-Rom is in the drive.
Press the dial for more than two
seconds to display the name of the
street along which you are travelling.
Rotation of the dial-navigator:
This allows you to
move round the
screen and thus select a function.
It also allows you:
- with a 'setting' type parameter,
after selection, to increase or de-
crease the value,
- with a 'list' type parameter, after
opening the list, to scroll through
the values,
- with map guidance, to increase or
reduce the zoom.
407 saloon and 407 SW comfort

104 -
14-02-2005
105
-
14-02-2005
General menu
Switch on the RT3 GPS audio/
telephone and insert the navigation
CD-Rom.
Press the "MENU" button to access
the general menu.
During guidance, if the navigation
CD-Rom is present, the screen dis-
plays different information depending
on the manoeuvres to be carried
out.
1.
Current manoeuvre or compass
or course (if calculation in
progress or zone not mapped).
2. Next manoeuvre to be carried
out.
3. Next road to be taken.
4. Current road.
5. Estimated time of arrival at
destination.
6. Distance to inal destination.
7. Distance to next manoeuvre.
Notes:
- depending on the situation of the vehicle and on the reception of
GPS information, this information
may disappear from the screen
temporarily,
- during guidance, the navigation CD-Rom must remain in the RT3
GPS audio/telephone drive.The satellite navigation
system with the CT
monochrome screen or the
16/9 colour screen
General notes on the display
CT monochrome screen16/9 colour screen Select the Navigation/
Guidance icon using the
navigator, then validate
by pressing the navigator
to access the main "Navi-
gation - Guidance" menu.
Instrument panel screen
407 saloon and 407 SW comfort

106 -
14-02-2005
107
-
14-02-2005
The main "Navigation - Guidance"
menu offers various options for acti-
vation or management of guidance:
- choice of the type of destination
address (entering of address,
service, GPS co-ordinates, stored
address),
- modiication to the initial route,
- displaying of the chosen destina- tion,
- setting of the guidance option pa- rameters,
- stop or resume guidance (display- ing of the message which changes
depending on the previous status).
Navigation - Guidance
The "Select a destination" menu
offers various options for reaching a
destination:
- entering a postal address,
- selecting a service available in a town (town hall, hotel, cinema, air-
port...),
- entering GPS details,
- selecting a destination stored in the directory,
- selecting one of the previous desti- nations.
Selecting a destination
The last guidance address is dis-
played.
To ill in the entry zones, select and
validate in succession the zones
"Town", "Road" then "N°" (the last
two zones are optional).
The "OK" function permits validation
of the address and access to the
guidance activation function.
The "Store" function permits record-
ing of the address in a directory ile.
The "Curr. loc" function permits
display of the current address.
Entering an address
407 saloon and 407 SW comfort

106 -
14-02-2005
107
-
14-02-2005
To enter the name of a town, select
each letter by turning the navigator or
by pressing the navigation buttons,
then validate each letter by pressing
the navigator.
If an error is made entering the let-
ters, the "Change" function or the "C"
button permits erasing of the last let-
ter entered.
Note:
following the validation of a
letter, only those which could make
up a name existing in the database
appear.
As letters are entered, the "List" func-
tion indicates the number of towns
beginning with the same letters. Ac-
tivation of this function permits selec-
tion of a town from the list.
Entering the name of the town
Enter the number of the street previ-
ously entered.
Select the "OK" function, then con-
irm by pressing the navigator.
Note: if the number of the street en-
tered is not listed, it is rejected. The
list of junctions is displayed automati-
cally.
Select a street from the "Junctions"
function, which avoids having to en-
ter the street number.
The full destination is displayed.
Select the "OK" function, then
conirm by pressing the navigator
to access the guidance activation
function. Follow the instructions
given by the system.
Entering the number of the road

or junction
When the list contains fewer than ive
names, these are displayed automat-
ically. Select a town then validate by
pressing the navigator.
When the complete name of the
town is displayed, select the "OK"
function then conirm by pressing the
navigator.
Note:
once the town has been en-
tered, you can conirm by pressing
"OK". You will then be guided to the
centre of this town automatically.
Entering the name of the road
Enter the name of the street in the
same way as the name of the town.
When the full name of the street is
displayed, select the "OK" function
then conirm by pressing the navigator.
Entering the town and road using
the alphanumeric keypad
Press the numeric key which corre-
sponds to the letter required until the
letter appears on the screen, then
conirm by pressing the # key after
each letter.
407 saloon and 407 SW comfort

108 -
14-02-2005
109
-
14-02-2005
Selecting a service
If you wish to be directed to a service,
select the category corresponding to
the service,
then conirm by pressing
the navigator.
The list of services corresponding to
the category selected is displayed.
Select the service then conirm by
pressing the navigator to access the
"Choice of a location" function. Note:
if the service selected is not
available in the programmed loca-
tion, a temporary message informs
you of this.
Following validation of the location,
the service closest to it is displayed.
The distance indicated is the dis-
tance as the crow lies from the serv-
ice to the selected location.
The last address entered is dis-
played.
There are three options for deining
the location in which you wish to ob-
tain this service:
- accept the last address entered us- ing the "OK" function,
- ill in the "Town" and "Road"
zones,
- automatically enter the name of your current location using the
"Curr. loc" function. An indication on the edge of the
screen (x/n) shows you the maximum
number of establishments providing
the same service within a radius of
30 miles (50 km), as the crow lies,
from the selected location.
Use buttons "<" and ">" to consult
the list provided.
When the establishment of your
choice is displayed, you can: ฀•฀฀
select the "OK" function to activate
guidance towards this service,
฀•฀฀ select the "Store" function to enter
this establishment in your directory. The most recent destinations are
shown.
There are three possible methods
of deining the location to which you
wish to travel:
- accept the last details input by
means of the "OK" function,
- input the details of your destination,
- automatically input the details of your current location by means of
the "Curr. loc" function.
GPS details
407 saloon and 407 SW comfort
