jump start PONTIAC FIREBIRD 1999 Owners Manual

5-
yellowblue
5-1
Section 5 Problems on the Road
Here you'll find what to do about some problems that can occur on the road.
5
-2 Hazard Warning Flashers
5
-3 Other Warning Devices
5
-3 Jump Starting
5
-8 Towing Your Vehicle
5
-9 Engine Overheating5
-12 Cooling System
5
-24 If a Tire Goes Flat
5
-22 Changing a Flat Tire
5
-36 Compact Spare Tire
5
-37 If You're Stuck: In Sand, Mud, Ice or Snow

yellowblue
5-3
Other Warning Devices
If you carry reflective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind
your vehicle.
Jump Starting
If your battery has run down, you may want to use
another vehicle and some jumper cables to start your
vehicle. But please use the following steps to do it safely.
CAUTION:
Batteries can hurt you. They can be
dangerous because:

They contain acid that can burn you.

They contain gas that can explode or ignite.

They contain enough electricity to
burn you.
If you don't follow these steps exactly, some or
all of these things can hurt you.
NOTICE:
Ignoring these steps could result in costly damage
to your vehicle that wouldn't be covered by
your warranty.
The ACDelco Freedom battery in your vehicle
has a built
-in hydrometer. Do not charge, test or
jump start the battery if the hydrometer looks
clear or light yellow. Replace the battery when
there is a clear or light yellow hydrometer and a
cranking complaint.
Trying to start your vehicle by pushing or pulling
it won't work, and it could damage your vehicle.
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
NOTICE:
If the other system isn't a 12-volt system with a
negative ground, both vehicles can be damaged.

yellowblue
5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able to
start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set the
parking brake firmly on both vehicles involved in the
jump starting procedure. Put an automatic
transmission in PARK (P) before setting the
parking brake.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter. Turn off all lamps that aren't needed as well
as radios. This will avoid sparks and help save both
batteries. In addition, it could save your radio!
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered by
your warranty.
4. Open the hoods and locate the batteries.
CAUTION:
An electric fan can start up even when the engine
is not running and can injure you. Keep hands,
clothing and tools away from any underhood
electric fan.
Find the positive (+) and negative (-) terminals on
each battery.

yellowblue
6-38 Vehicle Storage
If you're not going to drive your vehicle for 25 days or
more, remove the black, negative (
-) cable from the
battery. This will help keep your battery from
running down.
CAUTION:
Batteries have acid that can burn you and gas
that can explode. You can be badly hurt if you
aren't careful. See ªJump Startingº in the Index
for tips on working around a battery without
getting hurt.
Contact your dealer to learn how to prepare your vehicle
for longer storage periods.
Also, for your audio system, see ªTheft
-Deterrent
Featureº in the Index.
Bulb Replacement
For the proper type of replacement bulb, see
ªReplacement Bulbsº in the Index.
For any bulb changing procedure not listed in this
section contact your dealer's service department.
Halogen Bulbs
CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.

yellowblue
8-8
Pontiac Roadside Assistance Program
Security While You Travel
1-800-ROADSIDE (1-800-762-3743)
As the proud owner of a new Pontiac vehicle, you are
automatically enrolled in the Pontiac Roadside Assistance program. This value
-added service is
intended to provide you with peace of mind as you
drive in the city or travel the open road.
Pontiac's Roadside Assistance toll
-free number is
staffed by a team of technically trained advisors, who
are available 24 hours a day, 365 days a year.
We take anxiety out of uncertain situations by providing
minor repair information over the phone or making
arrangements to tow your vehicle to the nearest
Pontiac dealer.
We will provide the following services for
3 years/36,000 miles (60 000 km), at no expense to you:

Fuel delivery

Keys locked in vehicle

Tow to nearest dealership for warranty service

Change a flat tire

Jump starts

Courtesy Transportation -- See Courtesy
Transportation section for details

9-
yellowblue
9-1
Section 9 Index
A
ccessory Plug 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Bag 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-24, 2-79 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-27 . . . . . . . . . . . . . . .
When Should it Inflate 1-26 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-72 . . . . . . . . . . . . . . . . . . . . .
Alarm 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the System 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming the System 2-16 . . . . . . . . . . . . . . . . . . . . . . . . .
Passive Arming 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Door Lock Switch Locking 2-15 . . . . . . . . . . . . . . . .
Shock Sensor 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-53 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-61 . . . . . . . . . . . . . . . . . . . . . .
Antenna, Power Mast Care 3-23 . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock
Brake System Warning Light 2-81, 4-7 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Appearance Care Materials 6
-63 . . . . . . . . . . . . . . . . . . . . . . .
Arbitration Program 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Controls, Steering Wheel 3-19 . . . . . . . . . . . . . . . . . . .
Audio Equipment, Adding 3-20 . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission
Check 7
-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-38 . . . . .
Operation 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Park Mechanism Check 7-20 . . . . . . . . . . . . . . . . . . . . . . . .
Running Engine While Parked 2-4 . . . . . . . . . . . . . . . . . . . .
Shifting Into PARK (P) 2-37 . . . . . . . . . . . . . . . . . . . . . . . .
Shifting Out of PARK (P) 2-39 . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Lock 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle, Rear 6-27, 7-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-10 . . . . . . . . . . . . . .
Warnings 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Leaving On A Long Trip 4-23 . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 8-4 . . . . . . . . . . . . . . . . . . .
Blizzard 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-6
Hitches, Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Reset the Oil Change Light 6-17 . . . . . . . . . . . . . . . . .
Hydraulic Clutch 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Clutch Check 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transmission Lock Check 7-20 . . . . . . . . . . . . . . . . .
Inflation, Tire 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-54 . . . . . . . . . . . . . . . . .
Inspections
Brake System 7
-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-21 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Axle 7-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key in the Ignition 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-18 . . . . . . . . . . . . . . . . . . . . . .
Key Release Button 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry
Battery Replacement 2
-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Matching Transmitter(s) to Your Vehicle 2-9 . . . . . . . . . . . .
Operation 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Resynchronization 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-64 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-31 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-64 . . . . . . . . . . . . . . . . . . .
Lamps
Courtesy 2
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delayed Illumination 2-19, 2-53 . . . . . . . . . . . . . . . . . . . . .
Exit Lighting 2-19, 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Map 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches, Seatback 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-38 . . . . . . .
Lighter 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-24, 2-79 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-81, 4-7 . . . . . . . . . . . .
Brake System Warning 2-80 . . . . . . . . . . . . . . . . . . . . . . . . .
