Page 3 of 166
6
Familiarisation
INTERIOR
Trip computer
Using the MENU button, this system allows
control or consultation of the various vehicle
c o n fi g u r a t i o n s / i n f o r m a t i o n s u c h a s d e a c t i v a t i o n
of the passenger’s airbag, automatic locking of
the doors, language, etc.
66
Folding multifunction passenger seat
The front passenger seat can be placed in one
o f t h r e e p o s i t i o n s :
- seat for carrying a passenger,
- table to accommodate your various documents,
- f u l l y f o l d e d f o r t r a n s p o r t i n g l o n g o b j e c t s .
80
Audio system
T h e s e s y s t e m s b e n e fi t f r o m t h e l a t e s t
t e c h n o l o g y : M P 3 c o m p a t i b l e a u d i o s y s t e m
and Bluetooth
®
hands-free kit.
71
Cruise control
This system maintains the speed of the vehicle
at a programmed value.
42
Electronic gearbox
This system assures perfect driving by
combining a fully automatic mode and a
manual mode.
48
Page 13 of 166
16
Familiarisation
DRIVING SAFELY
Electronic gearbox Display in the instrument panel Moving off
48
T h i s fi v e - s p e e d g e a r b o x o f f e r s a c h o i c e
between the comfort of automated operation or
the pleasure of manual gear changing.
R. Reverse.
N. Neutral.
A. Automated mode.
M +/-. Sequential mode.
E. Economy programme. The gear and the driving mode selected
appears in the instrument panel screen.
R: reverse gear.
N: neutral.
AUTO: automatic mode.
1 2 3 4 5: gears engaged.
E: Economy programme. Select position
N and press the brake pedal
fi r m l y w h i l e s t a r t i n g t h e e n g i n e .
Start the engine.
E n g a g e fi r s t g e a r ( m o v e f r o m t h e m i d d l e
position towards + ) o r r e v e r s e ( p o s i t i o n R )
using the gear lever.
Release the parking brake.
Release the brake pedal, then accelerate
away.
Page 14 of 166
17
FAMILIARISATION
Familiarisation
Going into engine STOP mode
Stop & Start
- with a manual gearbox; depress the
clutch pedal,
- with an electronic gearbox;
Page 15 of 166
18
Familiarisation
DRIVING SAFELY
1. STOP position- Off.
2. MAR position- Ignition on.
3. AVV position - Starting.
Ignition switch
STARTING
A v o i d a t t a c h i n g h e a v y o b j e c t s t o t h e
key, which could weigh on it while in
t h e i g n i t i o n s w i t c h ; t h i s c o u l d c a u s e
malfunctions.
32
Cruise control
1. C r u i s e c o n t r o l m o d e O n / O f f .
2. Programming of a speed/Decrease the
programmed value.
3. Programming of a speed/Increase the
programmed value.
4. C r u i s e c o n t r o l r e s u m e .
In order to be programmed or activated, the
vehicle speed must be higher than 18 mph
( 3 0 k m / h ) , w i t h a t l e a s t s e c o n d g e a r e n g a g e d
on the gearbox. Display in the instrument panel
The cruise control mode appears in the
instrument panel when it is selected.
Cruise control
42
Page 16 of 166
19
1
READY TO SET OFF
Instruments and controls
INSTRUMENT PANELS
1. Distance recorder in miles/kilometres.
2. Screen.
3. Fuel gauge.
4. Coolant temperature.
5. Rev counter.
Instrument panel with level 1 screen Instrument pan
el with level 2 screen
Instrument panel level 1 screen
- Time.
- Miles/Kilometres travelled.
- Trip computer/range, fuel consumption, average speed.
- Headlamp beam height.
- Programmable overspeed warning.
- Gear shift indicator.
- Stop & Start.
- Activating or deactivating the passenger's airbag.
Instrument panel level 2 screen
- Time.
- Date.
- Radio. - Miles/Kilometres travelled.
- Ambient temperature.
- Modes and gear engaged on the
electronic gear control gearbox.
- Trip computer/range, fuel consumption, average speed .
- Headlamp beam height.
- Programmable overspeed warning.
- Selection of the display language.
- Gear shift indicator.
- Stop & Start.
- Activating or deactivating the passenger's airbag.
- Activation or deactivation of automatic door locking on moving off.
Page 22 of 166
25
1
READY TO SET OFF
Instruments and controls
Warning lamp
is indicates Solution - action
Cruise control on. activation of the cruise
control. Manual selection. Chapter 1, "Steering mounted
controls"
Rear parking sensors on, accompanied by
a message in the
screen. a fault with the system. The audible system is not active.
Have it checked as soon as possible by a
PEUGEOT dealer.
Electronic gearbox on, accompanied by
a message in the
screen.
incorrect operation by the
driver.
Start the desired operation again.
fl a s h i n g , a c c o m p a n i e d
by an audible signal
and a message in the
screen. a fault with the gearbox.
Have it checked as soon as possible by a
PEUGEOT dealer.
Page 50 of 166
42
Steering mounted controls When the system is activated, The "Cruise
control" warning lamp comes on in the
instrument panel:
CRUISE CONTROL
"This is the speed at which the driver wishes
to drive".
This aid to driving in free-flowing traffic
enables the vehicle to maintain the speed
programmed by the driver, without use of the
accelerator pedal.
In order for it to be programmed or
activated, the vehicle speed must be greater
than 18 mph (30 km/h) with at least second
gear engaged on the manual gearbox. Selecting the function
- Place the ring in the
ON position. The cruise
control is selected but
is not yet active and
no speed has been
programmed. First activation/
Programming a speed
- Reach the chosen
speed by pressing the
accelerator.
- Move the control up (+) for at least one second then release it.
This programmes the reference speed. You
can release the accelerator pedal, and the
vehicle will maintain this speed.
Temporarily exceeding
of the speed
It is possible to accelerate
and drive momentarily at
a speed greater than the
programmed speed (for
example to overtake another vehicle).
When the accelerator pedal is released, the
vehicle will return to the programmed speed.
Deactivation
- Press the brake or clutch pedal.
The cruise control is also deactivated if the
ABS or ESP system is invoked.
Page 54 of 166
46
Gearbox and steering wheel Good practice
To change gear smoothly, always press the
clutch pedal fully down.
To prevent the mat from becoming caught
under the pedal:
- ensure that the mat is positioned correctly,
- never fit one mat on top of another.
Avoid leaving your hand on the gear knob as
the force exerted, even if slight, may cause
wear of the internal components of the
gearbox over time.
MANUAL GEARBOX
Reverse gear
Never engage reverse gear until the vehicle
is completely stationary.
The lever should be moved slowly to reduce
the noise on engaging reverse gear. If your vehicle is fitted with parking
sensors, the system comes into
operation when reverse gear is engaged,
confirmed by an audible signal.
Refer to the "Rear parking sensors"
section of chapter 3.
STEERING WHEEL ADJUSTMENT
When the vehicle is stationary, unlock the
steering wheel by pushing the lever down.
Adjust the depth and height of the steering
wheel, then lock by pulling the lever up fully.
Page 55 of 166
47
1
READY TO SET OFF
Gearbox and steering wheel
GEAR SHIFT INDICATOR *
System which reduces fuel consumption
by advising the driver to change gear on
vehicles fitted with a manual gearbox.
Operation
The system intervenes only when driving
economically.
The gear change recommendations must
not be considered compulsory, as the
configuration of the road, the amount of
traffic and safety remain determining factors
when choosing the best gear. Therefore,
the driver remains responsible for deciding
whether or not to follow the advice given by
the system.
This function cannot be deactivated. Example:
- You are in third gear.
- You press the accelerator pedal
moderately.
- The system may suggest that you engage a higher gear, if appropriate. The information appears in the form of the
indicator
SHIFT in the instrument panel
screen, accompanied by an up arrow for
changing up or a down arrow for changing
down
In the case of driving which
makes particular demands on the
performance of the engine (firm pressure
on the accelerator pedal, for example,
when overtaking...), the system will not
recommend a gear change.
* According to engine.
Page 56 of 166
48
Gearbox and steering wheel
ELECTRONIC GEARBOX
The five-speed electronic gearbox offers a
choice between the comfort of automated
operation or the pleasure of manual gear
changing.
This gearbox provides two driving modes:
- an automated mode for automatic control of the gears by the gearbox and therefore
without any action on the part of the
driver,
- a sequential mode for manual changing of the gears by the driver using the gear
lever.
It consists of:
1. a gear lever 1 on the centre console
for selecting the driving mode, reverse
gear and neutral or for changing gear in
sequential mode,
2. a button 2 to activate or deactivate the
economy programme. Gear lever gate
All movements of the gear lever are given
from the middle position.
N : neutral.
With your foot on the brake, select this
position to start, by moving the gear lever to
the right and then forwards
R : reverse gear.
With the vehicle stationary, keep your foot
on the brake pedal and move the gear lever
to the right and then backwards.
M +/-: sequential mode with manual gear
changing.
Make a long push to the left on the lever to
select this mode, then:
- push towards + to change up,
- push towards - to change down. Displays in the instrument panel
N. Neutral.
R. Reverse.
1 2 3 4 5. Gears engaged.
AUTO. Comes on when automated mode
is selected; it goes out when changing to
sequential mode.
E. It comes on when the economy programme
is activated; it goes off on deactivation.
A : automated mode.
Move the lever downwards to select this
mode.
E : economy programme.
Press this button to activate or deactivate it.
