Seats and Restraint Systems
....................... 7
Front Seats
.............................................. 9
Rear Seats
............................................. 20
Safety Belts
............................................ 22
Child Restraints
...................................... 46
Airbag System
........................................ 76
Restraint System Check
......................... 94
Features and Controls
................................ 97
Keys
....................................................... 99
Doors and Locks
.................................. 108
Windows
............................................... 115
Theft-Deterrent Systems
....................... 118
Starting and Operating Your Vehicle
..... 122
Mirrors
.................................................. 142
OnStar
®System
................................... 148Storage Areas
...................................... 150
Sunroof
................................................ 150
Retractable Hardtop
.............................. 153
Instrument Panel
....................................... 161
Instrument Panel Overview
................... 164
Climate Controls
................................... 182
Warning Lights, Gages, and
Indicators
.......................................... 192
Driver Information Center (DIC)
............ 209
Audio System(s)
................................... 219
Driving Your Vehicle
................................. 253
Your Driving, the Road, and
Your Vehicle
..................................... 254
Towing
................................................. 293
2007 Pontiac G6 Owner ManualM
1

Mirrors......................................................... 142
Manual Rearview Mirror............................. 142
Manual Rearview Mirror with OnStar
®....... 142
Automatic Dimming Rearview Mirror with
OnStar
®and Compass........................... 143
Automatic Dimming Rearview Mirror with
Compass............................................... 145
Outside Power Mirrors............................... 147
Outside Convex Mirror............................... 147
OnStar
®System.......................................... 148Storage Areas............................................. 150
Glove Box................................................. 150
Cupholder(s).............................................. 150
Center Console Storage Area.................... 150
Convenience Net....................................... 150
Sunroof....................................................... 150
Sunroof - Panoramic................................. 151
Retractable Hardtop.................................... 153
Lowering the Retractable Hardtop.............. 154
Raising the Retractable Hardtop................ 157
Section 2 Features and Controls
98

Automatic Dimming Rearview Mirror
with OnStar
®and Compass
Your vehicle may have an automatic dimming
rearview mirror with a compass and OnStar®
controls. For more information about OnStar®,
seeOnStar®System on page 148.
The automatic dimming feature turns on each time
the vehicle is started. To turn automatic dimming
off or on, press the left button below the mirror.
A green indicator light will be on when automatic
dimming is on.
There are also three OnStar
®buttons located at
the bottom of the mirror. See your dealer for more
information on the system and how to subscribe
to OnStar
®. SeeOnStar®System on page 148for
more information about the service OnStar®
provides.
Compass Operation
Press the on/off button once to turn the compass
on or off.
When the ignition and the compass feature are
on, the compass will show two character boxes for
a few seconds. After a few seconds, the mirror
will display the current compass direction.
Compass Calibration
If after a few seconds the display does not show a
compass direction, (N for North for example), there
may be a strong magnetic eld interfering with the
compass. Such interference may be caused by a
magnetic antenna mount, note pad holder, or
similar object. If the letter C appears in the compass
window, the compass may need to be reset or
calibrated.
The mirror can be calibrated by driving the vehicle
in circles at 5 mph (8 km/h) or less until the
display reads a direction.
143

Outside Power Mirrors
The controls for the
outside power mirrors,
are located on the
driver’s door.
Move the selector switch located next to the control
pad to the left or right to choose either the driver’s
side or passenger’s side mirror. To adjust a mirror,
use the arrows located on the control pad to move
the mirror in the desired direction. Adjust each
outside mirror so that a little of the vehicle and the
area behind it can be seen while sitting in a
comfortable driving position. Keep the selector
switch in the center position when not adjusting
either outside mirror.Both mirrors can manually be folded by pulling
them toward the vehicle. This feature may
be useful when going through a car wash or a
conned space. Push the mirrors away from the
vehicle, to the normal position, before driving.
Outside Convex Mirror
{CAUTION:
A convex mirror can make things (like
other vehicles) look farther away than
they really are. If you cut too sharply into
the right lane, you could hit a vehicle on
your right. Check your inside mirror or
glance over your shoulder before
changing lanes.
The passenger’s side mirror is convex. A convex
mirror’s surface is curved so more can be seen
from the driver’s seat. It also makes things, like
other vehicles, look farther away than they
really are.
147

Fuses Usage
POWER
MIRRORSPower Mirrors
EPS Electric Power Steering
RUN/CRANKCruise Control Switch, Passenger
Airbag Status Indicator, DSC Switch
HVAC
BLOWER HIGHHeating Ventilation Air Conditioning
Blower - High Speed Relay
CLUSTER/
THEFTInstrument Panel Cluster, Theft
Deterrent System
ONSTAR OnStar
®
NOT
INSTALLEDNot Used
AIRBAG (IGN) Airbag (Ignition)
HVAC CTRL
(BATT)Heating Ventilation Air Conditioning
Control Diagnostic Link Connector
(Battery)
PEDAL Adjustable Pedals
WIPER SW Windshield Wiper/Washer Switch
IGN SENSOR Ignition Switch
Fuses Usage
STR/WHL
ILLUMSteering Wheel Controls
Backlighting
NOT
INSTALLEDNot Used
RADIO Audio System
INTERIOR
LIGHTSInterior Lamps
REAR WIPER Not Used
POWER
WINDOWSPower Windows (Sedan)
HVAC
CTRL (IGN)Heating Ventilation Air Conditioning
Control (Ignition)
HVAC
BLOWERHeating Ventilation Air Conditioning
Blower Switch
DOOR LOCK Door Locks
ROOF/HEAT
SEATSunroof, Heated Seat, Power
Windows (Coupe, Retractable
Hardtop), Automatic Dimming
Rearview Mirror, Compass
417
