Fuses Usage
FAN HI Cooling Fan HI Relay
ABS-1 EBCM
ABS-2 EBCM
SJB BATT Instrument Panel Fuse BlockFuses Usage
ACC/IG1 IGN1 Relay
IG2/ST IGN2 Relay, Starter Relay
ACC/RAP Instrument Panel Fuse Block
P/WINDOW-2 Power Window Switch
5-91
Fuses Usage
P/W
WINDOW-1Power Window Switch
FAN LOW Cooling Fan LOW Relay
A/CON A/C Compressor Relay
PKLP LHTail Lamp (LH), Side Marker (LH),
Turn Signal & Parking Lamp (LH),
License Lamp
PKLP RHTail Lamp (RH), Side Marker (RH),
Turn Signal & Parking Lamp (RH),
License Lamp, I/P Fuse Block
ECU ECM, TCM
FRT FOG Front Fog Lamp Relay
F/PUMP Fuel Pump Relay
HAZARD Hazard Switch, Hood Contact Switch
HDLP HI LH Head Lamp (LH), IPC
HDLP HI RH Head Lamp (RH)
IPC IPC
HDLP LO LH Head Lamp (LH), I/P Fuse Block
HDLP LO RH Head Lamp (RH)
EMS-1 ECM, Injector
DLIS Ignition Switch
EMS-2EVAP Canister Purge Solenoid,
Thermostat Heater, HO2S,
MAF Sensor
SPARE Not UsedRelays Usage
F/PUMP
RELAYFuel Pump
STARTER
RELAYStarter
PARK LAMP
RELAYPark Lamp
FRONT FOG
RELAYFog Lamp
HDLP HIGH
RELAYHead Lamp High
HDLP LOW
RELAYHead Lamp Low
FAN HIGH
RELAYCooling Fan High
FAN LOW
RELAYCooling Fan Low
A/CON RELAY Air Conditioner
ENGINE MAIN
RELAYMain Power
ACC/RAP
RELAYI/P Fuse Block
IGN-2 RELAY Ignition
Misc. Usage
FUSE PULLER Fuse Puller
5-92
