Page 3 of 166
6
Familiarisation
INTERIOR
Trip computer
Using the MENU button, this system allows
control or consultation of the various vehicle
c o n fi g u r a t i o n s / i n f o r m a t i o n s u c h a s d e a c t i v a t i o n
of the passenger’s airbag, automatic locking of
the doors, language, etc.
66
Folding multifunction passenger seat
The front passenger seat can be placed in one
o f t h r e e p o s i t i o n s :
- seat for carrying a passenger,
- table to accommodate your various documents,
- f u l l y f o l d e d f o r t r a n s p o r t i n g l o n g o b j e c t s .
80
Audio system
T h e s e s y s t e m s b e n e fi t f r o m t h e l a t e s t
t e c h n o l o g y : M P 3 c o m p a t i b l e a u d i o s y s t e m
and Bluetooth
®
hands-free kit.
71
Cruise control
This system maintains the speed of the vehicle
at a programmed value.
42
Electronic gearbox
This system assures perfect driving by
combining a fully automatic mode and a
manual mode.
48
Page 4 of 166
7
FAMILIARISATION
Familiarisation
INSTRUMENTS AND CONTROLS
1. S t e e r i n g w h e e l a d j u s t m e n t c o n t r o l .
2. L i g h t i n g a n d d i r e c t i o n i n d i c a t o r
control stalk.
3. Instrument panel.
4. Steering mounted audio controls.
Bluetooth hands-free system.
5. Driver’s airbag.
Horn.
6. C r u i s e c o n t r o l s w i t c h e s .
7. Gear lever.
8. Parking brake.
9. Bonnet release.
10. Door mirror controls.
11. Fusebox.
12. M a n u a l h e a d l a m p h e i g h t a d j u s t m e n t .
13. S i d e a d j u s t a b l e a i r v e n t .
14. Front side window demisting vent.
15. Electric window controls.
16. Windscreen demisting vent.
17. Wiper/screenwash/trip computer
control stalk.
18. Steering lock and ignition.
19. C e n t r a l a d j u s t a b l e a i r v e n t s .
20. Passenger’s airbag.
21. MENU button.
22. Glove box.
23. 12 V accessory socket.
24. C i g a r l i g h t e r .
25. Ashtray.
26. Heating/air conditioning controls.
27. Audio system.
Page 12 of 166
15
FAMILIARISATION
Familiarisation
PASSENGER SAFETY
Passenger’s front airbag
The passenger’s front airbag is deactivated by
means of the MENU button, located to the right
of the steering wheel.
Seat belt not fastened
A. Driver’s seat belt not fastened warning
lamp.
101
105 Ladder type vertical partition
(Light van)
A ladder type vertical partition protects the
driver against the risk of load movement.
91
1. Press the MENU button.
2. S e l e c t " B a g " a n d c o n fi r m b y p r e s s i n g t h e
MENU button.
3. S e l e c t " O F F " a n d c o n fi r m b y p r e s s i n g t h e
MENU button.
4. S e l e c t " Y E S " a n d c o n fi r m b y p r e s s i n g t h e
MENU button.
Page 19 of 166
22
Instruments and controls
Warning lamp
is indicates Solution - action
Front airbag
Side airbag flashing or
continuously on.
the failure of an airbag. Have the system checked by a PEUGEOT dealer
without delay. Refer to the "Airbags" section of ch
apter 5.
Deactivation of the
passenger's front airbag on. that this airbag has been
deactivated intentionally in the
presence of a rear facing child seat. Configure via the trip computer MENU menu.
Refer to the "Menu" section of chapter 3.
ABS continuously on. failure of the system.
The vehicle retains conventional braking without a
ssistance.
However, you are advised to stop and contact a PEUG EOT dealer.
continuously on, coupled
with the parking brake
warning lamp. a fault with the electronic
brake force distributor.
Stop as soon as it is safe to do so, park,
switch off and contact a PEUGEOT dealer.
Trajectory control
system flashes for a few
seconds.
the ESP system has been
invoked. Intervention by the system to correct the
trajectory of the vehicle.
on, coupled with the
warning lamp in the
"ASR OFF" button
and accompanied by a
message in the screen. a fault with the ESP
system.
Contact a PEUGEOT dealer.
on, accompanied by a
message in the screen. a fault with the ASR/MSR
system.
Contact a PEUGEOT dealer.
on. a fault with the Intelligent
Traction Control. Contact a PEUGEOT dealer.
Hill start assist on. a fault with the hill start
assist system. Contact a PEUGEOT dealer.
Front brake pads on. brake pad wear. Have the pa ds replaced by a PEUGEOT dealer.
Page 23 of 166
26
Instruments and controls
Display displays indicates Solution - action
Stop & Start on.
engine STOP mode
invoked following a stop of
the vehicle. As soon as you want to move off, the
warning lamp goes off and the engine starts
automatically in START mode.
flashes for a few
seconds then goes
off. temporary unavailability
of STOP mode or
START mode invoked
automatically.
particular cases with STOP mode and START
mode. Chapter 1, "Steering mounted controls".
Gear shift indicator the arrow pointing up.
the possibility to change
up.
Chapter 1, "Gear shift indicator".
the arrow pointing
down. the possibility to change
down.
Ambient temperature
(°C/°F) the temperature which
flashes accompanied
by a message in the
screen. weather conditions
which could result in the
presence of ice on the
road.
Be especially vigilant and do not brake sharply.
Chapter 5, "Driving safety".
Date (YYYY/MM/DD)
Time (HH:MM) a setting:
of the Date.
of the Time. a configuration via the
MENU menu.
Chapter 3, "Menu".
Headlamp beam height a headlamp height
setting. a position from 0 to 3
depending on the load
carried. Adjust using the control on the dashboard.
Chapter 1, "Steering mounted controls".
Page 24 of 166
26
Instruments and controls
Display displays indicates Solution - action
Stop & Start on.
engine STOP mode
invoked following a stop of
the vehicle. As soon as you want to move off, the
warning lamp goes off and the engine starts
automatically in START mode.
flashes for a few
seconds then goes
off. temporary unavailability
of STOP mode or
START mode invoked
automatically.
particular cases with STOP mode and START
mode. Chapter 1, "Steering mounted controls".
Gear shift indicator the arrow pointing up.
the possibility to change
up.
Chapter 1, "Gear shift indicator".
the arrow pointing
down. the possibility to change
down.
Ambient temperature
(°C/°F) the temperature which
flashes accompanied
by a message in the
screen. weather conditions
which could result in the
presence of ice on the
road.
Be especially vigilant and do not brake sharply.
Chapter 5, "Driving safety".
Date (YYYY/MM/DD)
Time (HH:MM) a setting:
of the Date.
of the Time. a configuration via the
MENU menu.
Chapter 3, "Menu".
Headlamp beam height a headlamp height
setting. a position from 0 to 3
depending on the load
carried. Adjust using the control on the dashboard.
Chapter 1, "Steering mounted controls".
Page 36 of 166
35
1
READY TO SET OFF
Access
OPENING FROM THE INSIDE
Driver's door
Pull the interior handle to unlock.
Active locking : when the vehicle
speed approaches 12 mph (20 km/h),
a characteristic locking noise indicates that
your vehicle has been locked automatically.
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
This function is deactivated when the vehicle
is delivered.
Opening to 180°
Press the catch while opening the door.
Side-hinged rear doors
The 60/40 type asymmetrical hinged rear
doors have four closing points, including
a central closing point.
Pull the handle towards you.
Start by opening the large hinged door, then
unlock by pulling the lever to release and
open the small hinged door.
The two hinged doors open to 90°.
Driving with the small hinged door open is
permitted to make the transportation of long
loads easier. Observe the customary safety
indications, to attract the attention of other
drivers.
Page 38 of 166
37
1
READY TO SET OFF
Access
CLOSING FROM INSIDE
Central locking
Push the interior handle to lock the entire
vehicle or the door concerned. However,
if one of the doors is open or is not closed
correctly, the central locking does not work. Always remove the key from the
ignition when leaving the vehicle, even
for a short time. Closing from 180°
The check strap will re-attach automatically
when the hinged doors are closed, the small
door being closed first.
Load space
Press to lock the sliding side
doors and the rear doors
(Light van) from the driving
position.
Protection against attack
When the vehicle is started, the system
locks the driving position and load space
doors automatically when you reach
approximately 12 mph (20 km/h).
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
If none of the doors are opened during the
journey, the locking remains active.
This function is deactivated when the vehicle
is delivered.
Page 41 of 166
35
1
READY TO SET OFF
Access
OPENING FROM THE INSIDE
Driver's door
Pull the interior handle to unlock.
Active locking : when the vehicle
speed approaches 12 mph (20 km/h),
a characteristic locking noise indicates that
your vehicle has been locked automatically.
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
This function is deactivated when the vehicle
is delivered.
Opening to 180°
Press the catch while opening the door.
Side-hinged rear doors
The 60/40 type asymmetrical hinged rear
doors have four closing points, including
a central closing point.
Pull the handle towards you.
Start by opening the large hinged door, then
unlock by pulling the lever to release and
open the small hinged door.
The two hinged doors open to 90°.
Driving with the small hinged door open is
permitted to make the transportation of long
loads easier. Observe the customary safety
indications, to attract the attention of other
drivers.
Page 43 of 166
37
1
READY TO SET OFF
Access
CLOSING FROM INSIDE
Central locking
Push the interior handle to lock the entire
vehicle or the door concerned. However,
if one of the doors is open or is not closed
correctly, the central locking does not work. Always remove the key from the
ignition when leaving the vehicle, even
for a short time. Closing from 180°
The check strap will re-attach automatically
when the hinged doors are closed, the small
door being closed first.
Load space
Press to lock the sliding side
doors and the rear doors
(Light van) from the driving
position.
Protection against attack
When the vehicle is started, the system
locks the driving position and load space
doors automatically when you reach
approximately 12 mph (20 km/h).
This "AUTOCLOSE" function is activated or
deactivated via the "MENU".
If none of the doors are opened during the
journey, the locking remains active.
This function is deactivated when the vehicle
is delivered.
