PONTIAC FIREBIRD 1999 Owners Manual

yellowblue
2-45
As you signal a turn or a lane change, if the arrows don't
flash but just stay on as you signal a turn or lane change,
a signal bulb may be burned out and other drivers won't
see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index).
Headlamp High/Low Beam Changer
When the high beams
are on, this light on the
instrument panel also
will be on.
To change the headlamps from low beam to high or
from high beam to low, pull the turn signal lever all the
way toward you. Then release it.
Windshield Wipers
You control the windshield wipers by turning the band
with the wiper symbol on it, located on the turn
signal/multifunction lever.
For a single wiping cycle, turn the band to MIST. Hold
it there until the wipers start, then let go. The wipers will
stop after one cycle. If you want more cycles, hold the
band on MIST longer.
You can set the wiper speed for a long or short delay
between wipes. This can be very useful in light rain or
snow. Turn the band to choose the delay time. The
closer to LO, the shorter the delay.
For steady wiping at low speed, turn the band away
from you to the LO position. For high
-speed wiping,
turn the band further, to HI. To stop the wipers, turn the
band to OFF.
Damaged wiper blades may prevent you from seeing
well enough to drive safely. To avoid damage, be sure to
clear ice and snow from the wiper blades before using
them. If they're frozen to the windshield, carefully
loosen or thaw them. If your blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload your wipers. A circuit
breaker will stop them until the motor cools. Clear away
snow or ice to prevent an overload.

yellowblue
2-46 Windshield Washer
There is a paddle with the word PUSH on it at the top of
the turn signal/multifunction lever. To spray washer
fluid on the windshield, just push the paddle briefly. The
washer will continue to spray until you release the
paddle. The wipers will clear the window and wipe a
few more times before stopping or returning to the
previous setting. See ªWindshield Washer Fluidº in
the Index.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
Cruise Control (Option)
With cruise control, you can
maintain a speed of about
25 mph (40 km/h) or more
without keeping your foot
on the accelerator.
This can really help on long trips. Cruise control does
not work at speeds below about 25 mph (40 km/h).
When you apply your brakes or push the clutch pedal
(manual transmission), the cruise control shuts off.

yellowblue
2-47
CAUTION:

Cruise control can be dangerous where you
can't drive safely at a steady speed. So,
don't use your cruise control on winding
roads or in heavy traffic.

Cruise control can be dangerous on
slippery roads. On such roads, fast changes
in tire traction can cause needless wheel
spinning, and you could lose control.
Don't use cruise control on slippery roads.
If your vehicle is in cruise control when the optional
traction control system begins to limit wheel spin,
the cruise control will automatically disengage. (See
ªTraction Control Systemº in the Index.) When road
conditions allow you to safely use it again, you may turn
the cruise control back on.Setting Cruise Control
CAUTION:
If you leave your cruise control switch on when
you're not using cruise, you might hit a button
and go into cruise when you don't want to. You
could be startled and even lose control. Keep the
cruise control switch off until you want to use it.
1. Move the cruise control switch to ON.
2. Get up to the speed you want.
3. Push in the SET button at the end of the lever and
release it.
4. Take your foot off the accelerator pedal.

yellowblue
2-48
Resuming a Set Speed
Suppose you set your cruise control at a desired speed and
then apply the brake or clutch pedal. This, of course, shuts
off the cruise control. But you don't need to reset it.
Once you're going about 25 mph (40 km/h) or more,
you can move the cruise control switch from ON to
R/A (Resume/Accelerate) for about half a second.
You'll go right back up to your chosen speed and
stay there.
Increasing Speed While Using Cruise Control
There are three ways to go to a higher speed:

Use the accelerator pedal to get to the higher speed.
Push the button at the end of the lever, then release
the button and the accelerator pedal. You'll now
cruise at the higher speed.

To increase your speed in very small amounts,
briefly move the switch to R/A and then release it.
Each time you do this, your vehicle will go about
1 mph (1.6 km/h) faster.

Move the cruise switch from ON to R/A. Hold it
there until you get up to the speed you want, and
then release the switch.Reducing Speed While Using Cruise Control
There are two ways to reduce your speed while using
cruise control:

Push in the button at the end of the lever until you
reach the lower speed you want, then release it.

To slow down in very small amounts, briefly push
the button. Each time you do this, you'll go 1 mph
(1.6 km/h) slower.
Passing Another Vehicle While Using Cruise Control
Use the accelerator pedal to increase your speed. When
you take your foot off the pedal, your vehicle will slow
down to the cruise control speed you set earlier.
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brake
takes you out of cruise control. Many drivers find this to
be too much trouble and don't use cruise control on
steep hills.

yellowblue
2-49
Ending Out of Cruise Control
There are several ways to turn off the cruise control:

Step lightly on the brake pedal or push the clutch
pedal, if you have a manual transmission; or

Move the cruise switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
The main lamp control is a knob that works these lamps:

Headlamps

Taillamps

Parking Lamps

License Lamps

Sidemarker Lamps

Instrument Panel Lights
This setting turns on your headlamps and other
operating lamps.
This setting turns on your parking lamps and other
operating lamps without your headlamps.
Turn the knob to OFF to turn off the lamps.
Headlamps On Reminder
If you turn the ignition off and leave the lamps on, you
will hear a chime lasting up to five seconds. If the lamps
are still on when you open the driver's door, the chime
will sound again.

yellowblue
2-50 Headlamp Doors
The headlamp doors are designed to open when you turn
the headlamps on and close when you turn the
headlamps off. The headlamp doors can be opened
without turning on the headlamps by turning the
headlamps on, then turning the switch back to the
parking lamps position.
The headlamp doors should be open when driving in icy
or snowy conditions to prevent the doors from freezing
closed, and when washing the vehicle to help clean
the headlamps.
To open the headlamp doors manually:
1. Open the hood.
2. Remove the plastic cover from the retractor
motor knob.
3. Turn the retractor motor knob counterclockwise until the
headlamp door is fully open. The knob will get harder
to turn when the headlamp door is all the way up.
4. Replace the plastic cover on the retractor motor knob.
To manually close the headlamp doors, turn the lamps
off and turn the retractor motor knob clockwise. If the
headlamp doors aren't working properly, see your dealer
for help.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
For Canadian vehicles, a light sensor on top of the
instrument panel automatically turns the headlamps on,
so be sure it isn't covered.
The DRL system will not activate if the park brake is
engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when:

the ignition is on,

the headlamp switch is OFF,

the parking brake is released and

it is bright enough outside (on Canadian vehicles).
When the DRL are on, only your front turn signal lamps
will be on. The taillamps, sidemarker and other lamps
won't be on. Your instrument panel won't be lit up
either. When you use your turn signals, the front turn
signal and the taillamp of the desired side will flash.

yellowblue
2-51
For Canadian vehicles, when it's dark enough outside,
your front turn signal lamps will go out and your
headlamps will come on. The other lamps that come on
with your headlamps will also come on. When it's bright
enough outside, the regular lamps will go off, and your
front turn signal lamps will come on.
On a non
-Canadian vehicle, the headlamps have to be
turned on manually when you need them. On Canadian
and non
-Canadian vehicles, when the headlamps are
turned on, the front turn signal lamps will go out. When
you use your turn signals, the front turn signal lamp and
the taillamp on the desired side will flash.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps
Use your fog lamps for better vision in foggy or misty
conditions. Your parking lamps must be on or your fog
lamps won't work.
Your fog lamp switch is
located on your console.
To turn the fog lamps on, push the right side of the fog
lamp switch and a light on the switch will come on
indicating that the fog lamps are on. Push the left side of
the fog lamp switch to turn the fog lamps off.
The fog lamps will go off whenever your high
-beam
headlamps come on. When the high
-beam headlamps go
off, the fog lamps will come on again.
If your vehicle is equipped with the Content
Theft
-Deterrent System and your fog lamp switch is on,
the fog lamps may flash to indicate operation of the
Content Theft
-Deterrent System. See ªContent
Theft
-Deterrent Systemº in the Index.

yellowblue
2-52
Interior Lamps
Instrument Panel Brightness Control
The thumbwheel controls the brightness of your
instrument panel lights. Move the thumbwheel to
brighten or dim the lights. If you move the thumbwheel
all the way up, your courtesy lamps will come on.
Courtesy Lamps
When either door is opened, several interior lamps go
on. These lamps are courtesy lamps. They make it easier
for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled about 10 minutes after the ignition is turned to
OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (if equipped).

Turn the interior lamp switch from off to on.

Open the hatch.

yellowblue
2-53 Delayed Illumination
With delayed illumination, the courtesy lamps will come
on and stay on for 25 seconds after you close the doors
when entering the vehicle. They will also stay on for
five seconds after you close the doors when exiting the
vehicle. The times will be shortened if the ignition is
turned to RUN or if the power locks are activated. To
turn this feature on or off, see ªFeature Customizationº
in the Index.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition to help you see
while exiting the vehicle. To turn this feature on or off,
see ªFeature Customizationº in the Index.
Front Map Lamps
Your inside rearview mirror includes two map lamps.
Each lamp has its own switch. Use the switch closest to
the lamp to turn it on. The lamps will also go on when a
door is opened.
Retained Accessory Power (RAP)
Your vehicle is equipped with a Retained Accessory
Power (RAP) feature which will allow certain features
of your vehicle to continue to work up to 10 minutes
after the ignition key is turned to OFF.
Your convertible top, power windows and audio system
will work when the ignition key is in RUN or ACC.
Once the key is turned from RUN to OFF, these features
will continue to work for up to 10 minutes or until either
door is opened.
Your power door unlock and remote hatch release
features will work when the ignition key is in RUN or
ACC or if either door is open. Once the key is turned to
OFF, these features will continue to work for up to
10 minutes. If either door is open and the ignition key
is off, these features will continue to work until both
doors have been closed for about 30 seconds or until the
theft
-deterrent system arms. At that time, both the
power door unlock and remote hatch release features
will be disabled to enhance the security of the vehicle.
The power door lock function will work at all times
except when Lockout Prevention is enabled. See
ªLockout Preventionº in the Index.

yellowblue
2-54
Mirrors
Inside Day/Night Rearview Mirror
An inside rearview mirror is attached to your windshield.
The mirror has pivots so that you can adjust it.
You can adjust the mirror for day or night driving. Pull
the tab for night driving to reduce glare. Push the tab for
daytime driving.
Outside Manual Adjustable Mirror
Adjust the passenger's side outside mirror by hand so
that you can just see the side of your vehicle when you
are sitting in a comfortable driving position.
Manual Remote Control Mirror
Adjust the driver's side outside mirror with the lever on
the door. Adjust the mirror so that you can just see the
side of your vehicle when you are sitting in a
comfortable driving position.
Power Remote Control Mirror
(If Equipped)
The power mirror control is on the driver's door. To
adjust either mirror, move the center switch to L (left) or
to R (right). The center position is off. Then use the
touchpad to adjust the mirror.
