ignition PONTIAC FIREBIRD 1999 Owner's Guide

yellowblue
2-49
Ending Out of Cruise Control
There are several ways to turn off the cruise control:

Step lightly on the brake pedal or push the clutch
pedal, if you have a manual transmission; or

Move the cruise switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
The main lamp control is a knob that works these lamps:

Headlamps

Taillamps

Parking Lamps

License Lamps

Sidemarker Lamps

Instrument Panel Lights
This setting turns on your headlamps and other
operating lamps.
This setting turns on your parking lamps and other
operating lamps without your headlamps.
Turn the knob to OFF to turn off the lamps.
Headlamps On Reminder
If you turn the ignition off and leave the lamps on, you
will hear a chime lasting up to five seconds. If the lamps
are still on when you open the driver's door, the chime
will sound again.

yellowblue
2-50 Headlamp Doors
The headlamp doors are designed to open when you turn
the headlamps on and close when you turn the
headlamps off. The headlamp doors can be opened
without turning on the headlamps by turning the
headlamps on, then turning the switch back to the
parking lamps position.
The headlamp doors should be open when driving in icy
or snowy conditions to prevent the doors from freezing
closed, and when washing the vehicle to help clean
the headlamps.
To open the headlamp doors manually:
1. Open the hood.
2. Remove the plastic cover from the retractor
motor knob.
3. Turn the retractor motor knob counterclockwise until the
headlamp door is fully open. The knob will get harder
to turn when the headlamp door is all the way up.
4. Replace the plastic cover on the retractor motor knob.
To manually close the headlamp doors, turn the lamps
off and turn the retractor motor knob clockwise. If the
headlamp doors aren't working properly, see your dealer
for help.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
For Canadian vehicles, a light sensor on top of the
instrument panel automatically turns the headlamps on,
so be sure it isn't covered.
The DRL system will not activate if the park brake is
engaged prior to turning the ignition on.
The DRL system will make your front turn signal lamps
come on when:

the ignition is on,

the headlamp switch is OFF,

the parking brake is released and

it is bright enough outside (on Canadian vehicles).
When the DRL are on, only your front turn signal lamps
will be on. The taillamps, sidemarker and other lamps
won't be on. Your instrument panel won't be lit up
either. When you use your turn signals, the front turn
signal and the taillamp of the desired side will flash.

yellowblue
2-52
Interior Lamps
Instrument Panel Brightness Control
The thumbwheel controls the brightness of your
instrument panel lights. Move the thumbwheel to
brighten or dim the lights. If you move the thumbwheel
all the way up, your courtesy lamps will come on.
Courtesy Lamps
When either door is opened, several interior lamps go
on. These lamps are courtesy lamps. They make it easier
for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled about 10 minutes after the ignition is turned to
OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (if equipped).

Turn the interior lamp switch from off to on.

Open the hatch.

yellowblue
2-53 Delayed Illumination
With delayed illumination, the courtesy lamps will come
on and stay on for 25 seconds after you close the doors
when entering the vehicle. They will also stay on for
five seconds after you close the doors when exiting the
vehicle. The times will be shortened if the ignition is
turned to RUN or if the power locks are activated. To
turn this feature on or off, see ªFeature Customizationº
in the Index.
Exit Lighting
With exit lighting, the interior lamps will come on when
you remove the key from the ignition to help you see
while exiting the vehicle. To turn this feature on or off,
see ªFeature Customizationº in the Index.
Front Map Lamps
Your inside rearview mirror includes two map lamps.
Each lamp has its own switch. Use the switch closest to
the lamp to turn it on. The lamps will also go on when a
door is opened.
Retained Accessory Power (RAP)
Your vehicle is equipped with a Retained Accessory
Power (RAP) feature which will allow certain features
of your vehicle to continue to work up to 10 minutes
after the ignition key is turned to OFF.
Your convertible top, power windows and audio system
will work when the ignition key is in RUN or ACC.
Once the key is turned from RUN to OFF, these features
will continue to work for up to 10 minutes or until either
door is opened.
Your power door unlock and remote hatch release
features will work when the ignition key is in RUN or
ACC or if either door is open. Once the key is turned to
OFF, these features will continue to work for up to
10 minutes. If either door is open and the ignition key
is off, these features will continue to work until both
doors have been closed for about 30 seconds or until the
theft
-deterrent system arms. At that time, both the
power door unlock and remote hatch release features
will be disabled to enhance the security of the vehicle.
The power door lock function will work at all times
except when Lockout Prevention is enabled. See
ªLockout Preventionº in the Index.

yellowblue
2-66
You can store the sunshades two different ways:

When the T
-tops are in use, store the sunshades in
their storage area in the rear of the vehicle, and make
sure the cargo cover is in its closed, upright position.

When you have the T
-tops off and in their storage
slots, store the sunshades on the T
-tops, in their
installed position.
Convertible Top (If Equipped)
The following procedures explain the proper operation
of your convertible top.
Lowering Your Convertible Top
NOTICE:
Don't leave your convertible out with the top
down for any long periods of time. The sun and
the rain can damage your seat material and other
things inside your vehicle.
1. It is recommended that you park on a level surface.
Set the parking brake firmly. Shift an automatic
transmission into PARK (P) or a manual
transmission into REVERSE (R). The ignition must
be in ACC or RUN. Lower both sun visors.

yellowblue
2-71
3. Store each piece of the cover in its separate
compartment per graphic printed inside of the storage
bag. Store the bag in the hatch and close the hatch.
4. Disengage the two convertible top latches.
Raising Your Convertible Top
1. It is recommended that you park on a level surface.
Set the parking brake firmly. If you have an
automatic transmission, shift into PARK (P).
If you have a manual transmission, shift into
REVERSE (R). The ignition must be in ACC,
RUN or RAP must be on. Lower both sun visors
and lower both windows at least three inches (8 cm).
If the boot cover is in place, it must be removed first.
NOTICE:
It is not recommended that you raise or lower the
top while the vehicle is moving.
2. Push and hold the up
arrow (

) on the
convertible TOP switch.

yellowblue
2-73
Open the hatch and find the tab along the left side trim
panel. Lift up the tab and turn the valve counterclockwise
to release the hydraulic pressure. Turn the ignition key to
LOCK. You can now raise or lower your top manually.
Be sure to close the valve after installing your top so you
can raise or lower it electrically later.

yellowblue
2-79 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
This light will come on
when you start your engine,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
engine or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Voltmeter
You can read battery
voltage on your voltmeter.
If it reads less than 11 volts
or more than 16 volts while
your engine is running, and
it stays there, you may have
a problem with the
electrical charging system.
Have it checked right away. Driving with the voltmeter
reading in a warning zone could drain your battery.
If you idle your engine for a while, the voltmeter
reading might move into the yellow zone. If the reading
stays in the yellow zone while you are driving, you may
have a problem with the electrical charging system.
Have it checked. While the voltmeter reads in the yellow
zone, your battery may not be able to power certain
electrical accessories, like ABS. (If this happens, your
ABS INOP light will come on. See ªAnti
-Lock Brake
System Warning Lightº in the Index.)
If you must drive a short distance with the voltmeter
reading in a warning zone, turn off all your accessories,
including your air conditioning and audio system.

yellowblue
2-80 Brake System Warning Light
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though, you
need both parts working well.
If the warning light comes on, there is a brake problem.
Have your brake system inspected right away.
This light should come on
briefly when you turn the
ignition key to RUN. If it
doesn't come on then, have
it fixed so it will be ready
to warn you if there's
a problem.
If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the floor.
It may take longer to stop. If the light is still on, have the
vehicle towed for service. (See ªTowing Your Vehicleº
in the Index.)
CAUTION:
Your brake system may not be working properly
if the brake system warning light is on. Driving
with the brake system warning light on can lead
to an accident. If the light is still on after you've
pulled off the road and stopped carefully, have
the vehicle towed for service.
When the ignition is on, the brake system warning light
will also come on when you set your parking brake. The
light will stay on if your parking brake doesn't release
fully. If it stays on after your parking brake is fully
released, it means you have a brake problem.

yellowblue
2-81 Anti-Lock Brake System Warning Light
With the anti-lock brake
system, this light will come
on when you start your
engine and it will stay
on for three seconds.
That's normal.
If the anti
-lock brake system warning light stays on
longer than normal after you've started your engine, turn
the ignition off. Or, if the light comes on and stays on
when you're driving, stop as soon as possible and turn
the ignition off. Then start the engine again to reset the
system. If the light still stays on, or comes on again
while you're driving, your vehicle needs service. If the
light is on and the regular brake system warning light
isn't on, you still have brakes, but you don't have
anti
-lock brakes. Adjust your driving accordingly.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Traction Control System Warning Light
(Option)
This warning light should
come on briefly as you start
the engine. If the warning
light doesn't come on then,
have it fixed so it will be
ready to warn you if there's
a problem.
If it stays on, or comes on when you're driving, there
may be a problem with your traction control system and
your vehicle may need service. When this warning light
is on, the system will not limit wheel spin. Adjust your
driving accordingly.
The traction control system warning light will come on
if you turn the system off by pressing the TCS button
located in front of the console, the warning light will
come on and stay on. To turn the system back on, press
the button again. The warning light should go off.
(See ªTraction Control Systemº in the Index for
more information.)
If the traction control system warning light comes on
and stays on for an extended period of time when the
system is turned on, your vehicle needs service.
