engine PONTIAC FIREBIRD 1999 Owners Manual

yellowblue
6-66
There are three fuse centers on your vehicle. One (main
fuse block) is located behind a cover in the left side of
your instrument panel.The other two are in the engine compartment. Open the
cover on the boxes to expose the fuses.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the correct size.
If you ever have a problem on the road and don't have a
spare fuse, you can borrow one. Just pick some feature
of your car that you can get along without
-- like the
radio or cigarette lighter
-- and use its fuse, if it is the
size you need. Replace it as soon as you can.

yellowblue
6-70
Fuse and Relay Center 2
Fuse Usage
INJ Fuel Injectors (Not used for V6)
(LH injectors for V8 Ignition
Module)
INJ Fuel Injectors (All for V6) (RH
injectors for V8 and Ignition
Module)Fuse Usage
ENG SEN Mass Air Flow Sensor, Heated
Oxygen Sensor, Skip Shift
Solenoid (V8 Only), Reverse
Lockout Solenoid, Brake Switch
STRTR Powertrain Control Module
(PCM), Clutch Pedal Switch
ABS IGN Anti
-Lock Brake System Module
PCM IGN Powertrain Control Module
(PCM)
ETC Electronic Throttle Control
(V6 Only)
ENG CTRL Ignition Module (V6 Only),
Automatic Transmission, Charcoal
Canister Purge Solenoid
A/C CRUISE Air Conditioning Compressor
Relay, Cruise Control Switches
and Module
ENG CTRL Engine Controls, Fuel Pump,
Powertrain Control Module
(PCM), A.I.R. Pump and
Cooling Fans

yellowblue
6-71
Fuse Usage
I/P
-1 HVAC Blower Control and Relay
IGN Ignition Switch, Relay and Starter
Enable Relay
I/P
-2 Instrument Panel Fuse Center
Relay Description
AIR SOL Air Solenoid
AIR PUMP Air Pump
A/C COMP Air Conditioning Compressor
FUEL PUMP Fuel Pump
STARTER Starter
IGN Engine Controls, Cruise Controls,
Air Conditioning
Replacement Bulbs
Back-up 3155. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp 921. . . . . . . . . . . . .
Front Parking and Turn Signal 3157NAK. . . . . . . . . .
Headlamp
High Beam 4701. . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Beam 4703. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sidemarker Lamp 194. . . . . . . . . . . . . . . . . . . . . . . . .
Tail Lamp Only 194. . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Lamps 3057. . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the
Index for more information.
Air Conditioning
See the refrigerant . . . . . . . . . . . . .
information label under the hood.
Automatic Transmission
Drain and Refill 5.0 quarts (4.7 L). . . . . . . . . . . . . . .
Overhaul
3800 V6 8.8 quarts (8.3 L). . . . . . . . . . . . . . . . . . . .
5.7L V8 10.8 quarts (10.2 L). . . . . . . . . . . . . . . . . .

yellowblue
6-72
Cooling System
3800 V6
With Manual Transmission 11.6 quarts (11.0 L). . . .
With Automatic Transmission 11.4 quarts (10.8 L). . .
5.7L V8
With Manual Transmission 11.9 quarts (11.3 L). . . .
With Automatic Transmission 11.8 quarts (11.2 L). .
Crankcase
Oil and
Filter Change 3800 V6 (VIN K) 4.5 quarts (4.3 L). . .
5.7L V8 (VIN G) 5.5 quarts (5.2 L)
Fuel Tank 16.8 gallons (63.6 L). . . . . . . . . . . . . . . . . .
Manual Transmission
Five
-Speed 3.4 quarts (3.2 L). . . . . . . . . . . . . . . . .
Six
-Speed 4 quarts (3.8 L). . . . . . . . . . . . . . . . . . . .
Rear Axle Lubricant 1.75 quarts (1.7 L). . . . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the appropriate level, as recommended in
this manual. Recheck fluid level after filling.
Engine Specifications
Type
VIN Engine Code K 3800 V6. . . . . . . . . . . . . . . . .
VIN Engine Code G 5.7L V8. . . . . . . . . . . . . . . . . .
Fuel Delivery Fuel Injection. . . . . . . . . . . . . . . . . . . .
Valve Arrangement In
-Head . . . . . . . . . . . . . . . . . . . .
Displacement
3800 V6 231 cubic inches (3791 cc). . . . . . . . . . . . .
5.7L V8 350 cubic inches (5662 cc). . . . . . . . . . . . .
Firing Order
3800 V6 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 1
-8-7-2-6-5-4-3 . . . . . . . . . . . . . . . . . . . . .
Wheel Nut Torque 100 lb
-ft (140 N´m) . . . . . . . . . . .
Thermostat Starts
to Open 177
-184
F (81

-85
C) . . . . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.

yellowblue
6-73
Normal Maintenance
Replacement Parts
Air Cleaner Filter A1163C. . . . . . . . . . . . . . . . . . . . . .
Battery 75
-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter
3800 V6 PF47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 PF44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filter
3800 V6 G627. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 GF578. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PCV Valve
3800 V6 CV892C. . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 CV895C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Cap RC24. . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plug
3800 V6 41
-921 (0.060 inch gap) . . . . . . . . . . . . . . .
5.7L V8 41
-931 (0.060 inch gap) . . . . . . . . . . . . . . .
Windshield Wiper Blade Replacement
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 24 inches (610 cm). . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length
Firebird/Formula 193.3 (491.1). . . . . . . . . . . . . . . . .
Trans AM/GT 193.7 (491.3). . . . . . . . . . . . . . . . . . .
Width 74.4 inches (189.0 cm). . . . . . . . . . . . . . . . . . .
Height
Coupe 52.0 inches (131.2 cm). . . . . . . . . . . . . . . . .
Convertible
Firebird/Formula 52.7 inches (134.0 cm). . . . . . .
Trans Am/GT 52.4 inches (133.1 cm). . . . . . . . . .
Wheelbase 101.1 inches (256.6 cm). . . . . . . . . . . . . .
Front Tread 60.7 inches (154.2 cm). . . . . . . . . . . . . . .
Rear Tread 60.6 inches (154.0 cm). . . . . . . . . . . . . . .

yellowblue
Scheduled Maintenance
7-5
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.
Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to the
completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the maintenance
be recorded.* Your vehicle has an Engine Oil Life Monitor. This
monitor will show you when to change the engine oil
and filter
-- usually between 3,000 miles (5 000 km)
and 7,500 miles (12 500 km) since your last oil change.
Under severe conditions, the indicator may come on
before 3,000 miles (5 000 km). Never drive your vehicle
more than 7,500 miles (12 500 km) or 12 months
without an oil and filter change.
The system won't detect dust in the oil. So if you drive
in a dusty area, be sure to change your oil and filter
every 3,000 miles (5 000 km) or sooner if the
OIL CHANGE light comes on. Remember to reset
the Oil Life Monitor whenever the oil is changed. For
more information, see ªOil Change Lightº in the Index.
+ A good time to check your brakes is during tire
rotation. See ªBrake System Inspectionº under ªPeriodic
Maintenance Inspectionsº in Part C of this schedule.

Scheduled Maintenance
yellowblue
7-6
7,500 Miles (12 500 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
15,000 Miles (25 000 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Inspect engine air cleaner filter if you are driving in dusty conditions.
Replace filter if necessary.
An Emission Control Service. (See footnote
.)
Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90F (32C) or higher.
± In hilly or mountainous terrain.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

yellowblue
Scheduled Maintenance
7-7
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the
fluid and filter every 50,000 miles (83 000 km).

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
22,500 Miles (37 500 km)

Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)ACTUAL
SERVICED BY:MILEAGE
DATE

Scheduled Maintenance
yellowblue
7-8
30,000 Miles (50 000 km)

Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)

Change automatic transmission fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90F (32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, change the
fluid and filter every 50,000 miles (83 000 km).
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
Replace engine air cleaner filter.
An Emission Control Service.
Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)ACTUAL
SERVICED BY:MILEAGE
DATE

yellowblue
Scheduled Maintenance
7-9
37,500 Miles (62 500 km)

Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)

Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
45,000 Miles (75 000 km)

Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)

Inspect engine air cleaner filter if you are driving in dusty conditions.
Replace filter if necessary.
An Emission Control Service. (See footnote
.)
Change automatic transmission fluid and filter if the vehicle is mainly
driven under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches
90F (32C) or higher.
± In hilly or mountainous terrain.
(Continued)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
