PEUGEOT 5008 2010.5 Owners Manual
Manufacturer: PEUGEOT, Model Year: 2010.5, Model line: 5008, Model: PEUGEOT 5008 2010.5Pages: 345, PDF Size: 22.77 MB
Page 311 of 345
07
3
2
1
6
4
5
279
SELECTING/PLAYING MUSIC
CD, MP3/WMA CD
The playing and displaying of an MP3/WMA compilation may depend on the recording programme and/or the settings used. W e r e c o m m e n d t h e I S O 9 6 6 0 fi l e s t a n d a r d .
Press the MUSIC button.
Select the "Select music" function a n d p r e s s t h e d i a l t o c o n fi r m .
Press the up or down button to select the next/previous folder.
Select the music source required: CD, MP3/WMA CD. Press the dial to c o n fi r m . P l a y b e g i n s .
Select music
Press the MUSIC button again or select the Music Menu function and p r e s s t h e d i a l t o c o n fi r m .
Press one of the buttons to select a music track.
Press and hold one of the buttons for fast forward or rewind play. Music Menu
T h e l i s t o f t r a c k s o r M P 3 / W M A fi l e s a p p e a r s u n d e r M u s i c M e n u .
MUSIC MEDIA PLAYERS
Page 312 of 345
07
43
1
2
280
MUSIC MEDIA PLAYERS
Connect the portable device (MP3/WMA player…) to the auxiliary JACK socket or to the USB port, using a suitable audio cable.
Press the MUSIC button then press it again or select the Music Menu function and press the dial to c o n fi r m .
Select the AUX music source and p r e s s t h e d i a l t o c o n fi r m . P l a y b e g i n s automatically.
Select the "External device" function and press the dial to activate it.
External device
The display and management of the controls is via the porta
ble device.
USING THE EXTERNAL INPUT (AUX)
Music Menu
JACK/USB AUDIO CABLE NOT SUPPLIED
Page 313 of 345
08
1
2
3
2
1
4
281
* The services available depend on the network, the SIM
card and the compatibility of the Bluetooth telephone used. Check the t elephone manual and with your network provider for details of the services available to you. A list of mobile telephones with the best level of compatibility is available from the dealer network.
BLUETOOTH TELEPHONE
CONNECTING A TELEPHONE
For reasons of safety and because they require prolonged atte ntion on the part of the driver, the operations for pairing the Bluetooth mobile telephone to the hands-free system of the Peugeot Con nect Navigation must be carried out with the vehicle stationary. The ignition must be on.
Activate the telephone's Bluetooth function.
The last telephone connected is reconnected automatically.
Enter the authentication code on the telephone. The code to be entered is displayed on the screen.
To change the telephone connected, press the PHONE button, then select Phone Menu and press the dial to c o n fi r m .
Once the telephone has been connected, Peugeot Connect Navigation can synchronise the address book and the call list. T his synchronisation may take a few minutes * .
Select "Connect phone". Select the t e l e p h o n e a n d p r e s s t o c o n fi r m .
The list of telephones connected previously (4 maximum) appears on the multifunction screen. Select the telephone required for a new connection.
Press the PHONE button.
F o r a fi r s t c o n n e c t i o n , s e l e c t "Search phone" and press the dial to c o n fi r m . T h e n s e l e c t t h e n a m e o f t h e telephone.
Search phone
Connect phone
Page 314 of 345
08
1
3
2
2
1
282
Select the "Yes" tab to accept or "No" t o r e f u s e a n d c o n fi r m b y p r e s s i n g the dial.
RECEIVING A CALL MAKING A CALL
An incoming call is announced by a ring and a superimposed display on the multifunction screen.
Yes
To hang up, press the PHONE button or press the dial and select "End call" t h e n c o n fi r m b y p r e s s i n g t h e d i a l .
End call
Press the PHONE button.
Select "Dial number", then dial the telephone number using the virtual keypad.
Select the Phone Menu function and p r e s s t h e d i a l t o c o n fi r m .
The list of the last 20 calls made and received in the veh
icle appears under Phone Menu. You can select a number and press the dial to make the call.
No
It is also possible to select a number from the address book. You can select "Dial from address book". The Peugeot Connect Navigation can record up to 4 000 entries.
Press the end of the steering mounted control for more than tw o seconds to gain access to the address book.
Phone Menu
Dial number
To delete a number, press the PHONE button then press and hold on a call number to display a list of actions including:
Delete entry
Delete list
BLUETOOTH TELEPHONE
Press the end of the steering mounted control to accept the call or end the call in progress.
Page 315 of 345
09
4
3
2
1
6 5
283
CONFIGURATION
SETTING THE DATE AND TIME The SETUP function gives access to the following options: Syst
em language, Date & Time, Display (Brightness, Colour, Map colour), Vehicle, Units, System.
Adjust the settings one by one using t h e d i r e c t i o n a r r o w s a n d c o n fi r m b y means of the dial.
Select the "Date format" function and p r e s s t h e d i a l t o c o n fi r m .
Select the "Set date & time" function a n d p r e s s t h e d i a l t o c o n fi r m .
C o n fi r m t h e f o r m a t r e q u i r e d u s i n g t h e d i a l .
Pressing the SETUP button for more than 2 seconds gives access to:
These settings must be entered again if the battery has been disconnected.
Press the SETUP button.
C o n fi r m t h e f o r m a t r e q u i r e d u s i n g the dial.
Select the "Time format" function and p r e s s t h e d i a l t o c o n fi r m .
Set date & time
Select the "Date & Time" function a n d p r e s s t h e d i a l t o c o n fi r m .
Demo mode
GPS coverage
Description of the unit
Date & Time
Page 316 of 345
10
1
284
TRIP COMPUTER
TRIP COMPUTER
Press the MODE button several times in succession until the trip computer is displayed.
Range: displays the distance which can travelled with the remaining fuel detected in the tank, based on the average fuel consumption over the last few miles (kilometres).
T h i s d i s p l a y e d v a l u e m a y v a r y s i g n i fi c a n t l y f o l l o w i n g a c h a n g e i n the vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are d i s p l a y e d . A f t e r fi l l i n g w i t h a t l e a s t 5 l i t r e s o f f u e l , t h e r a n g e i s recalculated and is displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits, contact a PEUGEOT dealer.
Each press of the button at the end of the wiper stalk displays the different trip computer information in succession, according t o the screen.
A FEW DEFINITIONS
- The "vehicle" tab:
The range, the current fuel consumption and the distance remaining.
- The "1" (trip 1) tab with:
The average speed, the average fuel consumption and the distance travelled calculated over route "1".
- The "2" (trip 2) tab with the same functions for a second route.
Current fuel consumption: only calculated and displayed above 20 mph (30 km/h).
Average fuel consumption: this is the average fuel consumption since the last trip computer zero reset.
Distance travelled: calculated since the last trip computer zero reset.
Distance remaining to the destination: calculated with reference t o t h e fi n a l d e s t i n a t i o n , e n t e r e d b y t h e u s e r . I f g u i d a n c e i s a c t i v a t e d , the navigation system calculates it as a current value.
Average speed: this is the average speed calculated since the last trip computer zero reset (ignition on).
Page 317 of 345
11
RADIO
285
SCREEN MENU MAP
"Traffic" Menu
Messages on route
Only warnings on route
All warning messages
All messages
Within 2 miles (3 km)
Geo. Filter
Within 3 miles (5 km)
Within 6 miles (10 km)
Within 30 miles (50 km)
Within 60 miles (100 km)
"Music" Menu
Select music
Sound settings
Balance/Fader
Bass/Treble
Linear
Equalizer
Classic
Jazz
Rock/Pop
Techno
Vocal
Loudness
Speed dependent volume
Reset sound settings
"Radio" Menu
Waveband
AM
Linear
FM
Manual tune
Sound settings
Balance/Fader
Bass/Treble
Equalizer
MAIN FUNCTION
OPTION A
option A1
option A2
OPTION B...
1
2
3
1
2
4
1
2
3
4
3
3
3
3
2
2
2
2
4
4
4
4
4
3
3
3
3
3
2
3
2
2
3
3
3
3
1
2
3
2
3
Page 318 of 345
286
Abort guidance/Resume guidance
Destination input
Geo position
Map
Stopovers
Add stopover
Navigate HOME
Choose from address book
Rearrange route
Choose from last destinations
Replace stopover
Delete stopover
Recalculate
Fast route
Short route
Optimized route
POI search
POI nearby
Route options
Route type
Short route
Fast route
"Navigation" Menu
City
Street
Enter new address
Country
Navigate HOME
City district
House number
Start route guidance
Postal code
Save to address book
Intersection
Address input
POI near destination
POI in city
POI in country
POI near route
Choose from address book
3
3
Choose from last destinations
TMC station information
Loudness
Speed dependent volume
Reset sound settings
3
3
3
1
2
4
4
4
4
4
4
4
4
4
4
4
3
2
3
3
2
3
4
4
4
4
3
3
3
3
4
4
4
2
4
2
3
3
3
3
3
3
4
Classic
Jazz
Rock/Pop
Techno
Vocal
4
4
4
4
4
Page 319 of 345
287
Avoid ferries
Recalculate
Settings
Navi volume
POI categories on Map
Set parameters for risk areas
Display on map
Visual alert
Sound alert
3
2
4
3
3
3
4
4
4
Dial from address book
"Phone" Menu
Search phone
Call lists
Connect phone
Select ring tone
Phone/Ring tone volume
Phones connected
Enter mailbox number
Settings
Disconnect phone
Rename phone
Delete pairing
Delete all pairings
Show details
"SETUP" menu
System language *
English
Español
Deutsch
Italiano
Français
Nederlands
Polski
Portuguese
Date & Time *
Set date & time
Date format
Time format
1
2
2
2
2
3
3
4
4
4
4
4
2
3
3
3
1
2
3
3
3
3
3
3
3
3
3
3
3
2
Avoid motorways
Route dynamics
T r a f fi c i n d e p e n d e n t
Semi-dynamic
Avoidance criteria
Avoid toll roads
Optimized route
3
3
4
4
4
4
4
* Available according to model.
Page 320 of 345
288
* Available according to model.
Dark blue
Map colour
Night mode for map
Units
Day mode for map
Vehicle *
Vehicle information
Alert log
Status of functions
Temperature
Celsius
Fahrenheit
Metric/Imperial
Kilometres (Consumption: l/100)
Kilometres (Consumption: km/l)
Miles (Consumption: MPG)
System
Auto. Day/Night for map
Factory reset
Software version
Automatic scrolling
3
4
4
2
4
3
4
4
2
3
4
4
3
4
4
4
2
4
3
3
3
Colour
Pop titanium
Toffee
Blue steel
Technogrey
3
4
4
4
4
Display
Brightness
2
3
