FAMILIARISATION Sunroof (Saloon)
This roof improves the ventilation and
light in the passenger compartment.
70
68
103
102
Tyre under-inflation detection
This system checks the pressure of the
tyres while driving and warns you if a
malfunction occurs. Rear screen (SW)
This rear screen provides remarkable
accessibility and makes the loading
of objects easier without opening the
boot.
Visual and audible front and
rear parking sensors
This system warns you if an obstacle
is detected in front of or behind the
vehicle in forward or reverse gear.
Page 6 of 249
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Multifunction screen.
2. Audio and telematics system.
3. Automatic air conditioning controls.
4. Deactivation of the audible parking
sensors.
Central locking from the inside.
Alarm control.
Hazard warning lamps.
SPORT suspension control.
Deactivation of the ESP system.
Child lock.
5. Ashtray/Front cigar lighter
(100 W max).
6. Gear lever.
7. Parking brake.
8. Retractable cup holder.
9. Armrest with storage compartment
and USB port.
10. 12 volt accessories socket
(100 W max).
11. Rear ashtray.
139
213
Peugeot Connect Media
Peugeot Connect Navigation
184
Peugeot Connect Sound
Page 12 of 249
FAMILIARISATION
Instrument panel
A. When the ignition is on, the fuel
gauge needle should rise.
B. W h e n t h e e n g i n e i s r u n n i n g , i t s a s -
sociated low level warning lamp
should switch off.
C. When the ignition is on, the oil level
indicator should display "OIL OK"
for a few seconds.
If the levels are not correct, top up the
level which is low.
Lighting of the indicator lamp indicates
the status of the corresponding function. When the ignition is on, the orange and
red warning lamps come on.
When the engine is running, these
warning lamps should switch off.
If any warning lamp remains on, refer to
the page concerned.
18
20
104
A. Audible front/rear parking
sensors off.
B. Central locking.
C. Alarm interior volumetric
protection off.
D. Hazard warning lamps.
E.
S e l e c t i o n o f t h e e l e c t r o n i -
cally controlled suspension.
F. E l e c t r o n i c s t a b i l i t y p r o -
gramme ESP off.
62
65
86
97
86
Warning lamps Switch panel
Page 23 of 249
1
24
P a r t i c l e e m i s s i o n fi l t e r
saturation warning lamp
(Diesel engine)
With the engine running, this indi-
c a t e s t h a t t h e p a r t i c l e e m i s s i o n fi l t e r
is star-ting to become saturated (ex-
ceptionally prolonged urban driving
t y p e c o n d i t i o n s : l o w s p e e d , l o n g t r a f fi c
jams...) or a low diesel additive reser-
voir level.
I n o r d e r t o r e g e n e r a t e t h e fi l t e r , y o u a r e
advised to drive, as soon as possible
w h e n t h e t r a f fi c c o n d i t i o n s p e r m i t , a t a
speed of 40 mph (60 km/h) or above
f o r a t l e a s t fi v e m i n u t e s ( u n t i l t h e w a r -
ning lamp is switched off).
If the warning lamp remains on, con-
tact a PEUGEOT dealer.
Following prolonged use of the vehi-
cle at very low speeds or at idle, you
may, exceptionally, notice an emission
of water vapour at the exhaust during
acceleration. This does not affect the
performance of the vehicle or the en-
vironment.
Service warning lamp
This is displayed to indicate an engine
management system fault.
Contact a PEUGEOT dealer as soon
as possible. Automatic gearbox fault
warning lamp
This indicates an automatic gearbox
fault.
The gearbox will operate in down-
graded mode, locked in 3rd gear.
Never force the selector lever.
Consult a PEUGEOT dealer.
Electronically controlled
suspension fault warning
lamp
This indicates an electronically con-
trolled suspension malfunction.
Select automatic operation and con-
tact a PEUGEOT dealer as soon as
possible. Parking sensor system
warning lamp
In reverse gear, this indicates a park-
ing sensor system fault.
Consult a PEUGEOT dealer. Electronically controlled
suspension indicator lamps
This comes on when the SPORT func-
tion is activated. This comes on when the SPORT
function is deactivated.
Automatic illumination of
headlamps indicator lamp
Automatic illumination of
headlamps deactivation
indicator lamp
Automatic rain sensitive
wipers indicator lamp
Automatic rain sensitive
wipers deactivation
indicator lamp
This comes on when the AUTO func-
tion is activated.
This comes on when the AUTO func-
tion is deactivated.
This comes on when the AUTO func-
tion is activated.
This comes on when the AUTO func-
tion is deactivated.
Page 35 of 249
3COMFORT
35
For even air distribution, take care
not to obstruct the exterior air intake
grille located at the bottom of the wind-
screen, the vents, the air outlets under
the front seats and the air extractor lo-
c a t e d b e h i n d t h e fl a p s i n t h e b o o t .
I n c e r t a i n c a s e s o f p a r t i c u l a r l y a r d u o u s
use (towing the maximum load on a
s t e e p g r a d i e n t i n h o t w e a t h e r ) , c u t t i n g
o f f t h e a i r c o n d i t i o n i n g p e r m i t s r e c o v -
e r y o f t h e e n g i n e p o w e r a n d t h e r e f o r e
i m p r o v e m e n t o f t h e t o w i n g c a p a c i t y .
C l o s e t h e w i n d o w s t o b e n e fi t f r o m t h e
f u l l e f f e c t i v e n e s s o f t h e a i r c o n d i t i o n i n g .
E n s u r e t h a t t h e p a s s e n g e r c o m p a r t -
m e n t fi l t e r i s i n g o o d c o n d i t i o n . H a v e
t h e fi l t e r e l e m e n t s r e p l a c e d p e r i o d i c a l -
l y . I f y o u d r i v e i n a d u s t y e n v i r o n m e n t ,
r e p l a c e i t t w i c e a s o f t e n .
T h e a i r c o n d i t i o n i n g s y s t e m d o e s n o t
contain chlorine and is not harmful to
t h e o z o n e l a y e r .
O p e r a t e t h e a i r c o n d i t i o n i n g s y s t e m
for 5 to 10 minutes, once or twice a
m o n t h , t o k e e p i t i n p e r f e c t w o r k i n g
o r d e r .
T h e w a t e r f o r m e d b y t h e a i r c o n d i t i o n i n g
c o n d e n s a t i o n i s d i s c h a r g e d v i a a n o p e n -
i n g p r o v i d e d f o r t h i s p u r p o s e . T h e r e f o r e ,
a p u d d l e o f w a t e r m a y f o r m u n d e r n e a t h
t h e v e h i c l e w h e n s t a t i o n a r y . I f t h e s y s t e m d o e s n o t p r o d u c e c o l d a i r ,
do not use it and contact a PEUGEOT
d e a l e r .
1. C e n t r e p a n e l v e n t s .
2. Adjustment of the glove box air
fl o w ( s e e s e c t i o n " I n t e r i o r l a y o u t " ) .
3. A i r o u t l e t t o p a s s e n g e r f o o t w e l l s .
4. Two ventilation vents at the rear at
the base of the centre console be-
t w e e n t h e p a s s e n g e r s .
5. S i d e v e n t s .
6. Front windows demisting/defrosting
v e n t s .
7.
W i n d s c r e e n d e m i s t i n g / d e f r o s t i n g v e n t s .
8. S u n s h i n e s e n s o r .
9. A i r d i f f u s e r g r i l l e .
AUTOMATIC AIR CONDITIONING REGULATION
Use of the automatic regulation of the
a i r c o n d i t i o n i n g i s r e c o m m e n d e d . I t
p e r m i t s a u t o m a t i c a n d o p t i m i s e d c o n -
trol of all of the following functions: air
fl o w , p a s s e n g e r c o m p a r t m e n t t e m p e r -
a t u r e a n d a i r d i s t r i b u t i o n , b y m e a n s
o f v a r i o u s s e n s o r s , s o p r e v e n t i n g t h e
n e e d f o r y o u t o c h a n g e y o u r r e f e r -
ence settings other than the value dis-
p l a y e d .
Air diffuser
T h e a i r d i f f u s e r g r i l l e , l o c a t e d a t t h e t o p
o f t h e c e n t r e c o n s o l e , s i g n i fi c a n t l y i m -
p r o v e s d i s t r i b u t i o n a n d fl o w s a n d p r e -
vents air currents, while maintaining an
o p t i m u m t e m p e r a t u r e i n s i d e t h e p a s -
s e n g e r c o m p a r t m e n t .
Do not cover the sunshine sensor
8 .
It is required for regulation of the air
c o n d i t i o n i n g .
Advice on operation
To obtain even ventilation,
avoid closing the air diffuser
grille 9 .
In hot weather, in order to obtain in-
t e n s e v e n t i l a t i o n , y o u c a n c l o s e t h e
air diffuser grille and use vents 1 and
5 o n l y .
I f , w h e n t h e v e h i c l e h a s b e e n p a r k e d
in the sun for a long time, the interior
t e m p e r a t u r e r e m a i n s v e r y h i g h , d o n o t
h e s i t a t e t o v e n t i l a t e t h e p a s s e n g e r
c o m p a r t m e n t f o r a f e w m i n u t e s .
Page 84 of 249
5
75
Automatic illumination of
headlamps
T h e d i p p e d b e a m h e a d l a m p s s w i t c h
o n a u t o m a t i c a l l y i f t h e l i g h t i s p o o r a n d
when the windscreen wipers operate
continuously. They switch off when
the light is bright enough or the wind-
screen wipers stop.
Warning: in foggy weather or in snow,
t h e s u n s h i n e s e n s o r c a n d e t e c t s u f fi -
c i e n t l i g h t . T h e l i g h t i n g w i l l n o t c o m e
o n a u t o m a t i c a l l y . I f n e c e s s a r y , y o u
m u s t s w i t c h t h e d i p p e d b e a m h e a d -
l a m p s o n m a n u a l l y . Activation Manual "Guide-me-home" lighting
When you leave your vehicle, the side-
l a m p s a n d d i p p e d b e a m h e a d l a m p s
can be left on for a few seconds.
When the function is activated, the
i n d i c a t o r l a m p c o m e s o n o n t h e
5 - d i a l i n s t r u m e n t p a n e l s c r e e n .
To deactivate or activate the
function, use the "Persona-
l i s a t i o n - c o n fi g u r a t i o n "
m e n u o n y o u r m u l t i f u n c t i o n
screen.
F o r s a f e t y r e a s o n s , a c t i v a t i o n /
d e a c t i v a t i o n o f t h e " A u t o m a t i c
i l l u m i n a t i o n o f h e a d l a m p s s "
f u n c t i o n v i a t h e m e n u m u s t b e
carried out when stationary. To deactivate or activate the
" A u t o m a t i c g u i d e - m e - h o m e
lighting" function, use the
"Personalisation - confi-
guration" m e n u o n y o u r
m u l t i f u n c t i o n s c r e e n .
The duration of the lighting
can be set via the "Person-
a l i s a t i o n - c o n fi g u r a t i o n "
m e n u o f y o u r m u l t i f u n c t i o n
screen.
Automatic "Guide-me-home"
lighting
When you leave your vehicle
with
the automatic illumination of head-
lamps a c t i v a t e d , t h e s i d e l a m p s a n d
d i p p e d b e a m h e a d l a m p s r e m a i n o n
for the duration selected after the igni-
tion is switched off.
Deactivation
When the function is deactivated,
t h e i n d i c a t o r l a m p c o m e s o n o n t h e
5 - d i a l i n s t r u m e n t p a n e l s c r e e n .
D o n o t c o v e r t h e s u n s h i n e /
brightness sensor, located in
the centre of the windscreen.
It is used to regulate the air
c o n d i t i o n i n g a n d f o r t h e a u t o m a t i c i l -
l u m i n a t i o n o f h e a d l a m p s .
If the sunshine/brightness sensor
does not function correctly, the
s i d e l a m p s a n d d i p p e d b e a m h e a d l a m -
p s c o m e o n .
Consult a PEUGEOT dealer.
Activation:
switch off the engine,
" fl a s h " t h e h e a d l a m p s ,
get out of the vehicle and lock it.
Page 85 of 249
5
75
Automatic illumination of
headlamps
T h e d i p p e d b e a m h e a d l a m p s s w i t c h
o n a u t o m a t i c a l l y i f t h e l i g h t i s p o o r a n d
when the windscreen wipers operate
continuously. They switch off when
the light is bright enough or the wind-
screen wipers stop.
Warning: in foggy weather or in snow,
t h e s u n s h i n e s e n s o r c a n d e t e c t s u f fi -
c i e n t l i g h t . T h e l i g h t i n g w i l l n o t c o m e
o n a u t o m a t i c a l l y . I f n e c e s s a r y , y o u
m u s t s w i t c h t h e d i p p e d b e a m h e a d -
l a m p s o n m a n u a l l y . Activation Manual "Guide-me-home" lighting
When you leave your vehicle, the side-
l a m p s a n d d i p p e d b e a m h e a d l a m p s
can be left on for a few seconds.
When the function is activated, the
i n d i c a t o r l a m p c o m e s o n o n t h e
5 - d i a l i n s t r u m e n t p a n e l s c r e e n .
To deactivate or activate the
function, use the "Persona-
l i s a t i o n - c o n fi g u r a t i o n "
m e n u o n y o u r m u l t i f u n c t i o n
screen.
F o r s a f e t y r e a s o n s , a c t i v a t i o n /
d e a c t i v a t i o n o f t h e " A u t o m a t i c
i l l u m i n a t i o n o f h e a d l a m p s s "
f u n c t i o n v i a t h e m e n u m u s t b e
carried out when stationary. To deactivate or activate the
" A u t o m a t i c g u i d e - m e - h o m e
lighting" function, use the
"Personalisation - confi-
guration" m e n u o n y o u r
m u l t i f u n c t i o n s c r e e n .
The duration of the lighting
can be set via the "Person-
a l i s a t i o n - c o n fi g u r a t i o n "
m e n u o f y o u r m u l t i f u n c t i o n
screen.
Automatic "Guide-me-home"
lighting
When you leave your vehicle
with
the automatic illumination of head-
lamps a c t i v a t e d , t h e s i d e l a m p s a n d
d i p p e d b e a m h e a d l a m p s r e m a i n o n
for the duration selected after the igni-
tion is switched off.
Deactivation
When the function is deactivated,
t h e i n d i c a t o r l a m p c o m e s o n o n t h e
5 - d i a l i n s t r u m e n t p a n e l s c r e e n .
D o n o t c o v e r t h e s u n s h i n e /
brightness sensor, located in
the centre of the windscreen.
It is used to regulate the air
c o n d i t i o n i n g a n d f o r t h e a u t o m a t i c i l -
l u m i n a t i o n o f h e a d l a m p s .
If the sunshine/brightness sensor
does not function correctly, the
s i d e l a m p s a n d d i p p e d b e a m h e a d l a m -
p s c o m e o n .
Consult a PEUGEOT dealer.
Activation:
switch off the engine,
" fl a s h " t h e h e a d l a m p s ,
get out of the vehicle and lock it.
Page 88 of 249
5
78
Automatic rain sensitive
windscreen wipers
Activation REAR WIPER CONTROL (407 SW)
Deactivation
Do not cover the rain sensor
located on the windscreen be-
h i n d t h e r e a r v i e w m i r r o r .
W h e n u s i n g a n a u t o m a t i c c a r
wash to wash your vehicle, switch off
the ignition or check that the wiper
s t a l k i s n o t i n t h e a u t o m a t i c p o s i t i o n .
In winter, it is advisable to wait for the
w i n d s c r e e n t o c o m p l e t e l y c l e a r o f i c e
b e f o r e o p e r a t i n g t h e a u t o m a t i c w i p e r s . Automatic rear wiper
If the windscreen wipers control is ac-
tivated and you engage reverse gear,
t h e r e a r w i p e r o p e r a t e s i n i n t e r m i t t e n t
m o d e .
Note: if a bicycle carrier is
used, deactivate this function
by going to the "personalisa-
t i o n - c o n fi g u r a t i o n " m e n u o n
t h e m u l t i f u n c t i o n s c r e e n o r i n s t a l l a
special bicycle carrier approved by
PEUGEOT.
T u r n t h e r i n g t o t h e fi r s t n o t c h f o r i n t e r -
m i t t e n t w i p i n g .
The control must be reactivated if
the ignition has been switched off.
T o d o t h i s , m o v e t h e c o n t r o l t o a n y
position then return it to the required
position.
Move the control to position
0 then re-
turn it to the AUTO position.
A n i n d i c a t o r l a m p c o m e s o n o n t h e i n -
s t r u m e n t p a n e l s c r e e n , a c c o m p a n i e d
b y a m e s s a g e o n t h e m u l t i f u n c t i o n
screen.
In the AUTO position, the windscreen
w i p e r s o p e r a t e a u t o m a t i c a l l y a n d
adapt their speed to the intensity of
the rainfall.
C o n t r o l w i t h a u t o m a t i c w i p i n g o n l y
In the event of malfunction , the
windscreen wipers will operate in in-
t e r m i t t e n t m o d e .
Contact a PEUGEOT dealer to have
t h e s y s t e m c h e c k e d .
C o n t r o l w i t h I n t e r m i t t e n t a n d a u t o m a t i c w i p i n g
Manual operation of the wiper stalk in-
terrupts the AUTO position, the deacti-
v a t i o n i n d i c a t o r l a m p c o m e s o n o n t h e
i n s t r u m e n t p a n e l s c r e e n , a c c o m p a -
n i e d b y a m e s s a g e o n t h e m u l t i f u n c -
tion screen. Manual operation of the wiper stalk by
m o v i n g t h e s t a l k
A up and returning
it to position "0" interrupts the AUTO
position, the deactivation indicator
l a m p c o m e s o n o n t h e i n s t r u m e n t p a n -
e l s c r e e n , a c c o m p a n i e d b y a m e s s a g e
o n t h e m u l t i f u n c t i o n s c r e e n .
Page 89 of 249
5
78
Automatic rain sensitive
windscreen wipers
Activation REAR WIPER CONTROL (407 SW)
Deactivation
Do not cover the rain sensor
located on the windscreen be-
h i n d t h e r e a r v i e w m i r r o r .
W h e n u s i n g a n a u t o m a t i c c a r
wash to wash your vehicle, switch off
the ignition or check that the wiper
s t a l k i s n o t i n t h e a u t o m a t i c p o s i t i o n .
In winter, it is advisable to wait for the
w i n d s c r e e n t o c o m p l e t e l y c l e a r o f i c e
b e f o r e o p e r a t i n g t h e a u t o m a t i c w i p e r s . Automatic rear wiper
If the windscreen wipers control is ac-
tivated and you engage reverse gear,
t h e r e a r w i p e r o p e r a t e s i n i n t e r m i t t e n t
m o d e .
Note: if a bicycle carrier is
used, deactivate this function
by going to the "personalisa-
t i o n - c o n fi g u r a t i o n " m e n u o n
t h e m u l t i f u n c t i o n s c r e e n o r i n s t a l l a
special bicycle carrier approved by
PEUGEOT.
T u r n t h e r i n g t o t h e fi r s t n o t c h f o r i n t e r -
m i t t e n t w i p i n g .
The control must be reactivated if
the ignition has been switched off.
T o d o t h i s , m o v e t h e c o n t r o l t o a n y
position then return it to the required
position.
Move the control to position
0 then re-
turn it to the AUTO position.
A n i n d i c a t o r l a m p c o m e s o n o n t h e i n -
s t r u m e n t p a n e l s c r e e n , a c c o m p a n i e d
b y a m e s s a g e o n t h e m u l t i f u n c t i o n
screen.
In the AUTO position, the windscreen
w i p e r s o p e r a t e a u t o m a t i c a l l y a n d
adapt their speed to the intensity of
the rainfall.
C o n t r o l w i t h a u t o m a t i c w i p i n g o n l y
In the event of malfunction , the
windscreen wipers will operate in in-
t e r m i t t e n t m o d e .
Contact a PEUGEOT dealer to have
t h e s y s t e m c h e c k e d .
C o n t r o l w i t h I n t e r m i t t e n t a n d a u t o m a t i c w i p i n g
Manual operation of the wiper stalk in-
terrupts the AUTO position, the deacti-
v a t i o n i n d i c a t o r l a m p c o m e s o n o n t h e
i n s t r u m e n t p a n e l s c r e e n , a c c o m p a -
n i e d b y a m e s s a g e o n t h e m u l t i f u n c -
tion screen. Manual operation of the wiper stalk by
m o v i n g t h e s t a l k
A up and returning
it to position "0" interrupts the AUTO
position, the deactivation indicator
l a m p c o m e s o n o n t h e i n s t r u m e n t p a n -
e l s c r e e n , a c c o m p a n i e d b y a m e s s a g e
o n t h e m u l t i f u n c t i o n s c r e e n .
Page 118 of 249
8DRIVING
102
TYRE UNDER-INFLATION DETECTION
Sensors check the tyre pressure dur-
ing driving and trigger a warning in the
event of malfunction.
D e fl a t e d t y r e Instrument panel display warn-
ing lamp.
This is accompanied by the audible
signal and the message on the mul-
tifunction screen identifying the wheel
concerned.
If this warning lamp comes on, have
the tyre pressure checked as soon as
possible.
Puncture
This warning lamp, accompanied by
the audible signal and the message on
the multifunction screen identifying the
wheel concerned, is followed by illumi-
nation of the 'STOP' warning lamp. Stop as soon as it is safe to do so,
avoiding any sudden movement of the
steering wheel and the brakes.
Change the damaged wheel (punc-
t u r e d o r v e r y d e fl a t e d t y r e ) , a n d h a v e
the tyre pressure checked as soon as
possible.
Sensor(s) not detected or faulty
Instrument panel screen warn-
ing lamp. All repairs and changing of
t y r e s o n a w h e e l fi t t e d w i t h t h i s
system must be carried out by
a PEUGEOT dealer.
If, when changing a tyre, you install a
wheel which is not detected by your
vehicle, you must have the system re-
initialised by a PEUGEOT dealer.
T h e t y r e u n d e r - i n fl a t i o n d e t e c t i o n s y s -
tem is an aid to driving which does not
replace the need for the driver to be
vigilant or to drive responsibly.
This system does not eliminate the
need to have the tyre pressures
checked regularly (see the label on
the door pillar) to ensure that the op-
timum dynamic performance of the
vehicle is maintained and prevent pre-
mature wear of the tyres, particularly
in arduous driving conditions (heavy
load, high speed).
The tyre pressures must be checked
cold, at least once a month. Remem-
ber to check the pressure of the spare
wheel.
T h e t y r e u n d e r - i n fl a t i o n d e t e c t i o n
system may experience temporary
interference due to electromagnetic
emissions on a frequency close to that
used by the system.
Note : this message is also
displayed when one of the
wheels is away from the ve-
hicle (being repaired) or when
one or more wheels without a sensor
a r e fi t t e d .
Instrument panel display warn-
ing lamp.
This is accompanied by the audible
signal and the message on the mul-
tifunction screen which indicates that
u n d e r - i n fl a t i o n d e t e c t i o n i s a b s e n t
from one (or several) wheel(s) or that
there is a fault in the system.
Contact a PEUGEOT dealer to replace
the faulty sensor(s).
