PEUGEOT 807 2005 Owners Manual

94 -
28-02-2005
95
-
28-02-2005
THE KEYS
The keys allow you to switch on the
ignition and to independently operate
the locks on the driver's door and
passenger door, the fuel iller cap,
the glove box, the passenger air bag
disarming switch and the child safety
lock. Vehicles itted with deadlocking Unlocking
Press button B to unlock the vehicle.
This is conirmed by rapid lashing of
the direction indicators.
The remote control
Version with normal locking
Press button A to lock the vehicle.
This is conirmed by ixed lighting of
the direction indicators for approxi-
mately two seconds. Pressing button
A for more than
2 seconds, in addition to locking
or deadlocking, permits automatic
closing of the windows and places
the sunroofs in the partially open
position, if they were open. To
close them completely, you must
press their switch before leaving
the vehicle.
Folding/opening out the key
To tuck away the key blade, press
button E, then fold it down into the
remote control module.
To open out the key, press button E.
Central locking
From the driver's door or passenger
door, the keys allow you to lock,
deadlock or unlock the doors and
tailgate, as well as fold back the
exterior mirrors.
If one of the doors or the tailgate is
open, the central locking does not
work.
The remote control performs the
same functions at a distance. If the vehicle is locked and
unlocking is activated inad-
vertently, unless the doors
are opened within 30 sec-
onds, the vehicle will lock
automatically.
Opening/Closing the electric
sliding side doors
Pressing button C opens or closes
the rear right door.
Pressing button D opens or closes
the rear left door.
Note: this press unlocks the vehicle
before opening the corresponding
door.
Deadlocking renders the
internal and external door
locking controls inoperative.
Never leave anyone inside
the vehicle when the vehicle
is deadlocked.
Pressing button A locks the vehicle.
This is conirmed by ixed lighting of
the direction indicators for approxi-
mately two seconds.
A second press on button A within
ive seconds of locking changes this
to deadlocking.
This is conirmed by ixed lighting of
the direction indicators for approxi-
mately two seconds.
Note: if the deadlocking is operated
from inside the vehicle, it will change
to normal locking when the vehicle is
started.
Access and starting

94 -
28-02-2005
95
-
28-02-2005
Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park:
F press button A, the courtesy lights
come on and the direction indica-
tors lash for a few seconds.
Changing the battery of the
remote control
The information "battery lat" is given
by an audible signal, accompanied
by a message on the multi-function
display.
To replace the battery (ref.: CR1620/
3 volts), unclip the casing using a
coin at the ring.
If the remote control does not work
after the battery has been changed,
re-program the remote control.
Programming the remote
control
Following changing of the remote
control battery or disconnection of
the vehicle battery, the remote con-
trol must be reprogrammed.
F Wait at least one minute before
using the remote control.
F Switch on the ignition.
F Press button A or B for at least
ive seconds within the next ten
seconds.
F Switch off the ignition.
F Wait at least one minute before
using the remote control.
The remote control is now working
again.
Key in ignition
A message on the multi-function
display, accompanied by a buzzer on
opening the driver's door, indicates
that the key has been left in the
ignition.
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code
must be recognised for starting to be
possible.
If the system does not function
correctly , the central locking button
indicator light, situated on the cour-
tesy light console, lashes rapidly
when the ignition is switched on (2nd
notch).
In this case your vehicle will not
start.
Contact a PEUGEOT dealer as soon
as possible.
Access and starting

94 -
28-02-2005
95
-
28-02-2005
Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park:
F press button A, the courtesy lights
come on and the direction indica-
tors lash for a few seconds.
Changing the battery of the
remote control
The information "battery lat" is given
by an audible signal, accompanied
by a message on the multi-function
display.
To replace the battery (ref.: CR1620/
3 volts), unclip the casing using a
coin at the ring.
If the remote control does not work
after the battery has been changed,
re-program the remote control.
Programming the remote
control
Following changing of the remote
control battery or disconnection of
the vehicle battery, the remote con-
trol must be reprogrammed.
F Wait at least one minute before
using the remote control.
F Switch on the ignition.
F Press button A or B for at least
ive seconds within the next ten
seconds.
F Switch off the ignition.
F Wait at least one minute before
using the remote control.
The remote control is now working
again.
Key in ignition
A message on the multi-function
display, accompanied by a buzzer on
opening the driver's door, indicates
that the key has been left in the
ignition.
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code
must be recognised for starting to be
possible.
If the system does not function
correctly , the central locking button
indicator light, situated on the cour-
tesy light console, lashes rapidly
when the ignition is switched on (2nd
notch).
In this case your vehicle will not
start.
Contact a PEUGEOT dealer as soon
as possible.
Access and starting

96 -
28-02-2005
97
-
28-02-2005
Make a careful note of the
number on each key. The
key number is coded on the
label attached to the key.
If the keys are lost, your
PEUGEOT dealer can rapidly sup-
ply you with new keys.
The high frequency remote con-
trol is a sensitive system; do not
operate it while it is in your pocket
as there is a possibility that it may
unlock your vehicle, without you
being aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Do not operate the deadlocking
function if there is anyone inside
the vehicle.
Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the ignition
key when you leave the vehicle,
even for a short time.
Do not repeatedly press the but-
ton of your remote control out of
range and out of sight of your ve-
hicle. You run the risk of stopping
it from working and the remote
control would have to be repro-
grammed. When purchasing a second-hand
vehicle;
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.CONFIDENTIAL CARD
It contains the identiication code
necessary for any work carried out by
a PEUGEOT dealer on the electronic
immobiliser system. This code is
hidden by a ilm, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or jour-
ney, however, it is advisable to take
it with you along with your personal
papers.
Access and starting

96 -
28-02-2005
97
-
28-02-2005
THE ALARM
This provides two types of protection:
- exterior protection: it sounds if a
door, the tailgate or the bonnet is
opened.
- interior protection: it sounds if the volume inside the passenger com-
partment changes (breaking of a
window or a movement inside the
vehicle). Note:
if you wish to lock your vehicle
without setting the alarm, use the
door lock.
When the alarm is triggered, the si-
ren sounds and the direction indica-
tor lights lash for thirty seconds.
After triggering, the alarm remains set.
Warning: if the alarm has been trig-
gered ten times in succession, on the
eleventh time it becomes inactive.
Note: if the red warning light, located
in the centre of the fascia, lashes
rapidly, the alarm has been triggered
while you were away from your ve-
hicle. To stop it lashing, insert the
remote control key and switch on the
ignition. F
In the next ten seconds, press
button A, located on the left-hand
side of the fascia, until the red in-
dicator light is on continuously,
F Get out of the vehicle,
F Within the next ive minutes, set
the alarm by locking or deadlock-
ing using the remote control (the
red indicator light, located in the
centre of the fascia, lashes once
a second).
Note: when the alarm is set but the
remote control does not operate:
F Unlock the doors with the key and
open the door. The alarm is trig-
gered.
F Switch on the ignition in the next
ten seconds. The alarm is dis-
armed.
Do not make any modifica-
tions to the alarm system
as this could cause faults.
Setting the alarm
F
Switch off the ignition and get out
of the vehicle.
F Set the alarm within ive minutes
of getting out of the vehicle, by
locking or deadlocking using the
remote control (the red indicator
light, located in the centre of the
fascia and visible from the out-
side, lashes once per second).
Disarming
Unlock the vehicle with the remote
control key (the red indicator light,
located in the centre of the fascia,
goes out).
To set the alarm with exterior
protection only
If, while you are away from the ve-
hicle, you wish to leave a window
partially open or a pet inside the
vehicle, you should choose exterior
protection only.
F Close the sunroofs,
F Switch off the ignition, Incorrect operation
When the ignition is switched on, if
the red indicator light, located in the
centre of the fascia, comes on for ten
seconds, there is a fault in the siren
connection.
Contact a PEUGEOT dealer to have
the system checked.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
THE DOORS
Opening the doors from outside
Opening the doors from inside
Note: the door opening switches
do not function when the vehicle is
deadlocked. Locking/Unlocking from the inside
Press button
A, the red warning light
comes on when the vehicle is locked
and switches off when it is unlocked.
This locks/unlocks the doors and the
tailgate.
Note: if the vehicle is locked or dead-
locked from outside, the red warning
light lashes and button A does not
function. In this case, use the key or
the remote control for unlocking.
Electric sliding side doors
Opening/Closing from the front:
- press the corresponding switch B
to open or close.
An audible signal accompanies the
opening and closing of the door.
Automatic central locking
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
You can activate or deactivate this
function.
To switch on
Press and hold button
A.
Activation of the function is accom-
panied by an audible signal and the
message ''Automatic locking of
the doors activated'' on the multi-
function display.
To switch off
Press and hold button A.
Deactivation of the function is ac-
companied by an audible signal.
"Door open" alert
With the engine running or the vehi-
cle moving, a diagram locating the
door on the multi-function display
and an audible signal warn you that
a door is not properly closed. Opening/Closing from the
2nd row:
- press the corresponding switch
C
to open or close.
Disarming the 2nd row controls:
- press the rear electric functions disarming switch.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
THE DOORS
Opening the doors from outside
Opening the doors from inside
Note: the door opening switches
do not function when the vehicle is
deadlocked. Locking/Unlocking from the inside
Press button
A, the red warning light
comes on when the vehicle is locked
and switches off when it is unlocked.
This locks/unlocks the doors and the
tailgate.
Note: if the vehicle is locked or dead-
locked from outside, the red warning
light lashes and button A does not
function. In this case, use the key or
the remote control for unlocking.
Electric sliding side doors
Opening/Closing from the front:
- press the corresponding switch B
to open or close.
An audible signal accompanies the
opening and closing of the door.
Automatic central locking
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
You can activate or deactivate this
function.
To switch on
Press and hold button
A.
Activation of the function is accom-
panied by an audible signal and the
message ''Automatic locking of
the doors activated'' on the multi-
function display.
To switch off
Press and hold button A.
Deactivation of the function is ac-
companied by an audible signal.
"Door open" alert
With the engine running or the vehi-
cle moving, a diagram locating the
door on the multi-function display
and an audible signal warn you that
a door is not properly closed. Opening/Closing from the
2nd row:
- press the corresponding switch
C
to open or close.
Disarming the 2nd row controls:
- press the rear electric functions disarming switch.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
Opening/Closing using the
remote control:
- press button C to open or close the
rear right door.
- press button D to open or close the
rear left door.
Note: the electric sliding side doors
are itted with an obstacle detection
system.
If an obstacle appears while the door
is closing, the door re-opens.
If an obstacle appears while the door
is opening, the door stops.
In both cases, complete the required
action manually using the handle. The force with which the
door moves may cause
injury.
When opening or closing the
door, ensure that nothing
prevents the required manoeuvre.
Do not leave children or animals
near the door controls without super-
vision. If necessary, disarm the con-
trols, then remove the key from the
ignition, even for a short time.
Before setting off, check that the
door is correctly closed and locked
(see "door open" warning).
Child safety
A - Mechanical
This prevents either of the rear doors
being opened from inside.
F Turn the switch A a quarter of a
turn using the ignition key.
B - Electric
This disarms all the electrical con-
trols in the rear:
F electric windows,
F sliding side doors,
F sunroofs.
With the ignition on, press button B.
The message "Child safety acti-
vated" appears on the multi-function
display, accompanied by an audible
signal.
Always remove the ignition
key when leaving the vehi-
cle, even for a short time.
Access and starting

98 -
28-02-2005
99
-
28-02-2005
Opening/Closing using the
remote control:
- press button C to open or close the
rear right door.
- press button D to open or close the
rear left door.
Note: the electric sliding side doors
are itted with an obstacle detection
system.
If an obstacle appears while the door
is closing, the door re-opens.
If an obstacle appears while the door
is opening, the door stops.
In both cases, complete the required
action manually using the handle. The force with which the
door moves may cause
injury.
When opening or closing the
door, ensure that nothing
prevents the required manoeuvre.
Do not leave children or animals
near the door controls without super-
vision. If necessary, disarm the con-
trols, then remove the key from the
ignition, even for a short time.
Before setting off, check that the
door is correctly closed and locked
(see "door open" warning).
Child safety
A - Mechanical
This prevents either of the rear doors
being opened from inside.
F Turn the switch A a quarter of a
turn using the ignition key.
B - Electric
This disarms all the electrical con-
trols in the rear:
F electric windows,
F sliding side doors,
F sunroofs.
With the ignition on, press button B.
The message "Child safety acti-
vated" appears on the multi-function
display, accompanied by an audible
signal.
Always remove the ignition
key when leaving the vehi-
cle, even for a short time.
Access and starting

100 -
28-02-2005
101
-
28-02-2005
TAILGATE
Simultaneous locking or
unlocking of the tailgate and the
doors
The tailgate is locked or unlocked
by the remote control or the driver's
door or passenger door lock.
To open, operate the handle A and
lift the tailgate.
Note: The tailgate locks automati-
cally when the vehicle is being driven
at more than 6 mph (10 km/h) and
unlocks when one of the front doors
is opened.
Tailgate release
This enables the tailgate to be un-
locked in the event of a central lock-
ing fault.
F Fold back a 2nd row rear seat,
F Fold back a 3rd row rear seat or
the bench seat to gain access to
the lock from inside the boot,
F Insert a small screwdriver into
hole B in the lock and push it
towards the left to unlock the tail-
gate.
REAR WINDOWS
To partially open the rear windows,
tilt the lever and push it fully to lock
the windows in the open position.
"Tailgate open" warning
When the engine is running or the
vehicle is being driven, you are
warned if the tailgate is not closed
correctly by a diagram on the multi-
function display, accompanied by an
audible signal.
Access and starting
