Hood Release
To open the hood:
1. Pull the handle with
this symbol on it. It is
located under the
instrument panel on
the driver side of
the vehicle.
2. Then go to the front of the vehicle and push the
secondary hood release lever to the right.
3. Lift the hood, release the hood prop rod from its
retainer, and put the hood prop into the slot in the
hood marked with an arrow.
Before closing the hood, be sure all the ller caps are
on properly. Then lift the hood to relieve pressure on the
hood prop. Remove the hood prop from the slot in the
hood and return the prop to its retainer. Then let
the hood down and close it rmly.
5-13

Engine Compartment Overview
When you open the hood on the 2.4L L4 engine, this is what you see:
5-14

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B. Engine Cooling Fan. SeeCooling System on
page 5-32.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
D. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-21.
E. Engine Coolant Surge Tank. SeeEngine Coolant
on page 5-33.F. Pressure Cap. SeeCooling System on page 5-32.
G. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 5-42.
H.Battery on page 5-45.
I. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
J.Engine Compartment Fuse Block on page 5-112.
5-15

When you open the hood on the 3.5L V6 engine, this is what you see:
5-16

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B.Power Steering Fluid on page 5-39.
C. Engine Cooling Fan. SeeCooling System on
page 5-32.
D. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
E. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-21.
F. Engine Coolant Surge Tank. SeeEngine Coolant
on page 5-33.G. Pressure Cap. SeeCooling System on page 5-32.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 5-42.
I.Battery on page 5-45.
J. SeeEngine Compartment Fuse Block on
page 5-112.
K. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
5-17

When you open the hood on the 3.6L V6 engine, this is what you see:
5-18

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B.Power Steering Fluid on page 5-39.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
D. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-21.
E. Electric Engine Cooling Fans (Out of View).
SeeCooling System on page 5-32.
F. Engine Coolant Surge Tank. SeeEngine Coolant on
page 5-33.
G. Pressure Cap. SeeCooling System on page 5-32.H. Brake Master Cylinder Reservoir. See “Brake Fluid”
underBrakes on page 5-42.
I. Automatic Transmission Fluid Cap/Dipstick.
See “Checking the Fluid Level” underAutomatic
Transmission Fluid (2.4L L4, 3.5L and 3.6L V6
Engines) on page 5-29orAutomatic Transmission
Fluid (3.9L Engine) on page 5-29.
J.Battery on page 5-45.
K. Underhood Fuse Block. SeeEngine Compartment
Fuse Block on page 5-112.
L. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
5-19

When you open the hood on the 3.9L V6 engine, this is what you see:
5-20

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B. Engine Coolant Bleed Valve.
C.Power Steering Fluid on page 5-39.
D. Automatic Transmission Fluid Dipstick (Out of View).
See “Checking the Fluid Level” underAutomatic
Transmission Fluid (2.4L L4, 3.5L and 3.6L V6
Engines) on page 5-29orAutomatic Transmission
Fluid (3.9L Engine) on page 5-29.
E. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
F. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-21.
G. Engine Coolant Surge Tank. SeeEngine Coolant on
page 5-33.
H. Pressure Cap. SeeCooling System on page 5-32.
I. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 5-42.
J.Battery on page 5-45.
K. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
L.Engine Compartment Fuse Block on page 5-112.Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick handle is a yellow loop. See
Engine Compartment Overview on page 5-14for
the location of the engine oil dipstick.
1. Turn off the engine and give the oil several minutes
to drain back into the oil pan. If you do not do this,
the oil dipstick might not show the actual level.
2. Pull the dipstick and clean it with a paper towel or
cloth, then push it back in all the way. Remove it
again, keeping the tip down and check the level.
5-21

When to Add Engine Oil
If the oil is below the MIN mark for the L4 engine or
below the cross-hatched area at the tip of the dipstick
for the V6 engine, add at least one quart/liter of the
recommended oil. This section explains what kind of oil to
use. For engine oil crankcase capacity, seeCapacities
and Specifications on page 5-118.Notice:Do not add too much oil. If the engine has so
much oil that the oil level gets above the upper mark
that shows the proper operating range, the engine
could be damaged.
SeeEngine Compartment
Overview on page 5-14for
the location of the
engine oil ll cap.
Add enough oil to put the level somewhere in the proper
operating range. Push the dipstick all the way back in
when you are through. L4 Engine
V6 Engine
5-22
