YOUR 807 AT A GLANCE14REAR PARKING
ASSISTANCE
This system, installed in the rear
bumper, detects any obstacle
(person, vehicle, tree, barrier,
kerb, ...) behind the vehicle.
Switching on
With the engine running, the sys
tem is activated when reverse
gear is engaged. A bleep indi
cates that it is active.
The proximity information is
given by an audible signal, con
sisting of bleeps which becomes
more rapid as the vehicle
approaches the obstacle.
When the distance between the
rear of the vehicle and the obsta
cle is less than approximately
twentyfive centimetres, the audi
ble signal becomes continuous. ➜When you change to
neutral, the system
becomes inactive
again. TYRE UNDERINFLATION
DETECTION
Sensors check the pressure of
the tyres while driving and trigger
a warning in the event of a mal
function (speed above 15 mph
[25 km/h]).
Tyre(s) underinflated
When this message appears on
the multi–function display, accom
panied by an audible signal, have
the pressure of the tyres checked
as soon as possible.
Tyre(s) punctured
The appearance of this message,
accompanied by an audible sig
nal, is followed by illumination of
the
STOP warning light.
Stop immediately, avoiding any
sharp action on the steering
wheel or the brakes.
Change the damaged (punctured
or significantly underinflated)
wheel and have the pressure of
the tyres checked as soon as
possible.
Note: if the damaged wheel is
stored in the boot temporarily, it
will transmit this message again
as a reminder that it must be
repaired, which will prevent
another warning of the same type
being displayed.
The spare wheel does not have a
sensor. X type pressure sensor(s)
missing
The appearance of this message,
accompanied by an audible
warning, indicates that one wheel
(or more) is no longer detected.
Consult a PEUGEOT dealer to
have the faulty sensor(s)
replaced.
Warning:
this message is also
displayed when one of the
wheels is removed from the vehi
cle (for repair) or when a wheel is
fitted which is not equipped with
a sensor (winter tyres).
This system does not eliminate
the need to have the pressure
of the tyres checked regularly.
131141

PEUGEOT SERVICING Your vehicle's servicing schedule is based on level Aservices (engine oil change, checks and topups) and level Cservices
( level A + workshop operations carried out every 40,000/36,000 miles (60 00 0 km)) in accordance with the tables on the fol
lowing pages.
Irrespective of the conditions in which your vehicle is used, the interval between two level Aservices may not exceed:
• For petrol engines, 20,000 miles (30 000 km) or 2 years .
• For HDI turbo diesel engines, 12,000 miles (20 000 km) or 2 years .
In all cases, the extension of the service intervals mea ns that the engine oil level must be checked regularly: top
ping up of the oil between oil changes is normal.
It is for this reason that your PEUGEOT dealer invites you to make an intermediate visit between each service. The
service indicator does not indicate when this visit is d ue.
This visit is to be made between two services.
A Peugeot professional will carry out a quick check and will top up the levels if necessary (oil, coolant, screenwash up to
2 litres).
If the oil level is too low there is a risk of serious d amage to the engine: check the engine oil level at least every
3,000 miles (5 000 km)
This extended servicing has been made possible by modifications t o our vehicles and to the lubricants:
THUS IT IS ESSENTIAL TO ONLY USE ENGINE LUBRICANTS THAT ARE APPROVED AND RECOMMEN DED BY THE
MANUFACTURER (see "Lubricants" pages).
Arduous conditions of use
If the vehicle is used in certain particularly arduous condition s such ascontinuous doortodoor use, town use (e.g. taxi),
repeated short journeys, with the engine cold in low tem peraturesor for long stays in hot countries with temperatures
often above 30 °C , cold countrieswith temperatures often below minus 15 °C, countries with a dusty atmosphere, and
countries whose lubricantsor fuels do not conform to our recommendations.
It is necessary to follow an "Arduous conditions" servicing schedule w hich includes special operations and shorter service
intervals:
• Every 12,000 miles (20 000 km) or every year for petrol vehicles.
• Every 10,000 miles (15 000 km) or every year for HDI Turbo Diesel en gine vehicles.
PEUGEOT SERVICING
18
18-11-2002

Level
Operations Description of operation 1st service
AC Intermediate
LEVEL
CHECK
DRAIN/REFILL
REPLACE
PEUGEOT SERVICING 19
Oil filter.
Fuel filter
*(petrol). Fuel filter element (diesel). Air filter element. Spark plugs (petrol).
Engine oil. Bleed fuel filter (diesel).
Engine oil (check + topup). Manual gearbox oil (check + topup). Battery (check + topup) if cap is removable. Screen wash (check + topup). Coolant (check + topup). Brake fluid (check + topup). Power steering fluid (check + top up according to specification). Operation of lights and indicators. Condition of glass, headlamp and light lenses and mirrors. Horn. Windscreen washer jets. Condition of wiper blades. Condition and tension of the ancillary drive belts. Handbrake. Condition of hydraulic circuits (hoses and covers).
Condition of rubber boots and gaiters. Brake pads.
o Play in hubs, link rods, ball joints, flexible mountings. Shock absorbers. Rear drum brake lining wear. Condition and pressure of tyres (including spare wheel). Emission control check as per current legislation (petrol). Smoke opacity (diesel). Pollen filter (according to specification).

oVisual check of the whole vehicle.

: All driving conditions o: Arduous conditions * According to destination
ROAD TEST
A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT
18-11-2002

PEUGEOT SERVICING23
Zero reset Y our PEUGEOT dealer carries out
this operation after each service.
However, if you carry out the service
yourself, the reset procedure is as
follows:
 Switch off the ignition,
 Press and hold the trip recorder
reset button,
 Switch on the ignition.
The display begins a countdown.
When the display shows "=0", relea
se the button; the service symbol
disappears.
Important: after this operation, if
you wish to disconnect the battery,
lock the vehicle and wait for at least
five minutes, otherwise the zero re
set will not be registered.
MAINTENANCE OF PARTS SUBJECT TO WEAR AND A CHECK OF
CONSUMABLES
Certain essential components on your vehicle are subject to checks a t specific
frequencies.
• The brake fluid is to be replaced at a maximum of every 36,000/40,000 miles
(60 000km) or every two years;
• The pollen filter must be checked at each serviceby a PEUGEOT dealer
(services and intermediate visits) or more often, depending on the environ
ment (dust, pollution, etc.);
• For HDI turbo diesel engines with particulate emission filter , maintenance
of the filterand topping up of the additive reservoirmust be carried out at a
maximum of every 48,000 miles (80 000 km) by a PEUGEOT dealer;
• Replacement of the timing belt: contact a PEUGEOT dealer.
• Air bags and pretensioning parts on seat belts must be checked every
10 years.
• Tyre pressure sensors are to be replaced every 10 years.
• The check on tyre inflation presure must be carried out cold at least once a
month.
Note: the engine coolant does not have to be replaced.
18-11-2002

Maximum
Minimum
Check the level with
the dipstick and top it
up.
The figure shown is
only correct if the vehicle has been
on stable, level ground, with the
engine stopped, for 10 minutes.
No oil
The message "Top
up the oil" appears
on the multifunction
display, accompa
nied by an audible signal.
It is essential to top up the oil to the
correct level, otherwise the engine
may be damaged.
Oil gauge fault
Flashing of the seg
ments indicates a
fault.
Check the level
using the dipstick.
Consult a PEUGEOT dealer. Control module display
After switching on the ignition, three
functions are shown in succession:
– service indicator (see correspond ing section),
– engine oil level indicator,
– total distance recorder (total and trip distances).
Note: the total and trip distances are
displayed for thirty seconds, when
the ignition is switched off, on open
ing the driver's door as well as on
locking and unlocking the vehicle.
It also displays the automatic gear
box positions and programmes
selected (see corresponding sec
tion).
Engine oil level
When the ignition is switched on, the
engine oil level is indicated for
approximately 10 seconds, after the
service information. Lighting rheostat
With the lights on,
press the button to
vary the intensity of
the lighting of the
control module, the
instrument panel, the
air conditioning dis
play and the multi–function display.
When the lighting reaches the mini
mum (or maximum) setting, release
it then press again to increase (or
reduce) the brightness.
As soon as the lighting is of the
brightness required, release the
button.
Trip recorder
zero reset
With the ignition on,
press the button.
INSTRUMENTS AND CONTROLS
34
18-11-2002

Removing a seat
Fold the corresponding seat.
Grasp the two bars Gunder the seat
and tighten them securely.
The front anchorages unlock.
Lift the seat and carry it using the
carrying handle H.
Refitting a seat
Check that there is no obstacle
obstructing the slides or preventing
correct locking of the seat.
Locate the front anchorages in the
slides (if necessary tighten the two
bars Gsecurely).
Tilt the folded seat towards the rear.
The rear anchorages lock.
Lift the seat back (for the centre seat,
move control E) Turning a seat round
The rear seats can be placed in the
'rearwards facing' position.
For this, after the seat has been fold
ed, carry out the removal and replac
ing operations for the seat and turn it
round.
YOUR 807 IN DETAIL
94
Table position of the centre seat
Place the head restraint in the low
position.
Push control Eupwards.
Tilt the seat back forwards.
You now have a table with two cup
holders.
Folding the centre seat
Place the seat in the table position.
Lift control F
Place the seat in the closed position. This turning operation
must be carried out with
the engine switched off.
It is prohibited to sit facing
the rear when the vehicle
is being driven.
Never use the adjusting straps to
remove, refit or transport a seat.
When the vehicle is being driven,
it is prohibited to place a side seat
in the closed position, when a
passenger is sitting in the 3rd row.
18-11-2002

YOUR 807 IN DETAIL
110
SUNROOFS You have three sunroofs each with
an independent control.
However, the front passengers' con
trol can also operate the two rear
sunroofs simultaneously.
•partially open the roof: press and
hold part Aof the switch.
•to open the roof completely:
press part Aof the switch briefly.
•to close it completely: press part
B of the switch briefly, then keep it
pressed.
•safety autoreverse
When the sunroof is sliding closed
and meets an obstacle, it stops then
opens again.
Note: in the presence of ice, if the
sunroof does not close, press the
control until the roof is fully open,
then close the roof. Note:
following reconnection of the
battery, if the sunroof does not close,
release the control and press it sev
eral times until the roof is fully
closed. Continue to press the control
for approximately five seconds after
closing.
Disarming of the 2 nd
and 3 rd
row
controls:
– press the rear electrical functions disarming switch.
Note: the sunroof shutter is manual.
To open it, lift the handle and slide it
rearwards.
To close it, slide it forwards until the
handle locks. OPENING THE BONNET
From inside:
– lift the cover at the left foot of the
passenger seat.
– pull the control upwards.
From outside: lift the catch and
raise the bonnet.
Bonnet strut
Secure the strut to hold the bonnet open.Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked.
"Bonnet open" warning
This warning is linked to the alarm
option only.
With the engine running or the
vehicle moving, a diagram on the
multifunction display, accompanied
by an audible signal, warns you that
the bonnet is not properly closed.
18-11-2002

The ESP system offers
increased safety during
normal driving, but should
not incite the driver to
take risks or to drive at
high speed.
The operation of the system is
ensured to the extent to which the
recommendations of the manufac
turer regarding the wheels (tyres
and wheel rims), the braking
components, the electronic com
ponents and the assembly and
repair procedures within the
PEUGEOT network are observed.
After an impact, have the system
checked by a PEUGEOT dealer.
Operation of the ASR and ESP
systems
When one of these two sys
tems is operating, this light
flashes.
YOUR 807 IN DETAIL 129
Disarming the ESP / ASR
systems
In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),
it could prove useful to disarm the
ASR and ESP systems to make the
wheels spin and regain grip.
Press switch "1", situated under
the steering wheel on the right of
the fascia.
The indicator light comes
on, accompanied by the
message "ESP/ASR dis
armed" : the ESP and ASR
systems no longer act on
the engine operation but remain
active on the brakes.
They engage again:  automatically above 20 mph
(30 km/h),
 manually by pressing switch
1 again. Operating check
When a malfunction of the
systems occurs, the indicator
light comes on accompanied
by an audible signal and the
message "ESP/ASR not
operational" on the multifunction dis
play.
Contact a PEUGEOT dealer to have
the system checked.TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP)
These systems are linked and com
plement the ABS.
The ASR system optimises drive to
prevent the wheels skidding, by acting
on the brakes of the drive wheels and
on the engine. It also allows the direc
tional stability of the vehicle to be
improved on acceleration.
If there is a variation between the tra
jectory followed by the vehicle and
that required by the driver, the ESP
system automatically acts on the
engine and the brake of one or more
wheels, in order to put the vehicle
back on course.
18-11-2002

YOUR 807 IN DETAIL
134
MANUAL GEARBOX
Reverse
*
To change to reverse gear, lift the
ring under the gear lever knob and
push the gear lever to the left then to
the front.
Reverse gear can only be
engaged when the vehicle is sta
tionary with the engine idling.
* According to engine. AIR BAGS
The air bags have been designed to
maximise the safety of the occu
pants in the event of serious colli
sions. They work in conjunction with
the forcelimiting seat belts. The
electronic detectors register and
analyse any abrupt deceleration of
the vehicle : if the triggering thresh
old is reached, the air bags inflate
instantly and protect the occupants
of the vehicle.
Immediately after the impact, the air
bags deflate rapidly so that they do
not hinder the visibility of the occu
pants nor their exit if necessary from
the vehicle.
The air bags are not deployed in the
case of collisions which are not seri
ous, for which the seat belt is suffi
cient to ensure maximum protection.
The seriousness of a collision
depends on the nature of the obsta
cle and the speed of the vehicle at
the moment of the collision.
Air bags only operate when the
ignition is switched on.
Note:
the gas escaping from the air
bags can be a minor irritant. FRONT AIR BAGS
These are folded in the centre of the
steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,
except in cases where the passen
ger air bag is disarmed.
Front air bag fault
If this warning light comeson, accompanied by an
audible signal and the mes
sage "Air bag fault" on the
multi–function display, con
tact a PEUGEOT dealer to
have the system checked.
18-11-2002

YOUR 807 IN DETAIL
134
MANUAL GEARBOX
Reverse
*
To change to reverse gear, lift the
ring under the gear lever knob and
push the gear lever to the left then to
the front.
Reverse gear can only be
engaged when the vehicle is sta
tionary with the engine idling.
* According to engine. AIR BAGS
The air bags have been designed to
maximise the safety of the occu
pants in the event of serious colli
sions. They work in conjunction with
the forcelimiting seat belts. The
electronic detectors register and
analyse any abrupt deceleration of
the vehicle : if the triggering thresh
old is reached, the air bags inflate
instantly and protect the occupants
of the vehicle.
Immediately after the impact, the air
bags deflate rapidly so that they do
not hinder the visibility of the occu
pants nor their exit if necessary from
the vehicle.
The air bags are not deployed in the
case of collisions which are not seri
ous, for which the seat belt is suffi
cient to ensure maximum protection.
The seriousness of a collision
depends on the nature of the obsta
cle and the speed of the vehicle at
the moment of the collision.
Air bags only operate when the
ignition is switched on.
Note:
the gas escaping from the air
bags can be a minor irritant. FRONT AIR BAGS
These are folded in the centre of the
steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,
except in cases where the passen
ger air bag is disarmed.
Front air bag fault
If this warning light comeson, accompanied by an
audible signal and the mes
sage "Air bag fault" on the
multi–function display, con
tact a PEUGEOT dealer to
have the system checked.
18-11-2002
